CB ELECTRONICS TMC-1 Service manual

CB Electronics
TMC-1 Monitor Remote
Reference
Version 6.0

TMC-1 Reference Manual
C
CB B E El le ec ct tr ro on ni ic cs s
CB Electronics has made every effort to ensure the accuracy of information contained within
this document, which is nevertheless supplied for information purposes only and does not
constitute any form of warranty or guarantee.
All trademarks acknowledged.
The information in this document is subject to change without notice.
The nformation in the manual is updated as the TMC-1 is improved, you can find the latest
version of the software on the product web page.
CB Electronics
Loddonside, Lands End House
Beggars Hill Road
Charvil
Berkshire RG10 0UD
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Tech Support: [phone]
Web: www.colinbroad.com

TMC-1 Reference Manual
INTRODUCTION 1
CONNECTIONS 2
INSTALLATION 2
Power 3
Connecting to XMon or A-Mon 3
XMon to HD-15 Converter 4
RJ45 Breakout Box 4
Connecting to N P DAD AX/DX32, N P Penta or Avit M RX 4
Connecting to D-Mon 5
PFL/AFL from the Mixer/Workstation 5
Hard Ware Mute 5
Record/Play tallies for Auto Mute/Auto alkback/ alkback Resume 5
SETTING UP TMC-1 6
F OR THE FIRST TIME OR AFTER M AJOR S OFTWARE U PDATE 6
Factory Default: 6
/B Gain 1 & 2 6
Listen Gain 1 & 2 6
AFL Gain 6
P ROTECTED /C ALIBRATED S ETTINGS 7
NPUT AND OUTPUT TRIMS 8
Input rim: 8
Speaker rim: 8
Using MC-1v5 to adjust rims 10
Mono rim: 11
7.1, 5.1 and User rim: 11
Cal A/B rim: 12
Cal P 12
CALIBRATING THE SPL LISTENING LEVEL 13
Why is there no overall output level adjustment for the speaker sets? 13
Power Amplifier Input Pad 14
OPERATION 14
Meters Page: 15
Speaker Mute: 15
Speaker Solo Page: 15
Input Select with Sum Enabled 15
Cue Sends Page: 16
Cue Sends Page with Select Depressed 16
Cue Mutes 16
Select Page: 17
In/Out Preset 17

TMC-1 Reference Manual
Information display: Shown Below 18
FORMAT 18
Auto Mute Page 19
Auto alkback 20
User Keys, GPIO’s and Auto: 20
Setup Menu: 21
/B, L/B, AFL Page 21
TMC-1 C ONTROLS 22
[Mute] Key: 22
[Dim] Key : 23
[Page] Key: 23
[Select] and [Ctrl] Keys: 23
[Select] Key: 23
[Ctrl] Key: 23
USER FUNCTION KEYS: 24
Display Keys [1] – [8] 25
[User]: 25
Function Keys: [Fn-1], [Fn-2], [Fn-3] 25
Function Keys - normal operation after factory Reset 25
Knob Push 25
USER KEY FUNCTION TABLE 25
U SER K EYS -C OMMON TO A LL 26
TMC1-X MON O NLY 30
TMC1-P ENTA O NLY 30
TMC-1-DM ON ONLY 32
TMC-1-AM ON ONLY 33
Knob Push 33
Display Keys [1] – [8] 34
M ETERS P AGE 35
User keys: [1], [2], [3], [4], [5], [6], [7], [8]: 35
U SER K EY BANK 2 35
M ETER S OURCE 36
TMC-1-XM ON M ETER S OURCE 36
TMC-1-P ENTA M ETER S OURCES 36
TMC-1-DM ON M ETER S OURCE 36
TMC-1-AM ON M ETER S OURCES 37
C UE S ENDS P AGE 38
User keys: [1], [5], [6], [8]: 38
[ v ] and [ ^ ]: 38
[Enable]: 38
[PFL]: 38
[Select] 38

