Challenge Xtreme CX-TS 800 User manual

CX-TS 800
Table Saw
Artikel-Nr.: 4340765
Ident-Nr.: 01011

Komponenten / Ersatzteile
Position Artikel-Nr. Beschreibung
9 434076002009 plastic block
13 434076002013 switch
23 434076002023 round screw M8x15
29 434076002029 inner flange
31 434076002031 outer flange
32 434076002032 nut M12
33 434076002033 cover plate
34 434076002034 screw M4x6
38 434076002038 riving knife
39 434076002039 upper guard
40 434076002040 dust pipe
41 434076002041 screw M3x6
42 434076002042 table insert
43 434076002043 mitre gauge
44 434076002044 rip fence
45 434076002045 plastic screw M6x12
46 434076002046 flat washer 6
47 434076002047 lock piece für Parallelanschlag
48 434076002048 push stick
49 434076002049 staff guage
0 434076002050 wrench for saw blade nut für Sägeblattmutter
0 434076002051 strain relief
0 434076002052 screw
0 434076002053 rubber foot round
0 434076002054 screw M5 x 12 M5 x 12
0 434076002055 nut M5 M5
0 434076002056 screw M4 x 12 M4 x 12
0 434076002057 screw M4 x 8 M4 x 8
0 434076002058 washer 4,3 x 10 x 1
0 434076002059 spring washer

Original Operating Instructions
Table Saw
WARNING! PLEASE READ THESE INSTRUCTIONS
BEFORE OPERATING THIS UNIT
KEEP THIS MANUAL FOR FUTURE REFERENCE
Helpline No 0844 801 8701 / IRE 189 094 6244
Art.-Nr.: 43.407.65 I.-Nr.: 11011 CX-TS 800

Contents Page
1. Safety information 3
2. Layout and items supplied 8
3. Proper use 9
4. Important Notes 10
5. Technical data 10
6. Before starting the equipment 10
7. Assembly 11
8. Using the Saw 15
9. Sawing Operations 16
10. Cleaning, maintenance and ordering of spare parts 17
11. Disposal and recycling 17
12. Storage 17
13. Declaration of Conformity 19
14. Guarantee 20
Helpline No 0844 801 8701 / IRE 189 094 6244
2

Important!
When using equipment, a few safety precautions
must be observed to avoid injuries and damage.
Please read the complete operating manual with due
care. Keep this manual in a safe place, so that the
information is available at all times. If you give the
equipment to any other person, give them these
operating instructions as well.
We accept no liability for damage or accidents which
arise due to non-observance of these instructions
and the safety information.
Helpline No 0844 801 8701 / IRE 189 094 6244 3
Note the instructions for use!
Caution! Risk of injury! Do not reach into the running saw blade.
Wear a breathing mask!
Wear ear muffs!
Wear safety goggles!
Wear safety gloves

