Professional Loudspeakers
Your Global Driver Solutions Partner
Celestion International Ltd, Claydon Business Park, Great Blakenham, Ipswich IP6 ONL, UK
Celestion adopts a progressive policy and reserve the right to alter drive unit specifications and/or appearance without prior notice 08/05
TF1015
General Specifications
Nominal diameter (mm/in)...................................... 254/10
Power rating (AES, W rms) ........................................... 70
Nominal impedance (
Ω
) ................................................. 8
Voice coil diameter (mm/in)..................................... 38/1.5
Magnet type............................................................ Ferrite
Magnet weight (kg/oz)............................................0.48/17
Chassis type ................................................. Pressed steel
Sensitivity (dB) .............................................................. 95
Frequency range (Hz)........................................... 80-6000
Coil material ............................................... Round copper
Former material .................................................. Polyimide
Cone material ..................................... Kevlar loaded paper
Surround material .......................................... Cloth-sealed
Suspension ............................................................. Single
Xmax (mm/in)...................................................... 2.0/0.08
Gap depth (mm/in)............................................... 6.0/0.24
Voice coil winding width (mm/in) ....................... 10.0/0.39
Small Signal Parameters
D (m/in) ............................................................ 0.21/8.27
Fs(Hz) .......................................................................... 89
Mmt (g/oz) ...................................................... 23.15/0.82
Mmd (g/oz) ...................................................... 19.50/0.69
Qms .......................................................................... 3.90
Qes ........................................................................... 1.29
Qts ........................................................................... 0.97
Re(
Ω
) ...................................................................... 5.51
Vas (lt/ft3) .......................................................... 23.4/0.83
Bl (Tm) ..................................................................... 7.40
Cms (mm/N) .............................................................. 0.14
Rms (kg/s) ................................................................. 3.33
Le(mH) ...................................................................... 0.52
Mounting Information
Overall diameter (mm/in) .................................. 256/10.08
Overall depth (mm/in).......................................... 100/3.94
Cut-out diameter (mm/in).................................... 229/9.02
Mounting slot dimensions (mm/in)........... 6 x 8/0.24 x 0.31
Number of mounting slots ............................................... 4
Mounting PCD range (mm/in) .............................. 245/9.65
Unit weight (kg/lb).................................................. 1.7/3.7
Packed Dimensions & Weight
Single pack size W x D x H (mm/in)...........280 x 280 x 120
............................................................ /11.0 x 11.0 x 4.7
Single pack weight (kg/lb) ........................................ 2/4.4
Multi pack (96) size W x D x H (mm/in) ...... 1080 x 880 x 840
.......................................................... /42.5 x 34.6 x 33.1
Multi pack (96) weight (kg/lb) .............................. 200/441
• Excellent bass and mid-range performance
• Cost-effective unit, optimised for use in 2-way systems
• Rigid chasis design for maximum energy transfer
• Vented magnet assembly for enhanced cooling
Frequency Response and Impedance Curves
FREQUENCY (Hz) Measured - 1W @ 1m, 2π