TMC-1 Reference Manual
Cue Sends Display with [Select] depressed 39
Speaker Mute and Solo pages 39
Speaker Select keys [1]-[8]: 39
NPUT S ELECT PAGE 40
Input Select keys [1]-[8]: 40
Input Select page with Sum Enabled 41
TALKBACK 41
Internal alkback and Listen-back Latching 42
MC-1 Internal/External Microphone Gain adjust 42
XMon alkback: 42
Penta alkback: 42
Internal/External alkback and Listen-back Latching [1] and [6] 42
MC-1 Internal Microphone Gain adjust 42
MC-1 External Microphone Gain adjust 42
Auto- /B & Auto Mute 43
ENGINEER HEADPHONE SOURCE SELECTION 44
SYSTEM SETUP 45
Setup Menu: 45
Menu 01 – Meter Order 45
Menu 02 – alkback Latch Enable 45
Menu 3 – F Brightness 46
Menu 4 – op Display 46
Menu 5 – HUI AFL 46
Menu 6 – Mute Monitors when Listen Active 46
Menu 7 – Cue Output when alkback Active 47
Menu 8 – Level Display ype 47
Menu 9 alkback keys when Record Active 47
Menu 10 – Cal A / Cal B/Cal P Lock 47
Menu 11 – A / B Switch Lock 47
Menu 12 – Listen Speaker Output Assign 48
TMC-1-PENTA: LISTEN1 IS SENT TO LEFT AND LISTEN 2 IS SENT TO
RIGHT ADVANCED SETUP 48
ADVANCED SETUP 4
Adv Menu 01 – Lock/Un-Lock User Keys 49
Adv Menu 02 – Calibration Mode Enable 49
Adv Menu 03– SPL/Dolby Display for 0dB Gain 49
Adv Menu 04– External /B Dim 50
Adv Menu 05 – Volume Knob push switch Function 50
Adv Menu 06 – Page key function 51
Menu 07 – Select Key Off function 51

TMC-1 Reference Manual
Adv Menu 08 – Ctrl Key Off function 51
Adv Menu 09, 10, 11, 12, 13, 14 – GPI Inputs 51
he default function for GP4 in is Ext /B 2 52
Adv Menu 15 – AFL/PFL GPI Active level 53
Adv Menu 16 – GPI Record ally Active Level 53
Adv Menu 17 – GPI Play ally Active Level 53
Adv Menu 18 – GPO 1 Output Function 53
Adv Menu 19 – GPO 2 Output Function 53
Adv Menu 20 – GPO 3 Active High/Low 53
Adv Menu 21 – Maximum Gain 53
Adv Menu 22 – Factory Reset 54
TMC-1-XMON ONLY ADVANCED MENU’S 55
Adv Menu 23 – Alt Output Select 55
Adv Menu 24 – Communications 55
Adv Menu 25 – XPand Surround 55
TMC-1-PENTA ONLY ADVANCED MENU’S 55
Adv Menu 23 – Alt Output Select 55
Adv Menu 24 – Digital Headroom 56
Adv Menu 25 – Insert Makeup Gain 56
Adv Menu 22 –Set default Analogue Output level (On Menu Exit) 56
Adv Menu 27 – Write I/O Names o Penta / DAD AX/DX32 58
Adv Menu 28 – Reset Penta / DAD AX/DX32 to Defaults on Menu Exit 58
TMC-1-DMON ONLY ADVANCED MENU’S 5
Adv Menu 23 – Digital Headroom 59
Adv Menu 24 – Define Cue Mix Using 59
TMC-1-AMON ONLY ADVANCED MENU’S 60
Adv Menu 23 – Alt Output Select 60
Adv Menu 24 – Centre Speaker Fitted? 60
Adv Menu 25 – LFE Speaker Fitted? 60
Adv Menu 26 – Rear Surround Speakers Fitted 60
Adv Menu 27 – Communications 61
Adv Menu 28 – XPand Surround 61
GPIO 62
GPO Open Collector Outputs 63
Connecting a lamp to a Open collector outputs 63
Connecting a LED to a Open Collector Output 63
GPI Inputs 65
C ONNECTING A SWITCH TO A GP NPUT 65
C ONNECTING TO THE A VID S6 65
C ONNECTING TO THE A VID S YNC O 66

