Certes PentaClass A User manual

Certes PentaClass A, AB, Runa
Users manual
hear. understand.

• iPod, iPad are trademarks of Apple Inc. Registered in the U.S. and other countries.
• Wi-Fi®, Wi-Fi Alliance® are registered trademarks of the Wi-Fi Alliance.
• The Bluetooth® trademark is owned by the Bluetooth® SIG.
NOTES
• The contents of this user’s manual shall not be reprinted in part or whole without permission.
• The contents of this user’s manual are subject to change without notice.
Important Safeguards
READ INSTRUCTIONS
All the safety and operating instructions should be read before the appliance is operated.
RETAIN INSTRUCTIONS
The safety and operating instructions should be retained for future reference.
HEED WARNINGS
All warnings on the product and in the operating instructions should be adhered to.
FOLLOW INSTRUCTIONS
All operating and maintenance instructions should be followed.
CLEANING
Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp
cloth for cleaning.
ATTACHMENTS
Do not use attachments that are not recommended by the product manufacturer as they may cause hazards.
WATER AND MOISTURE
Do not use this product near water - for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet
basement, or near a swimming pool and the like. Immersion in water will destroy the PentaClass speaker, microphone
or remote.
GROUNDING OR POLARIZATION
For US only: This product may be equipped with either a polarized 2-wire AC line plug (a plug having one blade wider
than the other) or a 3-wire grounding type plug, a plug having a third (grounding) pin. The 2-wire polarized plug does
not fit in the outlet, try reversing the plug. If the plug still fails to fit, contact your electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the polarized plug. The 3-wire grounding type plug will fit into a grounding
type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to
replace your obsolete outlet. Do not defeat the safety purpose of the grounding type plug.
For UK only: In UK, a BS approved power cord with molded plug has a Black (five Amps) fuse installed for use with this
equipment. If a power cord is not supplied with this equipment please contact your supplier.
POWER-CORD PROTECTION
Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or
against them, paying particular attention to cords at plugs, convenience receptacles and the point where they exit from
the product.
LIGHTNING
For added protection for this product during a lightning storm, or when it is left unattended and unused for a long
time, unplug it from the wall outlet and disconnect the cable system. This will prevent damage to the product due to
lightning and power-line surges.
OVERLOADING
Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or
electric shock.
OBJECT AND LIQUID ENTRY
Never push objects of any kind into this product through openings as they may touch dangerous voltage points or
short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.
SERVICING
Do not attempt to service this product yourself as opening or removing covers may expose dangerous voltage or other
hazards. Refer to qualified service personnel.
DAMAGE
Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following
conditions:
• When the power-supply cord or plug is damaged.
• If liquid has been spilled, or objects have fallen into the product.
• If the product has been exposed to rain or water.
• If the product does not operate normally by following the operating instructions adjust only those controls that are
covered by the operating instructions as an improper adjustment of other controls may result in damage and will often
require extensive work by a qualified technician to restore the product to its normal operation.
• If the product has been dropped or damaged in any way.
• When the product exhibits a distinct change in performance - this indicates a need for service.
REPLACEMENT PARTS
When replacement parts are required, be sure that the service technician uses only spare parts approved by Certes. If
you are uncertain, contact Certes. Unauthorized substitutions may result in fire, electric shock or other hazards and will
void the warranty.
SAFETY CHECK
Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
Certes PentaClass Operating Manual02

• iPod, iPad are trademarks of Apple Inc. Registered in the U.S. and other countries.
• Wi-Fi®, Wi-Fi Alliance® are registered trademarks of the Wi-Fi Alliance.
• The Bluetooth® trademark is owned by the Bluetooth® SIG.
NOTES
• The contents of this user’s manual shall not be reprinted in part or whole without permission.
• The contents of this user’s manual are subject to change without notice.
Important Safeguards
READ INSTRUCTIONS
All the safety and operating instructions should be read before the appliance is operated.
RETAIN INSTRUCTIONS
The safety and operating instructions should be retained for future reference.
HEED WARNINGS
All warnings on the product and in the operating instructions should be adhered to.
FOLLOW INSTRUCTIONS
All operating and maintenance instructions should be followed.
CLEANING
Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp
cloth for cleaning.
ATTACHMENTS
Do not use attachments that are not recommended by the product manufacturer as they may cause hazards.
WATER AND MOISTURE
Do not use this product near water - for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet
basement, or near a swimming pool and the like. Immersion in water will destroy the PentaClass speaker, microphone
or remote.
GROUNDING OR POLARIZATION
For US only: This product may be equipped with either a polarized 2-wire AC line plug (a plug having one blade wider
than the other) or a 3-wire grounding type plug, a plug having a third (grounding) pin. The 2-wire polarized plug does
not fit in the outlet, try reversing the plug. If the plug still fails to fit, contact your electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the polarized plug. The 3-wire grounding type plug will fit into a grounding
type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to
replace your obsolete outlet. Do not defeat the safety purpose of the grounding type plug.
For UK only: In UK, a BS approved power cord with molded plug has a Black (five Amps) fuse installed for use with this
equipment. If a power cord is not supplied with this equipment please contact your supplier.
POWER-CORD PROTECTION
Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or
against them, paying particular attention to cords at plugs, convenience receptacles and the point where they exit from
the product.
LIGHTNING
For added protection for this product during a lightning storm, or when it is left unattended and unused for a long
time, unplug it from the wall outlet and disconnect the cable system. This will prevent damage to the product due to
lightning and power-line surges.
OVERLOADING
Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or
electric shock.
OBJECT AND LIQUID ENTRY
Never push objects of any kind into this product through openings as they may touch dangerous voltage points or
short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.
SERVICING
Do not attempt to service this product yourself as opening or removing covers may expose dangerous voltage or other
hazards. Refer to qualified service personnel.
DAMAGE
Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following
conditions:
• When the power-supply cord or plug is damaged.
• If liquid has been spilled, or objects have fallen into the product.
• If the product has been exposed to rain or water.
• If the product does not operate normally by following the operating instructions adjust only those controls that are
covered by the operating instructions as an improper adjustment of other controls may result in damage and will often
require extensive work by a qualified technician to restore the product to its normal operation.
• If the product has been dropped or damaged in any way.
• When the product exhibits a distinct change in performance - this indicates a need for service.
REPLACEMENT PARTS
When replacement parts are required, be sure that the service technician uses only spare parts approved by Certes. If
you are uncertain, contact Certes. Unauthorized substitutions may result in fire, electric shock or other hazards and will
void the warranty.
SAFETY CHECK
Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
Certes PentaClass Operating Manual 03