Helpline No 0844 801 8701 / IRE 189 094 6244
4
Safety regulations
Important. The following basic safety actions must be
taken when using electric tools in order to protect the
user from electric shocks and the risk of injury and
fire. Read and follow these instructions before using
the equipment.
1. Keep your work area tidy
- Untidy work areas can result in accidents.
2. Make allowance for ambient conditions
- Do not expose electric tools to rain. Never use
electric tools in damp or wet locations. Provide
good lighting. Do not use electric tools near
flammable liquids or gases.
3. Guard against electric shock
- Avoid bodily contact with earthed parts (e.g.
pipes, radiators, cookers and refrigerators).
4. Keep children away
- Do not allow other persons to touch the tool or
cable, keep them away from your work area.
5. Keep your electric tools in a safe place. -
Unused tools should be stored in a dry, locked
room out of children’s reach.
6. Do not overload your tools
- Tools work better and safer when used within
their quoted capacity range.
7. Use the right tool.
- Do not use tools or attachments too weak for
heavy duty work. Never use tools on jobs for
which they are not intended; for example, do not
use a hand-held circular saw to fell trees or lop off
branches.
8. Wear suitable work clothes
- Do not wear loose clothing or jewelry. They can
be caught in moving parts. Rubber gloves and
nonskid footwear are recommended when working
outdoors. Wear protective hair covering to contain
long hair.
9. Wear safety goggles.
- Use a dust mask when working on dusty jobs.
10. Do not use the cable for purposes other than
that for which it is designed.
- Do not carry the tool by its cable and do not
use the cable to pull the plug out of the socket.
Protect the cable from heat, oil and sharp edges.
11. Secure your workpiece
- Use clamps or a vise to hold the workpiece
securely. This is safer than using your hand and
also enables you to operate the machine with
both hands.
12. Do not overstretch.
- Avoid abnormal working postures. Make sure
you stand squarely and keep your balance at all
times.
13. Take care of your tools
- Keep your tools sharp and clean in order to
work well and safely. Follow the maintenance
regulations and the instructions for changing
tools. Check the power plug and cable on a
regular basis and have them replaced by an
authorized specialist if they are damaged. Check
the extension cable regularly and replace it if
damaged. Keep handles dry and free from oil and
grease.
14. Pull the power plug
- When tools are not in use, before starting any
maintenance work or when changing attachments
such as saw blades, drill bits and all kinds of
mounted tools.
15. Always remove keys and wrenches after use
- Before switching on, make sure that all keys
and wrenches have been removed from the
equipment.
16. Avoid unintentional starting
- Never carry a tool with your finger on the switch
button while the tool is connected to the power
supply. Make sure that the switch is turned off
when connecting the tool to the power supply.
17. Extension cables out of doors
- Use only authorized and accordingly labeled
extension cables out of doors.
18. Be alert at all times
- Keep an eye on your work. Use common sense
when working. Never use the tool when you are
distracted.
19. Check the equipment for damage
- Before using the tool each time, check the
safety devices or any slightly damaged parts to
ensure that they are in good working order. Check
that the moving parts are working correctly, that
they do not jam, and that no parts are damaged.
Make sure that all parts are fitted correctly to
ensure that the equipment remains safe to
use. Unless otherwise stated in the operating
instructions, damaged guards and parts have to
be repaired or replaced by a customer service
workshop. Damaged switches have to be replaced
by a customer service workshop. Never use tools
with a switch that cannot be turned on and off.
20. Important.
- For your own safety you must only use the
accessories and additional units listed in the
operating instructions or recommended or
specified by the manufacturer. The use of
mounted tools or accessories other than those
recommended in the operating instructions or
catalog may place your personal safety at risk.
21. Repairs may only be carried out by a qualified
electrician
- This electric tool complies with the pertinent
safety regulations. Repair work must only be