TMC-1 Reference Manual
T/B MIC I/P 66
USB PORT 67
P OWER 67
C ONFIGURATION 67
HU E MULATION 67
M D T IMECODE 67
F IRMWARE U PDATES 67
R ECOVERY 68
NETWORK PORT 6
DHCP 69
OSC (O PEN S OUND C ONTROL ) 70
User Keys 70
OSC Slave O/P 72
OSC WiFi Connections 72
SETTING THE TMC-1 USER KEY FUNCTIONS 75
S ETTING THE NPUT , O UTPUT , S PEAKER , M ETER AND U SER N AMES 75
PRESETS 76
TMC-1 INTERNAL CONNECTIONS 7
Corrected XMon 15 pin Connections 80
TALKBACK &HEADPHONES CONNECTOR (XMON)TMC-1 HD15 (VGA)
CONNECTOR 80
TMC-1 HD15 (VGA) CONNECTOR 81
C ONNECTING A A VID CON C ONSOLE TO THE MTRX/D AD AX32/NTP P ENTA 82
TMC-1-XM ON /A-M ON RJ45 B REAKOUT B OX 83
C ONNECTING THE TMC-1 H EADPHONES AND T ALKBACK M ICROPHONE TO THE DAD A X 32, NTP P ENTA
720 AND A VID MTRX 84
S INGLE M INI S PEAKER 85
GLOSSARY 85
CUSTOMER QUESTIONS 86

TMC-1 Monitor Controller Introduction
14 September 2018  CB Electronics 1 Version 6.0
I
In nt tr ro od du uc ct ti io on n
The TMC-1 Monitor Controller is supplied with different software to suit the system controlled,
TMC-1-XMon, TMC-1-Penta, TMC-1-DMon, TMC-1-AMon and TMC-1-Remote
•Connects to Avid XMon via 1 pin ‘D’ connector.
•Connects Trinnov D-Mon via Ethernet. Use the TMC-1-DMon Manual
with this manual
•Connects to DAD AX32/NTP Penta via Ethernet. Use the TMC-1-
Penta Manual with this manual
•Connects to A-Mon via HD1 and DCC VGA Cable
•Protected calibration settings
•Internal Talkback Microphone
•Play tally from Play GP Input, MTC, HUI or LTC
•Record/Red Light GP Input/Output
•Record Tally from Record GP Input or HUI
•Auto-Mute Main LS, Studio LS, Talkback and Listen Back
programmable from Play and Record GPI or HUI
•Before, During and After automation of Studio L/S and Headphone
Output.
•Two separate talkback destinations
•Dual Calibration Settings By default 8 and 80 SPL
•Dedicated speaker solo/mute keys.
•GPIO for Talkback, Listenback, PFL/AFL
•Stem Input mixing with Mute and Solo
•A/B Input selection
This guide will introduce the TMC-1 with examples and illustrations
Further information and software upgrade and x-mon, d-mon, penta, amon version
information can be found at
www.colinbroad.com/cbsoft/tmc1/tmc1.html for tmc-1-xmon
www.colinbroad.com/cbsoft/tmc1/tmc1penta.html for tmc-1-penta
www.colinbroad.com/cbsoft/tmc1/tmc1dmon.html for tmc-1-dmon
www.colinbroad.com/cbsoft/amon/amon.html for tmc-1-amon
Features

