GENERALINFORMATION
0-6
Oncethecodenumberofthelockisobtainedlookup
thisnumberina keycuttingbook.
Allsidebarlocks(excepttrunk)furnishedtothefield
bytheParts'Departmentareuncoded,thatis,theyare
furnishedwithouttumblers,springsorspringretainers,
thesepartsareservicedseparately.Thetumblerscome
infivedifferentdepths,indicatedbynumbers.
Thesidebarlockshavesixtumblerpositions,andin
lookingupthecuttingcode,thefollowingmaybeusedas
anexample.Afterkeycodenumberisdetermined,either
fromkeyorfromnumberstampedonlockcylinderrefer
toyourcodebookandrecordthekeycuttinginformation
asfollows:
KeyofLock
CodeNumber
0V11
CuttingorTumbler
positionfromhead
oflock
KeyCutting
CodeNumerical
545431
123456
NOTE:
Keyblanksusedforignitionanddoor
locksarestampedwithan"A"whilerearcom-
partmentandgloveboxblanksarestampedwith
a"B".
Thenumberthatiswrittenabovethecuttingortumbler
positionindicateseachdifferenttumblerwhichistobe
droppedintoeachtumbierslotofthelock.
Incaseswherea codebookisnotavailable,thedia-
gramshownonFigure19maybeusedtodeterminethe
tumblersrequiredtoassembleanuncodedlockcylinder.
1.
Laythekeyonthediagram(fig.19)withbottomof
keyflushwithedgeofthedrawing,headandpoint
carefullylinedup.
2.
Readthecodeinnumbers12345fromtheheadofthe
keytotheendfrompositions1 to6 inclusive.As
eachdepthisdeterminedwritethatnumberinthe
blankspaceprovidedabovethepositionnumbers
(1-2-3-4-5-6).
3.
Withkeyproperlylinedupondiagram,allcutsthat
showinthefirstsectionaremarked
"1"
J
4.
Cutsthatfallinthefirstblacksection,mark"2".
5.Cutsthatfallinthefirstwhitesection,mark"3".
6.Cutsthatfallinsecondblacksection,mark"4".
7.Cutsthatfallinthesecondwhitesection,mark"5".
Afterthenumbershavebeendeterminedandwritten
abovethecuttingpositionsthelockcylindershouldbe
assembledasfollows.
LockCylinderAssembly—RefertoFigure20
1.
Holdcylinderwithheadofcylinderawayandstarting
•...attheheadofthecylinder,insertthetumblersin
theirproperslotsintheordercalledforbythe
code,ribbedsidetowardyouandlongpointdown.
2.
Afteralltumblersareinplace,checkforcorrect-
nesswiththecode.Thenpresstumblersdownwith
onefinger.
3.
Insertonetumblerspringinthespaceprovided
aboveeachtumbler.
CAUTION:Ifthespringsaretangled,donot
pullthemapart—unscrewthem.
4.
Reversethelockcylindersothattheheadofthe
cylinderisnowtowardyou.Insertthespringre-
tainersothatoneofitssixprongsentersintoeach
ofthespringsandthetwolargeendprongsslideinto
theslotsateitherendofthecylinder.Pressthe
retainerdownwithonefinger.
5.Tocheck,insertproperkeyandiftumblersarein-
stalledproperlythesidebarwillbeallowedtodrop
down.Ifbardoesnotdropdown,removethekey,
springretainer,springsandtumblersandreas-
semblecorrectly.
NOTE:
Ifthetumblershavenotbeenassembled
correctlyandnotaccordingtothecode,the
tumblerscanberemovedfromthecylinderby
holdingitwiththetumblerslotsdown,pulling
thesidebaroutwiththefingersandjarringthe
cylindertoshakethetumblersout.Thispro-
cedureisnecessarybecauseafterthetumblers
havebeenpresseddownintothecylinderthey
areheldintheirslotsbythecrossbar.
6.Ifaftercheckingitisfoundthatthelockisas-
sembledproperly,removekeyandplacecylinderin
INSERTING
TUMBLERCHECKING
WITHCODE
STAKING
POINTS
NSERTING
TUMBLERSPRINGS
INSERTING
SPRINGRETAINER
Fig.
19—TumblerRequirementDiagram
Fig.
20—AssemblingLockCylinder
CHEVROLETCHASSISSERVICEMANUAL