Helpline No 0844 801 8701 / IRE 189 094 6244 5
carried out by a trained electrician, otherwise the
equipment may cause accidents.
22. Connect up a vacuum extraction system
- If there are provisions for connecting up a
vacuum extraction system, make sure that such a
system is fitted and in use.
Special safety instructions
1. Safety actions
• Bladesthataredeformedorcrackedmust
not be used.
• Ifthetableinsertisworn,replaceit.
• Useonlybladeswhicharerecommendedbythe
manufacturer and comply with EN 847-1. When
changing the blade, make sure that the cutting
width is not smaller and the saw plate not bigger
than the thickness of the splitter.
• Makesurethatthechosenbladeissuitableforthe
material that is to be cut.
• Ifnecessary,wearsuitablepersonalprotection
equipment. This could consist of:
- Ear plugs to prevent the risk of damaging your
hearing;
- A breathing mask to avoid the risk of inhaling
hazardous dust.
- Always wear gloves when handling saw blades
and rough materials. Whenever practicable, saw
blades must be carried in a container.
• Thefollowingcanhaveaninfluenceondust
development:
- Worn, damaged or cracked saw blades
- Recommended capacity of the vacuum extraction
system: 20 m/s
- Proper guidance of the workpiece
• Bladesmadeofhigh-alloyhigh-speedsteel
(HSS) must not be used.
• Keepthepushstickorhandleforapushblockat
the machine at all times, even when you are not
using them.
2. Maintenance and service
• Thefollowingconditionscanhaveaninfluenceon
noise impact on the operator:
- Type of sawblade (e.g. saw blades designed to
reduce noise development)
- Material of the workpiece
- The force with which the workpiece is pushed
against the sawblade
• Faultsonthemachineoritsguards,safetydevices
and blade must be reported to the person in
charge as soon as they are discovered.
3. Safe operation
• Useapushstickorthehandlewithapushblockto
feed the workpiece safely past the saw blade.
• Usethesplitterandsetitcorrectly.
• Usetheupperbladeguardandsetittothecorrect
position.
• Donotcutrebatesorgrooveswithoutfittinga
suitable guard, e.g. a tunnel-type guard, over the
saw table.
• Circularsawsmustnotbeusedforslottingjobs
(cutting grooves which end in the workpiece).
• Useonlybladeswhosepermissiblemaximum
speed is not lower than the maximum spindle
speed of the bench-type circular saw and of the
material to be cut.
• Useonlythetransportdevicestomovethe
machine. Never use the guards for handling or
moving the machine.
• Whileyouaremovingthemachineitisbestto
cover the top part of the blade, e.g. with the guard.
• Securelongworkpiecesagainstfallingoffatthe
end of the cut (e.g. with a roller stand etc.)
4. Additional instructions
• Givethesesafetyregulationstoallpersonswho
work on the machine.
• Donotusethissawtocutfirewood.
• Donotusethissawtocross-cutroundwood
• Caution!Handsandfingersmaybeinjuredonthe
rotating saw blade.
• Themachineisequippedwithasafetyswitchto
prevent it being switched on again accidentally
after a power failure.
• Beforeyouusethemachineforthefirsttime,
check that the voltage marked on the rating plate
is the same as your mains voltage.
• Ifyouneedtouseanextensioncable,makesure
its conductor cross-section is big enough for the
sawʼs power consumption. Minimum crosssection:
1 mm2.
• Ifyouuseacablereel,thecompletecablemustbe
pulled off the reel.
• Checkthepowercable.Neveruseafaultyor
damaged power cable.
• Operatorshavetobeatleast18yearsofage.
Trainees of at least 16 years of age are allowed to
use the machine under supervision.
• Keepyourworkplacecleanofwoodscrapandany
unnecessary objects.
• Personsworkingonthemachineshouldnotbe
distracted.
• Notethedirectionofrotationofthemotorandsaw
blade.
• Afteryouhaveswitchedoffthemotor,never

