Carrier Comfort Network TeLINK User manual

808-970
Rev. 6/00
TeLINK Installation Instructions
Installation
TeLINK is a device designed to allow a CCN to communicate with another CCN over a tele-
phone network. The device establishes this CCN to CCN link through modems.
Install the Modem
1. Insert the factory- or field-supplied PCMCIA Type II modem card into the back of the
TeLINK enclosure (refer to Figure 1).
Connectors
Figure 1 indicates the connectors that are used to provide power to the TeLINK, and to connect it
to the CCN.
Make these connections in the following order:
2. Connect an RJ-11 modular telephone jack to the modem card.
3. Connect a factory- or field-supplied unregulated 9 Vac power supply to the 0.1" (2.5 mm)
power jack.
4. Connect the primary CCN Communication Bus to the factory-supplied, three-pin screw
terminal-type CCN Bus connector. Consult the CCN Installation and Start-up Manual
(808-211) for information concerning the wiring that must be provided for that purpose.
Optional
5. For your convenience, the RJ-11 telephone jack can be connected from the front of the
TeLINK enclosure to the Network Service Tool (refer to Figure 2) .
Figure 1
Back View
Page 1 of 2

808-970
Rev. 6/00
Figure 2
Front View
Address and Baud Rate
If necessary, use the Network Service Tool to set the address and baud rate of the CCN port. The
default address is Bus # 0, Element # 50, and the baud rate is 9600 (adjustable to 38.4K).
Recommended Modems
The following modems are recommended for use with TeLINK.
Baud Rate Recommended PCMCIA Type II Modems
56K 3Com 3CCM756
3Com 3CCM156
U.S. Robotics and Sportster are registered trademarks of U.S. Robotics, Inc.
Related Documentation
For more information about TeLINK, refer to the following:
TeLINK Overview and Configuration Manual (808-971)
TeLINK Product Data Sheet (808-969)
Page 2 of 2
