Congratulations on your purchase of a Chevrolet Corvette. Please read this information and your Owner
Manual to ensure an outstanding ownership experience. Note that your vehicle may not include all the
features described in this booklet. Keep this booklet with your Owner Manual for easy reference.
DRIVER INFORMATION
Instrument Panel . . . . . . . . . . . . . . .2
Instrument Panel Cluster . . . . . . . . .3
Driver Information Center (DIC) . . .4
KEY ESS ACCESS & PUSHBUTTON
START
Keyless Access Transmitter . . . . . .4
Opening the Doors . . . . . . . . . . . . . .5
Starting and Stopping Your
Engine ........................5
eaving the Vehicle . . . . . . . . . . . . .5
Opening and Closing the
Hatch/Trunk ....................5
ossofPower ..................6
MasterKey.....................6
PERFORMANCE & MAINTENANCE
Mobil 1®MotorOil ...............7
Extended Mobility Tires (EMT) . . . .7
Tire Pressure Monitor . . . . . . . . . . . .7
Selective Ride Control . . . . . . . . . . .8
Active Handling and Traction Control
Systems .......................8
1st–4th Shift Feature . . . . . . . . . . . .8
6-Speed Paddle Shift
with Automatic Modes . . . . . . . . . . .9
PremiumFuel ..................9
BrakeNoise....................9
AUDIO SYSTEMS
RDS Radio Functions . . . . . . . . . . .10
XM™ Satellite Radio . . . . . . . . . . . .10
Audio Steering Wheel Controls . . .10
Auxiliary Input Jack . . . . . . . . . . . .11
oadingaCD..................11
C IMATE CONTRO S
Automatic Climate Control . . . . . . .11
Defogging ....................12
CONVENIENCE
OnStar
®
......................13
Head-Up Display (HUD) . . . . . . . . .13
Personalization Features . . . . . . . .14
Passenger Air Bag Status
Indicator......................15
AutoSignal ...................15
Automatic Headlamp Control . . . .15
Interior ight Control . . . . . . . . . . .16
SeatControls .................16
Window Indexing . . . . . . . . . . . . . .16
TOP OPERATION
CoupeTop ....................17
Convertible Power Top . . . . . . . . . .17
Convertible Manual Top . . . . . . . . .18
OWNER INFORMATION
Opening the Hood . . . . . . . . . . . . .18
Car Wash Guidelines . . . . . . . . . . .19
Z06Features ..................19
Roadside Assistance . . . . . . . . . . .20
MyGM ink....................20

A. Head-Up Display (HUD) Controls
(if equipped)
B. Turn Signal/Multifunction Lever C. Instrument Cluster D. Windshield Wiper/Washer Lever E. Driver Information Center Controls F. Air Outlets
. Hazard Warning Flashers Button H. Horn I. Audio Steering Wheel Controls
(if equipped)
J. Pushbutton Start K. Shift Lever
L. Traction Control/Active Handling
Button
M.Climate Controls
N. Audio System/Navigation Controls
(if equipped)
O. love Box
etting to Know Your Corvette
2
Instrument Panel
See Section 3 of your Owner Manual.
DRIVER INFORMATION
A D E F G
HIJ K MN O
B C
L

3
See Section 3 of your Owner Manual.
A B C E I L N O P QTS
R
GH
Instrument Panel Cluster
Your vehicle’s instrument panel is
equipped with this cluster or one
very similar to it. The instrument
panel cluster includes these key
features:
A. Engine Coolant Temperature
age
B. Engine Oil Pressure age C. Lights On Reminder Light D. Security System Light E. Malfunction Indicator Lamp
(Check Engine Light)
F. 1st–4th Shift Indicator (manual
transmission only)
. Tire Pressure Warning Light
H. Tachometer
I. DIC Display J. Turn Signal Indicators
K. High Beam Indicator L. Speedometer M.MPH or km/h Indicator N. Brake Warning Light O. Traction Control System
Warning Light
P. Antilock Brake System
Warning Light
Q. Safety Belt Reminder Light
R. Air Bag Readiness Light
S. Voltmeter
T. Fuel age
DF MJ K
Note: The instrument panel cluster is
designed to let you know about many
important aspects of your vehicle’s
operation. It is important to read your
Owner Manual and become familiar
with the information being relayed to
you by the lights, gages and indicators,
as well as what action can be taken to
ensure safety and to prevent damage.

