CHART TEC 3000 User manual
January, 2010
New TEC 3000 Manual
The newest TEC 3000 Technical Manual*, revision C, is available online at www.chart-
biomed.com. This revision includes several new features:
• Freezer Dimensional Specifications
• Updated Menu Maps
• Preventative Maintenance Procedures
• Troubleshooting Quick Reference
*PN: 13289499
Checking Freezer Electrical Components
If it is suspected that one of the electrical components is not operating properly, an
evaluation may be in order. Below is a list of specifications for select items normal re-
sistance values.
1. Fill Valves (Dual 24VDC): 30 – 35 ohms
2. Fill Valve (Singular 24VDC): 60 – 70 ohms
3. BypassValve:60–70ohms
4. Bypass Sensor:
a. Room Temp: 1000 – 1100 ohms
b. Cryogenic Temp: 200 – 300 ohms
5. Humphrey 3 way: 140 – 145 ohms
6. Temperature Probes
a. Room Temp: 1000 – 1100 ohms
b. Cryogenic Temp: 200 – 300 ohms
CryoSystem Lids
All CryoSystems will now come standard with a plastic lid. This will replace the painted,
spun metal lid previously used.
New MVE Freezer Options
As of January 4, 2010, MVE freezer options are changing. Full auto freezers with
the TEC 3000 controller wilOQRZ come equipped with+ot*as%ypassDVVWDQGDUG
HTXLSPHQW. Batterybackup will be an optional accessory that will have to be added
to a purchaseorder. Full auto freezers without hot gas bypass will no longer be
available forpurchase. Part number changes and options are reflected in the 2010
BiologicalEquipment Price List (PN 10795610).
MVE Freezer Options
o Basic Freezer
- Manual fill freezer without plumbing or level and temperature monitoring
oFullAutoFreezerwithHotGasBypass
- Includes TEC 3000 controller, plumbing, and hot gas bypass
- Optional battery backup add-on
o MDD Freezer
- For European use only
- Complies with the European Medical Device Directive (MDD)
- Includes TEC 3000 controller, plumbing, hot gas bypass, and battery backup
The hot gas bypass feature allows the warm nitrogen gas in the supply line to be
vented when a fill is initiated. This stops warm gas from entering the freezer
storage space and helps maintain a stable temperature gradient while increasing
the efficiency by reducing unnecessary liquid nitrogen evaporation during fills.
This feature will increase the efficiency of any supply system whether using
liquid cylinders or a large bulk tank and vacuum insulated piping.
For specific part numbers, pricing, or questions, please contact your authorized
MVE Distributor or Chart BioMedical Customer Service.
