Carrier Transicold Vector User manual

62-60556-00
●Auto Start/Stop
●Continuous Run
●Temperature Setpoint
●Pretrip Check
●Alarm Display/Reset
●Trip Start
●Function Change
●Unit Data
●Manual Defrost
●Manual Operation
●Standby Operation
●Stopping
EASY TO RUN
CHECK OUT
THESE FUNCTIONS
CARRIER TRANSICOLD EUROPE S.A.S.
10-12, bd de l’Oise
F-95031 CERGY PONTOISE CEDEX
Phone : + 33 (0) 1 34 43 48 00 - Fax : + 33 (0) 1 34 43 48 48
MESSAGES SPELLED
OUT IN 8 LANGUAGES
MESSAGES SPELLED
OUT IN 8 LANGUAGES
500 CARRIER SERVICE STATIONS in EUROPE,
FORMER SOVIET UNION, MIDDLE EAST and AFRICA
Our company is constantly seeking to improve the quality of its products and, therefore,
reserves the right to modify its products without prior notice
Carrier Transicold Europe S.A.S. - S.A.S. au capital de 16 090 700 euros
R.C.S. Pontoise B 410 041 776 - Code APE 292 F - VAT : FR52410041776
The information contained in this document is not contractually binding,
and may not be reproduced without prior approval - 62-60556-00

EASY TO
STOP
Stopping
SETPOINT BOX TEMPERATURE
START/RUN
STOP
1
0
STANDBY
ENGINE
LANGUAGE
CONTINUOUS
RUN
START-STOPALARMDEFROSTCOOLHEAT
MANUAL
DEFROST
ALARM LIST
START-STOP
CONTINUOUS
SELECT
=
!
TRIP
START
FUNCTION
CHANGE
DATAPRETRIP
Place RUN / STOP switch to STOP to stop
unit.
1
1
FOR YOUR
PROTECTION
Safety
Your CARRIER product has been designed to meet all
European Safety requirements.
Please take notice of all stickers that have been placed on
this product for your safety.They are for your PROTECTION !
Beware of HIGH VOLTAGE (up to 700V) supplied by the
generator as the unit may start automatically. Before servi-
cing unit, make sure the RUN/STOP switch is in STOP position
and disconnect the negative battery cable.
Pacemaker holders must stay clear of the unit while operating
as the power generator supplies HIGH VOLTAGE.
Never dis-assemble the generator
HIGH MAGNETIC FIELD INSIDE.
The refrigerant contained in the refrigeration system
of your unit can cause frosbite, severe burns, or blind-
ness when in direct contact with the skin or eyes.
Replace cover after servicing battery to insure protection of
battery and terminals.
Disconnect battery before doing any electrical welding on unit or
trailer. This unit has a negative ground system.Do not reverse polarity.
Reverse polarity will cause immediate failure of electrical system.
Top up coolant into recovery bottle only.
Fill empty radiator through filler neck slowly to avoid air
entrapment.
Remove filler cap slowly.
Unit may start automatically.
Beware of fan blades and pulleys.
Beware of electric heaters.

Display
KEYPAD
The microprocessor “LogiCOLD” controls incorporated into
VECTOR are the most reliable control system available.
LogiCOLD is also designed to be the easiest to use.
A message center indicates clear instructions and prompts
the driver through each operation. The choice of
8 languages (Danish, Dutch, English, French, German,
Italian, Russian, Spanish) ensures LogiCOLD user-friendly.
LogiCOLD allows minimal input to obtain maximum
output, a true “Set it and forget it” design.
SETPOINT BOX TEMPERATURE
START/RUN
STOP
1
0
STANDBY
ENGINE
LANGUAGE
CONTINUOUS
RUN
START-STOPALARMDEFROSTCOOLHEAT
MANUAL
DEFROST
ALARM LIST
START-STOP
CONTINUOUS
SELECT
=
!
TRIP
START
FUNCTION
CHANGE
DATAPRETRIP
EASY TO
RUN
Standby Operation
SETPOINT BOX TEMPERATURE
START/RUN
STOP
1
0
STANDBY
ENGINE
LANGUAGE
CONTINUOUS
RUN
START-STOPALARMDEFROSTCOOLHEAT
MANUAL
DEFROST
ALARM LIST
START-STOP
CONTINUOUS
SELECT
=
!
Connect standby
cable to unit.
To power up the unit, place
the ENGINE / STANDBY
switch to STANDBY.
Place the RUN / STOP switch
to RUN to start unit.
1
1
Mode lights
Language switch
Engine/Standby
switch
Run/Stop
switch
Selectable
lights
Message center
3
3
Enter key
Up and Down
arrow key
2
2
Note : The unit is fitted with a phase detector which inhibits engine
start-up if the phases are reversed. In the latter case an alarm sounds.
Place the RUN/STOP switch in the STOP position. Disconnect the power
plug and switch the phases in the socket using a screwdriver.