etting to Know Your Corvette
4
Driver Information Center (DIC)
The DIC informs you of the status of
many of your vehicle’s systems and is
used to display driver personalization
features and warning/status messages.
The display is located at the bottom of
the instrument panel cluster.
The following DIC controls are located
on the instrument panel to the right of
the steering wheel.
(Fuel): Press this button to display
fuel information.
(Gages): Press this button to
display engine gage information and tire
pressure.
TRIP: Press this button to display the
odometer, trip information and engine
oil life.
OPTION: Press this button to scroll
through the personalization features that
are available on your vehicle.
RESET: Press this button to reset
system functions when displayed or to
acknowledge messages on the DIC.
This button is also used to select
personalization features within Options.
Warnings and Messages
If a problem is sensed in one of your
vehicle’s systems, a warning or
message will appear in the DIC display.
After a warning or message appears,
press the RESET button to clear the
display screen for further use.
Remember, pressing RESET only
makes the message disappear; it does
not resolve the problem.
Check Engine or Other Warning
ights with OnStar®(if equipped)
If your Check Engine light, or any other
warning message appears, you can
push the blue OnStar button and speak
to a live advisor. OnStar Advisors can
access certain diagnostic information
and can tell you how serious the
problem is, what you should do about it,
or can contact a dealer or Roadside
service for you. Refer to the OnStar
Owner uide for details.
See Section 3 of your Owner Manual.
Note: Your vehicle’s warnings and
messages provide critical information
that can prevent damage to your
vehicle. Review your Owner Manual to
become familiar with the information
displayed and the action required.
Keyless Access Transmitter
Your Corvette features
Keyless Access and
Pushbutton Start. You
can keep the Keyless
Access transmitter in
a pocket or purse
and operate the doors,
trunk and ignition.
The transmitter
communicates with the Corvette’s
computer system via antennas.
See Section 2 of your Owner Manual.
KEYLESS ACCESS AND
PUSHBUTTON START

5
Opening the Doors
To open the
doors, simply
touch the pad
located at the
rear edge of each
door. Once the
pad is pressed,
the doors unlock
and open if the
Keyless Access
transmitter is within three feet of the door.
See Section 2 of your Owner Manual.
Starting and Stopping
Your Engine
To Start the Engine:
1. Depress the brake
pedal on automatic
transmission-
equipped vehicles
or the clutch pedal
on manual
transmission-
equipped
vehicles.
2. Press the top of the Start button,
located on the instrument panel to the
right of the steering wheel.
The engine will start if the Keyless
Access transmitter is in the car.
To Stop the Engine:
1. Move the shift lever to Park (P) on
automatic transmission-equipped
vehicles or to 1st or Reverse (R)
on manual transmission-equipped
vehicles.
2. Press and hold the Off/ACC button
(the bottom part of the Start button)
for one second.
See Section 2 of your Owner Manual.
eaving the Vehicle
Open the door by pressing the button at
the front of the armrest. When exiting
the vehicle, take the Keyless Access
transmitter with you. You can lock your
vehicle using one of three methods:
• Lock the doors with the power door
lock switch located on the door panel,
step out, and close the door.
• Press the Lock button on the
transmitter after you step out of the
vehicle.
• Program your vehicle for Passive
Locking, covered in this booklet under
Personalization Features.
See Section 2 of your Owner Manual.
Opening and Closing the
Hatch/Trunk
Your Corvette provides three convenient
ways of opening the hatch/trunk:
• Touch the button located above the
license plate (the Keyless Access
transmitter must be within three feet
of the button).
• Press the Trunk Release button locat-
ed to the left of the steering wheel.
• Press the Trunk Release button on
the Keyless Access transmitter.
See Section 2 of your Owner Manual.