TMC-1 Reference Manual
14 September 2018  CB Electronics 2 Version 6.0
C
Co on nn ne ec ct ti io on ns s
The TMC-1 has six connectors on the rear as follows
•HD1 female: XMon connection including RS-422 or MIDI, Headphone, and Talkback
Microphone.
•USB: Used for Power and if connected to a DAW, can be used with MTC or HUI for
auto talkback and Timecode Display.
•¼” Jack: Headphone Cue monitor connection to X-Mon via 1 pin ‘D’.
•1 pin ‘D’ Male: GPIO in/out – Talkback 1 and 2 Enable/Selection, PFL/AFL enable,
H/W Mute output, LTC input, Play Input, Rec/Red light in/out.
•3. mm Jack: Electret Microphone input (Laptop Mic)
•RJ4 : Ethernet: Network connection
I
In ns st ta al ll la at ti io on n
The TMC-1 is designed as a desktop unit but may be mounted flush with the desktop. The
unit should be sited in any convenient position away from sources of moisture or excessive
heat. The TFT display brightness may be adjusted via the Setup menu to optimise viewing
under different lighting conditions.

TMC-1 Reference Manual
14 September 2018  CB Electronics 3 Version 6.0
TMC-1 and TMC-1-S6 , TMC-1 Rear view with Ethernet and T/B Mic Input
Power
Power the TMC-1 via the USB cable supplied. The TMC-1 may be powered directly from the
USB power supply included or connected directly to the DAW.
Connecting to XMon or A-Mon
The HD1 Female on the rear can be connected to the A-Mon with a DDC VGA cable, a
Conversion box is supplied to connect to the XMon.

TMC-1 Reference Manual
14 September 2018  CB Electronics 4 Version 6.0
XMon to HD-1 Converter
RJ4 Breakout Box
A Breakout box to RJ4 and Jacks is also available for use with both A-Mon and XMon, it
may also be used on the TMC-1-Penta and TMC-1-DMon to access the T/B Mic and
Headphone jack
The TMC-1 will recognize and configure XMon or A-Mon to the last TMC-1 setting on power
up. If the XMON is not discovered, then No XMon/No A-Mon will be displayed in the top
right of the TFT Display. Once good communications are established with the XMon/Amon,
this will then be replaced as selected in the Setup Menu. You can select to see the XMon
software revision; the software revision number of the XMon used to develop the TMC-1 was
“Version 11”.
Connecting to NTP DAD AX/DX32, NTP Penta or Avit MTRX
Connect via a network cable directly or via switch. The TMC-1 will detect any NTP device
on the network independent of subnet address. Selecting the NTP device in the E-Net page
will set the subnet address on the TMC-1. Alternatively set the correct subnet address on the
TMC-1 using a USB cable and the TMC1-win or TMC1-mac program.

TMC-1 Reference Manual
14 September 2018  CB Electronics 5 Version 6.0
Connecting to D-Mon
Connect via a network cable directly or via switch. The TMC-1 will detect any D-Mon
device on the network with the same subnet address. Selecting the D-mon in the E-Net
page. Set the correct subnet address on the TMC-1 using a USB cable and the TMC1-win or
TMC1-mac program.
PFL/AFL from the Mixer/Workstation
Available as a GPI input or via the USB Hui connection
Hard Ware Mute
GPO Output for external speaker switching, enabled on powerup, disabled by the mute
key, enabled using [Ctrl]+[Mute]
Record/Play tallies for Auto Mute/Auto Talkback/Talkback Resume
Available as a GPI input or via the USB Hui connection, Play tally also available from LTC or
Midi TC.

TMC-1 Reference Manual
14 September 2018  CB Electronics 6 Version 6.0
S
Se et tt ti in ng g u up p T TM MC C- -1 1
For the first time or after Major Software Update
Factory Default:
We recommend that you start from the factory default setting. This sets all gains and Trims
at 0dB and selects the Main input and Output. To do this, you need to enter the advanced
menu – see appendix B: Selecting the Advanced menu
Having setup the unit to its default setting, you can then adjust each input trim as required
to achieve the required SPL level and trim the speaker outputs where necessary.
Note: TMC-1 Penta Reconfigure the TMC-1-Penta from the TMC1-Penta2 program after a
factory reset
T/B Gain 1 & 2
Depress T/B 1 to adjust Talkback Microphone 1 gain [ ]
Depress T/B 2 to adjust Talkback Microphone 2 gain [8]
Listen Gain 1 & 2
Depress Listen 1 to adjust Listen Microphone 1 gain
Depress Listen 2 to adjust Listen Microphone 2 gain
AFL Gain
Press the [Select] and [Page] keys to display the [Select Page] screen. Press Levels [ ] and
scroll down to AFL I/P. The gain may now be changed via the Encoder.