Before Operating
• Be sure to use the power cord and the AC adapter included with your PentaClass.
• Be sure to use the power cord applicable to your local power specifications.
• When storing the product, do not leave it under direct sunlight or near heaters. It may become discolored, deformed,
or damaged.
• Do not place this product in any humidity, dusty, salt bearing wind, or vibrating locations. Use it only under the
following environmental conditions: temperature: 0°C - 40°C (32°F - 104°F), humidity: 30% - 85% (No condensation).
• Use a soft, dry cloth for cleaning. Do not use any volatile solvent such as thinner or benzene.
FOLLOW THE GUIDELINES BELOW TO PREVENT THE UNIT FROM DROPPING
• Use the product on a stable base, desk, or table. Do not place the product on an unstable base or slanted surface.
• Please install the product as recommended in this user manual.
• Place or wire the unit to prevent the AC adapter cord from pulling.
• Carry the product by holding the lower part of the main unit in both hands. Never hold the product by the tubes or
the top part.
• In time, the PentaClass performance and quality may deteriorate due to the lifetime of its parts. To purchase
replacement parts, consult the dealer from whom you purchased this product or our branch/office near your location.
REMOTE CONTROL BATTERY PRECAUTIONS
• If this product is not going to be used for a long time, take the batteries out of the remote control.
• Do not use rechargeable batteries (e.g., Ni-Cd (NiCad batteries)).
• Do not try to recharge or short-circuit the batteries.
• When disposing of used batteries, follow the instructions of your local municipality.
• Insert batteries from one side and pay particular attention to the polarity (+/- directions).
• Be sure to use CR2025 type batteries.
• If any liquid from a battery leaks on your skin or clothes, flush the area with clean water immediately. If it gets into your
eyes, flush immediately with clean water and then contact a doctor.
MICROPHONE BATTERY PRECAUTIONS
• Do not charge the microphone when it is placed near a heat source or in direct sunlight or another places where the
temperature exceeds +40°C (104°F).
• Do not store or leave the Microphone near a heat source or in direct sunlight or other places where the temperature
exceeds +40°C (104°F).
• Do not store or leave the Microphone in a cold place under -20°C (-4°F).
• Do not try to recharge the Microphone using an inappropriate charger, please use the USB charger included with this
product.
• Do not place the Microphone in liquids, rain and other moist places.
• In the event of any physical damage to the microphone please do not try to charge it. Contact your dealer or repair
service.
• If any liquid from a microphone battery leaks onto your skin or clothes, flush the area with clean water immediately. If
it gets into your eyes, flush immediately with clean water and then contact a doctor.
PRECAUTIONS REGARDING THE MICROPHONE LANYARD
To prevent unexpected accidents, please note the following:
• This lanyard is for the microphone only and should not be used for any other purposes.
• Do not wrap the lanyard around parts of your body such as your neck, arm, or finger.
• Do not leave it within reach of small children.
• For safety reasons, the break-away section of the lanyard has been designed to separate if too much force is applied.
Therefore, please avoid any overly strenuous movements and do not apply excessive force.
• The lanyard length adjustment feature is designed to be simple. Excessive force or strenuous movements may change
the length.
• Do not use excessive force when adjusting the lanyard. This could damage the lanyard.
• Be careful using the lanyard in environment where rotating or other mechanical equipment is operating.
PRECAUTIONS REGARDING PACKING PARTS
To prevent unexpected accidents, please note the following points:
• Keep all small parts such as plastic bags and installation hardware away out of reach of small children.
• Do not put the plastic bags on the head, keep them out of reach of small children.
• Do not eat or put in mouth, mounting brackets, cardboard parts, plastic bags, screws or any another parts supplied
with the product and keep away them from reach of small children.
OTHER SAFETY PRECAUTION
• Servicing and maintenance must be carried out by authorized service staff only.
• Use only spare parts approved by Certes. If you are uncertain, contact Certes.
• Make sure the device is securely mounted and installed in accordance with instructions before starting it.
• Regularly check the screws and other attachment devices.
• In the event of abnormal noise turn off the PentaClass and consult your supplier.
• Electrical installation must be carried out by an authorized electrician only.
• Take special care to not drop the equipment while mounting it to the ceiling.
• Never force anything into the openings or source inputs of the speaker equipment.
• Do not use this equipment if it shows obvious signs of damage from shipping or dropping.
• Make sure equipment is properly mounted according to the Mounting Instructions found in this guide. This is the only
approved method of installation; any other may cause a loss of your warranty.
NOTATION CONVENTIONS
Warning! Indicates a potentially hazardous situation which, if instructions are not followed, could result in
death or serious injury.
Certes PentaClass Operating Manual04

