Carrier VECTOR 1550 Series Installation and operating instructions

EVAPORATOR
CONDENSEREVXV
RECEIVER
Trailer Refrigeration
R
OPERATION&SERVICE
MANUAL
for
VECTOR 1550 & 1550 CITY
Trailer Refrigeration Units
62-61753-21

OPERATION&SERVICE
MANUAL
for
VECTOR 1550 & 1550 CITY
Trailer Refrigeration Units

i 62-61753-21
TABLE OF CONTENTS
Hystory..................................................................................................................................................................... 1-1
SECTION 1 - SAFETY PRECAUTIONS ................................................................................................................ 1-2
1.1 GENERAL PRODUCT SAFETY INSTRUCTIONS ON ALL CARRIER TRANSICOLD PRODUCT ......... 1-2
1.1.1 Important to read and follow during Regular maintenance:............................................................... 1-2
1.2 SAFETY PRECAUTIONS.......................................................................................................................... 1-3
1.3 SPECIFIC WARNING AND CAUTION STATEMENTS ............................................................................ 1-3
1.4 SPECIFIC R-452A REFRIGERANT WARNING AND CAUTION ............................................................. 1-6
1.5 SAFETY DECALS ..................................................................................................................................... 1-8
SECTION 2 - UNIT DESCRIPTION........................................................................................................................ 2-1
2.1 INTRODUCTION ....................................................................................................................................... 2-1
2.2 REFRIGERANT TYPES USED ................................................................................................................. 2-1
2.3 GENERAL DESCRIPTION........................................................................................................................ 2-1
2.4 CONDENSING SECTION ......................................................................................................................... 2-9
2.4.1 Engine................................................................................................................................................ 2-9
2.4.2 Engine Air System ............................................................................................................................. 2-9
2.4.3 Engine Switches, Transducers and Sensors ..................................................................................... 2-9
2.4.4 Generator (GEN)................................................................................................................................ 2-9
2.4.5 Compressor ....................................................................................................................................... 2-9
2.4.6 Compressor Switches, Transducers and Sensors ............................................................................ 2-9
2.4.7 Unloader Solenoid Valve (USV) ........................................................................................................ 2-9
2.4.8 Liquid Injection Solenoid Valve (LIV) ................................................................................................. 2-9
2.4.9 Condenser Coil .................................................................................................................................. 2-9
2.4.10 Ambient Air Temperature Sensor (AAT).......................................................................................... 2-10
2.4.11 Filter Drier ........................................................................................................................................ 2-10
2.4.12 Receiver........................................................................................................................................... 2-10
2.4.13 Economizer Circuit........................................................................................................................... 2-10
2.5 EVAPORATOR SECTION....................................................................................................................... 2-10
2.5.1 Evaporator Coil ................................................................................................................................ 2-10
2.5.2 Evaporator Expansion Valve (EVXV) .............................................................................................. 2-10
2.5.3 Compressor Suction Modulation Valve (CSMV).............................................................................. 2-10
2.5.4 Evaporator Switches, Transducers and Sensors ............................................................................ 2-10
2.6 SYSTEM OPERATING CONTROLS AND COMPONENTS................................................................... 2-11
2.6.1 Multiple Languages.......................................................................................................................... 2-11
2.6.2 Automatic Start-Stop........................................................................................................................ 2-11
2.6.3 Special Features .............................................................................................................................. 2-11
2.6.4 Temperature Controller Component Description And Location....................................................... 2-11
2.7 ELECTRONIC MODULES....................................................................................................................... 2-15
2.7.1 Overload Ground Fault Module (OGF) ............................................................................................ 2-15
2.7.2 Phase Reversal Module (PRM) ....................................................................................................... 2-15
2.8 OPTIONS................................................................................................................................................. 2-15
2.8.1 Light Bar........................................................................................................................................... 2-15
2.8.2 Door/Remote Switch(es).................................................................................................................. 2-15
2.8.3 Out of Range Alarm/Shutdown ........................................................................................................ 2-15
2.8.4 Remote Temperature Sensors ........................................................................................................ 2-16
2.8.5 IntelliSet/ProductShield.................................................................................................................... 2-16
2.8.6 Remote Control Panel ..................................................................................................................... 2-16
2.9 ENGINE DATA ........................................................................................................................................ 2-16
2.10 COMPRESSOR DATA ............................................................................................................................ 2-17
2.11 REFRIGERATION SYSTEM DATA ........................................................................................................ 2-17

