Catalina SUMMIT-8 Installation guide

Training Manual
2024 Model Year Product

▪GE Kitchen Appliances
▪GE Refrigerator
▪JBL Premium Sound System
▪OneControl Bluetooth Monitor Panel
▪MORyde StepAbove Entry Steps
▪Power Awning w/Multi-color LED Strip Lighting
▪Optional 200-Watt Solar Panel
▪Optional 30 Amp Solar Charge Controller
▪RV Link Wi-Fi Wired and Prepped
▪Screwed Cabinetry Construction & Benefits
▪Seamless Counter Tops Construction & Benefits
▪Black Tank Flush
▪Rear Ladder Prep
▪BAL NXG Frame
▪NXG Through Frame Slide Out
▪Gas/Electric Water Heater & Furnace
▪Additional Interior Value Features
▪Additional Exterior Value Features
Table of Contents
All pages are hyperlinked below for direct link to that page

GE® 17” RV Gas Range, Vented
Range Hood, and Microwave
17” Rangetop Features Include:
✓Edge-to-Edge Grates –Easily move cookware on this seamless surface
cooktop with continuous black matte grates.
✓Spark Ignition System –Easily light each burner by turning on the burner
a creating a spark with the spark ignition knob
✓Cast Metal, White Backlit, Range Knobs –Heavy cast metal knobs
offer durability with a high-end look. White backlit range knobs can be
conveniently turned on and off.
✓Three Burner Rangetop –8,000 BTU burner in the front, two 6,500 BTU
burners in the back. Offers plenty of heating power and space to cook
multiple dishes at once!
✓Sealed Cooktop Burners –Sealed burners contain spills and makes clean
up quick and easy.
Range Hood & Microwave Features Include:
✓Watts & Power Levels –This is a 900W microwave is on the high end of
the wattage spectrum for its size. It also comes with 10 power levels!
✓Convenience Cooking Controls –7 convenient easy cook modes like
popcorn and reheat buttons.
✓Instant On Controls –Instantly set the timer between 1-6 minutes with
the press of the instant on control button.
✓Filtered and Ducted Range Hood –Fumes and odors are vented
outside of your RV. The aluminum mesh filter can be easily washed under
water!
Back To Table of Contents. Click Here
GE Appliances include a 2-year warranty!

Features Include:
✓Semi-Automatic Defrost –designed to save energy and
improve battery performance.
✓Deep Freezer w/ a Shelf –Accommodates larger items; even a
bag of ice.
✓Adjustable Glass Fridge Shelves –Two adjustable shelves to
organize food storages.
✓Door Bins/Storage –Frees up shelf space in the fridge & freezer.
✓Clear Crisper Drawer –Helps preserve fresh fruits and
vegetables.
✓LED Lighting –Energy efficient and bright.
✓Compressor Cooling System –No external ventilation
required.
✓12V DC Power –Specifically engineered for the RV and boat
industries.
Differentiation Benefit: Wall Switch for the
Refrigerator
✓Catalina wires our 12V refrigerators to a switch
located next to the refrigerator giving the owner the
ability to turn off the refrigerator completely
**The 12V refer is a standard build item. Catalina offers a 7 cu. Ft.
gas/electric RV refer as an option.
GE® 9.8 Cu. Ft. 12 Volt DC
Power Top-Freezer Refrigerator
Back To Table of Contents. Click Here
GE Appliances include a 2-year warranty!

JBL Premium Sound System
The Benefits:
✓2 Zones of Audio Control with dual zone control.
▪Have the TV/Radio playing through interior speakers (zone A)
with a Bluetooth device playing on the outside speakers (zone
B).
✓Bluetooth Connectivity.
✓FM Tuner with 10 Presets.
✓HDMI ARC Cable Installed to Connect to TV (Yellow HDMI Plug).
✓Parametric Lighting with 3 Different Light Modes.
✓Interior JBL Speakers Specifically Paired for Optimal Sound.
✓Exterior Speakers Specifically Paired for Optimal Sound.
Differentiation Benefit: Name Brand Sound System
✓Catalina uses the JBP Premium Sound System. Very few
other brands in our segment even know what sound
equipment they are using!
Back To Table of Contents. Click Here