Before Operating
• Be sure to use the power cord and the AC adapter included with your PentaClass.
• Be sure to use the power cord applicable to your local power specifications.
• When storing the product, do not leave it under direct sunlight or near heaters. It may become discolored, deformed,
or damaged.
• Do not place this product in any humidity, dusty, salt bearing wind, or vibrating locations. Use it only under the
following environmental conditions: temperature: 0°C - 40°C (32°F - 104°F), humidity: 30% - 85% (No condensation).
• Use a soft, dry cloth for cleaning. Do not use any volatile solvent such as thinner or benzene.
FOLLOW THE GUIDELINES BELOW TO PREVENT THE UNIT FROM DROPPING
• Use the product on a stable base, desk, or table. Do not place the product on an unstable base or slanted surface.
• Please install the product as recommended in this user manual.
• Place or wire the unit to prevent the AC adapter cord from pulling.
• Carry the product by holding the lower part of the main unit in both hands. Never hold the product by the tubes or
the top part.
• In time, the PentaClass performance and quality may deteriorate due to the lifetime of its parts. To purchase
replacement parts, consult the dealer from whom you purchased this product or our branch/office near your location.
REMOTE CONTROL BATTERY PRECAUTIONS
• If this product is not going to be used for a long time, take the batteries out of the remote control.
• Do not use rechargeable batteries (e.g., Ni-Cd (NiCad batteries)).
• Do not try to recharge or short-circuit the batteries.
• When disposing of used batteries, follow the instructions of your local municipality.
• Insert batteries from one side and pay particular attention to the polarity (+/- directions).
• Be sure to use CR2025 type batteries.
• If any liquid from a battery leaks on your skin or clothes, flush the area with clean water immediately. If it gets into your
eyes, flush immediately with clean water and then contact a doctor.
MICROPHONE BATTERY PRECAUTIONS
• Do not charge the microphone when it is placed near a heat source or in direct sunlight or another places where the
temperature exceeds +40°C (104°F).
• Do not store or leave the Microphone near a heat source or in direct sunlight or other places where the temperature
exceeds +40°C (104°F).
• Do not store or leave the Microphone in a cold place under -20°C (-4°F).
• Do not try to recharge the Microphone using an inappropriate charger, please use the USB charger included with this
product.
• Do not place the Microphone in liquids, rain and other moist places.
• In the event of any physical damage to the microphone please do not try to charge it. Contact your dealer or repair
service.
• If any liquid from a microphone battery leaks onto your skin or clothes, flush the area with clean water immediately. If
it gets into your eyes, flush immediately with clean water and then contact a doctor.
PRECAUTIONS REGARDING THE MICROPHONE LANYARD
To prevent unexpected accidents, please note the following:
• This lanyard is for the microphone only and should not be used for any other purposes.
• Do not wrap the lanyard around parts of your body such as your neck, arm, or finger.
• Do not leave it within reach of small children.
• For safety reasons, the break-away section of the lanyard has been designed to separate if too much force is applied.
Therefore, please avoid any overly strenuous movements and do not apply excessive force.
• The lanyard length adjustment feature is designed to be simple. Excessive force or strenuous movements may change
the length.
• Do not use excessive force when adjusting the lanyard. This could damage the lanyard.
• Be careful using the lanyard in environment where rotating or other mechanical equipment is operating.
PRECAUTIONS REGARDING PACKING PARTS
To prevent unexpected accidents, please note the following points:
• Keep all small parts such as plastic bags and installation hardware away out of reach of small children.
• Do not put the plastic bags on the head, keep them out of reach of small children.
• Do not eat or put in mouth, mounting brackets, cardboard parts, plastic bags, screws or any another parts supplied
with the product and keep away them from reach of small children.
OTHER SAFETY PRECAUTION
• Servicing and maintenance must be carried out by authorized service staff only.
• Use only spare parts approved by Certes. If you are uncertain, contact Certes.
• Make sure the device is securely mounted and installed in accordance with instructions before starting it.
• Regularly check the screws and other attachment devices.
• In the event of abnormal noise turn off the PentaClass and consult your supplier.
• Electrical installation must be carried out by an authorized electrician only.
• Take special care to not drop the equipment while mounting it to the ceiling.
• Never force anything into the openings or source inputs of the speaker equipment.
• Do not use this equipment if it shows obvious signs of damage from shipping or dropping.
• Make sure equipment is properly mounted according to the Mounting Instructions found in this guide. This is the only
approved method of installation; any other may cause a loss of your warranty.
NOTATION CONVENTIONS
Warning! Indicates a potentially hazardous situation which, if instructions are not followed, could result in
death or serious injury.
Certes PentaClass Operating Manual 05

Contents
IMPORTANT SAFEGUARDS
Before Operating
INTRODUCTION
What’s in the Box?
Introducing Certes PentaClass
Features for all Certes PentaClass models
NAMES OF CERTES PENTACLASS PARTS
Operation of the Main Unit
Rear Panel and Cable Connection
Names of Remote Control Parts
Preparation of Remote Control
Replacement Battery Installation
Remote Control Operating Range
The Runa Microphone
Your Runa Microphone Components and Button Commands
Preparing your Runa Microphone
Charging Your Runa Microphone Battery
The Runa Microphone IR Remote Control Operating Range
CERTES PENTACLASS MODELS
PentaClass A
PentaClass AB
PentaClass Runa
PentaClass Microphone
OPERATIONAL DESCRIPTION
Turning on the PentaClass
Connectivity
Connecting to Device Using AUX Input
Connecting to Device Using Bluetooth
Connecting Microphone to the PentaClass
Power Saving Mode
02
04
08
08
09
09
10
10
11
11
12
12
12
13
13
13
13
14
15
15
16
17
18
20
20
20
20
20
21
22
CHANNEL MIXER AND STATUS INDICATION
System Status Indication
Channel Mixer
Mixer Status Indication
VOLUME ADJUSTMENT
Feedback Cancellation
AUDIO PRESETS
SYSTEM RESET
Bluetooth Reset
System Setting Reset
INSTALLATION
Determining Speaker Location
Installation Materials / Tools Required
Safety Rules for Installation
Mounting on the Ceiling
Mounting Procedure for Suspended Ceiling
Mounting Procedure for Wall
DAISY CHAINING
TROUBLESHOOTING
PENTACLASS TECHNICAL SPECIFICATION
Input Source Specifications
PentaClass Speaker Specification
PentaClass Microphone Specification
REGULATORY
NOTES
22
22
22
22
23
23
24
24
24
24
25
25
26
26
26
27
28
29
30
30
30
30
31
32
34
Certes PentaClass Operating Manual06

Contents
IMPORTANT SAFEGUARDS
Before Operating
INTRODUCTION
What’s in the Box?
Introducing Certes PentaClass
Features for all Certes PentaClass models
NAMES OF CERTES PENTACLASS PARTS
Operation of the Main Unit
Rear Panel and Cable Connection
Names of Remote Control Parts
Preparation of Remote Control
Replacement Battery Installation
Remote Control Operating Range
The Runa Microphone
Your Runa Microphone Components and Button Commands
Preparing your Runa Microphone
Charging Your Runa Microphone Battery
The Runa Microphone IR Remote Control Operating Range
CERTES PENTACLASS MODELS
PentaClass A
PentaClass AB
PentaClass Runa
PentaClass Microphone
OPERATIONAL DESCRIPTION
Turning on the PentaClass
Connectivity
Connecting to Device Using AUX Input
Connecting to Device Using Bluetooth
Connecting Microphone to the PentaClass
Power Saving Mode
02
04
08
08
09
09
10
10
11
11
12
12
12
13
13
13
13
14
15
15
16
17
18
20
20
20
20
20
21
22
CHANNEL MIXER AND STATUS INDICATION
System Status Indication
Channel Mixer
Mixer Status Indication
VOLUME ADJUSTMENT
Feedback Cancellation
AUDIO PRESETS
SYSTEM RESET
Bluetooth Reset
System Setting Reset
INSTALLATION
Determining Speaker Location
Installation Materials / Tools Required
Safety Rules for Installation
Mounting on the Ceiling
Mounting Procedure for Suspended Ceiling
Mounting Procedure for Wall
DAISY CHAINING
TROUBLESHOOTING
PENTACLASS TECHNICAL SPECIFICATION
Input Source Specifications
PentaClass Speaker Specification
PentaClass Microphone Specification
REGULATORY
NOTES
22
22
22
22
23
23
24
24
24
24
25
25
26
26
26
27
28
29
30
30
30
30
31
32
34
Certes PentaClass Operating Manual 07

