2 Overview
Thank you for purchasing from Chemtrac, Inc.
The UVM5000 is a continuous UV 254nm organic testing monitor
which utilizes an innovative dual path measurement technique,
shown in the following illustration.
The UVM5000 is designed to take sensor readings at 90-
degree angles to each other through two different path lengths
through a rectangular quartz flow cell. The two sensor readings
give the amount of light able to pass through two different path
lengths of test water. From these two measurements alone, the
UV transmittance (UVT) or UV absorbance (UVA) of the test
water is calculated without continuous need for calibration.
By continuously taking readings in the two directions through
the flow cell, calibration is effectively performed every time a
sample is taken. Therefore, quartz fouling and lamp fluctuations
are inherently compensated for by the measurement process
itself, improving accuracy.
Your product model and serial number are as follows:
*Your Serial Number is located on the inside of the cabinet door.
Model Number
UVM5000
Serial Number*

Chemtrac UV254 Monitor –UVM5000 v 2.1
Chemtrac, Inc. 5
3 Safety
3.1 Safety Instructions
Please read and follow all safety instructions outlined in this owner’s manual prior to
installation and/or operation.
1. Visually inspect this analyzer prior to installation. If the
quartz flow cell or UV lamp is broken or damaged in any
way, do not use. Contact Chemtrac for replacement parts.
2. Ensure that all responsible personnel carefully read this
manual before installing or servicing this analyzer.
3. This analyzer contains a UV lamp, which emits light at UV
wavelengths. Never look directly at the UV light, as it could
cause permanent eye damage and burn unprotected skin.
4. Never service this analyzer without unplugging the power
supply.
5. Failure to properly install and maintain this analyzer may
impact its effectiveness and warranty.
6. Improper use of this analyzer may cause injury.

Chemtrac UV254 Monitor –UVM5000 v 2.1
Chemtrac, Inc. 6
4 Technical Specifications
The UVM5000 provides affordability, increased accuracy, and reduced maintenance.
Table 1: UVM5000 Specifications
CHARACTERISTIC
TECHNICAL DATA
RANGE
10-100% UVT 0.0025-1 UVA
ACCURACY
± 0.5% FS
RESOLUTION
0.1% UVT 0.001 UVA
UNITS
cm-1
PATH LENGTH
10 mm (position A); 20 mm (Position B)
SAMPLING TIME
10 seconds
CALIBRATION
The dual light path technology allows for continuous automatic calibration during operation.
Periodic in-situ zeroing to DI water
CLEANING
•Significantly reduced clean requirements due to dual path measurement capability.
•Periodic in-situ chemical cleaning or optional automatic chemical cleaning
SELF-DIAGNOSTICS
Detection and diagnosis of internal system fault
OPERATOR
INTERFACE
Five push buttons to control a comprehensive hierarchical menu system
DISPLAY
•4-line x 20-character backlit LCD.
•Indicator light for system alarms and warnings
ALARMS
Operator configurable alarms for: high and low set points, low lamp output, leak detected,
system fault, etc.
HUMIDITY CONTROL
Humidity sensor with large plug-in regenerating desiccant system
OUTPUTS
•4-20mA output configurable to either UVA or UVT
•RS232 for configuration via PC
•Digital Output / Dry Contact
WAVELENGTHS
253.7 nm
LIGHT SOURCE
Low pressure mercury UV lamp
LAMP LIFE
12 to 18 months
DIMENSIONS
17”high x 14” wide x 8” deep (43 cm x 36 cm x 20 cm)
ENCLOSURE
NEMA 4x, wall mountable
FLOW RATE
300-1000 mL/min
PRESSURE RATING
20 PSI (1.38 bar)
FLUID CONNECTIONS
1/4” (6 mm) push-to-connect fittings and flex tubing
ELECTRICAL
24 VDC 40W power adapter (accepts 90-250 VAC 50/60 Hz)
STORAGE TEMP.
-20°C to +60°C (-4°F to +140°F)
OPERATING TEMP.
0°C to 45°C (32°F to 113°F)
RATED WATER TEMP.
0°C to 75°C (32°F to 167°F). With high temperature upgrade: 70°C to 95ºC (158°F to 203°F)
WEIGHT
22 lb (10 kg)
WETTED MATERIAL
HDFE, Nickel-plated Brass, Polypropylene, Quartz, Teflon, Viton, 316 Stainless Steel
WARRANTY
1-year limited warranty
11