etting to Know Your Corvette
6
If the Transmitter Battery Is Weak:
1. Place the transmitter in the glove box
transmitter pocket with the buttons
facing toward the passenger side of
the vehicle.
2. Press the brake pedal with the
vehicle in Park (P) (with an automatic
transmission), or press the clutch
pedal (with a manual transmission).
3. Press the Start button. The vehicle
will start.
The transmitter battery should be
replaced as soon as possible. The
Driver Information Center may display
a FOB BATTERY LOW message.
See Section 2 of your Owner Manual.
oss of Power
oss of Vehicle Electrical Power
If your vehicle has lost battery power,
you can open the driver’s door manually.
If Outside the Vehicle:
1. Insert your master key into the lock
cylinder located above the rear
license plate and turn to open the
trunk.
2. Manually lift the trunk lid.
3. Pull the door release handle (A)
located on the driver’s side of the
trunk.
The driver’s door can now be opened.
If Inside the Vehicle:
• Pull the door
release handle (B)
located on the floor
next to the seat.
oss of Keyless
Access Transmitter
Battery Power
Under normal use,
the battery in your
transmitter should last about three
years. If the transmitter battery becomes
weak, it may cause the Driver
Information Center to display a NO
FOBS DETECTED message when you
try to start the vehicle.
The master key
is stored inside
the Keyless
Access
transmitter. To
remove the
master key, push
the small button
near the bottom
end of the transmitter and pull out the
key.
See Section 2 of your Owner Manual.
Master Key
B
A

The Tire Pressure Monitor alerts you
when a significant reduction in pressure
occurs in one or more of your vehicle’s
tires by illuminating the (low tire
pressure) warning light on the instrument
panel cluster. The low tire pressure
warning light will remain on until you
correct the tire pressure.
A CHECK LOW TIRE PRESSURE
message may also appear on the DIC
(if equipped).
Correcting the Tire Pressure
When the low tire pressure warning light
illuminates, you must fill the tire to the
proper tire inflation pressure (just as you
must refuel the vehicle when the low
fuel warning light illuminates). The Tire
and Loading Information label shows the
correct inflation pressure for the tires
when they’re cold. “Cold” means your
vehicle has been sitting for at least three
hours or driven no more than one mile.
You can temporarily remove the DIC
message by acknowledging it with your
DIC controls. However, at the next
vehicle start-up, the DIC message will
reappear if the tire pressure has not
been corrected.
During cooler conditions, the low tire
pressure warning light may appear when
the vehicle is first started and then turn
off as you start to drive the vehicle. This
could be an early indicator that your tire
pressures are getting low and need to
be inflated to the proper pressure.
See Section 5 of your Owner Manual.
7
PERFORMANCE & MAINTENANCE
Mobil 1®Motor Oil
Your Corvette comes factory-filled with
Mobil 1®with Super Syn motor oil.
Corvette’s computer system monitors
the life of the oil to inform you when it
needs to be changed.
To view the remaining oil life, press the
TRIP button repeatedly until Oil Life
appears in the DIC display. The oil life
monitor is programmed to correspond to
the attributes of Mobil 1 with Super Syn.
If you use any motor oil other than
Mobil 1 or equivalent synthetic oil, the
oil life monitoring system will not be
accurate.
Whenever your oil is changed, press
and hold the RESET button while Oil
Life is displayed in the DIC display to
reset the oil life monitor. The system will
reset to 100% and calculate when the
next oil change is required.
See Section 5 of your Owner Manual.
Extended Mobility Tires (EMT)
The Corvette is equipped with Run-Flat
oodyear Extended Mobility Tires (EMT)
that eliminate the need for a spare. The
tire design enables safe function during
and after loss of pressure for some
distance at a moderate speed. The
shorter the distance that you drive with
loss of pressure, the better the chance
that the tire can be repaired.
As soon as possible, contact Roadside
Assistance for the nearest authorized
M or run-flat tire servicing facility and
have the tire inspected.
See Section 5 of your Owner Manual.
Note: The Tire Pressure Monitor can
alert you about low tire pressure, but it
doesn’t replace normal monthly tire
maintenance.
Tire Pressure Monitor
(if equipped)