TMC-1 Reference Manual
14 September 2018  CB Electronics 7 Version 6.0
Protected/Calibrated Settings
The gain structure of the TMC-1 monitor control is determined by a number of protected
calibration menu's and settings. The only absolute setting is Gain, SPL and Dolby level are
also determined by the speakers and their amplifiers.
To remove the protection and enable calibration
1) Depress [select] and [Page] to access the “Select Page”
2) Select [Setup]
3) Calibration enable is in the Advanced Setup, to access depress [Select] and [->]
keys to access Adv Menu 01.
4) Depress the [->] key to access Adv Menu 02:- Calibration Lock
) Use the [^] and [v] keys to select Unlock All
6) Use the [Page] to exit setup, the TFT display will now show “Calibration” in the top
Right.

TMC-1 Reference Manual
14 September 2018  CB Electronics 8 Version 6.0
Input and output trims
The TMC-1 has programmable input and output gain trims, these may be set in Calibration
Mode which is enabled in the advanced menu. The Input and output gain trims can be
viewed on the "Levels" pages, to access depress [select] and [Page] to access the “Select
Page” the depress the [Levels] key. Use the [->] key to step through the pages.
Input Trim:
Each input has a -10db to +20dB input trim in 1dB steps, the Input trim is before the meters
and is used to match levels between different inputs. For example the Dolby RMU default
output level is -10dB. Normally we set the Input trim for the RMU at +10dB
1. Enable Calibration as above
2. Select the Meters page
3. Enable the input Selection [I/P Sel], this is a user defined key
4. Disable [Sum]
. Depress and hold the selected input, a Red Box in the lower right will display the
Input Trim
6. Adjust as required whilst holding selected input key depressed
7. Repeat as required for all inputs
8. Disable Calibration
Speaker Trim:
Each speaker output has a +/-4dB trim in 0. dB steps. The output trim is after the meters and
used for individual speaker calibration. To maximise signal to noise the range is limited,
where necessary attenuate the speaker amplifier input or use a input pad.
The TMC-1-penta provides two extra global menu settings as follows
•"Adv menu 20 - Digital Headroom" Output attenuation on all outputs
•"Adv Menu 22 - Analogue Output for 0dBFS" on all Analogue outputs
To set the speaker trim, select the Meters page then enable speaker Solo using the [Solo]
key, by default this is the [Ctrl/Spk.Solo] key.
1. Enable Calibration

TMC-1 Reference Manual
14 September 2018  CB Electronics 9 Version 6.0
2. Connect input to Pink Noise at reference level (-20dBFS 0dBm nominal)
3. Enable the “Solo” page using the [Solo] key (Note Solo is a user function), Select the
required output and speaker, on the Penta version you can step through the
speaker banks using the [Solo] key.
4. Solo the individual speaker, hold the speaker key depressed, a Red Box in lower
right will display the speaker trim
. Adjust as required whilst holding speaker key depressed.
6. Repeat as required for all speakers
7. Disable Calibration

TMC-1 Reference Manual
14 September 2018  CB Electronics 10 Version 6.0
Using TMC-1v to adjust Trims
TMC-1v Software for Mac or Windows may also be used adjust the input and output trims,
The password to enable calibration is "1984" (Big Brother is watching). You can save and
recall the calibration using TMC-1v .
The Number of speakers in each speaker Set can be defined and the speaker set selected.
Selecting a speaker will also solo the speaker when Calibrate is illuminated Where
appropriate the Digital headroom and Analog Level for 0dBFS will also be displayed.
The Solo Defeat key will remove any speaker solo.
It is recommended that the settings are saved to a file after Calibration for later recall.