Chemtrac UV254 Monitor –UVM5000 v 2.1
Chemtrac, Inc. 7
5 Installation
5.1 Site Assessment
Prior to installation, the site should be assessed to collect all relevant information that may affect the installation
or operation of the system. Chemtrac has provided a checklist that can be used to ensure any installation or
operational problems can be addressed, resulting in the most efficient and effective installation and startup of
the system.
Table 2: Installation site assessment checklist and recommendations
CHECK
TIP
1
System installed outdoors?
Avoid areas with high exposure to sun and weather if possible.
2
If outdoors, system in direct
sunlight?
Select shaded area/shade hood for system or indoor location.
3
Temperature range at the
installation location?
Maximum operating temperature of 50°C.
4
Expected humidity at the
installation location?
Areas of high humidity may benefit from a spare desiccant pack.
5
Type of material the system will
be mounted on? (i.e. Concrete,
steel, railing)
Ensure the mounting hardware is appropriate and will support up to 50lbs
per component.
6
Sufficient space and clearance
to access and service the
system?
Refer to drawings in mounting section to ensure appropriate location is
selected. Minimal distance between system components is favored.
7
Power available at installation
location?
100-240VAC 50/60 Hz 4.0A input power required.
8
System location relevant to
measurement stream, what is
the distance?
Shortest possible distance minimizes measurement lag.
9
Favorable measuring
conditions? (i.e. no turbulence,
air bubbles, large suspended
solids etc.)
Select location with minimal measurement interferences.
10
Pressurized system able to
supply 300-1000 ml/min flow?
If necessary, use a needle valve to lower flow and maintain less than 20
PSI in analyzer. Splice connection from the side of the pressurized pipe, to
avoid air bubbles from top and sediment on bottom.
5.2 Unpacking and Inspection
To begin, remove the monitor from the packaging and carefully
inspect the product to ensure that no visible damage has occurred
during shipping. Next, ensure to remove the packing material that
is contained inside the cabinet. It is important to note that the
quartz flow cell and the rotating arm have been packed separately.
The following items will be:

Chemtrac UV254 Monitor –UVM5000 v 2.1
Chemtrac, Inc. 8
Table 3: Unpacking Checklist
ITEM
UVM5000 Organics Monitor
Rotating Arm Assembly (packed inside the UVM5000 enclosure)
10 mm x 20 mm Quartz Flow Cell (packed inside the UVM5000 enclosure)
1L Calibration Bottle with ¼” Flex Tubing
24 VDC Power Adapter and Cable (packed inside the UVM5000 enclosure)
Dehumidifier (packed inside the UVM5000 enclosure)
Owner’s Manual
Please ensure all items are unpacked and accounted for before moving on to assembly.

Chemtrac UV254 Monitor –UVM5000 v 2.1
Chemtrac, Inc. 9
5.3 Assembly
5.3.1 Installing the Rotating Arm
1. Position the flat side of the motor shaft so it is facing out as shown in Figure 5.1.
2. Place the rotating arm on the motor shaft as shown in Figure 5.2, pushing down as far as possible.
3. Tighten the shaft locking screw with a #2 Phillips screwdriver as shown in Figure 5.3.
5.3.2 Installing the Quartz Flow Cell
1. Remove the flow cell carefully from the packaging. The flow cell should be clean, and care should be
taken to prevent fingerprints, especially in the middle region of the flow cell where the light beam passes
through. (Wearing gloves is recommended.)
2. Insert the flow cell into position under the flow cell header as shown below in Figure 5.4. Align the black
dot on the flow cell with the black dot on top of the white plastic flow cell guide.
3. Carefully and slowly lower the clamp ensuring it is aligned with the flow cell as shown in Figure 5.5 and
Figure 5.6. The flow cell clamp should not require much force when clamping down. If any significant
force is required, try adjusting the position of the flow cell to prevent damage.
Figure 5.1: Flat edge facing out
Figure 5.2: Slide arm on to shaft
Figure 5.3: Tighten locking screw
Figure 5.4: Place flow cell on seal
Figure 5.5: Lower clamp
Figure 5.6: Tighten clamp

