Challenge MS-5 Guide

F.300-BT
August 2015
MODEL MS-5
Technical Service and Parts Manual
Serial Numbers:
965600 through 159999,
MS5-A-150000 and up
Sold and Serviced by
The Challenge Machinery Company
6125 Norton Center Drive
Norton Shores, MI 49441-6081 USA
ChallengeMachinery.com
The Challenge Machinery Company provides owner's manuals on its
products solely as a courtesy to its customers. See the information below
before using this manual.
These manuals are for reference only. These manuals include products which are noncurrent,
unsupported or no longer produced by The Challenge Machinery Company, and are provided solely as
an accommodation to our customers. By providing these manuals, The Challenge Machinery Company
makes no representation or warranty as to the products, their current condition, or their suitability or fitness
for use in any particular application, which are the sole and independent responsibility of the product
owner and user.
Older products may not comply with current safety procedures, guidelines or regulations, and it
is the product owner's and user's responsibility to evaluate the suitability and fitness of the
products in their current use and application. The Challenge Machinery Company makes no
representation, warranty or recommendation regarding any modifications which may be required
on non-current or unsupported products. The Challenge Machinery Company assumes no liability
for any modification or alteration to any Challenge product, and any such modification or
alteration to any Challenge product is not authorized by The Challenge Machinery Company. The
availability of these manuals is solely for the purpose of providing reference information for the products.
This manual may not be complete in all aspects of product maintenance and repair. All products should
be used only by qualified and properly trained personnel, following proper safety procedures. All
products should be regularly inspected and maintained, and their condition, application and use should
be periodically evaluated by qualified personnel. Only qualified and properly trained technicians should
perform maintenance, repair and replacement procedures. Attempting these procedures without proper
training may cause machine damage or operator injury!
Products may be unsupported by The Challenge Machinery Company due to age or the unavailability of
parts from their original manufacturer. No parts or product support will be available to repair or maintain
unsupported products. Older products may not be UL listed (if the product does not have a UL label it is
not a listed product), and may not comply with applicable installation or other regulations or requirements
if relocated to a new facility. Many municipalities require a product to be UL listed before an electrician
will connect power to them. Often the cost of updating an older product to comply with current safety
regulations is greater than the value of the product.

2
1.0 Introduction
THIS MANUAL is designed to help you get the most from your Challenge equipment. Keep this
manual in a safe, convenient place for quick reference by operators and service personnel.
SAFETY ALERT! This symbol means CAUTION: Personal safety
instructions! Pay special attention to the instructions in bold type. Personal injury may result if the
precautions are not read and followed.
READ THIS MANUAL BEFORE OPERATING! Follow precautions and instructions given and you
should have years of trouble-free operation. If after reading the manual questions still remain, contact
your Authorized Challenge Dealer.
FOR PARTS AND SERVICE, contact the Authorized Challenge Dealer from whom you purchased
your machine. Use the illustrations and parts lists at the back of this manual to identify the correct
parts needed. Always give the SERIAL NUMBER and MODEL of your machine to insure the correct
parts are sent as soon as possible.
Take a few minutes right now to RECORD YOUR MACHINE SERIAL NUMBER in the space
provided below. Also be sure to fill out the warranty card accompanying your machine and return it
DIRECTLY TO CHALLENGE.
If you bought a used machine, it is important to have the following information on record at Challenge.
Copy this page, fill in the information and send it care of The Challenge Service Department, 6125
Norton Center Drive Norton Shores MI 49441-6081.
CHALLENGE MODEL
SERIAL NUMBER
ATTN
COMPANY
ADDRESS
CITY
STATE/PROVINCE
ZIP
PHONE
DATE INSTALLED
DEALER NAME & CITY
* WARRANTY INFORMATION *
It is very important that you read and understand the conditions outlined in the Warranty Information
Sheet attached to the outside of the shipping container of your machine.
The Warranty Information Sheet must be filled out completely and returned to THE CHALLENGE
MACHINERY COMPANY in order for the warranty to be issued for this machine.
Challenge® is a registered trademark of
The Challenge Machinery Company6125 Norton Center DriveNorton Shores, MI 49441-6081
Copyright© 1999-2015 by The Challenge Machinery Company. All rights reserved. Printed in the U.S.A

