CEOPA CE-1070P User manual

5ZoneMixingAmplifier
UserManual
CE-1070P/1130P/1260P/1360P

ThreeMICinput,twoAUXinput,oneAUXoutput,suitforPAsystem.
70V,100Vlinevoltageoutputand4Ohm~16Ohmconstantresistance
(balance)output
MIC1haspriorityinputandmutefunction
IndividualvolumecontrolforMICandAUX
Bassandtreblecontrol
FiveLEDlevelmeter,convenienttomonitortheworkingstate
Outputshortcircuitprotectionandalarm
ThisamplifiercanbeasmallPAsystem
5channelportoutput
indicatorsof
Pleasereadthisusermanualcarefullybeforeoperation.
PerformanceFeature
1
UserManual
CH1CH2CH3CH4CH5
AUX2AUX1

CH1 CH2 CH3 CH4CH5
11
CH1CH2CH3CH4CH5
AUX2
Frontpanel
1.Powerindicator2.Powerswitch3.LEDlevelmeter
4.Basscontrol5.Treblecontrol6.MICvolumecontrol
7.AUX1volumecontrol8.9.PriorityMICinput
10.Channelbutton
AUX2volumecontrol
Note:When5LEDindicatorsarelightforlongtime,itmeansoverload
distortion.thenshouldturnthevolumelowtill4or5indicatorglinting.
Rearpanel
1.Mutecontrol2.MIC2&MIC3input3.AUX1&AUX2input
4.AUXoutput5.Commonoutput6.4~16Ohmoutput
7.70Voutput8.100Voutput9.AC220~240Vpowerinput
10.Fuse11.Channeloutputport
2
10 9
AUX1

ConnectionIllustration
MIC1haspriorityinput,andMIC1inputsignalcanrestrainotherinputsignal.
AndtherestraindegreecanbeadjustedbytheMUTEontherearpanel,The
rangefrom0db~35dbabove,itwillbesetontheMAXplacebeforeleaving
factory.
""
1.Besuretoreadthesenotesbeforeusing
2.Besuretocomplythemostimportantsafetynotesofsafetysymboland
messageinthemanualcontent.
3.Ithaselectricityintheoutputport,pleaseoperatethisequipmentunder
theguidanceofprofessionals.
SafetyNotes
3
CH1CH2CH3CH4CH5
AUX2
CH1CH2CH3CH4CH5
1
2
AUX1
AUX2AUX1

1.ThisamplifierisusedinPAsystem,shouldbelayinthegoodventilationplace,
donotlayinthesurroundingofhightemperature.
2.Donotexposetheequipmentundertherainorthesurroundingwithwaterand
otherliquid,soasnottocausefireorelectricshock.
3.Pleaseuseunderspecifiedvoltage(AC200~240V,50/60Hz).Itmaybecause
fireorelectricshockwhenthevoltagevaluehigherthanthespecified.
4.Donotcutofforchangethepowercable,soasnottocausedamage,additional,
donotletthepowercableneartheheater,alsodonotlaytheheavyobjectwhich
includetheequipmentonthecable.soasnottocausefireorelectricshock.
5.Afterfinishingspeakerconnection,pleasebesuretorecovertheprotection
coverintheoutputport.becauseitcanreachto100Voutputvoltageinthe
outputport,sodonottouchthetheseports,soasnottobeelectricshock.And
theseportscannotasthepowerofotherequipments.
6.Donotinstallorlaythisequipmentonthelocationofinstability,suchas
shakingorskewofthetable,lestequipmentfallingandcausinginjurytopersons
ordamagetoequipmentandproperty.
7.Ifthehandiswet,pleasedonotusehanddirectlytoinsertorpulloutthepower
plug,itmaycauseelectricshock.
8.Ifyouwanttopulloutthepowerplug,besuretoholdtheplug,donotholdcable.
whenthepowercabledamaged,usingthisequipmentmaybecausefireor
electricshock.
9.Ifyouwanttomovetheequipment,pleasebesuretopullouttheplugfromthe
socket.
10.Donotblocktheventilationplaceontheequipmentshell,otherwiseitmay
causeinternaloverheatingandfire.
11.Donotinstallthisequipmentintheplacewherehashumidity,moredust,direct
sunlight,heater,soot,vapor,otherwiseitmaycausefireandelectricshock.
InstallationNotes
4