Chemtrac UV254 Monitor –UVM5000 v 2.1
Chemtrac, Inc. 10
5.3.3 Installing the Ribbon Cable
Note: Ensure not to pinch the ribbon cable when installing as this
can create a weak spot in the cable and reduce the life of the
cable.
1. Position the flex ribbon connector to the rotating arm as
shown in Figure 5.7.
2. Press the connector into the slot until you feel it click into
place (Figure 5.8).
3. Press the top and bottom hold down clamps against the
connector to anchor it into position (red arrows in Figure
5.8).
4. Attach the other end of the ribbon cable into the slot at the
control board and then secure the top and bottom clamps
against the connector (Figure 5.9).
Figure 5.8: Snap receptacle into place; secure clamps
Figure 5.9: Attach cable to control board
Press clamp down
so that it is flush
with connector
Opposing clamp
hidden from view.
Press up.
Figure 5.7: Orient ribbon cable

Chemtrac UV254 Monitor –UVM5000 v 2.1
Chemtrac, Inc. 11
5.4 Mounting
The monitor should be attached to the wall at all four of the
mounting holes provided (top left and right; bottom left and
right in Figure 5.10). Use screws and washers that are
sturdy enough to support the cabinet weight of
approximately 20 lbs.
Cabinet dimensions are to the nearest 1/8 inch. Refer to
Section 18, Cabinet Dimensions and Clearance for
drawings of dimensions and clearance.
The expanded view at right
(Figure 5.11) shows an example
of a ¼” bolt and washer inserted
in the front side of the cabinet.
5.5 Plumbing
Process water from a pressurized pipe flows into the monitor via a ¼”
push to connect fitting. The sample is analyzed by the sensor inside
the cabinet and discharged to drain as shown in Figure 5.12.
IMPORTANT: If the UVM5000 was supplied with the Dual Feed or
Auto Clean option, be sure to review the manual(s) that were supplied
with those optional devices before plumbing the system.
A shut off valve must be installed to allow the flow to the monitor to be
shut off when servicing is required. A flow control valve is also
recommended to regulate the flow to 0.3 –1.0 L/min. A simple needle
valve is often used if pressure is somewhat consistent.
Figure 5.10: Cabinet mounting
Figure 5.12: Analyzer plumbing overview
Figure 5.11: Sample bolt and
washer for attachment

Chemtrac UV254 Monitor –UVM5000 v 2.1
Chemtrac, Inc. 12
There are two push-in fittings on the side of the cabinet labeled IN and
OUT as shown in Figure 5.13.
1. Connect ¼” OD flex tubing from the process to the IN-push
connector on the monitor.
2. Connect another piece of ¼” tubing to the OUT port on the monitor
and divert the line to the drain.
IMPORTANT: The test water must be allowed to flow unrestricted to the
drain so that no significant water pressure occurs inside the analyzer.
The maximum pressure rating for the monitor is 20 PSI.
Figure 5.13: Plumbing ports

Chemtrac UV254 Monitor –UVM5000 v 2.1
Chemtrac, Inc. 13
5.6 Turbidity and Filtration
Depending on the application, the role of turbidity can be
treated either as a part of the measurement, or as an
interference in the measurement.
For example, a UV disinfection application will generally
require a transmittance measurement that includes the
effects of both dissolved organics and light blocking
particulate, whereas an organics monitoring application will
often require a measurement of the organics isolated from
the light blocking effects of particulate.
Because of this, Chemtrac’s monitors can include an
optional 550 nm turbidity compensation measurement.
Since 550 nm light is not significantly sensitive to organic
material but is sensitive to light blocking particulate, the
550-nm turbidity compensation measurement can provide
an isolated measurement of turbidity that allows this
turbidity component to be extracted from the 254-nm
measurement. This results in a measurement of organics
material independent of turbidity and particulate in the
water. The same results can also be achieved by removing
light blocking particulate from the sample stream through
filtration.
5.6.1 Turbidity Compensation (Optional)
Optional turbidity compensation can be added to any
UV254 analyzer. Turbidity compensation allows for
sampling without filtration in water with turbidity levels
below ~60 NTU. Above 60 NTU, a 50-200-micron filter
should be installed prior to sampling. If 50-micron is not
sufficient to obtain 60 NTU on the filter effluent, a 20-micron
filter should then be added. Refer to menu item Turbidity
Comp. in Section 9, Menu Structure, to enable the turbidity
compensation feature.
5.6.2 Filtering
All UV254 analyzers without turbidity compensation can
obtain an accurate reading of dissolved organic matter at
a turbidity level below ~10 NTU. If the sample water has
turbidity levels that fluctuate above 10 NTU, a 50-micron
filter should be installed prior to sampling. Should 50-
micron not be sufficient to obtain 10 NTU on the filter
effluent, a 20-micron filter should then be added.