1.0 Introduction
3
TABLE OF CONTENTS
1.0 Introduction .......................................................................................................................................2
2.0 Safety................................................................................................................................................4
2.1 Precautions...................................................................................................................................4
2.2 Power Lockout Procedure ............................................................................................................4
2.3 Warning Label Definitions.............................................................................................................5
3.0 Maintenance Guide...........................................................................................................................6
3.1 Routine Maintenance....................................................................................................................7
4.0 Troubleshooting ............................................................................................................................. 10
5.0 Main Assemblies............................................................................................................................ 12
5.1 Main Assembly –Front View..................................................................................................... 12
5.2 Main Assembly –Side Elevation ............................................................................................... 16
5.3 Main Assembly –Top View ....................................................................................................... 20
5.4 Main Assembly –Spindle Guard (S/N’s 135928 and up) .......................................................... 22
5.5 Table Adjustment Assembly...................................................................................................... 24
5.6 Basic Machine Schematic.......................................................................................................... 26
5.7 Power Panel Assembly –208/230V (1ph)................................................................................ 28
5.8 Power Panel Assembly –208/230/460V (3ph).......................................................................... 32
5.9 Power Panel Assembly –380/415V (3ph)................................................................................. 36
5.10 Label –Component Placement/Heater settings...................................................................... 38
5.11 Hydraulic Power Unit –Single and Three Phase .................................................................... 40
5.12 Drill Head Assembly ................................................................................................................ 41
5.13 Narrow Drill Head Assembly.................................................................................................... 42
5.14 Two Hand Control Option........................................................................................................ 44
5.15 Drill Guard Kit .......................................................................................................................... 46
5.16 Belt Guard Switch Replacement Kit ........................................................................................ 47

4
2.0 Safety
2.1 Precautions
This machine is designed for one-person operation. Never operate the machine with more
than one person.
Safe use of this machine is the responsibility of the operator. Use good judgment and
common sense when working with and around this machine.
Read and understand all instructions thoroughly before using the machine. If questions
remain, contact the dealer from which you purchased this machine. Failure to understand the
operating instructions may result in personal injury.
Only trained and authorized people should operate this machine.
Do not alter safety guards or devices. They are for your protection. Severe personal injury
may result.
Disconnect power before cleaning or performing maintenance. See Section 2.2 Power
Lockout Procedure.
Observe all caution labels on this machine.
High Speed Drill - Keep rags, loose clothing and long hair away form rotating drill. Personal
injury could result from items being caught on drill.
Keep foreign objects off table and away from drill.
Be extremely careful when handling and changing the drills. Severe lacerations or
dismemberment could result from careless handling procedure.
Keep the floor around the machine free of trim, debris, oil and grease.
If the machine sounds or operates abnormally, turn it off and consult the Trouble Shooting
section of this manual. If the problem cannot be corrected, have it checked by a qualified
service person or your Authorized Challenge Dealer.
CRUSH HAZARD, keep feet off the pedal when handling paper under the pressure feet. DO
NOT REST FOOT ON PEDAL at any time!
DO NOT REACH UNDER THE DRILL AREA!
DO NOT OPERATE WITH ANY GUARDS REMOVED! Replace all guards after adjusting,
lubricating or servicing the machine.
Severe Lacerations - Contact with high-speed drill could cause severe injury. Always turn
machine off and wait for drill to stop before removing drill bits. Keep hands away from drill(s)
when operating.
2.2 Power Lockout Procedure
For maximum safety when making adjustments or repairs to your machine, be sure to lock out the
main power control switch to which the machine is connected. The switch should be moved to the
OFF position and a padlock placed in the loop. The person servicing the machine should hold the
key.
Figure 1

2.0 Safety
5
2.3 Warning Label Definitions
The following warning labels are found at various locations on your machine. Read and understand
the meaning of each symbol. If a label is lost from the machine, it should be replaced. The item
number and location of each label can be found in Section 5.0, Main Assemblies.
HAZARDOUS AREA
Disconnect power before cleaning, servicing, or making adjustments not requiring
power. Do not alter safety guards or devices; they are for your protection. Replace
all guards. Do not operate with any guards removed.
EYE WEAR
Always wear eye protection when operating this machine.
SHOCK HAZARD
Disconnect power before removing cover. Replace cover before operation.
SINGLE OPERATOR
Do not operate with more than one person.
CUT/CRUSH HAZARD
Keep hands from under drills.