62-61753-21 ii
2.12 ELECTRICAL DATA................................................................................................................................ 2-18
2.13 COMPONENT RESISTANCE & CURRENT DRAW DATA .................................................................... 2-19
2.14 SAFETY DEVICES.................................................................................................................................. 2-19
2.15 REFRIGERANT CIRCUIT DURING COOLING ...................................................................................... 2-19
2.16 HEAT AND DEFROST ............................................................................................................................ 2-20
SECTION 3 - OPERATION .................................................................................................................................... 3-1
3.1 STARTING UNIT - ENGINE OPERATION................................................................................................ 3-1
3.2 STARTING UNIT - STANDBY OPERATION ............................................................................................ 3-2
3.3 SELF TEST ............................................................................................................................................... 3-3
3.4 PRETRIP ................................................................................................................................................... 3-4
3.5 CHANGING SET POINT ........................................................................................................................... 3-7
3.6 START-STOP OPERATION...................................................................................................................... 3-8
3.6.1 Start-Stop Parameters ....................................................................................................................... 3-8
3.6.2 Restart Voltage .................................................................................................................................. 3-9
3.6.3 Charging Amps .................................................................................................................................. 3-9
3.7 CONTINUOUS OPERATION .................................................................................................................. 3-10
3.8 SLEEP MODE ......................................................................................................................................... 3-11
3.9 MANUAL DEFROST ............................................................................................................................... 3-13
3.10 TRIP START............................................................................................................................................ 3-14
3.11 VIEW ACTIVE ALARMS.......................................................................................................................... 3-15
3.12 VIEW INACTIVE ALARMS ...................................................................................................................... 3-16
3.13 UNIT DATA.............................................................................................................................................. 3-17
3.14 VIEW HOURMETERS............................................................................................................................. 3-20
3.15 FUNCTIONAL PARAMETERS................................................................................................................ 3-21
3.16 LANGUAGE SELECTION ....................................................................................................................... 3-25
3.17 STOPPING UNIT..................................................................................................................................... 3-26
3.18 DATA RECORDING ................................................................................................................................ 3-27
3.18.1 Microprocessor Information ............................................................................................................. 3-27
3.18.2 Data Recording ................................................................................................................................ 3-27
3.18.3 Data Downloading............................................................................................................................ 3-27
3.18.4 Data Recorder Power-Up ................................................................................................................ 3-27
3.19 OPTIONS................................................................................................................................................. 3-28
3.19.1 IntelliSet ........................................................................................................................................... 3-28
3.19.2 Remote Control Panel ..................................................................................................................... 3-31
SECTION 4 - TEMPERATURE CONTROL ........................................................................................................... 4-1
4.1 INTRODUCTION ....................................................................................................................................... 4-1
4.2 SYSTEM START-UP................................................................................................................................. 4-1
4.2.1 Standby Start-Up ............................................................................................................................... 4-1
4.2.2 Engine Start-Up ................................................................................................................................. 4-1
4.2.3 Transition To High Speed .................................................................................................................. 4-2
4.3 START-STOP OPERATION...................................................................................................................... 4-3
4.3.1 Start-Stop Configuration .................................................................................................................... 4-3
4.3.2 Stop Parameters ................................................................................................................................ 4-3
4.3.3 Re-Start Parameters .......................................................................................................................... 4-4
4.4 CONTINUOUS OPERATION .................................................................................................................... 4-4
4.5 TEMPERATURE CONTROL..................................................................................................................... 4-4
4.5.1 Temperature Determination............................................................................................................... 4-4
4.5.2 Heat/Cool/Null Mode Switching Logic................................................................................................ 4-4
4.5.3 Cool Mode.......................................................................................................................................... 4-5
4.5.4 Heat Mode ......................................................................................................................................... 4-5

iii 62-61753-21
4.5.5 Null Mode........................................................................................................................................... 4-5
4.5.6 Defrost Mode ..................................................................................................................................... 4-5
4.6 USER SELECTED OVERRIDE OPERATION .......................................................................................... 4-6
4.6.1 Supply Air Limit Control ..................................................................................................................... 4-6
4.6.2 Temperature Range Lock 1 & 2......................................................................................................... 4-7
4.6.3 ProductShield..................................................................................................................................... 4-9
4.6.4 ProductShield Temperature Ranges ............................................................................................... 4-10
4.7 PREPROGRAMMED SOFTWARE OVERRIDES................................................................................... 4-10
4.7.1 High Discharge Temperature........................................................................................................... 4-10
4.7.2 RAT & SAT Alarms Both Active....................................................................................................... 4-10
4.7.3 Engine Speed Overrides.................................................................................................................. 4-10
4.7.4 Operating Mode Overrides .............................................................................................................. 4-11
SECTION 5 - TECHNICIAN INTERFACE.............................................................................................................. 5-1
5.1 TECHNICIAN CONFIGURATION/ TEST MODES (REMOVE JUMPER MODE) ..................................... 5-1
5.1.1 Configuration Mode............................................................................................................................ 5-1
5.1.2 Component Test Mode ...................................................................................................................... 5-1
5.1.3 Service Mode ..................................................................................................................................... 5-3
5.2 DOWNLOADING DATA WITH THE PC CARD......................................................................................... 5-4
5.3 INSTALLING NEW SOFTWARE USING A PC Card................................................................................ 5-5
5.3.1 Procedure .......................................................................................................................................... 5-5
5.3.2 Troubleshooting Loading Problems ................................................................................................... 5-5
5.4 LogiCOLD MICROPROCESSOR REPLACEMENT & CONFIGURATION SETUP.................................. 5-6
5.4.1 Microprocessor Replacement ............................................................................................................ 5-6
5.4.2 Microprocessor Setup ........................................................................................................................ 5-6
5.4.3 Configurations Via Keypad ................................................................................................................ 5-7
5.4.4 Functional Parameters Via Keypad ................................................................................................... 5-7
5.4.5 Microprocessor Final Checkout ......................................................................................................... 5-8
SECTION 6 - MESSAGECENTER......................................................................................................................... 6-1
6.1 MessageCenter MESSAGES .................................................................................................................... 6-1
SECTION 7 - ALARM TROUBLESHOOTING ....................................................................................................... 7-1
7.1 INTRODUCTION ....................................................................................................................................... 7-1
7.2 NOTES ...................................................................................................................................................... 7-1
7.3 DRIVER / OPERATOR ALARMS.............................................................................................................. 7-3
1LOW FUEL LEVEL WARNING....................................................................................................... 7-3
7.4 SHUTDOWN ALARMS.............................................................................................................................. 7-4
11 LOW ENGINE OIL PRESSURE ..................................................................................................... 7-4
12 HIGH COOLANT TEMPERATURE ................................................................................................ 7-5
13 HIGH DISCHARGE PRESSURE.................................................................................................... 7-7
14 HIGH A/C AMPS............................................................................................................................. 7-8
15 BATTERY VOLTAGE TOO HIGH .................................................................................................. 7-9
16 BATTERY VOLTAGE TOO LOW ................................................................................................. 7-10
17 HIGH COMP DISCHARGE TEMP................................................................................................ 7-11
18 LOW REFRIGERANT PRESSURE .............................................................................................. 7-12
19 LOW FUEL SHUTDOWN ............................................................................................................. 7-14
20 MAXIMUM COMPRESSOR ALARMS.......................................................................................... 7-15
21 TECHNICIAN RESET REQUIRED............................................................................................... 7-15
22 LOW SUCTION SUPERHEAT ..................................................................................................... 7-16
23 A/C CURRENT OVER LIMIT ........................................................................................................ 7-17
24 COMPRESSION RATIO EXCEEDED .......................................................................................... 7-19
27 HIGH SUCTION PRESSURE....................................................................................................... 7-20
28 CHECK REFRIGERATION SYSTEM........................................................................................... 7-21
7.5 START-UP / ENGINE ALARMS .............................................................................................................. 7-22