MGC
EASY TO
START
Auto Start / Stop
SETPOINT BOX TEMPERATURE
START/RUN
STOP
1
0
STANDBY
ENGINE
LANGUAGE
CONTINUOUS
RUN
START-STOPALARMDEFROSTCOOLHEAT
MANUAL
DEFROST
ALARM LIST
START-STOP
CONTINUOUS
SELECT
=
!
Place RUN/STOP switch
in RUN position.
Press the START-STOP/CONTINUOUS key until
the START-STOP light on the controller
illuminates.
Toggle the LANGUAGE switch as soon
as you select 1 of the 8 available
languages :
English - French - Spanish - German -
Danish - Dutch - Italian - Russian.
3
3
Verify that “START/STOP MODE SELECTED” is
displayed on the message center and that the
START-STOP light is illuminated.
EASY TO
RUN
Manual Operation
SETPOINT BOX TEMPERATURE
START/RUN
STOP
1
0
STANDBY
ENGINE
LANGUAGE
CONTINUOUS
RUN
START-STOPALARMDEFROSTCOOLHEAT
MANUAL
DEFROST
ALARM LIST
START-STOP
CONTINUOUS
SELECT
=
!
Place the ENGINE/STANDBY switch
to ENGINE.
While preheating place RUN/STOP switch
to RUN.“MANUAL START MODE SELECTED”
will appear in message center.
Place manual GLOW/CRANK switch (MGC)to
Glow and hold for 5 to 15 seconds.
2
2
3
3
4
4Place GLOW/CRANK switch in CRANK position
to crank and start.
Electrical box
(located inside
unit roadside
front door).
1
1
START/STOP MODE SELECTED
1
1
2
2
4
4

EASY TO
START
Continuous Run
SETPOINT BOX TEMPERATURE
START/RUN
STOP
1
0
STANDBY
ENGINE
LANGUAGE
CONTINUOUS
RUN
START-STOPALARMDEFROSTCOOLHEAT
MANUAL
DEFROST
ALARM LIST
START-STOP
CONTINUOUS
SELECT
=
!
Place RUN/STOP switch
in RUN position.
Verify that “CONTINUOUS RUN MODE
SELECTED” is displayed on the message
center and that the CONTINUOUS RUN
light is illuminated.
Press the START-STOP/CONTINUOUS key
until the CONTINUOUS RUN light on the
controller illuminates.
EASY TO
SELECT
Manual Defrost
SETPOINT BOX TEMPERATURE
START/RUN
STOP
1
0
STANDBY
ENGINE
LANGUAGE
CONTINUOUS
RUN
START-STOPALARMDEFROSTCOOLHEAT
MANUAL
DEFROST
ALARM LIST
START-STOP
CONTINUOUS
SELECT
=
!
Press the MANUAL DEFROST key. The
DEFROST light will come on and the
message center will display “DEFROST
CYCLE STARTED” for 5 seconds or flash
“CANNOT START DEFROST CYCLE” for 5
seconds.
Unit will not defrost if box temperature
is above +4°C.
DEFROST CYCLE STARTED
1
1
CONTINUOUS RUN MODE SELECTED
1
1
2
2
3
3

EASY TO
SET
Temperature Setpoint
SETPOINT BOX TEMPERATURE
START/RUN
STOP
1
0
STANDBY
ENGINE
LANGUAGE
CONTINUOUS
RUN
START-STOPALARMDEFROSTCOOLHEAT
MANUAL
DEFROST
ALARM LIST
START-STOP
CONTINUOUS
SELECT
=
!
With the message center at the
default display press the UP
ARROW or DOWN ARROW key to
change setpoint to the desired
value.The display will flash to indi-
cate that the setpoint reading
being displayed is a non-entered
value. The message center will
show “ TO SCROLL, THEN = TO
SAVE”.The setpoint display will
flash for 5 seconds if = has not
been pressed.
Verify that the message “SETPOINT CHANGED” is
displayed on the message center.
Press the = (ENTER) key to save the new
setpoint.
EASY TO
READ
Unit Data
SETPOINT BOX TEMPERATURE
START/RUN
STOP
1
0
STANDBY
ENGINE
LANGUAGE
CONTINUOUS
RUN
START-STOPALARMDEFROSTCOOLHEAT
MANUAL
DEFROST
ALARM LIST
START-STOP
CONTINUOUS
SELECT
=
!
DATA
Press the SELECT key until DATA is
illuminated.
Press the = key.
Press the UP or DOWN ARROW key to display the
next or previous unit data value.
1
1
2
2
3
3
SUCTION PRESSURE:
1
1
2
2
3
3
SETPOINT CHANGED