6
3.0 Maintenance Guide
NOTICE
The instructions on the following
pages are for the use of trained
service personnel only!
Attempting to perform repair and
replacement procedures without
proper training may cause
machine damage or operator
injury!
PARTS CUSTOMERS: The Challenge Machinery Company provides parts with the express
understanding that they are to replace parts found missing or no longer serviceable on
equipment designed and/or manufactured by Challenge. The Challenge Machinery
Company assumes no liability for any modification or alteration to any Challenge products,
and any such modification or alteration to any Challenge product is not authorized by The
Challenge Machinery Company. Any modification or alteration of any Challenge product
will void any remaining warranty.

3.0 Maintenance Guide
7
3.1 Routine Maintenance
General
Production losses can be reduced if good maintenance practices are followed. The following
suggestions may be helpful:
1. Recognize the fact that the user of hydraulic equipment has more control over maintenance than
the manufacturer.
2. Technicians should be familiar with use, care, and limitations of the equipment. Technicians and/or
maintenance personnel SHOULD READ THIS MANUAL COMPLETELY.
3. Use properly trained maintenance personnel.
4. Establish a program of systematic preventative care for your equipment or put this machine on an
existing preventative maintenance program.
5. Analyze and isolate trouble before having any part of the equipment dismantled.
6. Be aware of how your machine should sound and perform. If the machine is not operating properly
or if it doesn’t “sound right”, stop running your job immediately and try to identify the problem.
7. Call the dealer for any problems that cannot be handled by your own personnel.
Always handle drills with care to avoid severe lacerations, even dull drills
are sharp enough to cause lacerations.
Daily
1. Keep drills sharp! Sharpen drills often and reset the drill depth if needed.
2. Lubricate the hollow drills frequently with the Drill-Ease provided.
3. For better hollow drill life, remove the drills when not in use and soak in light oil. Wipe off excess
oil before drilling.
4. Wipe off excess grease from the drill heads and idlers.
Weekly (or every 40 hours of operations)
1. Spray the chip chute with silicone spray to prevent the drill chips from sticking and piling up.
Monthly
1. Oil the table height adjusting knob shaft with a light machine oil. Wipe off excess oil.
2. Check the hydraulic oil supply for the proper level. This check is made by removing the rear panel
and visually checking the hydraulic oil level in relation to the oil fill line located on the hydraulic tank
(fig. 2 page 8). The oil level should be no higher then the oil fill line to allow room for expansion of

8
the oil when running. Use only a recommended premium grade anti-wear hydraulic oil series ISO
VG 100. Oils other then the recommended type will cause seals, cups and ‘o’-rings to deteriorate.
Fig. 2
Yearly
1. Check all adjustments
2. Tighten all screws
3. Change the hydraulic oil in the reservoir. Oil may have to be changed more often if
contamination of any kind gets in the oil.
Vertical Table Guide
PINCH POINT: This adjustment requires a guard to be removed for
adjustment and testing purposes only. Be very careful while adjusting. Replace all guards before
operating. DO NOT operate machine with any guards removed.
The vertical guide block is located on the right side of the machine beneath the table and may need
periodic adjustments to keep the table steady, yet allow it and stock to fall away from the drills as rapidly
as possible. The table down stroke is controlled by the weight of the table (gravity) and return springs.
Remove the guide block cover guard. Tighten the two guide block lock nuts (fig. 3) and power the table
up by pressing the foot pedal. Gradually back the lock nuts off evenly until the table releases freely.
Retest the upstroke and table return, and check the table for side play. Replace guard.
Oil Fill Level
Line

3.0 Maintenance Guide
9
Fig. 3
PINCH POINT: Replace guard after adjusting
Hydraulic
Through normal use, hydraulic systems gum up and seals wear. Signs of wear are hydraulic leaks and
erratic operations of the vertical speed. Check with your Authorized Dealer for a current repair and/or
replacement policy.
NEVER USE Automatic Transmition oil or brake fluid as a substitute! Oils
other than the recommended type (premium grade anti-wear hydraulic oil ISO series VG 100) will cause
seals, cups and O-rings to deteriorate. Unsafe operating conditions will result.
Drill Heads
Through normal use, bearings will wear and need replacement. Signs of wear are excessive noise,
heat or loose spindles.
Lock Nut