Helpline No 0844 801 8701 / IRE 189 094 6244
6
slow down the saw blade by applying pressure to its
side.
• Onlyfitbladeswhicharewellsharpenedandhave
no cracks or deformations.
• Neverdismantlethemachineʼssafetydevicesor
render them inoperative.
• Faultysawbladesmustbereplacedimmediately.
• Neverusesawbladeswhichdonotcomplywith
the data specified in this manual.
• Itisimperativetomakesurethatalldeviceswhich
cover the saw blade are in good working order.
• Important: It is prohibited to use this saw to make
plunge cuts.
• Damagedorfaultysafetydeviceshavetobe
replaced immediately.
• Thesplitterisanimportantsafetydevice.Notonly
does it guide the workpiece, it also prevents the
kerf closing behind the blade so that there is no
kickback from the workpiece. Note the thickness
of the splitter. The splitter should never be thinner
than the saw blade body or thicker than the width
of its kerf.
• Theguardhoodhastobeloweredoverthe
workpiece for each cut.
• Besuretouseapushstickwhenslittingnarrow
workpieces (smaller than 120 mm in width).
• Nevercutworkpieceswhicharetoosmalltohold
securely in your hand.
• Itisimperativefortheparallelstoptobeclamped
on the right-hand side of the blade whenever you
cut narrow workpieces to size.
• Alwaysstandtothesideofthesawbladewhen
working with the saw.
• Neverloadthemachinesomuchthatitcutsout.
• Alwayspresstheworkpiecefirmlyagainstthesaw
table.
• Makesurethatoff-cutsdonotcatchonthesaw
bladecrown.Riskofcatapulting!
• Refitallguardsandsafetydevicesimmediately
after you have completed any repairs or
maintenance work.
• Besuretoobservethesafetyinformationand
operating and maintenance instructions issued by
the manufacturer, as well as the dimensions listed
in the Technical Data.
• Itisimperativetoobservetheaccidentprevention
regulations in force in your area as well as all
other generally recognized rules of safety.
• Notetheinformationpublishedbyyour
professional associations.
• Connectupthedustextractionsystemonall
jobs. The operator has to be informed about the
conditions with an influence on dust development,
e.g. the type of material being processed (source
and collection of the dust), the significance of local
separation arrangements, and the correct setting
of hoods, baffle plates and guides.
• Operatethesawonlywithasuitablevacuum
extraction system or a standard industrial vacuum
cleaner.
• Neverremoveloosesplinters,chipsorjammed
pieces of wood when the saw blade is running.
• Torectifyfaultsorremovejammedpiecesof
wood, always switch off the machine first. Pull the
powerplug!
• Ifthesawinggapisworn,replacethetableinsert.
Pullthepowerplug!
• Thiselectrictoolcomplieswiththepertinentsafety
regulations.
• Keepyourworkareacleanandtidy.
• Untidyandunlitworkareascanresultin
accidents.
• Keepthetooloutoftherainandawayfrom
moisture.
• Theingressofwaterintoanelectrictoolincreases
the risk of an electric shock.
• Becareful,watchwhatyouaredoingandusean
electric tool sensibly. Do not use the tool if you are
tired or under the influence of drugs, alcohol or
medication.
• Amomentofinattentionwhenusingtheelectric
tool can result in serious injuries.
• Donotuseanelectrictoolwithadefectiveswitch.
An electric tool that cannot be switched on or off is
dangerous and must be repaired.
• Keepunusedelectrictoolsoutofthereach
of children. Do not allow people who are not
familiar with the tool or who have not read these
instructions to use the tool. Electric tools are
dangerous if they are used by inexperienced
people.
• Keepyourcuttingtoolssharpandclean.
Carefully maintained cutting tools with sharp
cutting edges will jam less and are easier to
control.
• Iftheconnectionleadontheelectrictoolis
damaged, it must be replaced by a specially
prepared connection lead available from our
customer service organization.
• Haveyourtoolrepairedonlybytrainedpersonnel
using only genuine spare parts. This will ensure
that you tool maintains its safety standard.
• Themachinehastobesetupwhereitcanstand
securely.
• Allcoversandsafetydeviceshavetobeproperly

Helpline No 0844 801 8701 / IRE 189 094 6244 7
fitted before the machine is switched on.
• Itmustbepossibleforthebladetorunfreely.
• Whenworkingwithwoodthathasbeenprocessed
before, watch out for foreign bodies such as nails
or screws etc.
• BeforeyouactuatetheOn/Offswitch,makesure
that the saw blade is correctly fitted and that the
machine’s moving parts run smoothly.
• Followtheinstructionsforlubricationandchanging
tools.
• Keephandlesdry,cleanandfreefromoiland
grease.
• Keepthepushstickorhandleforapushblockat
the machine at all times, even when you are not
using them.
• Donotcutrebatesorgrooveswithoutfittinga
suitable guard, e.g. a tunnel-type guard, over the
saw table.
• Useonlythetransportdevicefortransportingthe
machine.
• Whileyouaremovingthemachineitisbestto
cover the top part of the blade, for example using a
guard.
Do not lose these safety instructions.

Helpline No 0844 801 8701 / IRE 189 094 6244
8
Layout (Fig. 1)
1 Saw table
2 Saw blade guard
3 Push stick
4 Saw blade
5 Splitter
6 Table insert
7 Parallel stop
8 Motor
9 Power cable
10 Stand
11 On/Offswitch
12 Star-grip screw for parallel stop
13 Scale for angle settings
14 Star-grip screw for height adjustment
15 Screw for saw blade guard
16 Cross stop