TMC-1 Reference Manual
14 September 2018  CB Electronics 11 Version 6.0
Mono Trim:
When Mono is enabled the output has a +/-4dB trim in 0. dB steps.
1. Enable Calibration
2. Select the Meters page
3. Hold the [Mono] key depressed (Mono is a User key), a Green Box in the lower right
will display the Mono trim
4. Adjust as required whilst holding [Mono] Depressed
. Disable Calibration
7.1, .1 and User Trim:
When 7.1 or .1 are enabled the surround outputs have a 0dB to -12dB trim in 0. dB steps.
1. Enable Calibration
2. Select the Meters or Input/Output page
3. Hold the [7.1] or [ .1] User key depressed, a Green Box in the lower right will
display the 7.1 or .1 trim
4. Adjust as required whilst holding [7.1] or [ .1] Depressed
. Disable Calibration
Atmos, 7.1 and .1 calibrations
The setup procedure is as follows:
1) Setup the individual speaker trims in Atmos(immersive) mode
2) Select 7.1 is selected and adjust the 7.1 global surround trim until the surround level is
correct.
3) Select .1 or .1 DMix and adjust the 7.1 global surround trim until the surround level is
correct.

TMC-1 Reference Manual
14 September 2018  CB Electronics 12 Version 6.0
4) Example: The effect of adding trims for
Format Ls Rs Lb Rb
Atmos +1dB +0. dB -0. dB 0dB
7.1 Trim = -2dB -1dB -1. dB -2. dB -2dB
.1 or .1 DMix
Trim = -3. dB
-2. dB +3dB -4dB -3. dB
Sur-3dB -2dB -2. dB -3. dB -3dB
Note. the 5.1 and 7.1 calibration is very important when multiple speakers are
used for each surround channel.
Cal A/B Trim:
The factory reset value for Cal A is 8 and Cal B is 80. However, these values can be
adjusted when calibration is enabled.
1. Enable Calibration Mode
2. Whilst in the Advanced Setup, find “SPL @ 0dB Gain” Menu and set as close as
possible (2dB Steps)
3. Hold [Cal A] or [Cal B] depressed.
4. Adjust as required
. Disable calibration
Cal P
There is no adjustment for Cal P as it is defined with the preset.

TMC-1 Reference Manual
14 September 2018  CB Electronics 13 Version 6.0
C
Ca al li ib br ra at ti in ng g t th he e S SP PL L L Li is st te en ni in ng g L Le ev ve el l
The TMC-1 has 3 level display formats, SPL, Gain and Dolby, only Gain is absolute, SPL and
Dolby level are relative and calibrated by the user. The object of the calibration is to adjust
the output and speaker amplifier gain so that the monitor gain at the required listening
level is as close to 0dB as possible.
1) Decide on the listening level – for Film Dolby specify a SPL of 8 dBA.
2) Adv. Menu 2 - Enable Calibration mode on the TMC-1 (Unlock All)
3) Adv Menu 3 – Set the SPL Level Required +/-1dB
4) Menu 14 – Set the Display mode to dB
) TMC-1-Penta Only – Adv menu 22 – Set the Line level of 0dBFS
6) Exit menu and enable Speaker Solo, whilst holding the speaker key depressed adjust
the trim to 0dB
7) Select a Pink Noise Source to all channels and set up a SPL meter
8) Adjust the amplifier gain so that when the TMC-1 the gain display is approximately
0dB for the required SPL level. Switch to SPL display mode and use the TMC-1
speaker trim to make fine adjustments.
9) Repeat for each Speaker
Why is there no overall output level adjustment for the speaker sets?
In general amplifiers have too much gain, turning down the output on both analogue
and digital monitor systems would cause a reduction in the dynamic range, as this
attenuates the signal but not the noise. The optimum solution is to turn down the signal
at the input of the power amp, this will attenuate both the signal and any noise from the
monitor system. Where this is not possible use input pads on the input of the power amp
as detailed below.
For a detailed analysis of the XMon setup as an example see this document
http://www.colinbroad.com/cbsoft/tmc1/xmon/Optimise_xmon.pdf