10
4.0 Troubleshooting
Never work on this machine with the power on unless the instructions
say the machine power must be on. Lock the power off at the wall disconnect switch. See 2.2
Power Lockout Procedure page, 4.
Whenever repairing hydraulic components, loosen connections slowly
to bleed off any trapped pressure.
Problem;
WON'T START -
1. Blown fuse.
2. Main Power Switch in off position
3. Defective start button.
4. Safety shield or drill head cover interlock switches not contacted or defective.
5. Defective starter.
6. Overload tripped
7. Loose wire.
LACK OF POWER -
1. Low voltage.
2. Hydraulic fluid low.
3. Relief valve in pump stuck open.
4. Check speed control valve.
5. Hydraulic cylinder needs to be replaced.
SPINDLE MOTOR STALLS -
1. Low voltage.
2. Drive belt is loose.
3. Drill bits are dull.
4. Drill bits are plugged.
5. Drill heads need to be repaired.
TABLE STROKE WON’T ADJUST -
1. Stroke adjustment chain off sprockets.
2. Broken chain.
TABLE WON’T RETURN AUTOMATICALLY -
1. Check continuity between the isolated block and ground.

4.0 Troubleshooting
11
NOTES

12
5.0 Main Assemblies
5.1 Main Assembly –Front View
45000 Sheet 1 Rev. N

5.0 Main Assemblies
13
Main Assembly –Front View –Parts List
45000 Sheet 1 Rev. N
NO.
PART NO.
DESCRIPTION OF ACCESSORIES
QTY
1
16543
LEVELER
4
2
H-6424-6
3/8-16 HEX JAM NUT
4
3
45051
BASE ASSEMBLY
1
4
45049
BRACKET - LOWER BASE COVER
2
5
H-6910-102404
#10-24 X 1/2 BUTTON HD SOC. CAP SCREW
9
6
H-377
HYDRAULIC CYLINDER
1
7
H-6424-8
1/2-13 HEX JAM NUT
12
8
8843-1
SPRING - TABLE RETURN
2
9
45007
ROD - CYLINDER MOUNTING
4
10
H-7327-12
3/8 MEDIUM LOCKWASHER
8
11
H-7321-6
3/8 FLAT WASHER
8
12
H-6913-608
3/8-16 X 1 HEX HD CAP SCREW
4
13
45136-1
TABLE ADJUSTMENT ASSEMBLY
1
14
H-6918-616
3/8-16 X 2" SOC. HD. CAP SCREW
14
15
45073
BRACE - CROSS
1
16
S-1753-2
KNOB - TABLE ADJUSTMENT
1
17
H-6424-6
3/6-16 HEX JAM NUT
1
18
45070
BRACKET - MOTOR
1
19
H-6918-612
3/8-16 X 1-1/2 SOC HD CAP SCREW
2
20
45001
PIN - MOTOR
1
21
S-1193-50
1/2 'E' RING
2
22
11288
WASHER - NYLON
1
23
45077
SIDE FRAME - L.H.
1
24
45002
BRACKET ASSEMBLY - MOTOR
1
25
45079-1
DOVETAIL
1
26
27
45075
SIDE FRAME - R.H.
1
28
H-6913-612
3/8-16 X 1-1/2 HEX HD CAP SCREW
4
29
11288-1
WASHER - NYLON
4
30
45117
COVER - TABLE GUIDE - TOP
1
31
S-1088-5
#10 X 5/8 TYPE AB SCREW
2
32
45017
COVER - VERTICAL TABLE GUIDE
1
33
H-6910-102402
#10-24 X 1/4 BUTTON HD SOC. CAP SCREW
4
34
H-7321-4
1/4 FLAT WASHER
2
35
45092
COVER - TABLE ROD GUIDE
1
36
45011-2
TABLE
1
37
H-6918-510
5/16-18 X 1-1/4 SOC HD CAP SCREW
11
38
39
45084
ISOLATOR
2
40
45131
NUT - ADJUSTING
1
41
45135-1
CHAIN
1
42
45115-1
ROD - TABLE
1
43
45037
BRACKET - RETURN SPRING
1
44
H-236-3
ADAPTER - 9/16-18 S.A.E. 'O' RING TO TUBE
2