EASY TO
CHECK
Pretrip Check
SETPOINT BOX TEMPERATURE
START/RUN
STOP
1
0
STANDBY
ENGINE
LANGUAGE
CONTINUOUS
RUN
START-STOPALARMDEFROSTCOOLHEAT
MANUAL
DEFROST
ALARM LIST
START-STOP
CONTINUOUS
SELECT
=
!
DATA
Press the SELECT key until PRETRIP
is illuminated.
Verify that the display shows “TEST # 1”.
Press the = key to start PRETRIP.
EASY TO
CHANGE
Function Change
SETPOINT BOX TEMPERATURE
START/RUN
STOP
1
0
STANDBY
ENGINE
LANGUAGE
CONTINUOUS
RUN
START-STOPALARMDEFROSTCOOLHEAT
MANUAL
DEFROST
ALARM LIST
START-STOP
CONTINUOUS
SELECT
=
!
FUNCTION
CHANGE
Press the SELECT key until FUNCTION
CHANGE is highlighted.The message
“PRESS TO VIEW SETTINGS” willappear.
Press the UP or DOWN ARROW to scroll through
the Function list. ”TO SCROLL THEN = TO
SELECT” will appear.
3
3To change one of the Functions, bring the Function
you wish to change into the Message Center, and
press = (ENTER) key. “TOSCROLL, THEN = TO SAVE”
will show in the Message Center. Pressing either UPor
DOWN ARROW key will begin to change the Function
setting.The Message Center will flash, indicating that a
change has been made that has not been entered into
memory.
4
4
1
1
2
2
1
1
2
2
3
3
TEST # 1
PRESS TO VIEW SETTINGS
Continue pressing UP or DOWN ARROW key until the
desired value is shown, then press the = (ENTER) key.
The Message Center will stop flashing. The new value is
now in memory.
Note : Unit can be off when you start PRETRIP
Press and hold the = key for 5 seconds
will cancel the PRETRIP.

EASY TO
SET
Trip Start
SETPOINT BOX TEMPERATURE
START/RUN
STOP
1
0
STANDBY
ENGINE
LANGUAGE
CONTINUOUS
RUN
START-STOPALARMDEFROSTCOOLHEAT
MANUAL
DEFROST
ALARM LIST
START-STOP
CONTINUOUS
SELECT
=
!
TRIP
START
EASY TO
CHECK
Alarm Display / Reset
SETPOINT BOX TEMPERATURE
START/RUN
STOP
1
0
STANDBY
ENGINE
LANGUAGE
CONTINUOUS
RUN
START-STOPALARMDEFROSTCOOLHEAT
MANUAL
DEFROST
ALARM LIST
START-STOP
CONTINUOUS
SELECT
=
!
Press the ALARM LIST key. If there are no active
alarms in the alarm list, the display will say “NO
ACTIVE ALARMS” for 5 seconds.
Press the ALARM LIST key to scroll through the list
of alarms.
If there are active alarms in the alarm list, the
display will be “A” and the alarm message for the
latest active alarm in the list for 5 seconds.
2
2
3
3
When you reach the end of the alarm list, “LIST
END, = TO CLEAR ALARMS” is displayed.
4
4
To deactivate the active alarm list, press the = key
while “LIST END, = TO CLEAR ALARMS” is being
displayed.
5
5
To mark the start of a trip in the data
recorder, press the SELECT key until
TRIP START is lit.
If trip start is acknowledged by the data recorder,
“TRIP START ENTERED” will be displayed for 5
seconds and then the display will revert back to the
normal display.Otherwise “CANNOT ENTER TRIP
START” will flash and then the display will revert
back to the normal display.
Press the = key.
1
1
2
2
3
3
TRIP START ENTERED
1
1
NO ACTIVE ALARMS