62-61753-21 iv
30 FAILED TO RUN MINIMUM TIME................................................................................................ 7-22
31 FAILED TO START - AUTO MODE ............................................................................................. 7-23
34 ENGINE FAILED TO STOP.......................................................................................................... 7-24
35 CHECK STARTER CIRCUIT........................................................................................................ 7-25
36 CHECK COOLANT TEMPERATURE........................................................................................... 7-26
37 CHECK LOW SPEED RPM .......................................................................................................... 7-27
38 CHECK HIGH SPEED RPM ......................................................................................................... 7-28
39 CHECK ENGINE RPM.................................................................................................................. 7-29
40 CHECK GLOW PLUGS ................................................................................................................ 7-31
41 ENGINE STALLED ....................................................................................................................... 7-32
7.6 WARNING / STATUS ALARMS .............................................................................................................. 7-33
51 ALTERNATOR (BATTERY CHARGER) NOT CHARGING ......................................................... 7-33
53 BOX TEMP OUT-OF-RANGE ...................................................................................................... 7-34
53 BOX TEMP OUT-OF-RANGE (Continued)................................................................................... 7-35
54 DEFROST NOT COMPLETE ....................................................................................................... 7-36
55 CHECK DEFROST AIR SWITCH................................................................................................. 7-37
57 CHECK REMOTE SWITCH 1....................................................................................................... 7-38
58 CHECK REMOTE SWITCH 2....................................................................................................... 7-38
59 DATALOGGER (DATACORDER) NOT RECORDING ................................................................ 7-39
60 DATALOGGER (DATA RECORDER) TIME WRONG ................................................................. 7-40
61 DOOR OPEN ................................................................................................................................ 7-41
7.7 ELECTRICAL ALARMS........................................................................................................................... 7-42
71 BAD F2 OR F3 FUSE ................................................................................................................... 7-42
73 NO POWER-CHECK POWER CORD.......................................................................................... 7-43
75 COMP MOTOR OVERLOAD........................................................................................................ 7-44
76 CONDENSER MOTOR OVERHEATED....................................................................................... 7-45
76 CONDENSER MOTOR OVERHEATED (Continued)................................................................... 7-46
77 EVAP (EVAPORATOR) MOTOR OVERHEATED ....................................................................... 7-47
77 EVAP MOTOR OVERHEATED (Continued) ................................................................................ 7-48
89 CHECK REMOTE AUTO LIGHT .................................................................................................. 7-49
91 CHECK HTCON1 RELAY COIL ................................................................................................... 7-49
92 CHECK HTCON2 RELAY COIL ................................................................................................... 7-50
93 CHECK START UP BUZZER ....................................................................................................... 7-51
94 CHECK COMP CONTACTOR 1 (COMPRESSOR CONTACTOR RELAY) ................................ 7-51
95 CHECK CDCON RELAY COIL..................................................................................................... 7-52
96 CHECK GENCONR RELAY COIL................................................................................................ 7-52
98 CHECK HIGH TEMP THERMOSTAT (EVHTS)........................................................................... 7-53
99 CHECK STANDBY (POWER SUPPLY CONTACTOR RELAY) COIL......................................... 7-53
100 OVERLOAD/GROUND FAULT .................................................................................................... 7-54
109 CHECK EVCON COIL .................................................................................................................. 7-55
112 CHECK BYPASS (Unloader) CIRCUIT ........................................................................................ 7-56
113 CHECK ECONOMIZER CIRCUIT ................................................................................................ 7-57
114 CHECK LIV CIRCUIT ................................................................................................................... 7-58
7.8 SENSOR ALARMS.................................................................................................................................. 7-59
121 CHECK AMBIENT AIR SENSOR (AAT)....................................................................................... 7-59
122 CHECK RETURN AIR SENSOR (RAT) ....................................................................................... 7-60
123 CHECK SUPPLY AIR SENSOR (SAT) ........................................................................................ 7-61
124 CHECK DEFROST TERMINATION 1 SENSOR (DTT) ............................................................... 7-62
125 CHECK COMPRESSOR DISCHARGE SENSOR (CDT)............................................................. 7-63
126 CHECK FUEL SENSOR (FLS)..................................................................................................... 7-64
127 CHECK SUCTION TEMPERATURE SENSOR (CST)................................................................. 7-65
128 AMPS MEASURE ......................................................................................................................... 7-66
129 CHECK ENG COOLANT SENSOR (ENCT)................................................................................. 7-67
130 CHECK ENGINE RPM SENSOR (ENRPM)................................................................................. 7-68