2. Items supplied
• Carbide-tippedsawblade
• Parallelstop
• Pushstick
• Bench-typecircularsaw
• Crossstop
• 2xcombinedringwrench/facespanners.
3. Proper use
The bench-type circular saw is designed for the
slitting and cross-cutting of all types of timber,
commensurate with the machine’s size. The machine
is not to be used for cutting any type of roundwood.
The machine is to be used only for its prescribed
purpose.
Any use other than that mentioned is considered to
be a case of misuse. The user/operator and not the
manufacturer shall be liable for any damage or injury
resulting from such cases of misuse. The machine
is to be operated only with suitable saw blades. It is
prohibited to use any type of cutting-off wheel.
To use the machine properly you must also observe
the safety regulations, the assembly instructions and
the operating instructions to be found in this manual.
All persons who use and service the machine have to
be acquainted with this manual and must be informed
about its potential hazards.
It is also imperative to observe the accident
prevention regulations in force in your area. The
same applies for the general rules of occupational
health and safety.
The manufacturer shall not be liable for any changes
made to the machine nor for any damage resulting
from such changes.
Even when the machine is used as prescribed
it is still impossible to eliminate certain residual
risk factors. The following hazards may arise in
connection with the machineʼs construction and
design:
• Contactwiththesawbladeintheuncoveredsaw
zone.
• Reachingintotherunningsawblade(cutinjuries).
• Kick-backofworkpiecesandpartsofworkpieces
• Sawbladefracturing.
• Catapultingoffaultycarbidetipsfromthesaw
blade.
• Damagetohearingifessentialear-muffsarenot
worn.
• Harmfulemissionsofwooddustwhenthemachine
is used in closed rooms.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications.Ourwarrantywillbevoidedifthe
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
Helpline No 0844 801 8701 / IRE 189 094 6244 9

Helpline No 0844 801 8701 / IRE 189 094 6244
10
4. Important notes
Please read this manual carefully and pay attention
to the information provided. Use this manual to
familiarize yourself with the machine, its correct use
and safety regulations.
The corresponding safety information can also be
found in this instruction manual.
Sound and vibration
Sound and vibration values were measured in
accordance with EN 61029.
Idling
LpA sound pressure level 95 dB(A)
KpA uncertainty 3 dB
LWA sound power level 108 dB(A)
KWA uncertainty 3 dB
Wear ear-muffs / ear defenders.
The impact of noise can cause damage to hearing.
“The quoted values are emission values and not
necessarily reliable workplace values. Although there
is a correlation between emission and immission
levels it is impossible to draw any certain conclusions
as to the need for additional precautions. Factors
with a potential influence on the actual immission
level at the workplace include the duration of impact,
the type of room, and other sources of noise etc.,
e.g. the number of machines and other neighboring
operations. Reliable workplace values may also vary
from country to country. With this information the user
should at least be able to make a better assessment
of the dangers and risks involved.”
Keep the noise emissions and vibrations to a
minimum.
• Onlyuseapplianceswhichareinperfectworking
order.
• Serviceandcleantheapplianceregularly.
• Adaptyourworkingstyletosuittheappliance.
• Donotoverloadtheappliance.
• Havetheapplianceservicedwhenevernecessary.
• Switchtheapplianceoffwhenitisnotinuse.
5. Technical data
Supply Voltage: 230 V ~ 50 Hz
Power rating: 800 W S2 10 min
Idle speed n0: 2950 rpm
Carbide saw blade: 200 x 16 x 2.4 mm
Number of teeth: 20
Table size: 500 x 335 mm
Cutting height max. 90°: 43 mm
Cutting height max. 45°: 35 mm
Connector for dust extractor: dia. 35 mm
Size, complete: 500 x 335 x 370 mm
Weight: 13,1 kg
Load factor:
A load factor of S2 10 min (intermittent periodic duty)
means that you may operate the motor continuously
at its nominal power level (800 W) for no longer than
the time stipulated on the specifications label (10
minutesONperiod).Ifyoufailtoobservethistime
limitthemotorwilloverheat.DuringtheOFFperiod
the motor will cool again to its starting temperature.
6. Before starting the equipment
• Themachinehastobesetupwhereitcanstand
firmly, e.g. on a work bench, or it must be bolted to
a strong stand.
• Allthecoversandsafetydeviceshavetobe
properly fitted before the machine is switched on.
• Itmustbepossibleforthesawbladetorunfreely.
• Whenworkingwithwoodthathasbeenprocessed
before, watch out for foreign bodies such as nails
or screws etc.
• BeforeyouactuatetheOn/Offswitch,makesure
that the saw blade is correctly fitted and that the
machine’s moving parts run smoothly.
• Beforeyouconnectthemachinetothepower
supply, make sure the data on the rating plate is
the same as that for your mains.