Introduction
What’s in the Box?
Make sure your box contains everything listed. If any pieces are missing, contact your dealer.
Introducing Certes PentaClass
Thank you for purchasing the best classroom and conference room audio system available. The Certes PentaClass
enables you to transmit pristine voice clarity from the microphone while giving you the opportunity to project full
room multimedia HD audio sound using one device.
Features for all PentaClass models
ALL-IN-ONE DEVICE
Certes PentaClass combines your speaker, amplifier and mixer all in one.
360˚ OMNIDIRECTIONAL SOUNDFIELD
Enjoy truly rich sounds whenever your audience members are seated in the room.
ONE ROOM - ONE SPEAKER
Thanks to its special design, just one Certes PentaClass speaker is able to spread sound evenly in a room and is suitable
for room sizes of up to 120 m2(1300 ft2). If you have an auditorium larger than 120 m2(1300 ft2), you can daisy chain up
to 3 PentaClass speakers.
SIMPLE INSTALLATION
In a matter of minutes you can install PentaClass using the supplied mount on a ceiling or wall.
SYSTEM STATUS INDICATION
Depending on the PentaClass status, it will illuminate a specific color light.
POWER-SAVING MODE
Automatic power-saving mode switches on if there is no incoming signal for more than 20 minutes.
AUDIO PRESETS
These allows you to choose the audio mode, switching between voice, multimedia and music presets.
BIG AUDITORIUMS WELCOME
Thanks to our smart audio in/out system, you can daisy chain up to 3 Certes PentaClasses and cover auditoriums up to
360m2(3875 sq. ft.).
HI-FI ACOUSTIC DESIGN
The PentaClass design ensures pure vocal clarity, full high and mid-ranges and a rich bass for music.
ROBUST DESIGN
The natural birch plywood box, aluminum speaker protector and durable plastic parts are used to ensure a long-term
lifespan for your PentaClass. Thanks to its simple and elegant design it will fit into any interior.
BUILT-IN MIXER
The built-in mixer allows you to mix an analog input with Bluetooth or microphone channels without unplugging the
cables or disconnecting the wireless connection.
REMOTE CONTROL
All PentaClass versions come with a remote control for the easy operation of devices.
DYNAMIC RANGE COMPRESSION
Whether you are listening at a low or high volume, the DRC ensures the quality of non-distorted sound.
DAISY CHAIN READY
Thanks to the mixed Aux output, you can connect up to 3 Certes PentaClass's to cover much larger spaces including
auditoriums.
1
2
3
4
5
6
7
Certes PentaClass speaker
Power supply 19 V 2A
Power cord
Remote control with battery
Fixation bracket with screws
Safety wire
Plate for false ceiling
8
9
10
11
12
13
Flange
Runa Microphone*
Lanyard*
USB charger 5V1A*
Micro USB cable 1 m*
User’s manual
* included with Certes PentaClass Runa version
4
5
1
6
7
10
8
2
3
9
12
11
13
Certes PentaClass Operating Manual08

Introduction
What’s in the Box?
Make sure your box contains everything listed. If any pieces are missing, contact your dealer.
Introducing Certes PentaClass
Thank you for purchasing the best classroom and conference room audio system available. The Certes PentaClass
enables you to transmit pristine voice clarity from the microphone while giving you the opportunity to project full
room multimedia HD audio sound using one device.
Features for all PentaClass models
ALL-IN-ONE DEVICE
Certes PentaClass combines your speaker, amplifier and mixer all in one.
360˚ OMNIDIRECTIONAL SOUNDFIELD
Enjoy truly rich sounds whenever your audience members are seated in the room.
ONE ROOM - ONE SPEAKER
Thanks to its special design, just one Certes PentaClass speaker is able to spread sound evenly in a room and is suitable
for room sizes of up to 120 m2(1300 ft2). If you have an auditorium larger than 120 m2(1300 ft2), you can daisy chain up
to 3 PentaClass speakers.
SIMPLE INSTALLATION
In a matter of minutes you can install PentaClass using the supplied mount on a ceiling or wall.
SYSTEM STATUS INDICATION
Depending on the PentaClass status, it will illuminate a specific color light.
POWER-SAVING MODE
Automatic power-saving mode switches on if there is no incoming signal for more than 20 minutes.
AUDIO PRESETS
These allows you to choose the audio mode, switching between voice, multimedia and music presets.
BIG AUDITORIUMS WELCOME
Thanks to our smart audio in/out system, you can daisy chain up to 3 Certes PentaClasses and cover auditoriums up to
360m2(3875 sq. ft.).
HI-FI ACOUSTIC DESIGN
The PentaClass design ensures pure vocal clarity, full high and mid-ranges and a rich bass for music.
ROBUST DESIGN
The natural birch plywood box, aluminum speaker protector and durable plastic parts are used to ensure a long-term
lifespan for your PentaClass. Thanks to its simple and elegant design it will fit into any interior.
BUILT-IN MIXER
The built-in mixer allows you to mix an analog input with Bluetooth or microphone channels without unplugging the
cables or disconnecting the wireless connection.
REMOTE CONTROL
All PentaClass versions come with a remote control for the easy operation of devices.
DYNAMIC RANGE COMPRESSION
Whether you are listening at a low or high volume, the DRC ensures the quality of non-distorted sound.
DAISY CHAIN READY
Thanks to the mixed Aux output, you can connect up to 3 Certes PentaClass's to cover much larger spaces including
auditoriums.
1
2
3
4
5
6
7
Certes PentaClass speaker
Power supply 19 V 2A
Power cord
Remote control with battery
Fixation bracket with screws
Safety wire
Plate for false ceiling
8
9
10
11
12
13
Flange
Runa Microphone*
Lanyard*
USB charger 5V1A*
Micro USB cable 1 m*
User’s manual
* included with Certes PentaClass Runa version
4
5
1
6
7
10
8
2
3
9
12
11
13
Certes PentaClass Operating Manual 09

Names of Certes PentaClass parts
Operation of the main unit
Make sure your box contains everything listed. If any pieces are missing contact your dealer.
Rear Panel and Cable Connection
Aux in - Audio in (3.5mm mini Jack). An audio cable is not supplied with this product.
Aux out - Audio out (3.5mm mini Jack). An audio cable is not supplied with this product.
DC - Input for the AC adapter.
Connecting the AC adapter. Before inserting the AC adapter in an outlet, connect the DC plug of the supplied AC
adapter to the terminal on the rear panel.
Connecting the unit to another PentaClass (daisy chain), Induction loop devices or another audio preamplified devices
with an audio line input terminal on the connector panel.
To connect the unit to a device with an audio line output such as:
• Mobile phone • Microphone
• Tablet • DVD / VHS
• Projector • Computer
Names of Remote Control Components
Infrared Transmitter
Power ON/OFF Button
Mute Button
Volume down Button
Volume up Button
AUX channel ON/OFF Button
Bluetooth channel activation Button
Audio Preset
System status indication window and IR sensor location
Main Board housing
Sound reflector cone
Speaker grill with protective frame
Birch plywood soundbox
Phase inverter
Connector panel
1
2
2
3
3
1
1
2
2
3
3
4
4
5
5
6
6
7
7
1
2
3
4
5
6
7
8
1
1
2 3
45
6
7
Certes PentaClass Operating Manual10

