Casio EX-V8 - EXILIM Hi-Zoom Digital Camera User manual

(_ X IL_.IIVI
Digital Camera
EX..V8
User's Guide
Thank
• Before usin
contained in
• Keep the User's Guide in
reference.
• For the most t
product, visit the official EXILIM
Website at http://www.exilim.com/
K830PCM1DMX

MANAGING YOUR FILES 196
Files and Folders .......................... 196
Protecting a File Against Deletion ............ 197
Using the FAVORITE Folder ................. 199
Copying Files ............................. 201
DELETING FILES 2O4
Deleting a Specific File ..................... 204
Deleting All Files .......................... 205
Deleting FAVORITE Folder Snapshots ........ 205
CONTENTS
6

OTHER SETTINGS 206
Configuring Camera Sound Settings .......... 206
Turning the Startup Screen On or Off ......... 208
Specifying the File Name Serial Number
Generation Rule ........................... 209
Changing the Camera Date
and Time Setting .......................... 210
Using World Time ......................... 212
E Configuring World Time Settings 212
Changing the Display Language ............. 214
Changing the Brightness of
the Monitor Screen ........................ 215
Changing the USB Port Protocol ............. 216
Configuring [_] (PLAY) Button Settings ..... 217
Formatting Built-in Memory ................. 218
PRINTING 219
Types of Printing .......................... 219
Using Professional Print Service ............. 220
Using Your Printer to Print Images ........... 220
Using DPOF to Specify Images to be
Printed and the Number of Copies ............ 224
m Date Stamping 226
Supported Protocols ....................... 227
CONTENTS
7

USING THE CAMERA WITH
A COMPUTER 229
What you can do .......................... 229
Using the Camera with a Windows Computer .. 230
J Viewing and Storing Irnages on a Computer 234
J Transfer of Images from the Camera
and Management of Images on the Computer 241
J Playing Movies 243
J Uploading Movie Files to YouTube 244
J Editing a Movie 247
J Transferring Images to the Camera 248
J Viewing User Documentation (PDF Files) 252
J User Registration 252
M Exiting the CD-ROM Menu 252
Using the Camera with a Macintosh .......... 253
J Viewing and Storing Irnages on a Macintosh 254
J Transfer of Images from the Camera
and Management of Images on Your Macintosh 259
J Playing Movies 259
J Viewing User Documentation (PDF Files) 260
@ Registering as a User 260
Reading Files Directly from a Memory Card .... 261
Memory Card Data ......................... 262
APPENDIX 265
General Guide ............................ 265
Monitor Screen Contents ................... 267
Menu Reference ........................... 269
Indicator Lamps ........................... 272
Troubleshooting Guide ..................... 275
Finding the Problem and Fixing It 275
@Display Messages 280
Specifications ............................. 282
CONTENTS
8

Your camera treats each snapshot, movie, and Voice Recording, as a separate file.
You can delete, protect, and copy files as required.
Files are grouped in folders that are created automatically by the camera.
Files and folders have their own unique names, which are assigned automatically by the camera.
• For details about how folders are organized in memory, see "Memory Folder Structure" (page 262).
!I!I
Each folder can contain up to 9999 files named CIMG0001 through CIMG9999. The 26th file name:
extension on the file name depends on the file type.
• If a folder already contains 9999 files, recording another file will cause a new folder to C IM G 0026. J PG
r r
be created automatically. Serialnumber Extension
(4 digits)
Folders are named from 100CASlO _'to 999CASlO • 100th folder name:
• There can be up to 900 folders. 100CASIO'
The BEST SHOT mode (page 104) includes a sample scene that optimizes settings T
for auction site images. Depending on your camera model, the sample scene is Serial number (3 digits)
named either "For eBay" or "Auction".
- images recorded with the eBay scene are stored in a folder named "100 EBAY".
- Images recorded with the Auction scene are stored in a folder named
"100AUCT".
The BEST SHOT mode (page 104) also has a scene (named "For YouTube") that
optimizes movie settings for YouTube. Images recorded with the YouTube scene
are stored in a folder named "100YOUTB".
MANAGING YOUR FILES
196