Helpline No 0844 801 8701 / IRE 189 094 6244 11
7. Assembly
Always pull out the power plug before carrying
out any maintenance or conversion work.
7.1 Fitting the saw blade (Fig. 2/3)
• Caution!Pulloutthepowerplug.
• Unscrewthefixingscrews(20)andremovechip
bin cover (19).
• Undothenut(21)witharingwrench(30)onthe
nut itself and a face spanner (31) on the saw shaft
to apply counter-pressure.
• Caution!Turnthenutinthedirectionofrotationof
the saw blade (4).
• Takeofftheouterflange(22)andpulltheoldsaw
blade (4) off the inner flange by dropping the blade
at an angle.
• Cleanthemountingflange.
• Fitthenewsawbladeinreverseorder.
• Caution!Notethedirectionofrotation(seearrow
on the saw blade).
Please note that the saw bench is supplied with the
saw blade (4), splitter (5) and the saw blade guard (2)
already fitted.

Helpline No 0844 801 8701 / IRE 189 094 6244
12
7.2 Adjusting the splitter (Fig. 4-6)
• Removethesawbladeguard(2)(see7.3).
• Takeoutthetableinsert(6)(see7.4).
• Slackenthetwohexagonsocket-headscrews
(24).
• Adjustthesplitter(5)sothatthegapbetweenthe
saw blade (4) and the splitter (5) equals 3 - 5 mm
(see Fig. 6)
• Thesplitter(5)hastobeinlinewiththesawblade
(4) in longitudinal direction.
• Retightenthetwoscrews(24).
• Thesettingofthesplitterhastobecheckedeach
time after changing the saw blade.
7.3 Fitting the saw blade guard (Fig. 4)
• Mountthesawbladeguard(2)onthesplitter(5)
and align.
• Insertthescrew(15)throughtheholeinthesaw
blade guard (2) and in the splitter (5) and secure it
with the nut.
• Toremovethesawbladeguard,proceedin
reverse order.
7.4 Replacing the table insert (Fig. 4)
• Caution!Pulloutthepowerplug.
• Removethe6screws(23).
• Takeoffthesawbladeguard(2)(see7.3).
• Lifttheworntableinsert(6)upandout.
• Fitanewtableinsertinreverseorder.

Helpline No 0844 801 8701 / IRE 189 094 6244 13

Helpline No 0844 801 8701 / IRE 189 094 6244
14

Helpline No 0844 801 8701 / IRE 189 094 6244 15
8. Using the saw
8.1 On/Off switch (Fig. 7 Item 11)
• Thesawcanbeswitchedonbypressingthegreen
pushbutton “I”.
• Theredpushbutton“0”hastobepressedtoswitch
off the saw.
8.2 Parallel stop
8.2.1 Stop height (Fig. 7-9)
• Theparallelstop(7)suppliedwiththebenchtype
circular saw has two different guide faces.
• Forthickmaterialyoumustusethestoprail(25)
as shown in Fig. 8, for thin material you must use
the stop rail as shown in Fig. 9. When the stop
rail is used in this position, the Cross stop (Fig. 1 /
Item 16) can also be fitted to the parallel stop.
• Tochangetheheightofthestop,slackenthetwo
thumb screws (12) and pull the stop rail off the
carrier rail (26).
• Turnthestoprail(25)180°totheleftortheright,
depending on the required height of the stop, and
plug in back on the carrier rail (26).
• Re-tightenthethumbscrews(12).
8.2.2 Cutting width (Fig. 9)
• Theparallelstop(7)hastobeusedwhenmaking
longitudinal cuts in wooden workpieces.
• Slidetheparallelstop(7)totherightorleftsideof
the saw table (1).
• Theparallelstop(7)canbesettotherequired
dimension with the help of the scale (b) engraved
on the saw table (1).
• Tightenthetwothumbscrews(12)inordertofix
the parallel stop (7).
8.3 Adjusting the angle (Fig. 10/11)
• Slackenthestar-gripknobs(14).
• Youcannowadjusttheblade(4)totherequired
Angle (see scale (13)) by sliding the two star-grip
knobs.
• Re-tightenthestart-gripscrews(14).

