CarTrek CarTrek800 Assembly Instructions

GPS NAVIGATION SYSTEM
Hardware Instruction Manual
CarT r ek800
CosmicNavigation

2
CarT r ek800
Hardware Instruction Manual
Congratulations on choosing a CarTrek product. We have every expectation that you will be
completely satised with your new purchase.
To always guarantee optimal function and performance of your product, we would ask the
following:
• Before using the appliance for the rst time, carefully read the operating instructions and
adhere to the safety precautions!
• Also read the software user manual including the End User License Agreement.
• All activities at and with this appliance may only be carried out as described in
these operating instructions.
• Please be sure to include the operating instructions in case you pass along this
product to someone else.
Packaging
This appliance is delivered in protective packaging to prevent transportation damage.
Packaging materials are raw materials and can therefore be recycled. Please recycle these
materials.

3
CarT r ek800
Hardware Instruction Manual
Contents
1 Brief introduction of hardware 4
2 Specications 6
3 Operating the hardware 7
3.1 Turning the device On/Off and activating ‘sleep mode’ 7
3.2 The ‘Programs’ menu 8
4 With reference to environmental protection 9

4
CarT r ek800
Hardware Instruction Manual
1 Brief introduction of hardware

5
CarT r ek800
Hardware Instruction Manual
1. Touch screen
2. Indicator light:
Power on: no light
Battery charging: red light
Battery fully charged: green licht
3. TMC port
4. Headphone jack
5. SD-card slot
6. USB port
7. Stand-by button
8. Power button
9. Speaker

6
CarT r ek800
Hardware Instruction Manual
2 Specications
In the box:
- Satellite Navigation System
- SD card containing maps & CosmicSoft software
- Power lead with 12V car adaptor
- Car Mount & Cradle
- Getting Started Guide
- DVD containing user manuals
Product Speci cations:
CPU: Centrality Atlas II 396MHz
OS: Microsoft WinCE.NET 5.0
GPS Receiver: Built-in Atlas II
Internal Memory: 64MB SDRAM
Display: 4.3” colour TFT touch screen
Battery: Rechargeable Li-Ion, 1200 mAh
Expansion Slot: SD card (up to 2GB)
Ports: USB, TMC, Headphone
Dimensions: 103mm x 88mm x 20mm
Weight: 205g
Speaker: 1 Watt

7
CarT r ek800
Hardware Instruction Manual
3 Operating the hardware
3.1 Turning the device On/Off and activating ‘sleep
mode’
When the device is turned off, slide the Power button on the backside to “on” to turn on the
device. The indicator light will NOT light up and a loading screen will appear on the touch
screen. Please wait until the loading is nished.
When the device is turned on, ‘sleep mode’ can be activated by pressing the stand-by button
on top of the device for 2 seconds. The ‘entering sleepmode’ screen will appear before the
device switches of. In ‘sleep mode’ your device will save power and can be turned on quickly
by pressing the stand-by button again.
To completely switch off the device, slide the power button on the back of the device to
“Off”.

8
CarT r ek800
Hardware Instruction Manual
3.2 The ‘Programs’ menu
When your device has nished loading after turning it on, you will hear a notication sound
and the ‘Programs’ menu will appear. It consists of three buttons:
The ‘Navigation’ button
Tap this button to operate the navigation software of your device.
More information on the operation of the navigation software can
be found in the Software User Manual.
The ‘Settings’ button
Tap this button to view and/or change the settings of your device.
More information can be found on www.cartrekgps.com
The ‘GPS RECEIVER’ button
Press on this button to check the satellite reception of your system.
More information can be found on www.cartrekgps.com

9
CarT r ek800
Hardware Instruction Manual
Packing materials are raw materials and can be used again.
Keep packing materials separate. For more information about recycling
contact your local administration.
Old devices do not belong in the domestic refuse!
Dispose of old devices responsibly, and contribute to environmental protection.
Your local administration will inform you about collecting points and opening
times.
Old batteries do not belong in the domestic refuse!
Dispose of old batteries accordingly and contribute to environmental
protection. Your local administration will inform you about collecting points
and opening times.
This product complies with European directives
4 With reference to environmental protection