v 62-61753-21
131 CHECK EVAPORATOR TEMPERATURE SENSOR (EVOT) ..................................................... 7-69
133 CHECK REMOTE TEMPERATURE SENSOR 1 (REMSN1)....................................................... 7-70
134 CHECK REMOTE TEMPERATURE SENSOR 2 (REMSN2)....................................................... 7-70
135 CHECK REMOTE TEMPERATURE SENSOR 3 (REMSN3)....................................................... 7-70
7.9 Pretrip ALARMS ...................................................................................................................................... 7-71
P141 PRETRIP STOPPED BY USER ................................................................................................... 7-71
P145 CHECK SPEED SOLENOID CIRCUIT......................................................................................... 7-71
P151 CHECK GLOW PLUG CIRCUIT................................................................................................... 7-71
P152 CHECK FUEL SOLENOID CIRCUIT............................................................................................ 7-71
P153 CHECK RETURN AIR SENSOR .................................................................................................. 7-71
P154 CHECK SUPPLY AIR SENSOR................................................................................................... 7-72
P155 CHECK COOLANT TEMP SENSOR............................................................................................ 7-72
P156 CHECK BYPASS (UNLOADER SOLENOID VALVE) CIRCUIT .................................................. 7-72
P157 CHECK BATTERY CURRENT ..................................................................................................... 7-72
P158 CHECK AMBIENT AIR SENSOR ................................................................................................. 7-73
P159 CHECK DEFROST TERMINATION 1 SENSOR .......................................................................... 7-73
P160 CHECK DISCHARGE TEMPERATURE SENSOR ...................................................................... 7-73
P161 CHECK SUCTION TEMPERATURE SENSOR ........................................................................... 7-73
P169 CHECK ECONOMIZER CIRCUIT ................................................................................................ 7-73
P170 CHECK LIV (liquid Injection Valve) CIRCUIT ............................................................................... 7-73
P174 CHECK LOW SPEED RPM.......................................................................................................... 7-74
P175 CHECK HIGH SPEED RPM ......................................................................................................... 7-74
P177 CHECK EVAPORATOR SUPERHEAT ........................................................................................ 7-74
P180 CHECK SUCTION MODULATING VALVE .................................................................................. 7-74
P186 CHECK EVAPORATOR OUTLET TEMPERATURE.................................................................... 7-74
P187 CHECK HEATER 1 CIRCUIT ....................................................................................................... 7-75
P187 CHECK HEATER 1 CIRCUIT (Continued) ................................................................................... 7-76
P188 CHECK HEATER 2 CIRCUIT ....................................................................................................... 7-77
P188 CHECK HEATER 2 CIRCUIT (Continued) ................................................................................... 7-78
P189 CHECK EVAPORATOR FAN MOTOR......................................................................................... 7-79
P189 CHECK EVAPORATOR FAN MOTOR (Continued)..................................................................... 7-80
P190 CHECK CONDENSER FAN MOTOR........................................................................................... 7-81
P206 CHECK CONDENSER FAN CIRCUIT ......................................................................................... 7-82
P207 CHK COMPRESSOR CONTACT CIRC ....................................................................................... 7-82
P208 CHK GENERATOR CONT CIRC ................................................................................................. 7-83
P209 CHECK STANDBY CONT CIRCUIT ............................................................................................ 7-84
7.10 MAINTENANCE ALARMS....................................................................................................................... 7-85
223 ENGINE MAINTENANCE DUE .................................................................................................... 7-85
224 STANDBY MAINTENANCE DUE ................................................................................................. 7-85
225 GENERAL MAINTENANCE DUE................................................................................................. 7-86
226 SERVICE SOON-PM #1 DUE ...................................................................................................... 7-86
227 SERVICE SOON-PM #2 DUE ...................................................................................................... 7-87
228 SERVICE SOON-PM #3 DUE ...................................................................................................... 7-87
229 SERVICE SOON-PM #4 DUE ...................................................................................................... 7-88
230 SERVICE SOON-PM #5 DUE ...................................................................................................... 7-88
7.11 MICROPROCESSOR ALARMS.............................................................................................................. 7-89
232 SETPOINT ERROR ...................................................................................................................... 7-89
233 MODEL # ERROR ........................................................................................................................ 7-89
237 FUNCTION PARAMETERS ERROR ........................................................................................... 7-90
238 CONFIGURATIONS 1 ERROR .................................................................................................... 7-91
242 DISCHARGE PRESS CALIBRATE ERROR ................................................................................ 7-92
243 SUCTION/EVAP CALIBRATE ERROR ........................................................................................ 7-92
245 CANNOT SAVE SETTING ........................................................................................................... 7-93
246 EEPROM WRITE FAILURE ......................................................................................................... 7-93