Names of Certes PentaClass parts
Operation of the main unit
Make sure your box contains everything listed. If any pieces are missing contact your dealer.
Rear Panel and Cable Connection
Aux in - Audio in (3.5mm mini Jack). An audio cable is not supplied with this product.
Aux out - Audio out (3.5mm mini Jack). An audio cable is not supplied with this product.
DC - Input for the AC adapter.
Connecting the AC adapter. Before inserting the AC adapter in an outlet, connect the DC plug of the supplied AC
adapter to the terminal on the rear panel.
Connecting the unit to another PentaClass (daisy chain), Induction loop devices or another audio preamplified devices
with an audio line input terminal on the connector panel.
To connect the unit to a device with an audio line output such as:
• Mobile phone • Microphone
• Tablet • DVD / VHS
• Projector • Computer
Names of Remote Control Components
Infrared Transmitter
Power ON/OFF Button
Mute Button
Volume down Button
Volume up Button
AUX channel ON/OFF Button
Bluetooth channel activation Button
Audio Preset
System status indication window and IR sensor location
Main Board housing
Sound reflector cone
Speaker grill with protective frame
Birch plywood soundbox
Phase inverter
Connector panel
1
2
2
3
3
1
1
2
2
3
3
4
4
5
5
6
6
7
7
1
2
3
4
5
6
7
8
1
1
2 3
45
6
7
Certes PentaClass Operating Manual 11

Preparation of remote control
Remove plastic insulating sheet located at the bottom of remote control.
Replacement Battery Installation
Remove the battery compartment cover by sliding the cover. Pull out the cover.
Insert the battery with the polarity “+” facing up.
Replace the cover.
CAUTION
• Use only a 3V lithium battery (CR2025).
• Ensure that you have the batteries’polarity (+/−) aligned correctly.
• If the remote control gets wet, wipe it dry immediately.
• Avoid excessive heat and humidity.
• Do not short, heat, or disassemble batteries.
• Do not throw batteries into a fire.
• If you will not be using the remote control for a long time, remove the batteries.
• Dispose of used batteries according to your local regulations.
• Children may ingest small batteries; always keep batteries safe and out of reach of children and pets. WARNING: If a
battery is swallowed, consult a doctor immediately as this could result in asphyxiation or be an obstacle to digestion,
etc.
Remote control operating range
The remote control uses infrared transmission to control the PentaClass. It is necessary to point the remote directly at
the PentaClass. The remote will function well within a radius of about 7 meters (23 feet) and within a 140 degree angle
from the PentaClass IR sensor location level. If the PentaClass does not respond to the remote control, move it a little
closer.
The Runa Microphone
Your Runa Microphone components and button commands
Infrared Transmitter
Power ON/OFF
Hold Power ON/OFF button for a 3 seconds -
Pairs microphone with already paired PentaClasss speaker
Hold Power ON/OFF button for a 10 seconds -
Pairs microphone with a new, (non paired), PentaClasss speaker
Arrow Button 1
Arrow Button 2
LED Indication light
Micro USB charging slot
2.5mm output for the optional external over-the-ear microphone
Hold Volume up button together with Power ON/OFF button for 3 seconds - Bluetooth channel activates.
Hold Volume down button together with Power ON/OFF button for 3 seconds - AUX channel ON/OFF activates.
Preparing Your Runa Microphone
Take the microphone from the packaging and charge it before using it for the first time - the charging procedure is
described in the next paragraph.
Charging your Runa Microphone Battery
CHARGING PROCEDURE FOR MICROPHONE UNIT
Before using it for the first time, the microphone should be charged accordingly:
• Connect one end of the USB cable to the Micro USB charging slot and connect the other end of the USB cable to the
USB charger or your computer.
• If the USB charger is used, connect it to a 100-240V power supply outlet.
A fully charged microphone will last up to 7 hours of use. If microphones are used daily, they should be charged
frequently.
It will take up to 3-4 hours for the microphone to obtain a full charge.
MICROPHONE STATUS INDICATION WHILE IT’S CHARGING
• Steady orange - microphone is charging
• Steady green - microphone is fully charged
MICROPHONE STATUS INDICATION WHILE IT’S PAIRED TO THE PENTACLASS
• Blinking green - microphone is paired to the PentaClass
• Blinking red - microphone is paired to the PentaClass, but the battery is running out and it will last up to 30 minutes
• No status indication - microphone is disconnected from the PentaClass, (is not paired), or the Battery has fully
discharged
1
2
1
2
3
1 2 3
3
4
5
6
7
1
2
3
4
5
6
7
Certes PentaClass Operating Manual12

