CharlesWater 91550 Installation and operating instructions

VACUUM CLEANER AND BLOWER
Installation, Operation and Maintenance
Unit 17. Millbrook Business Park, Sybron Way • Crowborough, East Sussex TN6 3JZ United Kingdom
Phone: [phone] • E-mail: [email protected], Internet: Charleswater.co.uk
PPE-5089.E April 2014 Page 1 of 2 © 2014 CHARLESWATER LTD.
Figure 1. 91550 Vacuum Cleaner
Description
Compact lightweight blower /
vacuum cleaner designed for
precise removal and collection
of dry dust particles and debris
from electrostatic static sensitive
devices (ESDS). The conductive
nozzles drain-off any static
build-up to earth.
In order to comply with
EN 61340-5-1 recommendations
for working in an ESD protected
area (EPA), the appliance
housing, nozzles, hose, shoulder
strap, cable and accessories are
fully conductive.
The vacuum cleaner can retain
dust and fine dry particles
as small as 0.3 micron, the
vacuum cleaner is fitted with
a double-layer paper filter bag
and an electro-static charged
micro-motor filter.
“Tools intended for use within
the EPA [ESD protected area]
shall, as far as is practicable, be
so constructed that they do not
generate or hold an electrostatic
charge ….All tools and
machinery, for example electrical,
mechanical or pneumatic, shall
be so constructed that any
non-insulating part of the tool
or machine which may touch an
ESDS [ESD sensitive items] shall
be at EPA ground potential.” [EN
61340-5-1 clause 5.2.10 Tools,
machinery, dispensers and test
equipment]
The appliance can also be
converted in seconds into a
powerful blower for dust removal
in areas otherwise not accessible
- the blower’s air-current is
cfc-free and contains no oil or
water residue.
The appliance is constructed to
safety class II: Double insulated
design in compliance with CE
standards.
- Durable and compact design
- Motor has thermal protection
with RFI/EMC filter
- Hose assembly extends to
130cm
- Includes hard crevice and soft
rubber nozzle
- 1.2 l filter bag
- Advanced 5 stage filtration
system
- 3m long power cord
- Conductive carry strap
- Input power supply voltage:
220-240 volts
- Made in the Netherlands
Inspection
Remove the vacuum cleaner
from the carton and inspect for
shipping damages.
Each unit should include the
following:
1 Vacuum Cleaner
1 1.3m Hose
2 Nozzles
1 Carrying Strap
Optional Accessory:
- 91551: Replacement Bags,
Pack of 10
Operating instructions
1. Push hose end into
suction opening
2. Press the suction nozzle onto
the free suction hose-end
3. Place rocker switch in off
position
4. Set electronic control to
medium power
5. Insert the plug into the
electrical supply and start
appliance, pressing on-off
switch to “on” position.
TECHNICAL BULLETIN PPE-5089.E
Figure 2. 91550 Vacuum Cleaner
If there is substantial loss of
vacuum or blow-pressure, take the
following steps:
1. Remove appliance from
the EPA
2. Check whether nozzle or
suction-hose have become
blocked
3. Switch off appliance and
disconnect plug from
electrical supply
4. Lift metal bottom lock and
remove housing’s front cover
5. Remove and replace the
spent paper filter bag
6. Replace electrostatic micro-
motor filter.

Note: This appliance is equipped
with a thermal protection
device. To protect the motor
from overheating, it will switch
off automatically if there is an
inadequate air supply. To enable
a restart, check filters, bags,
nozzle and hose for blockages.
Also, reduce the power setting.
When the motor has cooled
down, the appliance should
restart after 15-20 minutes.
Safety points
When cleaning this equipment,
ensure it is switched-off and no
longer connected to the power
supply.
Ensure any object to be cleaned,
is itself connected to protective
earth ground in accordance with
EN 61340-5-1 recommendations.
Always use the on-off rocker
switch to turn the appliance on or
off.
This appliance is made for
indoor use only, it must be
stored in a dry place and should
not be operated under wet
conditions such as wet floors or
wet surfaces. Never touch the
appliance or the plug with wet
hands.
This appliance is not designed,
nor suitable, to collect liquids, nor
health endangering dust such
as asbestos or tropical wood
sawdust. Unplug the appliance
when it is not in use.
Do not pull the cord to unplug it,
do not use the cord to carry or
pull the appliance, keep the cord
away from hot surfaces.
Never use the appliance if the
cord or plug are damaged.
Never use the appliance if
the suction is blocked or with
completely restricted vacuum flow
or air exit.
Do not operate the vacuum
cleaner near flammable or
combustible liquids or fumes,
do not collect anything that is
hot, smoking or burning with the
cleaner. Do not pick-up burning
cigarettes, hot ashes or matches.
Use safety glasses when the
application is in blow mode, never
blow in corners or in the direction
of sharp objects such as staples,
paperclips, drawing-pins, needles,
pins and glass fragments.
Never use the appliance without
the filter bag and motor filter in
place. Never re-use spent filter
bags.
Unit 17. Millbrook Business Park, Sybron Way • Crowborough, East Sussex TN6 3JZ United Kingdom
Phone: [phone] • E-mail: [email protected], Internet: Charleswater.co.uk
PPE-5089.E Page 2 of 2 © 2014 CHARLESWATER LTD.
Limited Warranty
Charleswater expressly warrants that for a
period of one (1) year from the date of purchase,
Charleswater Vacuum Cleaners will be free of
defects in material (parts). Within the warranty
period, the material will be tested, repaired
or replaced at Charleswater’s option, free of
charge. Call Customer Service at 00 44 (0)
1892-665313 for a Return Material Authorisation
(RMA) and for proper shipping instructions and
address. You should include a copy of your
original packing slip, invoice, or other proof of
purchase date. Any unit under warranty should
be shipped prepaid to the Charleswater factory.
Warranty replacements will take approximately
two weeks.
Warranty Exclusions
THE FOREGOING EXPRESS
WARRANTY IS MADE IN LIEU OF ALL
OTHER PRODUCT WARRANTIES,
EXPRESSED AND IMPLIED, INCLUDING
MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE WHICH
ARE SPECIFICALLY DISCLAIMED. The
express warranty will not apply to defects or
damage due to accidents, neglect, misuse,
alterations, operator error, or failure to
properly maintain, clean or repair products.
Limit of Liability
In no event will Charleswater or any seller
be responsible or liable for any inury, loss
or damage, direct or consequential, arising
out of the use of or the inability to use the
product. Before using, users shall determine
the suitability of the product for their
intended use, and users assume all risk and
liability whatsoever in connection therewith.
