Chess MYMESH-HBSP Dimensions

Mymesh Product Sheet
Connect any light, anywhere.
MYMESH-HBSP
Ceiling High Bay (Spot) Passive Infra Red (PIR)
Occupancy Detector & Photocell
(Input: 100-240 Vac 50/60Hz)
This MYMESH-HBSP High Bay (Spot Detection) Lighting
Control can be mounted directly onto solid ceilings or
onto a range of diff erent mounting boxes. Confi gurable
for any room occupancy style, via the Mymesh App.
Installation:
Please read these instructions before installing the
product.
NOTE: MYMESH-HBSP is compatible with Mymesh
commissioning tools.
To be installed by a competent person with reference
to BS 7671 or equivalent local standards. If in doubt
consult a qualifi ed electrician.
• Plan where the NOTE: MYMESH-HBSP is to be
located (see diagram 1). Switch off supply and check
for hidden cables and pipes.
• The MYMESH-HBSP should be connected as shown
in diagram 2:
L - Live in. N - Neutral in.
• Knockout or drill the appropriate holes on the
mounting plate for attaching the plate to the ceiling
or back box (if applicable). Feed cables through
the appropriate (side or rear) entry hole. Screw the
back mounting plate to the ceiling or back box via
the mounting holes. Wire the cables into the sensor
head block terminal. Push the sensor head onto the
mounting plate and align the side clips with the slots
on the sensor heads.
Operation:
To check the operation of the MYMESH-HBSP:
• Turn on the supply then after 20 seconds if the sensor
has recognised movement of a person within its zone
of detection the integral red LED on MYMESH-HBSP
will stay illuminated for 4 seconds before the red LED
turns off .
• Thereafter, every time movement is detected
by MYMESH-HBSP the integral red LED will stay
illuminated for 4 seconds.
The control also features adjustable time out (time
lag) control and daylight threshold control which are
confi gured via the Mymesh App.
Precautions:
• Do not place the MYMESH-HBSP near heat sources,
fans or in ventilated ceiling voids.
• MYMESH-HBSP can be wired in parallel (sharing the
same Live and Neutral).
• Do not place close to, or positioned such that, any
light source points directly into the MYMESH-HBSP.
• Ensure wires and cables are securely held within the
connection terminals.
• The MYMESH-HBSP should be protected by a 5 or 6
Ampere mcb or fuse.
• Disconnect the MYMESH-HBSP from the circuit
before performing insulation testing of the wiring
circuit.
Status LED blinking sequence:
See diagram 4 overleaf.
Normal: Both LED’s off .
Identifi cation of device: Red LED blinks.
16/04/20 DAT0064 MYMESH-HBSP (Issue 01)

Chess Wise B.V. | Richard Holkade 8A | 2033 PZ Haarlem | The Netherlands
http://chess.nl | inf[email protected] | Tel: [phone]
Technical details:
INPUT
Voltage: 100 - 240Vac
Frequency: 50/60Hz
Max. mains current: 20mA
Standby current: 14mA
RADIO TRANSCEIVER
Operating frequencies: 2.4... 2,480 GHz
Max. output power: +4 dBm
LUX PARAMETERS
Range: 5 - 2000 lux
OPERATING CONDITIONS
Note: The temperature diff erence between the detection target
and the background must be at least 4 °C.
Ambient temperature: -20... +40 °C (lout 20mA)
Storage temperature: -25... +75 °C
Max. relative humidity: 0... 80%, non cond.
CONNECTORS
Terminal block Wire size: 0.5mm2- 2.5mm2solid or stranded
Wire strip length: 6-7mm
Tightening torque: 0,4 Nm/4 Kgf.cm
MECHANICAL DATA
Dimensions: 63mm x 91mm x 91mm
Weight: 110g (unpacked)
Degree of protection: IP20
Protection class: Built-in Class 2
Material (casing) Flame-retardant polycarbonate
Finish / Colour Matt /White (RAL 9003)
Protection class: Built-in Class 2
CONFORMITY AND STANDARDS
EMC emission:
EN 301 489-1 V2.2.0,
EN 301 484-3,
EN 55032: 2015,
EN61000-3-2: 2014,
EN61000-3-3: 2013
EMC immunity:
EN 301 489-1 V2.2.0,
EN 301 484-3
Environment:
Complies with WEEE and RoHS directives
CB scheme:
IEC60669-1:1998,
IEC60669-1:1998/AMD1:1999,
IEC60669-1:1998/AMD2:2006,
IEC60669-2:2002,
IEC60669-2-1:2002/AMD1:2008
Radio:
EN 300 440
5 YEAR WARRANTY
MYMESH-HBSP comes with a 5 year
warranty from the date of manufacture
and is CE marked.
Suggested typical wiring
N
L
230 Vac
5A or 6A MCB
or fuse
L
N
N
L
L - Live in. N - Neutral in.
Two neutral and two live terminals
are available for easy ‘loop in’ and
‘loop out’ connection.
DIAGRAM 1:
Detection
DIAGRAM 2:
Wiring:
DIAGRAM 3:
Dimensions:
DIAGRAM 4:
Status LED:
MYMESH-HBSP: Technical Specifi cations
Up to 5m
diameter
Up to 3m
NARROW
DETECTION (ND)
Mounting height
up to 12m
Perspective view -
ceiling mounted
Up
to
15m
SPOT
DETECTION (SP)
Mounting height
up to 20m
Perspective view -
ceiling mounted
Up to 28m
diameter
WIDE
DETECTION (WD)
Mounting height
up to 14m
Perspective view -
ceiling mounted
RESET ZONE
(behind moulding). Magnet
to be placed over the Reset
Sticker for reprovisioning.
STATUS LED.
Normal: Both LED’s off.
Identification of device:
Red LED blinks.
plan side
63
90
90
76