Chemtrac UV254 Monitor –UVM5000 v 2.1
Chemtrac, Inc. 14
5.7 Electrical Connections
The 24 VDC power is supplied to the UVM5000 by means
of a DC power adapter that is plugged into a wall outlet of
100-240 VAC 50/60 Hz. The two 24 VDC wires from the
adapter are run through the connector in the bottom of the
monitor. The black wire is connected to terminal #11 (-)
and the red wire (+) is connected to terminal #12, as
shown in Figure 5.14.
Both 24 VDC power and communication lines feed into the
monitor via one ¾” electrical conduit fitting on the bottom
of the monitor and must be connected to the terminal block
on the main control board.
5.8 4-20 Ma Connections and Dry Contacts
Primary communication is provided by a 4-20mA
sourcing current loop output. RS-232 is also included to
allow direct connection to a PC COM port if desired. A
configurable digital output / dry contact is also
available. These provide the operator with alarms for
operator configured UVT/UVA set-points and system
failure alarms. Dry contact connections are from
terminals #5 & #6. The 4-20 mA output connections are
from negative terminal #3 and positive terminal #4.
Dual Feed Connection –For the dual feed option, a
second pair of 4-20 mA output connections are from
negative terminal #1 and positive terminal #2. This
output signal is for the water stream 2.
Automatic Chemical Clean Connection - Power to
the optional Automatic chemical clean system is
provided at connector terminals #9 and #10, which run
to the left terminal block on the circuit board in the
chemical clean cabinet. Matching the correct polarity is
important. The chemical clean logic is through
connector terminals #7 & #8, which run to the right terminal
block on the circuit board in the chemical clean cabinet.
Polarity is not important.
Note: Terminal numbering from left to right
Figure 5.14: Power connections
Table 4: Main Terminals
1
Stream 2 4-20mA –(dual feed option only)
2
Stream 2 4-20mA + (dual feed option only)
3
4-20mA –
4
4-20mA +
5
Dry Contact Out
6
Dry Contact Out
7
Clean Control Out
8
Clean Control Out
9
24VDC Out –(Black) (for use with Auto Clean)
10
24VDC Out + (Red) (for use with Auto Clean)
11
24VDC In - (Black)
12
24VDC In + (Red)

Chemtrac UV254 Monitor –UVM5000 v 2.1
Chemtrac, Inc. 15
6 Start-up
After the monitor has been installed as described in the Installation section, operation of the monitor is very
straight-forward.
6.1 Start-up Instructions
1. Inspect the inside of the monitor to ensure all packing material (which may restrict moving parts inside
the monitor) has been removed.
2. Ensure the 24 VDC power wires are securely attached to the correct corresponding terminals. Do not
plug the monitor in at this time.
3. After making sure the flow rate has been set to 0.3 –1.0 L/min and the drain is unrestricted and not
kinked, open the inlet valve to allow test water to flow through the monitor and check for any leaks in the
flow cell, piping, and fittings for at least 10 minutes before proceeding to the next step. Ensure there are
no bubbles flowing through the flow cell and no water droplets are on the inside of the monitor.
4. Plug in the power supply. Display screen will read “Initializing.”
5. Calibrate your Analyzer. Measurements are not assumed to be accurate until the analyzer is calibrated.
See Section 8, Zeroing (Calibration).
6. Configure the monitor to your application, i.e. enter warning and alarm set points, dry contact, 4-20mA
set-up, data logging. See Section 9, Menu Structure.
IMPORTANT: In areas of high humidity, the UVM5000 door must remain closed for a minimum of three
hours to allow for the dehumidifier to dry the air inside the enclosure. (Refer to Section 13). If you
receive a Humidity alarm while calibrating, the door may not have been closed long enough. Wait until
the alarm is removed, and then start calibration again.
7 Operator Interface
1. Menu Button –Press to access menu.
2. Indicator Light
3. Zero Button –Press to calibrate.
4. Up/Down Buttons –Cycle through the menu.
5. Enter Button –Press to access menu options.
3
4
5
1
2
4
Figure 7.1: Operator interface