62-61753-21 vi
248 CONFIGURATION MODE / HP2 ERROR.................................................................................... 7-94
249 MICROPROCESSOR ERROR..................................................................................................... 7-95
SECTION 8 - SERVICE .......................................................................................................................................... 8-1
8.1 SECTION LAYOUT ................................................................................................................................... 8-1
8.2 SCHEDULED MAINTENANCE ................................................................................................................. 8-1
8.3 PRETRIP INSPECTION ............................................................................................................................ 8-3
8.4 ENGINE SERVICE AND COMPONENTS ................................................................................................ 8-4
8.4.1 Fuel System ....................................................................................................................................... 8-4
8.4.2 Priming the Fuel System.................................................................................................................... 8-4
8.4.3 Mechanical Fuel Pump Filter ............................................................................................................. 8-4
8.4.4 Electric Pump Filter............................................................................................................................ 8-5
8.4.5 Fuel Filter ........................................................................................................................................... 8-5
8.4.6 Fuel Level Sensor (FLS) .................................................................................................................... 8-5
8.4.7 Lube Oil Filter..................................................................................................................................... 8-5
8.4.8 Engine Air Cleaner............................................................................................................................. 8-6
8.4.9 Engine Speed Adjustment ................................................................................................................. 8-6
8.4.10 Radiator ............................................................................................................................................. 8-7
8.4.11 Water Pump V-Belt ............................................................................................................................ 8-7
8.4.12 Engine Speed Sensor ........................................................................................................................ 8-7
8.4.13 Crankcase Breather ........................................................................................................................... 8-7
8.4.14 Servicing Glow Plugs ......................................................................................................................... 8-8
8.5 REFRIGERANT SYSTEM SERVICE ........................................................................................................ 8-8
8.5.1 Removing The R-404A Refrigerant Charge ...................................................................................... 8-8
8.5.2 Removing The R-452A Refrigerant Charge ...................................................................................... 8-9
8.5.3 Refrigerant Leak Checking .............................................................................................................. 8-15
8.5.4 Evacuation ....................................................................................................................................... 8-15
8.5.5 Adding Refrigerant To System......................................................................................................... 8-16
8.5.6 Checking For Noncondensibles....................................................................................................... 8-17
8.6 REFRIGERANT SYSTEM COMPONENT SERVICE ............................................................................. 8-17
8.6.1 Compressor ..................................................................................................................................... 8-17
8.6.2 Evaporator Coil ................................................................................................................................ 8-18
8.6.3 Condenser Coil ................................................................................................................................ 8-19
8.6.4 Economizer Heat Exchanger ........................................................................................................... 8-19
8.6.5 Filter Drier ........................................................................................................................................ 8-20
8.6.6 Sight Glass Assembly...................................................................................................................... 8-20
8.6.7 Compressor Suction Modulation Valve (CSMV).............................................................................. 8-20
8.6.8 Electronic Expansion Valve ............................................................................................................. 8-22
8.6.9 Economizer, Unloader, & Liquid Injection Solenoid Valves............................................................. 8-24
8.6.10 Economizer Thermostatic Expansion Valve .................................................................................... 8-25
8.6.11 High Pressure Switch ...................................................................................................................... 8-25
8.6.12 Pressure Transducers ..................................................................................................................... 8-26
8.6.13 Defrost Air Switch ............................................................................................................................ 8-26
8.7 ELECTRICAL SYSTEM COMPONENT SERVICE ................................................................................. 8-27
8.7.1 Heaters ............................................................................................................................................ 8-27
8.7.2 Evaporator Fan & Motor .................................................................................................................. 8-27
8.7.3 Condenser Fan & Motor Assemblies ............................................................................................... 8-28
8.7.4 Battery Charger(s) ........................................................................................................................... 8-28
8.7.5 Generator......................................................................................................................................... 8-28
8.7.6 Compressor Discharge Temperature Sensor................................................................................. 8-33
8.7.7 Sensor Checkout ............................................................................................................................. 8-33
SECTION 9 Temperature Pressure Chart ........................................................................................................... 9-37
SECTION 10 - TROUBLESHOOTING ................................................................................................................. 10-1
10.1 DIESEL ENGINE ..................................................................................................................................... 10-1

vii 62-61753-21
10.1.1 Engine Will Not Start........................................................................................................................ 10-1
10.1.2 Engine Starts Then Stops................................................................................................................ 10-2
10.1.3 Engine Will Not Shut Off .................................................................................................................. 10-2
10.1.4 Starter Motor Malfunction ................................................................................................................ 10-2
10.1.5 Malfunction In The Engine Starting Circuit ...................................................................................... 10-3
10.1.6 Miscellaneous Engine Troubleshooting ........................................................................................... 10-3
10.2 BATTERY CHARGER ............................................................................................................................. 10-4
10.3 GENERATOR .......................................................................................................................................... 10-5
10.4 REFRIGERATION ................................................................................................................................... 10-6
10.4.1 Unit Will Not Cool............................................................................................................................. 10-6
10.4.2 Unit Runs But Has Insufficient Cooling............................................................................................ 10-6
10.4.3 Unit Operates Long Or Continuously In Cooling ............................................................................. 10-6
10.4.4 Unit Will Not Heat Or Has Insufficient Heating ................................................................................ 10-6
10.4.5 Unit Will Not Terminate Heating ...................................................................................................... 10-6
10.4.6 Defrost Cycle Malfunction ................................................................................................................ 10-7
10.4.7 Abnormal Pressure .......................................................................................................................... 10-7
10.4.8 Abnormal Noise ............................................................................................................................... 10-7
10.4.9 Control System Malfunction............................................................................................................. 10-8
10.4.10 No Evaporator Air Flow Or Restricted Air Flow ............................................................................... 10-8
10.4.11 Electronic Expansion Valve Malfunction.......................................................................................... 10-8
10.4.12 Solenoid Valve Malfunction ............................................................................................................. 10-9
10.4.13 Economizer System Malfunction ..................................................................................................... 10-9
SECTION 11 - WIRING ........................................................................................................................................ 11-1
11.1 HARNESS PLUG WIRING ...................................................................................................................... 11-1
11.2 DISPLAY HARNESS CONNECTIONS ................................................................................................... 11-5
11.3 WIRING SCHEMATIC ............................................................................................................................. 11-5