_NOTE
• You can view folder and file names on your computer. For
details about how file names are displayed on the camera's
monitor screen, see page 268.
• The total number of folders and files that is allowed
depends on the image size and quality, and capacity of the
memory card being used for storage.
You can protect an important file to ensure that it cannot be
deleted accidentally.
• Note that even if a file is protected, it will be deleted if you
perform the format operation (pages 14, 50, 218).
WProtecting a Specific File
1. In the PLAY mode, press [MENU].
2. On the "PLAY" tab, select "Protect" and then
press [1_].
3. Use [_] and [1_] to scroll through images until
the one you want to protect is on the monitor
screen.
MANAGING YOUR FILES
197

4. Use [A] and [Y] to
select "On" and then
press [SET].
An image that is protected is
indicated by the "_" icon.
5. Now you can repeat steps 3 and 4 to protect
another image or exit this procedure by
pressing [MENU].
To unprotect a specific file
Perform the procedure under "Protecting a Specific File", but in
step 4 select "Off" instead of "On".
WProtecting All Files in Memory
1. In the PLAY mode, press [MENU].
2. On the "PLAY" tab, select "Protect" and then
press [b'].
3. Use [A] and [V] to select "All Files : On" and
then press [SET].
This protects all files currently in memory.
4. Press [MENU].
To unprotect all files in memory
Perform the procedure under "Protecting All Files in Memory",
but in step 3 select "All Files : Off" instead of "All Files : On".
MANAGINGYOUR FILES
198

The FAVORITE folder is located in the camera's built-in
memory, and you can use it to store personal snapshots that you
do not want displayed during normal PLAY mode operations.
FAVORITE folder snapshots remain in camera memory, even if
you change to a different memory card.
• The FAVORITE folder can be used for snapshots only.
Saving an audio snapshot in the FAVORITE folder will save
the snapshot part only.
ICopying a File to the FAVORITE Folder
1. In the PLAY mode, press [MENU].
2. On the "PLAY" tab, select "Favorites" and
then press [1_].
3. Use [A] and [Y] to select "Save" and then
press [SET].
4. Use [,q] and [1_] to select the snapshot you
want to copy to the FAVORITE folder.
5. Use [A] and [V] to select "Save", and then
press [SET].
This saves a copy of the snapshot to the FAVORITE folder.
6. Now you can repeat steps 4 and 5 to save
another image, or press [MENU] twice to exit
this procedure.
MANAGINGYOUR FILES
199

• The snapshot copied to the FAVORITE folder is converted
to QVGA size (320 x 240 pixels). A snapshot in the
FAVORITE folder cannot be restored to its original size.
• Snapshots in the FAVORITE folder cannot be copied to a
memory card.
_NOTE
• The number of snapshots that can be stored in the
FAVORITE folder depends on the image quality of each
one, and how much built-in memory capacity is remaining.
WViewing Snapshots in the FAVORITE Folder
1. In the PLAY mode, press [MENU].
2. On the "PLAY" tab, select "Favorites" and
then press [b'].
3. Use [A] and [V] to select "Show" and then
press [SET].
4. File Name
Use [<] and [1_] to
scroll through the
snapshots in the
FAVORITE folder.
FA VORITE folder icon
5. After you are finished viewing the FAVORITE
folder snapshots, press [MENU] twice to exit
this procedure.
MANAGINGYOUR FILES
2OO

Perform the following steps to view FAVORITE folder
contents on your computer.
1. Remove the memory card from the camera.
2. Place the camera on the USB cradle (which is
connected to the computer).
3. Perform the required operations on your
computer to navigate to the camera's memory
and display the FAVORITE folder contents.
Files can be copied from the camera's built-in memory to a
memory card, or from a memory card to built-in memory.
This makes it possible, for example, to perform the following
steps and copy a file from your memory card to another person's
memory card.
(_) Copy the file from your memory card to the camera's built-in
memory.
_) Remove your memory card and insert the other person's
memory card.
(_) Copy the file from built-in memory to the other memory card.
• You can copy snapshots, movies, audio snapshots, or
Voice Recording files you recorded with your camera.
• You cannot copy a snapshot that is in the FAVORITE
folder.
• When a copied file image appears on the full-month
calendar screen, it is displayed on the date that it was
copied (page 172).
MANAGING YOUR FILES
201