Chemtrac UV254 Monitor –UVM5000 v 2.1
Chemtrac, Inc. 16
8 Calibration (Zeroing)
The monitor must be calibrated before accurate UVT/ UVA data can be read. Two methods for calibration can
be used:
•Zero monitor to DI or RO water reference of 100% UVT
•Zero monitor to a known water value
The first method is using 100% transparency as the standard by which the monitor is zeroed, whereas the
second method uses a known transparency. Both are accurate, but the second method allows for greater
accuracy because the expected measured values are presumably clustered around the known value instead of
falling within a wider range in the measurement scale.
8.1 Using RO or DI Water Method
Carry out these steps using a fresh supply of DI or RO water:
1. Close the monitor door and secure both door clamps.
2. Make sure the monitor is powered up.
3. Shut off the water supply to the monitor if not already
done.
4. Disconnect the ¼” supply tubing at the inlet connection
on the monitor.
5. Fill the supplied wash bottle with DI/RO water and
connect the ¼” bottle tubing to the inlet connection on
the monitor.
6. Hold a finger over the small vent hole in the wash
bottle cap, as shown in Figure 8.1.
7. Squeeze the bottle to get the DI water to flow through
the monitor.
8. Once the fluid starts to flow remove finger from the
vent hole and place bottle on top of the monitor, as
shown in Figure 8.2. The fluid should continue to flow
through the monitor. If it stops go back to step 6.
9. The LCD display should display a UVT or UVA reading
(depending on display mode).
10. Let about half the DI water run through the monitor
before pressing the Zero button. Use the down arrow
to select “Zero to DI Water”. Then press “Enter” and
the monitor will calibrate itself to 100% in UVT mode
or 0.000 in UVA mode.
11. The monitor has now been calibrated to DI/RO water.
Disconnect the wash bottle hose from the inlet of the
monitor.
12. Connect the supply line to the monitor and open the
valve to start the flow running.
Figure 8.1: Setting up flow
Figure 8.2: Bottle on top of cabinet

Chemtrac UV254 Monitor –UVM5000 v 2.1
Chemtrac, Inc. 17
8.2 Using Known Water Method
Carry out these steps:
1. Press the Zero button on the monitor. The Calibration menu appears.
2. Scroll down to ‘Custom Zero’ using the down arrow button. Press Enter.
3. A default value is displayed in the ‘New UVT:’ field (in this example, 75.0).
4. Press the up arrow to increase the number above 75.0 or the down arrow to decrease the number
below 75.0. When you have keyed in the number of known water transparency, press Enter.
Note that if you only know your UVA value then this can be converted to UVT using the formula:
UVT = 100 * 10(-UVA)
5. The monitor is now calibrated to the correct value.