9. Sawing operations
After each new adjustment it is advisable to carry out
a trial cut in order to check the set dimensions.
After switching on the saw, wait for the blade to reach
its maximum speed of rotation before commencing
with the cut.
Secure long workpieces against falling off at the end
of the cut (e.g. with a roller stand etc.)
Takeextracarewhenstartingthecut!
Never use the equipment without the suction
function. Regularly check and clean the suction
channels.
9.1 Cutting narrow workpieces
(width less than 120 mm) (Fig. 11)
• Adjusttheparallelstop(7)tothewidthof
workpiece you require.
• Feedintheworkpiecewithtwohands.Alwaysuse
the push stick (3) in the area of the saw blade (4).
(Apushstickissuppliedwiththesaw!)
• Alwayspushtheworkpiecethroughtotheendof
the splitter (5).
• Caution!Withshortworkpieces,usethepushstick
from the beginning.
9.2 Cutting extremely narrow workpieces
(width less than 30 mm)
• Adjusttheparallelstop(7)tothewidthof
workpiece you require.
• Usethepushblock(d)topresstheworkpiece
against the stop rail (25) and push the workpiece
with the push stick (3) through to the end of the
splitter (5).
There is no push block supplied with the saw!
(Available from your specialist dealer)
Helpline No 0844 801 8701 / IRE 189 094 6244
16

10. Cleaning, maintenance and
ordering of spare parts
Always pull out the mains power plug before starting
any cleaning work.
10.1 Cleaning
• Keepallsafetydevices,airventsandthemotor
housing free of dirt and dust as far as possible.
Wipe the equipment with a clean cloth or blow it
with compressed air at low pressure.
• Werecommendthatyoucleanthedevice
immediately each time you have finished using it.
• Cleantheequipmentregularlywithamoistcloth
and some soft soap. Do not use cleaning agents or
solvents; these could attack the plastic parts of the
equipment. Ensure that no water can seep into the
device.
10.2 Carbon brushes
• Incaseofexcessivesparking,havethecarbon
brushes checked only by a qualified electrician.
Important!Thecarbonbrushesshouldnotbe
replaced by anyone but a qualified electrician.
10.3 Maintenance
There are no parts inside the equipment which
require additional maintenance.
10.4 Ordering replacement parts:
Please quote the following data when ordering
replacement parts:
• Typeofmachine:CX-TS800
• Articlenumberofthemachine:43.407.65
• Identificationnumberofthemachine:11011
• Replacementpartnumberofthepartrequired
For our latest prices and information please go to
www.einhell.co.uk
11. Disposal and recycling
The unit is supplied in packaging to prevent its being
damaged in transit. This packaging is raw material
and can therefore be reused or can be returned to
the raw material system.
The unit and its accessories are made of various
types of material, such as metal and plastic.
Defective components must be disposed of as
special waste. Ask your dealer or your local council.
12. Storage
Store the equipment and accessories out of
children’s reach in a dark and dry place at above
freezing temperature. The ideal storage temperature
is between 5 and 30 °C.
Helpline No 0844 801 8701 / IRE 189 094 6244 17

Helpline No 0844 801 8701 / IRE 189 094 6244
18
Never place any electric tools in your household refuse.
To comply with European Directive 2002/96/EC concerning old electric and electronic
equipment and its implementation in national laws, old electric tools have to be separated
from other waste and disposed of in an environment-friendly fashion, e.g. by taking to a
recycling depot.
Recycling alternative to the demand to return electrical devices:
As an alternative to returning the electrical device, the owner is obliged to cooperate in
ensuring that the device is properly recycled if ownership is relinquished. This can also
be done by handing over the used device to a returns center, which will dispose of it
in accordance with national commercial and industrial waste management legislation.
This does not apply to the accessories and auxiliary equipment without any electrical
components which are included with the used device.
Technical changes subject to changeThe reprinting or reproduction by any other means, in whole or
in part, of documentation and papers accompanying products is
permittedonlywiththeexpressconsentofISCGmbH.