etting to Know Your Corvette
8
Active Handling and Traction
Control Systems
The Active Handling
and Traction Control
Systems help you
maintain directional
control during most
driving conditions
and limit wheelspin.
When the system is working, the Active
Handling message is displayed in the
DIC. You may also feel or hear the
system working.
• Press the Active Handling and
Traction Control Systems button
( ), located on the console, once
to turn off the Traction Control
System.
• Press twice to activate the
Competitive Driving Mode.
• Press and hold to turn off the
Active Handling and Traction Control
Systems.
Selective Ride Control
(if equipped)
The Selective Ride Control system
provides reduced impact harshness,
improved road isolation, improved high-
speed stability and handling response,
and better control of body ride motions.
To select the desired suspension setting
at any time, use the control knob located
on the center console.
Tour: Use for normal city and highway
driving. This setting provides a smooth,
comfortable ride.
Sport: Use where road conditions or
personal preference demand more
control. This setting provides more “feel,”
or response, to the road conditions.
See Section 4 of your Owner Manual.
1st–4th Shift Feature
(Manual Transmission)
The 1st–4th Shift Feature helps you
get the best possible fuel economy. A
1st–4th shift light will come on when the
following conditions are met:
• Engine coolant temperature is higher
than 169°F (76°C),
• You are going 15 to 19 mph (24 to 31
km/h), and
• You are at 21 percent throttle or less.
When the 1st–4th shift light comes
on, you can only shift from First (1) to
Fourth (4) instead of First (1) to
Second (2). You must complete the shift
into Fourth (4) to turn off this feature.
After shifting to Fourth (4), you may
downshift to a lower gear if you prefer.
See Section 2 of your Owner Manual.
Note: Forcing the shift lever into
any gear except Fourth (4) when the
1st–4th shift light comes on may
damage the transmission.
When turned off, the Active Handling
System and Traction Control Systems
light will come on, a chime will sound
and the Traction System and Active
Handling–Off message will be displayed
in the DIC.
• To turn on the Active Handling and
Traction Control Systems, press
again.
The system also will reset to On each
time the vehicle is started. Chevrolet
recommends that Active Handling and
Traction Control be left on.
See Section 3 of your Owner Manual.

9
Your vehicle's engine was designed to
use premium unleaded gasoline. See
your Owner Manual for information on
fuel use for your particular vehicle.
See Section 5 of your Owner Manual.
6-Speed Paddle Shift with
Automatic Modes
Automatic Modes
The familiar automatic transmission
shift positions have been replaced with
PRNDS. Drive (D) is the conventional
automatic shift mode optimized for
smooth shifts. The Sport (S) mode
also can be operated in a full automatic
mode with firmer shifts delivering
enhanced performance, but only if the
manual paddle shifters on the steering
wheel are not used.
Manual mode is selected by using the
manual paddle shifters in the Sport (S)
mode, which puts the driver in control of
gear selection.
Sport Mode (S)
Place the shift
lever in the
Sport (S) mode to
shift gears using
the paddle
shifters. Push
either paddle to upshift to the next
higher gear. Squeeze either paddle
behind the steering wheel spokes to
downshift to the next lower gear. The
current gear will be displayed in the
DIC on the instrument cluster or the
Head-Up Display (HUD) (if equipped).
If the current vehicle speed is too low
when requesting a higher gear or is too
high when requesting a lower gear, the
shift will not occur and an X over the
gear display will indicate that the
requested gear was denied.
Starting from a Stop
In the Sport mode, the transmission will
automatically downshift as the vehicle
slows down. From a stop, it will start in
second gear. It may also be started in
third gear if necessary, such as when
starting on slippery roads. Commanding
the vehicle to start up in fourth gear or
higher will be denied.
As vehicle speed increases, the
transmission will stay in the current gear
until the paddle is pushed to upshift.
If the upshift is not commanded by
pushing a paddle, the vehicle speed will
be limited in order to protect the engine.
See Section 2 of your Owner Manual.
Premium Fuel
Brake noise may occur under certain
weather or operating conditions with
your performance braking system. This
brake system is designed for best
performance using semi-metallic brake
pads. Brake noise is normal and does
not affect system performance.
See Section 4 of your Owner Manual.
Brake Noise

