Chenzhu CZ2077 User manual

CZ.CZ2277.11(S)E-4.1/16.11
5
4
1
2
1
3
2
5
4
(1).The isolators adopt screw terminals.
(2).The wires are single or multiple cables with a cross section area of
(3).The length of bared wires is about 8mm,locked tightly by M3 bolt.
2
0.5mm 2 ～2.5mm .
Connections
Installation
Isolator is designed for mounting on 35mm DIN guide rail.
(1).Make the upside of the isolator locked into the guide rail;
(2).Push the downside of the isolator in the rail.
W 4mm≤
2 2 0.5mm S 2.5mm≤ ≤
82 2
mm L 10mm≤ ≤
Wire
Wire
CZ2077
CZ2177
CZ2277
Isolator
User Manual
(1).Insert a screwdriver (its edge length≤6mm)into the downside metal
lock of the isolator;
(2).Push the screwdriver upwards,then prize the metal lock downwards;
(3).Take the isolator out of the guide rail.
Disassembly
(1) Every product has been tested strictly before delivery.If users find
any abnormality,please contact the nearest agent or our company.
(2) In 5 years from delivery date,if the product performs abnormally
under normal use conditions,we will repair it for free.
Add: Building 6, 201 Minyi Road, Caohejing Hi-Tech Park
Songjiang New Industrial Park, Shanghai 201612, P.R. China
Tel : [phone] Fax : [phone]
Email：[e-mail]
http://www.chenzhu-inst.com
Please read the instruction manual carefully before use the product,
and please safekeeping.
Please check whether the product type on the package accords
to the ordering contract;
Read this manual carefully before installation or using. If there is
anything unclear, please dial technic support hotline-400 881 0780;
Supply voltage is 24VDC, 220VAC is forbidden;
Users are not allowed to dismantle or repair the barrier otherwise
it will induce malfunction.
Caution
Maintenance

CZ2077
CZ2177
CZ2277
6
7
6
5
7
+
-
+
RL
-
DCS PLC、
-
+
RL
3(+ )
4(- )
5(+ )
6(- )
7(- )
6
5
7
24V DC
Ue
mV
7
6
+
-
7(+ )
6(- )
3(+ )
4(- )
+
RL
-
Ue
5(+ )
6(- )
3(+ )
4(- )
7(- )
Ue
1 2 3
Summarize Operation Conditions
(1). The air should not contain any medium corrupting the coat of
chrome,nickel and silver.Moreover,violent quiver and impact or any cause
of electromagnetic induction (such as big current or spark,etc.)must be
avoided when using.
(2). Operating temperature: -20℃~+60℃
(3). Storage temperature: -40℃~+80℃
(4). Relative humidity: 10%~90%
Application
Outline dimensions
92.4mm×97.7mm×7.6mm
2-wire
RTD
3-wire
RTD
4 20mA~
4 20mA~
DCS PLC、
24V DC
4 20mA~
DCS PLC、
24V DC
mV TC
2-wire
RTD
3-wire
RTD
TC
Note:
1.3-wire RTD system input, as far as possible to ensure equal three wire
resistance value.
2.terminals 6 and 7 must be connected when 2-wire RTD inputs.
Specification
Number of channel: 1
Supply voltage: 9~30V DC
Input: “Input signal and range list”
Note: 1.”%” of output accuracy is relative to the setting range, should
take a bigger of relative error and absolute error as the output accuracy
in application.
2. RTD input, allow max wire resistance 50Ω(3-wire);
3. TC input, transfer accuracy not contain cold junction compens-
ation error;Every increase in compensation wire 100Ω, cold end error
increases 0.2 ℃;
4. RTD type B input, the lower limits of temperature range must be
greater than 680℃, to meet the accuracy specifications.
5. mV signal has to be customized.
Output: Current: 0/4~20mA; Load resistance: RL≤
Alarm indication:
Lower limit overflow alarm, output current ≈3.8mA;
Upper limit overflow and breakage alarm, output current ≈20.8mA
(Notes: breakage alarm current＜4mA or other special requirements, be
customized)
Temperature drift: 0.01%F.S./℃
Cold junction compensation: ±1℃(Compensation range: -20℃~+60℃)
Intensive installation: ±3℃
Response time: Reach 90% of final value in 1s
Power supply protection:
Protect the barrier form reverse supply voltge destroy
Electromagnetic compatibility:According to GB/T 18268(IEC 61326-1)
Dielectric strength:
1500V AC;1minute(among power supply input and output )
Insulation resistance:
≥100MΩ;500V DC(among power supply,input,output and the shell)
Weight: Approx.45g
Suitable is apparatus:
2-/3-wire thermal resistance, thermal couple and mV signal
(Ue-9)/0.021
Loop-powered isolator, converts thermal resistance, thermal couple,
and mV signal field into 4~20mA current for driving load. It has sensor
breakage alarm indicator function. TC input has cold junction
compensation function. It is intelligent, indexing number of TC and range
can be configured through computer.
CZ2077: RTD input; CZ2177: TC input; CZ2277: RTD, TC input
T
E
J
-200℃～+400℃
-200℃～+900℃
-200℃～+1200℃
K
N
R
S
B
TC
mV
-200℃～+1372℃
-200℃～+1300℃
-40℃～+1768℃
-40℃～+1768℃
+320℃～+1820℃
-100mV～+100mV
Pt100
Cu50
Cu100
-200℃～+850℃
-50℃～+150℃
-50℃～+150℃
50℃
50℃
50℃
50℃
50℃
500℃
500℃
500℃
10mV
20℃
20℃
20℃
Type Range Min.span Accuracy
1℃/0.2%
40uV/0.2%
0.4℃/0.2%
0.4℃/0.2%
0.4℃/0.2%
3℃/0.2%
1℃/0.2%
1℃/0.2%
1℃/0.2%
1℃/0.2%
3℃/0.2%
3℃/0.2%
RTD
Configuration software EasyConfig
EasyConfig is configuration software. Based on the Windows operating
system, the software is easy to use for its friendly interface and the use of
USB interface. The parameters such as the sensor type and range scope
could be set in by users the software.
Version of operating system: Windows XP and above version
Hardware interface: USB interface
Dedicated adapter: USBCOM-MINI(dedicated USB to RS-232 serial
connection)