62-61753-21 viii
LIST OF ILLUSTRATIONS
Figure 2-2. Vector 1550 CITY Front View - Engine/Control Components ................................................................ 2-5
Figure 2-3. Evaporator Section - Grille Removed..................................................................................................... 2-7
Figure 2-4. Control Box............................................................................................................................................. 2-8
Figure 2-5. Control Module ..................................................................................................................................... 2-12
Figure 2-6. Display And Keypad ............................................................................................................................. 2-13
Figure 2-7. OGF Module ......................................................................................................................................... 2-15
Figure 2-8. PRM Module......................................................................................................................................... 2-15
Figure 2-9. Refrigerant Circuit Bypass Mode.......................................................................................................... 2-21
Figure 2-10. Refrigerant Circuit Standard Mode..................................................................................................... 2-22
Figure 2-11. Refrigerant Circuit Economized Mode................................................................................................ 2-23
Figure 4-1. Auto Start Sequence .............................................................................................................................. 4-2
Figure 4-2. Range Lock Settings - Non Overlapping................................................................................................ 4-8
Figure 4-3. Range Lock Settings - Overlapping........................................................................................................ 4-8
Figure 5-1. Technicians Interface Connections ........................................................................................................ 5-1
Figure 8-1. Fuel System Diagram ............................................................................................................................. 8-4
Figure 8-2. Fuel Bleed Components......................................................................................................................... 8-4
Figure 8-3. Mechanical Fuel Pump........................................................................................................................... 8-5
Figure 8-4. Electric Fuel Pump (Optional) ................................................................................................................ 8-5
Figure 8-5. Fuel Level Sensor Wiring ....................................................................................................................... 8-5
Figure 8-6. Lube Oil Flow Diagram ........................................................................................................................... 8-6
Figure 8-7. Engine Speed Adjustment...................................................................................................................... 8-6
Figure 8-8. Engine Crankcase Breather ................................................................................................................... 8-8
Figure 8-9. Refrigerant System Service Connections ............................................................................................. 8-8
Figure 8-9. Refrigerant System Service Connections ........................................................................................... 8-15
Figure 8-10. Compressor Kit................................................................................................................................... 8-17
Figure 8-11. Compressor Plug Retaining Clip ........................................................................................................ 8-18
Figure 8-12. Economizer Assembly ........................................................................................................................ 8-20
Figure 8-13. Suction modulation valve (CSMV)...................................................................................................... 8-21
Figure 8-14. CSMV Coil (Bi-Polar Design) ............................................................................................................. 8-21
Figure 8-15. Electronic expansion valve................................................................................................................. 8-22
Figure 8-16. Electronic Expansion Valve................................................................................................................ 8-23
Figure 8-17. Solenoid Valves (ESV, LIV & USV).................................................................................................... 8-24
Figure 8-18. Thermostatic Expansion Valve Bulb and Thermocouple ................................................................... 8-25
Figure 8-19. Typical Setup for Testing High Pressure Switch ............................................................................... 8-26
Figure 8-20. Defrost Air Switch Test Setup ............................................................................................................ 8-27
Figure 8-21. Evaporator Fan Bolts.......................................................................................................................... 8-28
Figure 8-22. Generator Assy (P/N 54-00589-50).................................................................................................... 8-32
Figure 8-23. Bolt Hole Pattern For Bell Housing and Crankshaft ........................................................................... 8-32
Figure 8-24. Compressor Discharge Temperature Sensor ................................................................................... 8-33

ix 62-61753-21
LIST OF TABLES
Table 2-1. Model Chart ............................................................................................................................................. 2-2
Table 3-1. Unit Data................................................................................................................................................ 3-18
Table 3-2. Functional Parameters .......................................................................................................................... 3-22
Table 4-1. Glow Time................................................................................................................................................ 4-2
Table 5-1. Component Test ...................................................................................................................................... 5-2
Table 5-2. Microprocessor Configurations................................................................................................................ 5-8
Table 8-1. Maintenance Schedule ............................................................................................................................ 8-2
Table 8-2. CSMV Connections ............................................................................................................................... 8-21
Table 8-3. EVXV Connections ................................................................................................................................ 8-22
Table 8-4. Blower Wheel Identification ................................................................................................................... 8-27
Table 8-5. Sensor Resistance (AAT, RAT, SAT, ENCT, EVOT, CST, DTT).......................................................... 8-34
Table 8-6. Sensor Resistance (CDT)...................................................................................................................... 8-35
Table 9-1. R-404A Temperature Pressure Chart.................................................................................................... 9-37
Table 9-2-1. R-452A Temperature Pressure Chart (DEGREE)............................................................................. 9-38
Table 9-2-11. R-452A Temperature Pressure Chart (FAHRENHEIT)................................................................... 9-39

62-61753-21
1-1
Hystory
REV
DESCRIPTION OF CHANGE
RELEASE
DATE
Rev-
Original release
RevG
Add of the chapter 1.1:
GENERAL PRODUCT SAFETY INSTRUCTIONS ON ALL CARRIER
TRANSICOLD PRODUCT
Add of R-452A refrigerant specification
Feb 2016