etting to Know Your Corvette
10
RDS Radio Functions
Your audio system is equipped with a
Radio Data System (RDS). RDS
features are available for use only on
FM stations that broadcast RDS
information. RDS relies on receiving
specific information from these stations
and will work only when the information
is available. With RDS, the radio can:
• Seek stations broadcasting the type
of programming you select. Press the
CAT button and turn the Tune knob to
select the desired category. Press SEEK
to search for the category selected.
• Receive announcements concerning
local and national emergencies.
• Display messages from radio stations.
• Seek stations with traffic
announcements.
When you tune to an RDS station, the
station name and call letters will appear
on the display along with the frequency.
RDS stations may also provide the time
of day, a program type (PTY) for current
programming and the name of the
program being broadcast.
To view the RDS time, if available, press
and hold the hour (H) and minute (M)
buttons.
RDS Messages
When using RDS, the following
messages may appear on your vehicle’s
audio system display:
A ERT!: Alert warns of local or national
emergencies. You will hear the
announcement, even if the volume is
muted or a CD is playing. You will not be
able to turn off ALERT! announcements.
INFO (Information): If the current
station has a message, the Information
icon will illuminate; press this button to
view the message.
AUDIO SYSTEMS TRAF (Traffic): Press this button to find
a station that broadcasts traffic
announcements. Once a station is
found, TRAF will appear on the display.
When a traffic announcement comes on,
you will hear it. Press SEEK to find the
next station that broadcasts traffic
information. To deactivate the traffic
function, press the TRAF button again.
See Section 3 of your Owner Manual.
XM™ Satellite Radio (if equipped)
XM™ Satellite Radio offers more than
170 channels of digital-quality sound
that goes wherever you go — coast to
coast. XM displays song title, artist or
entertainment genre by pressing the
(Information) button.
On equipped radios, two additional
listening bands are available: XM1 and
XM2. To access these bands, press the
BAND button until XM1 or XM2 appears
on the display.
After a three-month trail period,
activation and service subscription fees
apply. Service is based in the
continental U.S. and Canada.
For more information, visit XM online
at www.XMradio.com or call
1-800-852-XMXM (9696).
See Section 3 of your Owner Manual.
The following audio controls are located
on the steering wheel:
+ – (Volume): Press the plus or minus
button to increase or decrease the
volume.
(Seek/Scan): Press the up or
down arrow to go to the next or previous
Audio Steering Wheel Controls

11
oading a CD (if equipped with
the Multiple-Disc CD Player)
To oad a Single CD:
•
Press and release the Load button ( ).
• Insert a CD partway into the slot,
label side up. The CD changer will
pull the CD in. Once loaded, the CD
will begin to play automatically.
To oad Multiple CDs:
• Press and hold for two seconds.
A beep will sound and LOAD ALL
DISC will be displayed.
• When INSERT CD # appears on the
display, place a CD partway into the
slot, label side up. The CD changer
will pull the CD in. Once the disc has
been loaded, INSERT CD # will be
displayed again, indicating the next
CD may be loaded. Follow the
prompts to load up to six CDs. If the
radio is on, the last CD loaded will
begin to play automatically.
• When loading less than six CDs,
press the button to cancel the
loading function.
See Section 3 of your Owner Manual.
radio station or,
when a CD is
playing, to the next
or previous track.
Press and hold
either arrow for
two seconds to
scan radio
stations.
1–6 (Preset
Stations): Press this button to go to the
next preset radio station..
See Section 3 of your Owner Manual.
Note: If you add any label to a CD,
insert more than one CD into the slot at
a time, or attempt to play scratched or
damaged CDs, you could damage the
CD player. When using the CD player,
use only CDs in good condition without
any labels, load one CD at a time, and
keep the CD player and the loading slot
free of foreign materials, liquids or
debris.
Auxiliary Input Jack
There is an auxiliary input jack on the
upper right of the audio system faceplate.
You can connect an external audio
device using a 3.5 mm (1/8 inch) cable.
The radio will display AUX INPUT
DEVICE and play audio from that device.
Automatic Climate Control
CLIMATE CONTROLS
When automatic operation is active, the
system will automatically control the
inside temperature, the air delivery
mode and the fan speed.
To set Automatic operation:
Note: Input Jack not included on the
Navigation Radio.