Connect and Operate
Video!
Click Here
Download the
OneControl App
Below!!
Easy to Setup!
Step 1: Download the LCI OneControl app.
Step 2: Log into the mobile app.
Step 3: Connect your RV.
▪Scan QR Code
▪Push to Pair
▪Search Devices
Step 4: Enter RV Details.
Step 5: Set up a pin.
OneControl Bluetooth Monitor
Panel
The Benefits:
✓Control all monitor panel functions from your phone or tablet.
✓Open awning and slide outs while being able to see potential
obstructions.
✓Turn on/off lights without having to go back inside of the unit.
✓Check tank level and battery voltage and even set mobile alerts
to come through when tanks hit designated alert status.
✓Add additional accessories.
✓Receive message notifications including maintenance reminders
and tips.
Back To Table of Contents. Click Here

MORryde StepAbove
Entry Steps
Key Features:
✓Bounce-free, wobble-free stability
✓Lightweight; Easy to stow and unstow
✓Quick release leg adjustment; NO
PINS!
✓Wide top step for safety
✓Gradual step slope for full foot
placement
✓500lb. Weight Capacity
Entry Steps Vendor Video
Click to play video
Back To Table of Contents. Click Here

Multi-Colored LED
Lighted Power Awning
Key Features:
✓No Hassle Power Awning –push button on the
OneControl board, or open with your OneControl app!
✓Heavy Duty Vinyl Fabric –Anti-mildew, Anti-scuff,
and cold-crack tested.
✓Adjustable Pitch –Pitch control on each arm allows for
better sun blocking coverage. It also helps avoid pooling water!
✓8’ Extension – Solera Awnings extend out 8 ft. for plenty
of camp site shade coverage.
✓Multi-Color LED Light Strip w/Remote –
Provides 15 different colors + white. Also includes features such
as strobe, flash, fade, or smooth transition between colors.
Stand out from the crowd with a unique color!
Back To Table of Contents. Click Here

Go Power! 200 Watt
Solar Panel
Key Benefits:
✓Produces 9.6 amps of power charging capability, per hour, under standard solar conditions.
✓Capable of running a 12V refrigerator.
✓Monocrystalline power cells for higher efficiency.
✓Industry standard quick connect cables.
✓25-year limited solar panel output power warranty.
All Catalina’s are wired and prepped for solar standard. The panel and charge controller is an optional add
from the factory.
Back To Table of Contents. Click Here

Go Power! 30 Amp Bluetooth
Solar Charge Controller
Key Benefits:
✓Capable of handling up to 600 watts of solar power.
✓Bluetooth® ready with the Go Power! Connect app.
▪Set the battery type and charging profile
▪Turn your compatible Go Power! ISW Inverter on or off
▪Toggle Maximum Power Boost mode
▪View essential battery stats, including:
▪Battery Voltage
▪PV Charging Current
▪Battery State of Charge (SOC)
✓Regulates current flow from your solar modules to your batteries.
✓Temperature compensated pulse width modulation (PWM)
charging.
✓4 battery charging profiles: Sealed/Gel, AGM, Flooded and LiFePO4
(lithium).
✓4 stage charging: Bulk, Absorption, Float and Equalize.
✓Back lit LCD screen displays charging current, battery voltage and
battery state of charge.
✓Built-in USB charge port.
✓Heavy-duty terminals for low resistance connections.
✓Suitable for 12V solar systems up to 30 amps.
✓5-year warranty.
Solar Sizing
Worksheet
Click PDF →
Back To Table of Contents. Click Here