Preparation of remote control
Remove plastic insulating sheet located at the bottom of remote control.
Replacement Battery Installation
Remove the battery compartment cover by sliding the cover. Pull out the cover.
Insert the battery with the polarity “+” facing up.
Replace the cover.
CAUTION
• Use only a 3V lithium battery (CR2025).
• Ensure that you have the batteries’polarity (+/−) aligned correctly.
• If the remote control gets wet, wipe it dry immediately.
• Avoid excessive heat and humidity.
• Do not short, heat, or disassemble batteries.
• Do not throw batteries into a fire.
• If you will not be using the remote control for a long time, remove the batteries.
• Dispose of used batteries according to your local regulations.
• Children may ingest small batteries; always keep batteries safe and out of reach of children and pets. WARNING: If a
battery is swallowed, consult a doctor immediately as this could result in asphyxiation or be an obstacle to digestion,
etc.
Remote control operating range
The remote control uses infrared transmission to control the PentaClass. It is necessary to point the remote directly at
the PentaClass. The remote will function well within a radius of about 7 meters (23 feet) and within a 140 degree angle
from the PentaClass IR sensor location level. If the PentaClass does not respond to the remote control, move it a little
closer.
The Runa Microphone
Your Runa Microphone components and button commands
Infrared Transmitter
Power ON/OFF
Hold Power ON/OFF button for a 3 seconds -
Pairs microphone with already paired PentaClasss speaker
Hold Power ON/OFF button for a 10 seconds -
Pairs microphone with a new, (non paired), PentaClasss speaker
Arrow Button 1
Arrow Button 2
LED Indication light
Micro USB charging slot
2.5mm output for the optional external over-the-ear microphone
Hold Volume up button together with Power ON/OFF button for 3 seconds - Bluetooth channel activates.
Hold Volume down button together with Power ON/OFF button for 3 seconds - AUX channel ON/OFF activates.
Preparing Your Runa Microphone
Take the microphone from the packaging and charge it before using it for the first time - the charging procedure is
described in the next paragraph.
Charging your Runa Microphone Battery
CHARGING PROCEDURE FOR MICROPHONE UNIT
Before using it for the first time, the microphone should be charged accordingly:
• Connect one end of the USB cable to the Micro USB charging slot and connect the other end of the USB cable to the
USB charger or your computer.
• If the USB charger is used, connect it to a 100-240V power supply outlet.
A fully charged microphone will last up to 7 hours of use. If microphones are used daily, they should be charged
frequently.
It will take up to 3-4 hours for the microphone to obtain a full charge.
MICROPHONE STATUS INDICATION WHILE IT’S CHARGING
• Steady orange - microphone is charging
• Steady green - microphone is fully charged
MICROPHONE STATUS INDICATION WHILE IT’S PAIRED TO THE PENTACLASS
• Blinking green - microphone is paired to the PentaClass
• Blinking red - microphone is paired to the PentaClass, but the battery is running out and it will last up to 30 minutes
• No status indication - microphone is disconnected from the PentaClass, (is not paired), or the Battery has fully
discharged
1
2
1
2
3
1 2 3
3
4
5
6
7
1
2
3
4
5
6
7
Certes PentaClass Operating Manual 13

MICROPHONE BATTERY STATUS INDICATION CHECK
It is possible to check the battery level by pushing any button on the microphone:
• If the status indication is green - battery is charged.
• If the status indication is red - battery power is low.
• If there is no status indication - battery is fully discharged.
HOW TO STORE THE RUNA MICROPHONE
The microphone unit has Lithium-polymer battery. Do not store it in extreme temperatures, including, but not limited
to, leaving it in the hot sun. Elevated temperature and allowing the battery to sit at the 100% maximum charge for
extended periods of time will shorten your battery's life.
The Runa Microphone IR Remote Control
Operating Range
Your PentaClass microphone is multifunctional device, it can also be operated as remote control using infrared
transmission to control the PentaClass. It is necessary to point the remote directly at the PentaClass.
The remote will function well within a radius of about 7 meters (23 feet) and within a 140 degree angle from the
PentaClass IR sensor location level. If the PentaClass does not respond to the remote control, move a little closer.
Certes PentaClass Models
PentaClass A
PentaClass A is a specially designed multimedia system for classrooms with an omnidirectional 360º sound field. This
PentaClass A utilizes audio cables for delivering the audio signals to the speaker. It is suitable for classrooms or meeting
rooms where there is no need for voice amplification or wireless Bluetooth connectivity.
PentaClass A also is perfect for a daisy chain as slave speaker.
Because the PentaClass is a modular system you can make the following upgrades:
• Certes PentaClass A upgrade to Certes PentaClass AB (Bluetooth version) by ordering the additional Bluetooth Kit (part
no. 100111 Bluetooth module).
• Certes PentaClass A upgrade to Certes PentaClass AM, (Microphone version with Bluetooth). Simply purchase the
upgrade pack (part no. 106100 Microphone)
• Certes PentaClass A upgrade to Certes PentaClass Runa, (Microphone version with Bluetooth). Simply purchase the
Microphone upgrade pack (part no. 106100 Microphone) and Bluetooth Kit (part no. 100111 Bluetooth module).
NOTE
* Upgrades should only be installed by trained dealer personal or authorized repair service.
Certes PentaClass Operating Manual14

MICROPHONE BATTERY STATUS INDICATION CHECK
It is possible to check the battery level by pushing any button on the microphone:
• If the status indication is green - battery is charged.
• If the status indication is red - battery power is low.
• If there is no status indication - battery is fully discharged.
HOW TO STORE THE RUNA MICROPHONE
The microphone unit has Lithium-polymer battery. Do not store it in extreme temperatures, including, but not limited
to, leaving it in the hot sun. Elevated temperature and allowing the battery to sit at the 100% maximum charge for
extended periods of time will shorten your battery's life.
The Runa Microphone IR Remote Control
Operating Range
Your PentaClass microphone is multifunctional device, it can also be operated as remote control using infrared
transmission to control the PentaClass. It is necessary to point the remote directly at the PentaClass.
The remote will function well within a radius of about 7 meters (23 feet) and within a 140 degree angle from the
PentaClass IR sensor location level. If the PentaClass does not respond to the remote control, move a little closer.
Certes PentaClass Models
PentaClass A
PentaClass A is a specially designed multimedia system for classrooms with an omnidirectional 360º sound field. This
PentaClass A utilizes audio cables for delivering the audio signals to the speaker. It is suitable for classrooms or meeting
rooms where there is no need for voice amplification or wireless Bluetooth connectivity.
PentaClass A also is perfect for a daisy chain as slave speaker.
Because the PentaClass is a modular system you can make the following upgrades:
• Certes PentaClass A upgrade to Certes PentaClass AB (Bluetooth version) by ordering the additional Bluetooth Kit (part
no. 100111 Bluetooth module).
• Certes PentaClass A upgrade to Certes PentaClass AM, (Microphone version with Bluetooth). Simply purchase the
upgrade pack (part no. 106100 Microphone)
• Certes PentaClass A upgrade to Certes PentaClass Runa, (Microphone version with Bluetooth). Simply purchase the
Microphone upgrade pack (part no. 106100 Microphone) and Bluetooth Kit (part no. 100111 Bluetooth module).
NOTE
* Upgrades should only be installed by trained dealer personal or authorized repair service.
Certes PentaClass Operating Manual 15

PentaClass AB
PentaClass AB is a multimedia classroom system with an omnidirectional 360º sound field. It has been designed for
both wired and wireless audio connectivity with a Bluetooth audio-ready device. PentaClass AB is the perfect solution
for contemporary users using Bluetooth-enabled devices. PentaClass AB is recommended for rooms where voice
amplification is unnecessary.
Because the PentaClass is a modular system you can make the following upgrades:
• Certes PentaClass AB upgrade to Certes PentaClassRuna, (Microphone version with Bluetooth). Simply purchase the
Microphone upgrade pack (part no. 106100 Microphone).
NOTE
Upgrades should only be installed by trained dealer personal or authorized repair service.
PentaClass Runa
The PentaClass Runa is a fully equipped, 360° omnidirectional; classroom, conference or meeting room audio system
with built-in Bluetooth and teacher's / presenters HD wireless microphone we call The Runa.
The wireless 2.4 GHz Runa microphone, (which is designed for comfortable all day use), the Bluetooth connectivity and
all the many other features allow you to experience all the benefits offered by PentaClass.
Certes PentaClass AB upgrade to Certes PentaClass Runa, (Microphone version with Bluetooth). Simply purchase the
Microphone upgrade pack (part no. 106100 Microphone).
Certes PentaClass Operating Manual16