etting to Know Your Corvette
12
control. To change the setting, press the
Mode button again and select one of the
following:
• Vent: This mode directs most of the
air to the instrument panel outlets.
• Bi-Level: This mode directs air to the
instrument panel outlets and the floor
outlets.
• Floor: This mode directs most of the
air to the floor outlets.
Temperature Control: The driver-side
knob changes the temperature on the
driver’s and passenger’s side of the
vehicle. Turn the knob clockwise or
counterclockwise to manually increase
or decrease the temperature inside your
vehicle.
The passenger-side knob changes the
temperature on the passenger’s side of
the vehicle.
See Section 3 of your Owner Manual.
Defogging
To clear fog or frost from your
windshield, press the Windshield
Defogger button ( ). This mode
directs most of the air to the windshield.
When operating, the Defog symbol
appears on the display.
Rear Window Defogger
To remove fog or frost from the rear
window, press the Rear Window
Defogger button ( ) to turn the rear
window defogger on. It will turn off
automatically or can be turned off by
pressing the button again.
The heated outside rearview mirrors
also will be cleared when is
pressed.
See Section 3 of your Owner Manual.
1. Press the AUTO button.
2. Adjust the temperature to a
comfortable setting between 60°F
(16°C) and 90°F (32°C).
If you set the system at the coolest or
warmest temperature setting, the system
will remain in manual mode at that
temperature and it will not go into
automatic mode.
Manual Operation
Off: Press the driver-side climate control
knob to turn off the climate control
system. This is the only setting that fully
shuts off the fan. The digital display will
show only the outside temperature.
(Recirculation): Press this button
to turn the Recirculation mode on or off.
When on, it keeps outside air from
coming in the vehicle.
Recirculation is not available when using
the Defog mode because outside air is
needed to reduce moisture inside the
vehicle.
A/C Off: Press this button to turn the
air conditioning system off.
For maximum cooling on hot days,
do the following:
1. Open the windows to let hot inside
air escape; then close them.
2. Select the Vent mode.
3. Select Recirculation mode.
4. Turn on the A/C.
5. Select the coolest temperature.
6. Select the highest fan speed.
(Fan): Press this button to
manually increase or decrease the fan
speed.
(Mode): Press this button to
manually lock in the current air delivery
setting and to stop the automatic mode

13
OnStar®(if equipped)
You have one year of OnStar service
from the date you purchased your new
vehicle with one of two service plans,
Safety & Sound, or the up-level
Directions & Connections plan. Push your
OnStar button to ask an Advisor for
details about the service plan you have
or to upgrade your plan. Your vehicle has
a wide variety of capabilities, from
Remote Door Unlock to Automatic Airbag
Notification to Hands-Free Calling and
most vehicles can get driving directions
using Turn-by-Turn Navigation.
Visit onstar.com. For more information
about OnStar, refer to the OnStar Owner
uide, call 1-888-466-7827, or push the
blue button.
See Section 2 of your Owner Manual.
CONVENIENCE
Head-Up Display (HUD)
(if equipped)
Your vehicle’s Head-Up Display (HUD)
projects a range of instrument panel
cluster information on the windshield,
reducing the need to look away from the
road. The information appears as an
image toward the front of the vehicle.
The information displayed by the HUD
includes the speedometer, turn signal
indicators, high-beam headlamps
indicator, tachometer, oil and temperature
gages, performance shift light, check
gages warning light and -force gage.
The following HUD controls are located
on the instrument panel to the left of the
steering wheel.
MODE: Press this button to scroll through
the three HUD modes of Street Mode,
Track Mode 1 and Track Mode 2.
PAGE: Press this button to customize the
HUD modes as they are being
displayed.
:Press the up or down arrow to
adjust the up-and-down position of the
HUD on the windshield. (It cannot be
adjusted side-to-side.)
+ – : Press the (+) button to increase the
brightness and the (–) button to decrease
the brightness of the HUD image.
Off: To turn off the HUD image, press
and hold the (–) button.
If you change your seat position, you
may have to readjust the HUD image for
proper viewing.
If the ignition is on and you cannot see
the HUD image, check to see whether:
• Something is covering the HUD unit
• The brightness is adjusted properly
• The HUD image is adjusted to the
proper height
• Ambient light is low in the direction
your vehicle is facing
• A fuse is blown (see Fuses and Circuit
Breakers in your Owner Manual)
• The windshield and HUD lens are
clean (do not spray glass cleaner
directly on the HUD lens)
• You are wearing polarized
sunglasses, which could make the
image harder to see
See Section 3 of your Owner Manual.