1.Thisequipmenthaspassedthestrictinspection,however,youshouldturn
offthepower,pulloutthepowerplugwhendiscoversomefollowinganomalies
incase,andcontactthedealer.
A.Ifsmelledsmokeandpeculiarsmellwhichsetoutfromtheequipment.
B.Ifwateroranymetalimmergeorfallintotheequipment.
C.Iftheequipmentfellortheshelldamaged.
D.Ifthepowercabledamaged.
E.Iftheequipmentfailed.
F.Iftheequipmentdistortedbadly.
2.Thisequipmentcontainshighvoltagecomponents,pleasedonotarbitrarily
open,soasnottocausefireorelectricshock,ifneedtomaintain,please
contactdealerorprofessionalstohandle
3.Donotlayliquidcontainerormetalontheequipmenttop,iftheyfallintothe
equipment,itmaycausefireorelectricshock
4.Donotfallmetalorflammableobjectintotheventilationslot,soasnotto
causefireorelectricshock.Donottouchthepowerplugwhenthundering
andfulmination,soasnottocauseinjuryofelectricshock.
5.Donotlayheavyobjectontheequipmenttop,soastoavoidfallingor
damage,andevencauseinjurytopersonsordamagetoequipmentand
property,inaddition,heavyobjectfallingitselfmaycauseinjuryordamage
6.Iffoundvoicedistortionsituation,pleasedonotoperatethisequipmentforlong
time,thisisalsoafaultalarmmessage,ifuseunceasingly,itmaycause
overheatingandfire.
7.Tocleanequipment,pleasecontactwiththedealer,ifthedustaccumulatedin
theequipmentforlongtime,itmaycausefireordamage.
8.Laythisequipmentonastablelocation,andmakeaappropriatetreatmentto
preventfalling,otherwiseitmaycausetheequipmentfalling,andcauseinjury
topersonsordamagetoequipmentandproperty.
9.Soastoavoidtheinnertemperaturetorise,theequipmentshouldbe10
centimeterfarfromthebarrier.
OperationNotes
5

CE-1130P
130W
0.3KVA
11KG
12.5KG
F6AL250V
CE-1260P
260W
0.7KVA
12.1KG
13.6KG
F8AL250V
Parameter
Model
RatedPower
PowerConsumption
NetWeight.
GrossWeight
FuseSize
Dimension
Power
MicrophoneInputSensitivity
LineInput
LineOutput
FrequencyResponse
SignalNoiseRatio(SNR)
TotalHarmonicDistortion(THD)
OutputMode
ToneAdjustRange
CE-1070P
70W
0.25KVA
9.8KG
11.3KG
F4AL250V
89mm483mm366mm
AC200~240V,50/60Hz
8-11MV
280MV-320MV
1V10%
60Hz-15KHz3dB
70dB
2%80Hz-12.5KHz
2%UnderRatedCondition80Hz-12.5KHz)
4%(1/100RatedPowerOutput,80Hz-12KHz)
70V/100VOutput;4~16Output
WhenMIC1hassignedinput,
othersignalattenuate:0~-35dB
Bass:dB(100Hz)Treble:10dB(10KHz)
±
（±）
＞
≤（）
≤（，
≤
Ω
±±
6
MuteFunction
CE-1360P
360W
0.7KVA
14.1KG
15.6KG
F8AL250V

CAUTION:Donotopentheequipmentcoverarbitrarily,
soasnottoelectricshock.Pleasecontacttheprofessionals
tomaintainifnecessary.
CEOPAcorporation
www.ceopa.com