62-61753-21 1-2
SECTION 1 -
SAFETY PRECAUTIONS
1.1 GENERAL PRODUCT SAFETY INSTRUCTIONS ON ALL CARRIER TRANSICOLD PRODUCT
1.1.1 Important to read and follow during Regular maintenance:
Regular maintenance includes a quick overview of the units from a safety perspective:
Service Technician must pay particular attention, but not exclusively to the 3 direc-
tives here under.
- The aim is to eliminate any risks for the user, the maintenance technician, the public and
the environment.
For 3 the followings directives:
If a defect which could potentially create a safety related incident is found and is not part of
standard maintenance operation:
A quotation must be sent to the customer including this 2 remarks before intervention:
This is potentially a product safety issue.
An agreement to repair shall be found.
1. Check the Tightening of bolts, screws and that the unit is correctly fastened:
If any screws or bolts are missing:
Replace and tighten by using the good torque.
If a torque is not conform to the technical recommendation:
Apply the good torque.
2. Check doors, skins grills, panels, etc….
If missing or cracked:
Repair or change it
3. Check electrical wires, harnesses and fuel lines:
If not correctly attached:
Secure the attachment by using tie raps.
If damaged but not visibility of copper:
Repair with textile tape CTD02-00137-00 (2 or 3 layers)
If damaged and copper is visible
Repair with liquid plastic coating and cover the cable with textile tape CTD02-00137-00 (2 or 3
layers)
If multiple wires are damaged
Replace the entire cable.
For more information about safety rules of electrical wires, harnesses and fuel lines:
Refer to the service bulletin SB21-15 accessible from CTE partner website.
For 3 the previous directives:
If a defect which could potentially create a safety related incident is found and is not part of
standard maintenance operation:
A quotation must be sent to the customer including this 2 remarks before intervention:
This is potentially a product safety issue.
An agreement to repair shall be found.

62-61753-21
1-3
1.2 SAFETY PRECAUTIONS
Your Carrier Transicold refrigeration unit has been
designed with the safety of the operator in mind. Dur-
ing normal operation, all moving parts are fully en-
closed to help prevent injury. During all pre-trip inspec-
tions, daily inspections, and problem troubleshooting,
you may be exposed to moving parts. Please stay
clear of all moving parts when the unit is in operation
and when the unit Start/Run-Off switch is in the
START/RUN position.
CAUTION
Under no circumstances should anyone at-
tempt to repair the Logic or Display
Boards. Should a problem develop with
these components, contact your nearest
Carrier Transicold dealer for replacement.
CAUTION
Under no circumstances should a techni-
cian electrically probe the processor at any
point, other than the connector terminals
where the harness attaches. Microproces-
sor components operate at different volt-
age levels and at extremely low current
levels. Improper use of voltmeters, jumper
wires, continuity testers, etc. could perma-
nently damage the processor.
CAUTION
Most electronic components are suscepti-
ble to damage caused by electrical static
discharge (ESD). In certain cases, the hu-
man body can have enough static electrici-
ty to cause resultant damage to the com-
ponents by touch. This is especially true of
the integrated circuits found on the
truck/trailer microprocessor.
Auto-Start
Your refrigeration unit is equipped with Auto-Start in
both Start-Stop and Continuous Run Operation. The
unit may start at any time when the Start/Run-Off
Switch (SROS) is in the Start/Run position. A buzzer
will sound for 5 seconds before the unit is started.
When performing any check of the refrigeration unit
(e.g., checking the belts, checking the oil), make cer-
tain that the SROS is in the OFF position.
Engine Coolant
The engine is equipped with a pressurized cooling
system, including a pressurized coolant bottle. Under
normal operating conditions, the coolant in the engine
and radiator is under high pressure and is very hot.
Contact with hot coolant can cause severe burns. Do
not remove the cap from a hot radiator or bottle. If the
cap must be removed, cover it with a rag and remove
it very slowly in order to release the pressure without
spray.
Refrigerant
The refrigerant contained in the refrigeration system of
your unit can cause frostbite, severe burns, or blind-
ness when in direct contact with the skin or eyes. For
this reason, and because of legislation regarding the
handling of refrigerants during system service, we
recommend that whenever your unit requires service
of the refrigeration system you contact your nearest
Carrier Transicold authorized repair facility for service.
Battery
This unit is equipped with a lead-acid type battery. The
battery normally vents small amounts of flammable
hydrogen gas. Do not smoke when checking the bat-
tery. A battery explosion can cause serious physical
harm and/or blindness.
1.3 SPECIFIC WARNING AND CAUTION
STATEMENTS
To help identify the label hazards on the unit and ex-
plain the level of awareness each one carries, an ex-
planation is given with the appropriate consequences:
DANGER - warns against an immediate hazard which
WILL result in severe personal injury or death.
WARNING - warns against hazards or unsafe condi-
tions which COULD result in severe personal injury or
death.
CAUTION - warns against potential hazard or unsafe
practice which could result in minor personal injury, or
product or property damage.
The following statements are specifically applicable to
this refrigeration unit and appear elsewhere in this
manual. These recommended precautions must be
understood and applied during operation and mainte-
nance of the equipment covered herein.