Chemtrac UV254 Monitor –UVM5000 v 2.1
Chemtrac, Inc. 18
9 Menu Structure
MENU ITEM
DESCRIPTION
AVERAGING
On: 1 Off: 0
Average
Press ‘Enter’ then up/down to select running average for last 10 readings (Default = 0: Off)
UVT/UVA MODE
0 : UVT
1 : UVA
2 : Crltn.
Select
Press ‘Enter’ then up/down to select UVT, UVA, or Correlation mode (Default = 0: UVT)
SETPOINTS
UVT Warning
Press ‘Enter’ then up/down to select UVT warning set point (Default = 75)
UVT Alarm
Press ‘Enter’ then up/down to select UVT alarm set point (Default = 50)
UVA Warning
Press ‘Enter’ then up/down to select UVA warning set point (Default = 0.20)
UVA Alarm
Press ‘Enter’ then up/down to select UVA alarm set point (Default = 0.30)
Crltn. Warning
Press ‘Enter’ then up/down to select the correlation warning set point (Default = 160)
Crltn. Alarm
Press ‘Enter’ then up/down to select the correlation alarm set point (Default = 200)
4-20mA SETUP
4mA UVT
Press ‘Enter’ then up/down to select 4mA UVT reading for scaling (Default = 0)
20mA UVT
Press ‘Enter’ then up/down to select 20mA UVT reading for scaling (Default = 100)
4mA UVA
Press ‘Enter’ then up/down to select 4mA UVA reading for scaling (Default = 0)
20mA UVA
Press ‘Enter’ then up/down to select 20mA UVA reading for scaling (Default = 1)
4mA Crltn.
Press ‘Enter’ then up/down to select 4mA correlation reading for scaling (Default = 0)
20mA Crltn.
Press ‘Enter’ then up/down to select 20mA correlation reading for scaling (Default = 200)
SECONDARY DATA
Lamp 1
Displays the lamp output after it passes through the flow cell 1 cm position
Water 1
Displays the water output after it passes through the flow cell 1 cm position
VIS 1
Displays the raw VIS as it passes through the flow cell 1 cm position
Lamp 2
Displays the lamp output after it passes through the flow cell 2 cm position
Water 2
Displays the water output after it passes through the flow cell 2 cm position
VIS 2
Displays the raw VIS as it passes through the flow cell 2 cm position
Temperature
Displays temperature inside cabinet –Celsius
Humidity
Displays the relative humidity inside cabinet –RH
Status Code
Displays status code for system diagnostics
DRY CONTACT SETUP
See Set Alarms
0: Nothing
1: Alarm
Select
Press ‘Enter’ then up/down to select 0 or 1 to turn on/off dry contact (Default = 0: Nothing)

Chemtrac UV254 Monitor –UVM5000 v 2.1
Chemtrac, Inc. 19
MENU ITEM
DESCRIPTION
CLEANING SYSTEM
Enable Clean
Press ‘Enter’ then up/down to select 0 or 1 to turn on automatic cleaning system if
supplied (Default = 0)
Reset Clean
Press ‘Enter’then up/down to select 0 or 1 to reset fluid alarms after refilling fluid
(Default = 0)
Force Clean
Press ‘Enter’ then up/down to select 0 or 1 to force the cleaning system to begin a
cleaning cycle (Default = 0)
Pumping Time
Operator configurable. Enter a number between 90 and 180 seconds.
CLEAN FREQUENCY
0: No Cleaning
1: 4 hours
2: 12 hours
3: 24 hours
4: 3 days
5: 1 week
6: 2 weeks
7: 1 month
Select
Press ‘Enter’ then up/down to select cleaning frequency 0 - 7 (Default = 4: 3 days)
ROTATION
On: 1 Off: 0
Select
Press ‘Enter’ then up/down to turn on/off the rotating arm (Default = 1: On)
REF POSITION
*Factory settings
Steps
Press ‘Enter’ then up/down to change motor alignment, increasing the # adjusts the
position clockwise
RS-232 DATA LOG
Setup
Baud Rate: 9600
Fixed parameters for RS-232 logging
Parity : none
Fixed parameters for RS-232 logging
Stop Bits : 1
Fixed parameters for RS-232 logging
Flow Ctrl : none
Fixed parameters for RS-232 logging
Data for Log
Add:1 Remove:0
Sensors
Press ‘Enter’ then up/down to select all lamp and water sensor data (Default = 0)
Temp/Humid
Press ‘Enter’ then up/down to select cabinet temp and humidity data (Default = 0)
UVT
Press ‘Enter’ then up/down to select UVT data (Default = 1)
UVA
Press ‘Enter’ then up/down to select UVA data (Default = 0)
Crltn.
Press ‘Enter’ then up/down to select correlation data (Default = 0)
Status
Press ‘Enter’ then up/down to select status code for alarms & diagnostics (Default = 0)
* Factory setting - unit specific value set at factory. Value can be located on the label on the inside of the cabinet
door.