PentaClass AB
PentaClass AB is a multimedia classroom system with an omnidirectional 360º sound field. It has been designed for
both wired and wireless audio connectivity with a Bluetooth audio-ready device. PentaClass AB is the perfect solution
for contemporary users using Bluetooth-enabled devices. PentaClass AB is recommended for rooms where voice
amplification is unnecessary.
Because the PentaClass is a modular system you can make the following upgrades:
• Certes PentaClass AB upgrade to Certes PentaClassRuna, (Microphone version with Bluetooth). Simply purchase the
Microphone upgrade pack (part no. 106100 Microphone).
NOTE
Upgrades should only be installed by trained dealer personal or authorized repair service.
PentaClass Runa
The PentaClass Runa is a fully equipped, 360° omnidirectional; classroom, conference or meeting room audio system
with built-in Bluetooth and teacher's / presenters HD wireless microphone we call The Runa.
The wireless 2.4 GHz Runa microphone, (which is designed for comfortable all day use), the Bluetooth connectivity and
all the many other features allow you to experience all the benefits offered by PentaClass.
Certes PentaClass AB upgrade to Certes PentaClass Runa, (Microphone version with Bluetooth). Simply purchase the
Microphone upgrade pack (part no. 106100 Microphone).
Certes PentaClass Operating Manual 17

Runa microphone
Certes PentaClass Runa comes with a thumb-sized microphone/remote control. The smallest speaker’s microphone on
the market. 60x25x13mm (2.36”x0.79”x0.39”). The microphone weighs just 27 grams (0.95 ounces). Certes PentaClass
Runa comes with a thumb-sized microphone/remote control. The smallest speaker’s microphone on the market.
60x25x13mm (2.36”x0.79”x0.39”). The microphone weighs just 27 grams (0.95 ounces).
MICROPHONE FEATURES
2-in-1
The microphone has dual functionality - a microphone and a remote control.
FREQUENCY HOPPING
This ensures that only the cleanest frequency bands are automatically selected for the connection between the
microphone and PentaClass.
UN-COMPRESSED VOICE
The PentaClass microphone uses a state-of-the-art transmitter and receiver that operate in the 2.4 GHz worldwide
license-free band. Thanks to this digital transmission, you get pristine, high-definition voice reproduction.
TWO WEARING OPTIONS
Thanks to its small form factor, the microphone can be worn with a lanyard or clip. Just choose the option that suits you
best.
MICROPHONE LANYARD
The Certes Runa microphone lanyard is designed for frequent and comfortable use. Its length is adjustable and has a
safety break-away clip.
Please see the pictures describing how to attach
the lanyard to the microphone:
Adjust the length by using plastic cord lock.
Hang your Runa microphone on the lanyard using the clip.
Adjust the length so the microphone would be about 10cm away from mouth.
The safety break-away clip also can be used as a clip for easily taking the lanyard off your neck.
For better microphone performance adjust the microphone lanyard length as short as possible so the microphone is
closer to your mouth.
THE RUNA MICROPHONE FUNCTIONS
Your Runa microphone has been designed to be a HD wireless microphone, transceiver and remote control all in one
small, beautiful unit.
REMOTE CONTROL FUNCTIONALITY
When your Runa microphone is not paired with the PentaClass speaker, it can function as a remote control for the
PentaClass speaker. To send commands to the PentaClass speaker do the following:
Point the bottom of your Runa microphone towards your PentaClass Speaker.
Push the appropriate buttons on the Runa to send the commands to the PentaClass speaker as described in
paragraph 13.
NOTE: Because you are pointing the bottom of the Runa towards the PentaClass speaker in remote control mode, arrow
Button 1 serves as Volume down and arrow Button 2 serves as Volume up
MICROPHONE MODE FUNCTIONALITY
When your Runa is functioning as a microphone it will not function as a remote control for the PentaClass speaker. The
two arrow buttons on the Runa can raise and lower the volume of the Runa Microphone itself. You will not need to
point it towards the PentaClass speaker.
NOTE
In Microphone mode arrow Button 1 serves as Volume Up and arrow Button 2 serves as Volume Down. The center
power ON/OFF button disconnects pairing.
NOTE
When your Runa is connected to the PentaClass speaker, the Audio EQ is set to voice preset automatically by default.
1
1
2
2
3
3
1
2
Certes PentaClass Operating Manual18

Runa microphone
Certes PentaClass Runa comes with a thumb-sized microphone/remote control. The smallest speaker’s microphone on
the market. 60x25x13mm (2.36”x0.79”x0.39”). The microphone weighs just 27 grams (0.95 ounces). Certes PentaClass
Runa comes with a thumb-sized microphone/remote control. The smallest speaker’s microphone on the market.
60x25x13mm (2.36”x0.79”x0.39”). The microphone weighs just 27 grams (0.95 ounces).
MICROPHONE FEATURES
2-in-1
The microphone has dual functionality - a microphone and a remote control.
FREQUENCY HOPPING
This ensures that only the cleanest frequency bands are automatically selected for the connection between the
microphone and PentaClass.
UN-COMPRESSED VOICE
The PentaClass microphone uses a state-of-the-art transmitter and receiver that operate in the 2.4 GHz worldwide
license-free band. Thanks to this digital transmission, you get pristine, high-definition voice reproduction.
TWO WEARING OPTIONS
Thanks to its small form factor, the microphone can be worn with a lanyard or clip. Just choose the option that suits you
best.
MICROPHONE LANYARD
The Certes Runa microphone lanyard is designed for frequent and comfortable use. Its length is adjustable and has a
safety break-away clip.
Please see the pictures describing how to attach
the lanyard to the microphone:
Adjust the length by using plastic cord lock.
Hang your Runa microphone on the lanyard using the clip.
Adjust the length so the microphone would be about 10cm away from mouth.
The safety break-away clip also can be used as a clip for easily taking the lanyard off your neck.
For better microphone performance adjust the microphone lanyard length as short as possible so the microphone is
closer to your mouth.
THE RUNA MICROPHONE FUNCTIONS
Your Runa microphone has been designed to be a HD wireless microphone, transceiver and remote control all in one
small, beautiful unit.
REMOTE CONTROL FUNCTIONALITY
When your Runa microphone is not paired with the PentaClass speaker, it can function as a remote control for the
PentaClass speaker. To send commands to the PentaClass speaker do the following:
Point the bottom of your Runa microphone towards your PentaClass Speaker.
Push the appropriate buttons on the Runa to send the commands to the PentaClass speaker as described in
paragraph 13.
NOTE: Because you are pointing the bottom of the Runa towards the PentaClass speaker in remote control mode, arrow
Button 1 serves as Volume down and arrow Button 2 serves as Volume up
MICROPHONE MODE FUNCTIONALITY
When your Runa is functioning as a microphone it will not function as a remote control for the PentaClass speaker. The
two arrow buttons on the Runa can raise and lower the volume of the Runa Microphone itself. You will not need to
point it towards the PentaClass speaker.
NOTE
In Microphone mode arrow Button 1 serves as Volume Up and arrow Button 2 serves as Volume Down. The center
power ON/OFF button disconnects pairing.
NOTE
When your Runa is connected to the PentaClass speaker, the Audio EQ is set to voice preset automatically by default.
1
1
2
2
3
3
1
2
Certes PentaClass Operating Manual 19