62-61753-21
1-4
WARNING
LogiCOLD microprocessor equipped units
may start automatically at any time the
START/RUN-OFF switch (SROS) is not in
the OFF position. Also, the unit may be fit-
ted with two way communication equip-
ment that will allow stating of the unit from
a remote location even though the SROS is
in the off position.
WARNING
Be aware of HIGH VOLTAGE supplied at
the power plug or from the generator.
When performing service or maintenance
procedures: ensure any two way commu-
nication is disabled in accordance with the
manufacturers instruction, ensure the
START/RUN-OFF switch is in the OFF posi-
tion and, whenever practical, disconnect
the high voltage source and disconnect the
negative battery connection. NEVER dis-
assemble the generator: HIGH MAGNETIC
FIELD INSIDE! This field can interfere with
cardiac implants such as pacemakers and
defibrillators.
WARNING
Under no circumstances should ether or
any other starting aids be used to start en-
gine.
WARNING
Ensure the power plug is clean and dry be-
fore connecting to any electrical out-
let/receptacle. Do not connect to any elec-
trical outlet without checking that it meets
the 380/3/50 and 16 Amp electrical re-
quirements of the unit.
WARNING
Always place SROS in the OFF position
and turn off the high voltage power supply
before disconnecting the high voltage
power plug from the unit.
WARNING
If the unit is in Standby Operation and
powered, voltage will be applied to high
voltage components (i.e. the fan motor
contactor) and those components will op-
erate (i.e. the fan blades will turn) when
those components are energized using
component test mode.
WARNING
Do not remove the cap from a hot radiator;
if the cap must be removed, do so very
slowly in order to release the pressure
without spray.
WARNING
Inspect battery cables for signs of wear,
abrasion or damage at every Pretrip in-
spection and replace if necessary. Also
check battery cable routing to ensure that
clamps are secure and that cables are not
pinched or chafing against any compo-
nents.
WARNING
Use the required protective eye wear and
clothing when working with solvents.
WARNING
Beware of moving poly V-Belt and belt
driven components.
WARNING
When working with belts, beware of pinch
points.
WARNING
The +5.0 VDC (terminal B) is common be-
tween the Compressor Discharge Pressure
Transducer, the Compressor Suction Pres-
sure Transducer, and the RPM sensor. If
this circuit is shorted to ground (due to one
of the mentioned components being defec-
tive, or a worn wire) the MessageCenter will
show
Suction Pressure: -1 bar (-14.7 psig)
Discharge Pressure: 0 bar/psig
Engine RPM: 0.
WARNING
Before removal of the compressor, relieve
the internal pressure by very carefully
loosening the couplings to break the seal.

62-61753-21
1-5
WARNING
Do not use a nitrogen cylinder without
a pressure regulator. Cylinder pressure
is approximately 159.9 bar (2350 psig).
Do not use oxygen in or near a refrigerant
system as an explosion may occur. (See
Figure 8-19)
WARNING
High voltage (dielectric) testing must not
be performed on the machine without first
observing NEMA rules. The insulation of
this generator winding may be safely
checked by using a megohm meter. A high
reading indicates good insulation.
WARNING
Generators of this type should not be
"flashed". Operation with external voltage
source or momentary shorting of leads will
damage the generator and may cause inju-
ry.
CAUTION
Under no circumstances should anyone at-
tempt to repair the Logic or Display
Boards. Should a problem develop with
these components, contact your near-
est Carrier Transicold dealer for replace-
ment.
CAUTION
Service Mode MUST be used whenever re-
moving refrigerant charge, refrigerant leak
checking or evacuating.
CAUTION
The display and MessageCenter may be-
have differently during the software load-
ing process, depending on the version of
software currently in the controller. DO
NOT INTERRUPT THE SOFTWARE IN-
STALLATION PROCESS ONCE IT HAS
STARTED.
CAUTION
Unit uses R-404A OR R-452A and POE oil.
The use of inert gas brazing procedures is
mandatory for all Carrier Transicold refrig-
eration units; otherwise compressor failure
will occur. For more information Refer to
Technical Procedure 98-60068-00 Inert Gas
Brazing
CAUTION
When changing oil filter, the new filter
should be primed (partially filled)
with clean oil if possible. If the filter is
not primed, the engine may operate for
a period with no oil supplied to the bear-
ings.
CAUTION
Use only monopropylene glycol anti-freeze
as glycol by itself will damage the cooling
system. Always add pre-mixed 50/50 anti-
freeze and water to radiator/engine. Never
exceed more than a 60% concentration of
anti-freeze. Use a low silicate anti-freeze.
CAUTION
The mica shim must be used during disas-
sembly of the generator from the engine.
Never attempt to remove the rotor from the
stator. Leave the shim in place until the
generator is re-installed on the engine.
CAUTION
NEVER POUR COLD WATER INTO A HOT
ENGINE, however hot water can always be
added to a cold engine.
CAUTION
Only a refrigerant drum containing R-404A
or R-452A should be connected to this re-
frigeration unit in order to pressurize the
system. However, dry nitrogen may be
used to increase pressure. Any other gas
or vapor will contaminate the system and
require additional purging and evacuation.

62-61753-21
1-6
1.4 SPECIFIC R-452A REFRIGERANT WARNING
AND CAUTION
WARNING
R-452A is an A1 non-flammable refrigerant
blend; however certain of its constituents
are considered A2L midly flammable.
For this raison, it is imperative that the sys-
tem of a vector unit utilizing R-452A refrig-
erant be reclaim to a sufficient vaccum to
ensure all residual refrigerant is removed
from the system
Follow the R-452A refrigerant reclaim / re-
covery procedure before performing any
“Hot work” including but not limited to
brazing or welding on a unit that has been
charged with R-452A, to prevent flare up of
residual A2L refrigerant constituents
Refrigerant must be reclaimed until equip-
ment gauge indicates 20 inHG (-0.6bar) of
vacuum.
Refer to Section 8.5.2Removing The R-
452A Refrigerant Charge
Refer to the Service Bulletin SB06-16 for
additional information
CAUTION
As distinct of R404A refrigerant, R-452A
has slidding properties more important and
not negligeable between vapour state and
liquid state.
For a given temperature, the liquid state
pressure value and the vapour state pres-
sure value, of the R-452A refrigerant are
differents.
Refer to section 10 for Temperature pres-
sure chart