14
Main Assembly –Front View –Parts List (cont)
45000 Sheet 1 Rev. N
NO.
PART NO.
DESCRIPTION OF ACCESSORIES
QTY
45
H-6913-1012
5/8-11 X 1-1/2 HEX HD. CAP SCREW
1
46
H-7327-20
5/8 MEDIUM LOCKWASHER
1
47
45137
GUIDE ASSEMBLY - TABLE ROD
1
48
45116-2
BRACKET - TABLE MOUNTING
1
49
50
H-6910-1010
5/8-11 X 1-1/4 BUTTON HD. CAP SCREW
1
51
45118
STOP - TABLE TRAVEL
1
52
H-6918-405
1/4-20 X 5/8 SOC. HD CAP SCREW
2
53
45138
SPROCKET - TABLE ADJ.
1
54
45142
DECAL - TABLE ADJ.
1
55
H-7330-#10
#10 EXT. TOOTH LOCKWASHER
1
56
EE-2425
WIRE ASSEMBLY - AUTO TRIP
REF
57
H-6910-83208
SCREW - #8-32 X 1" BUT HD CAP
2
58
S-1781-16
LABEL - CAUTION
2
59
45165
BLOCK - TABLE ADJ. ROD
1
60
H-6938-406
SCREW, 1/4-20 X 3/8 SOC SET SCR
2
61
47157-5
SHIELD - PLEXIGLASS
1
62
S-1781-35
LABEL - SHOCK HAZARD
1
63
E-1152-36
SPACER - 1/4-20 X 2"
2
64
H-6910-403
SCREW - 1/4-20 X 3/8 BUT HD. CAP
2
65
H-7324-8
WASHER - 1/4-20 INT. TOOTH
2

5.0 Main Assemblies
15
Notes:

16
5.2 Main Assembly –Side Elevation
45000 Sheet 2 Rev. X

5.0 Main Assemblies
17
Main Assembly –Side Elevation –Parts List
45000 Rev. X
NO.
PART NO.
DESCRIPTION OF ACCESSORIES
QTY
1
E-875-4
FOOTSWITCH (REPAIRS ONLY)
REF.
2
H-7324-#10
#10 INT. TOOTH LOCKWASHER
23
3
H-6423-#10
#10-24 HEX NUT
16
4
H-6918-102406
#10-24 X 3/4 SOC. HD CAP SCREW
2
5
45048
COVER - LOWER BASE
1
6
H-6910-102404
#10-24 X 1/2 BUTTON HC SOC. CAP SCREW
50
7
H-7330-#10
#10 EXT. TOOTH LOCKWASHER
4
8
EE-2369-3
POWER PNL ASSY.-380/415V (3 PHASE)
1
8
EE-2385-3
POWER PNL ASSY.-(SINGLE PHASE)
1
8
EE-2386-3
POWER PNL ASSY.-208-230/460V (3 PH)
1
9
H-237-5
ELBOW 90%%D - 1/8 NPT X 9/16-18 TUBE
1
10
H-241-5
ADAPTER - 1/8 NPT X 9/16-18 TUBE
1
11
45110
PANEL - CONSOLE
1
12
4771-1
VALVE
1
13
45081
COVER
1
14
H-7322-8
1/2 POLISHED WASHER
1
15
S-1694
TYRAP
2
16
S-1781-11
CAUTION LABEL - SHOCK
1
17
18
19
20
EE-2753
WIRE ASSEMBLY - GROUND
1
21
45047-1
COVER - FRONT
1
22
45109
LABEL
1
23
45160
DRIVE BELT
1
24
45129
PULLEY ASSEMBLY (UNCROWNED)
2
25
20075-7
SHIM
2
26
45040-1
PIN - IDLER PULLEY
2
27
45043
COVER ASSEMBLY - TOP
1
28
45103-2
DRIVE PULLEY - 2.1" DIA.
1
29
H-6938-404
1/4-20 X 1/4 CUP PT. SOC. SET SCREW
3
30
45145-1
COVER ASSEMBLY - REAR
1
31
45015
BLOCK - GUIDE
1
32
H-6918-612
3/8-16 X 1-1/2 SOC. HD CAP SCREW
2
33
45016
GUIDE - VERTICAL
1
34
H-21S-500-1750
1/2 X 1-3/4 ROLL PIN
1
35
S-1073-50
1/2" RETAINING RING
3
36
A-10257-8
BEARING - FLANGED (BRONZE)
3
37
H-6918-616
3/8-16 X 2" SOC. HD CAP SCREW
2
38
45107
TIEBAR
1
39
45032
CHIP CHUTE - LOWER
1
40
H-5254-406
1/4-20 X 3/4 SOC. SHOULDER SCREW
2
41
45080-1
STUD - TABLE GUIDE
1