ICopying All Files in Built-in Memory to a
Memory Card
Thefollowingoperationcopiesallfilesfrom built-inmemorytoa
memorycard.Youcannotcopyfiles individually.
1. Load the memory card to which you want to
copy the files into the camera.
2. Turn on the camera,enter the PLAY mode and
then press [MENU].
3. On the "PLAY" tab, select "Copy" and then
press [I_].
4. Use [A] and [Y] to select "Built-in _ Card"
and then press [SET].
This starts the copy operation. Wait until the "Busy... Please
wait..." message disappears from the monitor screen before
performing any operation on the camera.
• After the copy operation is complete, the last file copied
will be displayed on the monitor screen.
mCopying a Single File from a Memory Card to
Built-in Memory
With this procedure, files must be copied one-by-one.
1. Load the memory card that contains the file
you want to copy into the camera.
2. Turn on thecamera, enter the PLAY mode and
then press [MENU].
3. On the "PLAY" tab, select "Copy" and then
press [I_].
4. Use [A] and [V] to select "Card _ Built-in"
and then press [SET].
5. Use [,il] and [1_] to select the file you want to
copy.
°Use [A] and [V] to select "Copy" and then
press [SET].
This starts the copy operation. Wait until the "Busy... Please
wait..." message disappears from the monitor screen before
performing any operation on the camera.
• The copied image reappears on the monitor screen after
the copy operation is complete.
MANAGINGYOUR FILES
202

7. Now you can repeat steps 5 and 6 to copy
another file, or you can exit this procedure by
pressing [MENU].
_NOTE
• Files are copied to the folder in built-in memory whose
name has the largest serial number.
MANAGINGYOUR FILES
2O3

You can delete files you no longer need, or after you transfer
them to your computer's hard disk or print them. This frees up
memory for new files.
You can delete one specific file, or you can delete all files
currently in memory.
Here we will explain the different file delete procedures,
including how to delete snapshots from the FAVORITE folders.
• Remember that a file delete operation cannot be undone.
Always make sure that you really no longer need a file
before deleting it.
• A protected file cannot be deleted. To delete a protected
file, first remove its protection (page 197).
• Deleting an audio snapshot deletes both the snapshot and
the audio file.
1. In the PLAY mode,
press [Y] ( _] _).
,
.
.
Use [_1] and [1_] to scroll through the images
until the one for the file you want to delete is
on the monitor screen.
Use [A] and [V] to select "Delete" and then
press [SET].
• To exit the delete operation without deleting anything,
select "Cancel".
Now you can repeat steps 2 and 3 to delete
another file.
• Youcanexitthisprocedurebypressing[MENU].
DELETING FILES
204

1. In the PLAY mode, press IV] (_ _).
2. Use [A] and [Y] to select "All Files Delete"
and then press [SET].
3. In response to the confirmation message that
appears, use [A] and [V] to select "Yes".
• To cancel the delete operation, select "No" instead of
"Yes".
4. Press [SET].
• This deletes all of the files and displays the message
"There are no files."
You can delete a single snapshot, or you can delete all the
snapshots currently in the FAVORITE folder.
1. In the PLAY mode, press [MENU].
2. On the "PLAY" tab, select "Favorites" and
then press [11_].
3. Use [A] and [V] to select "Show" and then
press [SET].
4. Press [V] ("_ _).
5. Use the procedures under "Deleting a Specific
File" and "Deleting All Files" to delete the
snapshots you want.
•Youcanexitthisprocedure by pressing [MENU] twice.
DELETING FILES
2O5

Your camera lets you configure the following sound settings.
• Type of sound and volume for shutter release and other
operations
• Volume level for movie and Voice Recording playback
ISelecting the Operation Sound
1. Press [MENU].
2. On the "Set Up" tab, select "Sounds" and then
press [,].
3. Use [A] and [V] to select the operation whose
sound you want to configure (Startup, Half
Shutter, Shutter, Operation) and then press
[,].
4. Use [A] and [Y] to select the setting you want
and then press [SET].
Sound one of the built-in Sound 1 - 5
sounds(1through5)
Turnsoundoff Off
OTHER SETTINGS
206