Wi-Fi Prep
Magnadyne RV Link
Key Features:
Please note that the features below reflect the advantages of the model WF-CON-LTE product.
✓High gain LTE antenna provide improved performance in
remote locations.
✓Connect your Hotspot through RV-Link to boost hotspot
capability.
✓Roof mounted WIFI/LTE extender uses high gain antennas
to boost WIFI signal at campgrounds, recreation areas and
rest stops. (1/2-mile range)
✓Router is easily configured in 10 minutes or less using a
smartphone, tablet or computer.
✓4G LTE Module: Optimized for M2M and IoT devices
150Mbps downlink rates 50Mbps uplink rates.
✓WIFI: Has a Frequency of 2.4GHz, a range 1/2 mile, and
dual Wi-Fi antennas.
✓LTE module certified to work on AT&T, Verizon, and
Rogers network (LTE setup instructions for are in the
router quick-start guide or by contacting Magnadyne
support).
✓Other providers are compatible. You would just need to
replace that providers SIM card in the modem portion of
the kit.
Multiple Ways to Use
1. Connect your mobile hotspot through
RV-Link to boost hotspot capability.
2. Purchase a 4G LTE plan for direct Wi-Fi
through cell towers.
3. Boost available Wi-Fi connections with ½
mile range.
Router and Modem is an after-market
purchase.
https://magnadyne.com/collections/rv-link-systems?custom=RV-Link
Back To Table of Contents. Click Here

A Higher Standard:
Screwed Cabinetry
Lumber Core Stiles:
Our construction requires us
to use real lumber core
stiles, so the screws have
something to grip into
securely.
Framing Table:
No guess work! This ensure
the right angles and
strongest fit for all of our
cabinets.
Pocket Holes:
Using a jig, we drill precise
pocket holes for the screws
we use in our construction.
This ensures quality and
strength every time.
The Catalina Cabinet Process
See The Difference! XParticle Board
▪Not a strong material core material for construction
▪Does not stand up to temperature changes and humidity
XStapled
▪Does not offer the same security and hold as screws
▪Inconsistent from stile to stile and cabinet to cabinet
XConstruction
▪Stapled cabinets are often built without the use of a framing table. This creates
inconsistencies, gapping and unleveled cabinets.
Back To Table of Contents. Click Here
Check Out Our Video!
Click Here

Seamless Thermofoil
Counter Tops
The production process and key quality
indicators:
✓CNC routed to specific engineered specs
✓Complete glue coverage preventing separation or gaps
✓Totally seamless coverage of the substrate; no gaps &
separation
✓Heat and pressure adherence process for a smooth
high-quality finish
✓Hand trimmed to prevent damage and ensure quality
coverage
Check Out How
They’re Made!
Click Here
AVOID THIS!
At Catalina we use our thermofoil counter tops in:
✓The Kitchen/Galley
✓Dinettes
✓Camp Kitchens
✓Bathrooms
Back To Table of Contents. Click Here
Check Out Our Video!
Click Here

Black Tank Flush
Standard
Traditional black tank cleaning methods require more equipment, take longer and are messy.
You’re going to
need a long hose!
You have to drag it
through your camper
to the bathroom.
Fight the hose and
cleaning attachment
down the toilet.
What a mess! Now
what?
Getting the dirty
hose back out of your
trailer. Yikes!
Hoping the tank is
getting cleaned
properly as you twist
and turn the hose.
Check Out Our Video!
Click Here
ADVANTAGES:
✓Quicker black tank cleaning process.
✓Easier method with no additional equipment needed.
✓Cleaner than dumping water buckets or pulling a hose through
your camper.
1. Connect the hose to your black tank flush
port
2. Open your black tank evacuation valve
3. Turn on the water.
3 easy steps!
Back To Table of Contents. Click Here

Rear Ladder
Prep
Key Features:
✓Portable, telescoping ladder for RVs
✓12' 6" or 14'6" telescopic extension
✓Weighs less than 30 lbs.
✓Retracts to 33.5" or 35.75" for easy storage and
transport
✓Sturdy 330 lb. weight capacity
✓Angled extension reaches 22" above your RV for
added stability
✓User-friendly, fast extension and retraction
✓Segmented locks on each step for increased
retraction control
✓Only compatible with RVs equipped with the
Lippert ladder receiver
Back To Table of Contents. Click Here