18
Main Assembly –Side Elevation –Parts List (cont)
45000 Rev. X
NO.
PART NO.
DESCRIPTION OF ACCESSORIES
QTY
42
H-5248-4
1/4-28 FLEX LOCK NUT
2
43
45012
VERTICAL TABLE GUIDE ASSEMBLY
1
44
H-6918-612
3/8-16 X 1-1/2 SOC. HD CAP SCREW
4
45
46
47
56143
WASTE BIN
1
48
E-3082
SWITCH - MAIN DISCONNECT
1
49
E-3083
SWITCH FACE - MAIN DISCONNECT
1
50
51
52
53
41130
PLATE - SERIAL NUMBER
1
54
55
45056
COVER - REAR
1
56
H-407-2
HYD POWER UNIT ASM. (50/60 C. 3 PH)
1
56
H-378-2
HYD. POWER UNIT ASM. (50/60C 1 PH.)
1
57
40016-2
VIBRATION MOUNT
4
58
H-7321-5
5/16 FLAT WASHER
4
59
H-7327-10
5/16 MED LOCKWASHER
4
60
H-6423-5
5/16-18 HEX HUT
4
61
E-3073-5
PUSHBUTTON - OFF (RED)
1
62
63
16520
RING - ANTI ROTATION
2
64
E-3073
PUSHBUTTON - ON (GREEN)
1
65
66
45147
COVER - LOWER BASE TOP
1
67
8254-2
GROMMET
1
68
S-1694-2
CABLE TIE
3
69
70
E-1237-2
WIRE NUT (3 PHASE MACHINES ONLY)
3
71
45150
COVER - CORNER
1
72
73
S-1781-16
CAUTION LABEL
1
74
H-21S-250-
1250
1/4 X 1-1/4 ROLL PIN
2
75
45159
CHIP CHUTE
1
76
S-1781-31
LABEL - SINGLE OPERATOR
1
77
E-709-R
WIRE, #18 GA. RED MTW 6" LONG
1
78
79
45173
BRACKET - DOOR INTERLOCK KEY
1
80
45176
COVER - DISCONNECT SWITCH
1
81
45168
GUARD - FOOTSWITCH
1
82
EE-2749-1
SWITCH ASM - BELT GUARD
REF
83
S-1781-35
LABEL - CAUTION
3

5.0 Main Assemblies
19
Main Assembly –Side Elevation –Parts List (cont)
45000 Rev. X
NO.
PART NO.
DESCRIPTION OF ACCESSORIES
QTY
84
EE-2751-1
CONDUIT ASM - CONTROL CONSOLE - 3PH
REF
84
EE-2751
CONDUIT ASM - CONTROL CONSOLE - 1PH
REF
85
S-1694-5
TYRAP - IDENTIFICATION
2
86
S-1781-46
LABEL - BELT INSTALLATION
1
87
H-6910-102406
SCREW - #10-24 X 3/4 BUT HD SOC
6
88
89
S-1781-42
LABEL - GROUND
1
90
H-7321-#10
WASHER - #10 PLAIN
2
91
S-1781-47
LABEL - FUSE REPLACEMENT
1
92
E-1152-62
SPACER
2
93
H-6416-102412
WELDNUT
1
94
H-6416-102406
WELDNUT
1
95
H-7321-5
5/16 FLAT WASHER (3 PH MACHINES
ONLY)
6
96
H-6888-102404
SCREW - #10-24 X 1/2 BUT HD, TAMP.
PROOF
4
97
45180
ACTUATOR - INTERLOCK SWITCH
1
98
45179
MAGNETIC CATCH
2
99
H-6923-44012
SCREW - #4-40 X 3/4 ROUND HD. MACH
2
100
H-7324-#4
WASHER - #4 INT. TOOTH
2
101
H-6423-#4
NUT - #4-40 HEX
2
102
A-10644-1
COLLAR
4

20
5.3 Main Assembly –Top View
45000 Sheet 3 Rev. G