I Setting the Operation Tone Volume Level
1. Press [MENU].
2. On the "Set Up" tab, select "Sounds" and then
press [,].
3. Use [A] and [V] to select "[] Operation".
4. Use [,q] and [1_] to specify the playback
volume setting you want and then press [SET].
• Youcansetthevolumeto oneofeight levelsinthe range
ofO(lowest)to7 (highest).
•SettingavolumelevelofOmutesthesound.
_NOTE
• The volume setting you configure here is also applied to
video output (page 166).
WSetting the Playback Volume Level
You can use this procedure to set the playback volume level for
moviesandaudiosnapshots,independentofthe operationtone
volume.
1. Press [MENU].
2. On the "Set Up" tab, select "Sounds" and then
press [_].
3. Use [A] and [V] to select "[] Play".
4. Use [41] and [b] to specify the operation tone
volume setting you want and then press [SET].
• Youcansetthe volumetooneof eightlevelsinthe range
ofO(lowest)to 7(highest).
•Settingavolumelevelof Omutesthe sound.
• The volume setting you configure here does not affect the
video output (page 166).
OTHER SETTINGS
207

You can configure the camera to display a startup screen of an
image you recorded, whenever you turn it on.
• Even if you configure startup screen settings in the PLAY
mode, the startup screen does not appear when turn on the
camera by pressing [_] (PLAY).
1. Press [MENU].
2. On the "Set Up" tab, select "Startup" and then
press [,].
3. Use [_1] and [1_] to scroll through the images
until the one you want to use as the startup
screen is on the monitor screen.
4. Use [A] and [Y] to select the setting you want
and then press [SET].
Use the selected image as the On
startup screen
Turn off the startup screen Off
_NOTE
• The following are the types of images that you can select
for the startup screen.
- Special startup screen images built into the camera
- Snapshots
- Audio snapshots (Audio does not play.)
• Only one startup screen image can be in effect at any time.
To change the startup screen to another image, simply
overwrite the current image with the new one.
• Formatting built-in memory (page 218) will delete the
current startup screen image.
OTHER SETTINGS
2O8

Use the following procedure to specify the rule that governs
generation of the serial number used in file names (page 196).
1. Press [MENU].
2. On the "Set Up" tab, select "File No." and then
press [,].
3. Use [A] and [V] to select the setting you want
and then press [SET].
Remember the numbers used for files. Files will
be named using the next sequential number,
even if files are deleted or if a blank memory card
is loaded.
• If a memory card is loaded that already has
files stored on it and the largest sequential
number in the existing file names is greater
than the largest sequential number
remembered by the camera, numbering of new
files will start from the largest sequential
number in the existing file names plus 1.
Restart the serial number from 0001 whenever all
files are deleted or when the memory card is
replaced with a blank one.
• If a memory card is loaded that already has
files stored on it, numbering of new files will
start from the largest sequential number in the
existing file names number plus 1.
Continue
Reset
OTHER SETTINGS
209

When changing the date and time setting, be sure to do so for
your Home City (the location where you normally use the
camera). If you already have your Home City setting configured
correctly, you can use the procedure under "Setting the Date
and Time for Your Home City" (page 211 ) to change the current
time setting only, if you want.
• Changing the time and date setting without correctly
configuring your Home City setting first will cause all of the
World Time (page 212) dates and times to be off.
ISelecting Your Home City
1. Press [MENU].
2. On the "Set Up" tab, select "World Time" and
then press [11_].
This displays the current World Time settings.
.
4.
5.
°
7.
Use [A] and [V] to select "Home" and then
press [1_].
Use [A] and [V] to select "City" and then
press [,].
Use [A], [V], [_], and [1_] to select the area
where your Home City is located and then
press [SET].
Use [A] and [V] to select your home city and
then press [SET].
After the setting is the way you want, press
[SET] to exit the setting screen.
OTHER SETTINGS
210

ISetting the Date and Time for Your Home
City
1. Press [MENU].
2. On the "Set Up" tab, select "Adjust" and then
press [,].
3. Set the date and the time.
iiii Ji!
Movethe cursorbetweensettings Press[_1]or [1_-]
Change the setting atthe cursor Press [A] or [V]
location Slidethe zoom
Toggle between12-hourand controllertowards
24-hourformat [_'1] or[E¢3].
4. After all of the settings are the way you want,
press [SET] to exit the setting screen.
WChanging the Date Format
You canselectfromamongthreedifferentformatsforthe date.
1. Press [MENU].
2. On the "Set Up" tab, select "Date Style" and
then press [11_].
,Use [A] and [Y] to select the setting you want
and then press [SET].
Example: December 19, 2007
07/12/19 YY/MM/DD
19/12/07 DD/MM/YY
12/19/07 MM/DD/YY
OTHER SETTINGS
211