BAL by Norco Industries
NXG FRAME
Eliminates:
✓Frame failures due to sub-standard steel.
✓Inconsistent placement of frame component parts.
✓Uneven main rails –varying camber and squareness.
✓Corrosion caused by incomplete paint coverage.
Key Benefits:
✓Manufactured with HSLA –High Strength Low Alloy Prime Steel with specifically controlled properties.
✓CNC controlled rail fabrication eliminated inconsistency of frame components, including spring axle
hanger placement.
✓Mechanically and CNC applied to achieve the desired positive camber, specific to each floorplan
✓Component parts are painted separately, then assembled.
✓Manual welding is minimized. Common components are robotically welded for consistent quality.
✓All fastened components are joined with Huck® fasteners. Huck® fasteners provide consistent clamp
load
Back To Table of Contents. Click Here

Through Frame Slide out
NXG FRAME
Key Features:
✓Arched Design –Strong, tighter, and more durable design
that helps hold the room against the trailers side wall.
✓Rack and Pinion Drive System –Simple and
reliable system with a single motor and easy manual override.
✓More Space! –Rack and pinion slide systems offer more
head room and more depth than other slide systems on the
market today.
✓Slide Room Supported by Frame –The
through frame design means the slide room itself is engineered
into the frame for that specific floor plan. This adds support to
the slide room and helps take the load off the sidewalls.
Description
BAL has set the new standard in slide-out technology with the award
winning ‘NXG SLIDE’ rack drive slide-out. The NXG SLIDE system provides an
unmatched level of durability and precision that was not available in older
generations of slide-out mechanisms. Due to the systems rigidity and
tightness, a user should experience years of trouble-free performance. All
components of the NXG SLIDE mechanism are individually coated with
highly effective corrosion-resistant e-coat or plating for extended life of the
slide-out drive. Required maintenance is limited to periodic cleaning and
lubrication of the main drive arms of the system. U.S. patent pending.
Back To Table of Contents. Click Here

Water Heater &
Furnace
35,000 BTU Furnace 6 Gal. Gas & Electric Water Heater
Dare to Compare!
Very few direct competitors use a 35,000
BTU furnace!
ADVANTAGES:
✓Longer Camping Season
✓More Comfort in Lower Temperatures
✓Less Run Time to Maintain Temperature;
Saves Propane
ADVANTAGES:
✓Direct Spark Ignition allows the user to start the
water heater from inside their camper.
✓Quick Recovery allows up to 16.2 gallons of water
to be heated per hour
✓Gas and Electric feature is STANDARD compared
to gas only models used by the competition
✓Water Pump/Winterization Kit (shown in the picture
above) allows the user to easily bypass and
winterize their own camper.
Back To Table of Contents. Click Here

Interior Added
Convenience Features
12V Vent Fan
THE BENEFITS:
✓Bathroom Ventilation.
✓Natural Skylight.
✓Air Circulation.
✓Prepped for
aftermarket upgrades.
ABS Tub Surround & Easy
Step Shower
USB/USB-C/12V Outlets Shower/Coat Hooks
THE BENEFITS:
✓ABS tub surround to
protect wall board from
water damage without
needing to dry off.
✓Built-in shelves.
✓Easy step; low
lip/shallow profile
shower.
THE BENEFITS:
✓Mostly found in our
bathrooms as towel
hooks.
✓Adds a small
convenience for
customers and free’s
up storage space.
THE BENEFITS:
✓Powered by 12V, unlike
the 110V plugs, so it
offers charging
capabilities from the
battery.
✓One on each side of the
main bedroom. Also
placed in the kitchen
and bunk rooms. Back To Table of Contents. Click Here

Exterior Added
Convenience Features
360 Siphon Roof Vent Cap
LP Quick Connect Battery Disconnect Switch
THE BENEFITS:
✓Runs off of the
Standard LP Bottles.
✓Convenience for
Grilling or Cooking
with LP.
✓Quick Connect Hose
Attachment.
THE BENEFITS:
✓Completely
Disconnects the
Battery from All
Systems.
✓Saves Battery Life.
✓Conveniently
Accessible on the A-
Frame.
THE BENEFITS:
✓Air passing through
creates a vacuum.
✓Gases are drawn
out.
✓Eliminates Odor.
✓Built-In Screen
Keeps Bugs Out.
G20 Tinted Windows
THE BENEFITS:
✓Only 20% of UV
light gets through.
✓Keeps the unit
cooler.
✓Protects furniture
from sun fade.
✓Adds some privacy
during the day.
Back To Table of Contents. Click Here
