IB-TR3000P Thermostat Instructions
See overleaf for further setting up information
ver 1.2
This thermostat is a combination model allowing you to
choose between 3 different models. A, AF and F model.
A model: air only, with built in sensor
AF model: air & floo r , with both built in and remote sensor
F model: floor only, with remote sensor
General Settings
Press buttton to Turn on/off the thermostat. When thermostat is turned off, the LCD will only display current room temperature. When the thermostat is
turned off, press and hold button M for 3 seconds to bring up a configuration menu. In this mode, press button M to select different features’ setting.
(Part I)
Menu #
1 Model (model selection)
Sd (switching differential)
ATC (air temp calibrate)
FTC (floor temp calibrate)
TR--AF (AF model only)
(TR= Temp readout )
MAXFT (set maximum floor
temp in AF model)
BL (backlight turning-on time
setting)
TF (temperature format)
CLOCK
24 (default), 12- hour or 24-hour clock system
PTD (program time delay)
2
3
4
5
6
7
8
9
10
11
12
Features description Features Explanation Adjustment
1 = 1 degree(default), 1.5 = 1.5 degrees.........
-1 = decrease 1 degree, 1 = increase 1 degree...
5s , 10s , 15s ,20s (default) , 25s, 30s.
A= to show air temperature, F=to show floor temperature,
A--F = to show both in 5 second intervals
40 degree(default)
30 seconds(default) On= always on, OFF= always off
C or F
Remarks: Not all menus are visible in certain models. For example, if you set the thermostat to A or F model, menu 6 and menu 7 will not be visable.
A, AF, F
(press up or down button to adjust)
-1 = decrease 1 degree, 1 = increase 1 degree...
This product should be installed by a qualified electrician.
If the floor sensor is short-circuit or broken, the LCD will display “Err” and the thermostat will cut off output.
Please Note: one of the following error messages will appear if one of these problems occur:
The numbers of degree difference before switching.
The default is 1°C which means the thermostat will
switch the
heating on 0.5°C below the set temperature
and will turn it off 0.5°C above the set temperature.
With a 2°C differential,
the heating will switch on 1°C
below the set temperature and will switch off 1°C
above the set temperature.
This is to calibrate air temperature if required.
This is to calibrate floor temperature if required.
This gives more time for user to set the programmes
before reverting back to standard display
This gives option to choose to show air temperature,
floor temperature or to show both floo& air in interval.
This is to protect the floor surface.
This is to set the backlight turning-on time. User
can also set the backlight always on or off.
This alows users to select between °C or °F.
12/24 HOUR clock system selection
Buttons and LCD display
Button / Icon Description
Turning on/off thermostat
Menu button / Program button
Increase the set value
Decrease the set value
Set the time and week days
M
The buttons are locked.
Heating is turned on
Button / Icon Description
Auto mode
Vacation mode
Manual override
Frost protection activated
Set temperature
Programmes number
Room temperature
RT
AUTO
SET
Floor temperature
Economy temperature
Comfort temperature
FT
The difference between set
temperature and room temperature,
more bars means more difference
Wed
Auto
override
SC(setpoint configuration) 4 means 4 independent setpoints, 2 means: setpoint 1 is the
same to setpoint 3 , setpoint 2 is the same to setpoint 4
This allows user to select 2 kinds of default setpoints
FP(Frost protection) on= activated, off= deactivated
This is to avoid room temperature goes below 5 °C

IB-TR3000P Thermostat Instructions (Part II)
Manual temperature override
When the up button is pressed the set temperature
is increased and when the down button is pressed
the set temperature is decreased and thermostat
will maintain the new set temperature until the next
set point(comfort level). To cancel the override
setting, just press and hold button 3 for 3 seconds.
Setting the clock and day of the week
This thermostat is fitted with a real time clock. It
is essential that the clock time and day are set
accurately if you require your programmed events
to start on time. Follow below easy steps,
1) Press button 3 once and the time will flash
2) Use the up and down arrow to change the time
3) Press button 3 again, the day of the week will flash
4) Use the up and down arro ws to change the day
5) Press button 3 again to accept
Press and hold button 2 (the M button) for 5 seconds to show program mode and day
selection
set all days the same, press and hold arrow down button for 5 seconds. To select an individual
day press the arrow
up or down in succession until the desired day is shown.
Press button 2 to bring up the first
set point (PROG#1). Use the up and down arrow to set time
for comfort level (default 07:00)
Press Button 2 again to show set
point 2 (economy mode) . Use the up and down arrows to
set economy time (default 9:30)
Press Button 2 again to show set
point 3 (comfort mode).
Use the up and down arrows to
set comfort time (default 16:30)
Press Button 2 again to show set
point 4 (economy mode) . Use the up and down arrows to
set economy time(default 22:30)
Press button 2 to accept
Press button 2 again and use the
up and down arrow to select
temperature (default 22 C)
Press button 2 again and use the
up and down arrows to select
temperature (default 16 C)
Press button 2 again and use the
up and down arrow to select
temperature (default 22 C)
Press button 2 again and use the
up and down arrows to select
temperature (default 16 C)
Programme your 4 daily events
Follow easy steps below,
PROG
12
34
1
2
3
4
5
6
7
8
9
10
Manual
Override
Lock
Lock the buttons
To lock the buttons, press and hold the up and down
unlock the buttons, press and hold the up and down
arrow buttons simultaneously for 3 seconds, to
arrow buttons simultaneously again.
Vacation
Vacation mode
To set vacation mode press and hold up arrow button
for 3 seconds,
use same procedure to exit this mode.
(default 10 deg C) all the time. Press up or down
button to change the set point.
Vacation mode will maintain a set temperature
Factory
Setting
Reset to Factory setting
In standby mode(when thermostat is turned off),
reset the thermostat fully to the configuration it
left the factory. (there will be a RESET appearing
press and hold button 2 and 3 for 3 seconds to
for 5 seconds)
Clock
Dimensions
81mm
86mm
m
m
6
8
Rear View
45mm
13mm
27 mm
2
6 mm
Side View
Floor
Temp
View floor temperature
If thermostat is set in AF model, and set to show
will be displayed and it will automatically revert
revert back to air temperature after 5 seconds.
air temperature only, press and hold down arrow
arrow button for 3 seconds, floor temperature
This product should be installed by
a qualified electrician.
Installation and Wiring
60mm
86mm
86mm
4mm
7mm
Carefully separate the front half of the thermostat from the back plate by placing a small
flat head terminal driver into the slots on the bottom face of the thermostat.
Carefully unplug the ribbon connector which is plugged in to the front half of the thermostat.
Place the thermostat front half somewhere safe. Terminate the thermostat as shown in the
diagrams below.
Screw the thermostat back plate on to the back box
Re-connect the thermostat ribbon cable and clip the two halves together.
LL
LOAD
(16A)
FEED
(220VAC+/-15%)
Floor Sensor
NN
16 Amp
3500 WATTS