Operational Description
Turning on the PentaClass
Plug the power adapter into the power input on the PentaClass.
Plug the power cord into to a 100-240V AC wall outlet.
To start the speaker push the On/Off button on the remote control.
Connectivity
All versions of the PentaClass have different connectivity options, so depending on the PentaClass system you have
purchased, please choose the correct one for your PentaClass.
Connecting to Device Using Aux Input
This type of connectivity is available for all PentaClass versions:
Connect your audio device, (phone, PC or another), using the 3.5mm mini-jack male/male cable, to the AUX input
located on the speaker's connector plate.
Start the speaker.
Play the audio from your device. Please note - it is recommended that you set the sound level to about 60% on your
device to avoid sound distortion. Control the volume by using volume up/down buttons of the PentaClass's remote
control.
Connecting to the PentaClass Using Bluetooth
Only PentaClass AB and PentaClass Runa versions have Bluetooth connectivity. The PentaClass A version has no
Bluetooth connectivity unless you have upgraded your PentaClass A version with the Bluetooth Kit (part no. 100111
Bluetooth module).
COMMON BLUETOOTH SIGNAL SOURCES
• Mobile phone • Computer
• Tablet • Other device incorporating Bluetooth technology.
To activate Bluetooth by the unit's remote control please do the following:
Turn on the speaker.
Press the Bluetooth button to activate the Bluetooth channel.
The PentaClass speaker Status indicator should start blinking in blue. This command will activate the Bluetooth
channel and it will become scanable for Bluetooth devices for 1.5 minutes.
In the list of Bluetooth devices on the Settings page of your device please find the Bluetooth device named
PentaClass-000000.... (the last 6 symbols will differ as they display the mac address of your PentaClass).
Connect your device to the PentaClass Bluetooth channel.
NOTE
• The Bluetooth channel is closed by default for security reasons.
• The Bluetooth channel cannot be opened while the PentaClass is linked to the microphone.
• There is no password for the Bluetooth connection.
• Once your Bluetooth device has established a connection to the PentaClass, it will be stored in the PentaClass'
memory. The PentaClass will remember your device.
• For security reasons the Bluetooth connection must be activated from your Bluetooth device every time you restart
the PentaClass.
• In the event that someone has made an unauthorized connection to the PentaClass, you can erase paired Bluetooth
devices from the PentaClass' memory by following these steps: While PentaClass is turned ON, open Bluetooth channel,
then push the mute button on the remote, - The PentaClass should display a white light.
• When the PentaClass is connected to an audio source via Bluetooth, the Bluetooth connection disconnects when the
microphone sends its pairing command.
Connecting the Runa Microphone to the PentaClass Speaker
MICROPHONE PAIRING
Microphone pairing is designed to be as simple as possible - just press the button on the mic and the system is ready to
use. You can use any Runa microphone with any PentaClass system in your school or facility. Just follow these steps:
If you pair your Runa microphone with the same PentaClass speaker you were paired with previously, (Pairing
Method 1):
As long as your PentaClass speaker is plugged into a wall outlet, regardless of your PentaClass' status, whether it is
turned On or Off, you can pair it with your Runa microphone.
Point the bottom of your Runa microphone towards the PentaClass speaker and HOLD the On/Off button on the
microphone for THREE seconds - The microphone's LED Indication light will illuminate green for 3 seconds and will
then change to an orange light which confirms that the command has been sent to the PentaClass.
Release microphone's On/Off button.
The status indication light on the top of the PentaClass will light Violet and then Orange or Yellow, (depending on
the Aux input status - see Mixer description), followed by 3 short beeps. This indicates that the microphone is paired
successfully.
If you pair a Runa microphone with a new PentaClass speaker, (Pairing Method 2):
As long as your PentaClass speaker is plugged into a wall outlet, regardless of your PentaClass' status, whether it is
turned On or Off, you can pair it with your Runa microphone.
Point the bottom of your Runa microphone towards the PentaClass and HOLD the On/Off button on the
microphone for TEN seconds - The microphone LED will display a green light for 3 seconds and will then change to
orange for 7 seconds, then a short Red light will confirm that the command has been sent to the PentaClass.
Release the microphone's On/Off button.
The status indication light on the PentaClass will display Violet and then Orange or Yellow (depending on Aux input
status - see Mixer description), followed by 3 short sound beeps. This means that the microphone is paired
successfully.
NOTE
• Your PentaClass microphone can only keep the last PentaClass speaker pairing data in its memory, so if you use
multiple PentaClass speakers with one microphone, please use Pairing Method 2 so that you are not pairing with the
last paired PentaClass speaker.
• When the PentaClass is connected to the audio source via Bluetooth, the Bluetooth connection will stop when the
microphone sends a pairing command.
• You can use multiple PentaClass microphones per building since there is no interference between two rooms /
auditoriums next to each other and every microphone pairs point-to-point to the correct PentaClass speaker.
• The Runa microphone's range is 15m, (45'), and has a frequency hopping feature, but in Wi-Fi busy environments the
range can be decreased. Please check carefully to be certain that the local Wi-Fi network doesn’t interfere with a paired
PentaClass system before installation.
• If the link is lost between the microphone and PentaClass speaker the radio module will try to re-establish the
connection within 15 seconds.
1
2
3
1
2
3
1
2
3
A
B
C
D
A
B
C
D
4
5
Certes PentaClass Operating Manual20