etting to Know Your Corvette
14
Flash at Unlock — Two short flashes of
all turn signals when unlocking the doors
or trunk. (Settings: YES/NO)
Flash at ock — One long flash of
all turn signals when locking the doors.
(Settings: YES/NO)
Fob Reminder — Horn sounds three
times when the driver’s door is closed
and a Keyless Access transmitter is
inside the vehicle. (Settings: YES/NO)
Passive Door ocking — Automatically
locks the doors when the ignition is
turned off, the Keyless Access
transmitter has been removed from the
vehicle and the doors have been closed
for eight seconds. (Settings:
OFF/SILENT/HORN)
Passive Door Unlock — Automatically
unlocks either the driver’s door or both
doors when the Keyless Access
transmitter is within three feet of the
door and the driver’s door touch pad is
pressed. (Settings: DRIVER/BOTH)
Auto Unlock — Automatically unlocks
either the driver’s door or both doors
when the shift lever is moved into
Park (P) (with an automatic
transmission), or the ignition is turned
off or is in Retained Accessory Power
mode (with a manual transmission).
(Settings: OFF/DRIVER/BOTH)
anguage — Select language in DIC
and Head-Up Display. (Settings:
English/ erman/French/Italian/Spanish/
Japanese)
Personalize Name — Show a name or
greeting on the DIC display when the
corresponding Keyless Access transmitter
is used or the memory button is
pressed. (Settings: YES/NO)
Personalization Features
Your Corvette offers personalization
capabilities that allow you to program
certain features to a preferred setting for
two different drivers. Personalization
Features will be recalled when the
vehicle senses the Keyless Access
transmitter as the door is opened, when
the Lock or Unlock button on the
transmitter is pressed, or when the
appropriate Memory button on the
driver’s door is pressed.
Available Personalization Features
include:
Auto Memory Recall (Automatic
Transmissions only) (if equipped) —
Driver’s seat, outside rearview mirrors
and telescopic steering wheel move to
memory-set driving position. (Settings:
YES/NO)
Auto Exit Recall (if equipped) —
Driver’s seat, outside rearview mirrors
and telescopic steering wheel move to
memory-exit position. (Settings:
YES/NO)
Approach ights — Activate parking
lamps, front fog lamps and back-up
lamps when you approach the vehicle.
(Settings: ON/OFF)
Twilight Delay — Parking lamps and
front fog lamps remain on with the
automatic headlamp system for a
selected period of time after exiting the
vehicle. (Settings: OFF/15S/30S/90S)

For your convenience, the headlamp
control can be left in the Auto mode for
automatic operation.
Automatic operation can be overridden
by selecting the Off/On position ( ).
To reset to Auto mode, turn the
headlamp control switch back to On and
then back to AUTO. Automatic mode will
also reset the next time the vehicle is
started if the switch is in the AUTO
position.
See Section 3 of your Owner Manual.
Automatic Headlamp Control
15
Personal Options Menu
To change the preferences of your
Personalization Features:
1. Make sure the vehicle is running
and in Park (P) (with an automatic
transmission) or in Neutral (with a
manual transmission) with the parking
brake set.
2. Press the OPTION button (the DIC
will display the current driver, 1 or 2,
for a few seconds and then display
the first Personal Options Menu item).
3. Use the RESET button to change the
setting of the displayed feature.
4. Press the OPTION button to scroll
through the list of features.
If a button is not pressed within 45
seconds, the DIC will exit the Personal
Options Menu.
Retained Accessory Power (RAP)
As an added convenience, Retained
Accessory Power (RAP) runs the
vehicle’s accessories (radio, power
windows, etc.) for a limited period of
time after the ignition is turned off.
See Section 2 of your Owner Manual.
Passenger Air Bag Status
Indicator
Your vehicle is equipped with a
Passenger Sensing System located in
the front passenger seat for the front
passenger frontal air bag, and a
passenger air bag status indicator
located on the rearview mirror.
See Sections 1 an 3 of your Owner Manual.
Auto Signal
The turn signal lever has two upward
and downward positions to signal a lane
change or a turn.
• To signal a lane change, raise or
lower the lever until the arrow on the
instrument panel cluster starts to
flash. Release the lever. The turn
signal will automatically flash three
times.
• To signal a turn, move the lever all of
the way up or down. The arrow on
the instrument panel cluster will flash.
The turn signal will stop flashing
when the turn is completed.
See Section 3 of your Owner Manual.

Heated Seats
(if equipped)
There is one
heated seat
control button
located on the
center console
for each seat.
Off: Press the
bottom of the
button ( )
to turn the
system off.
High: Press the top of the button once
to turn the system on high.
ow: Press the top of the button twice
to turn the system on low.
See Section 1 of your Owner Manual.
etting to Know Your Corvette
16
Seat Controls
The power seat controls are located on
the outboard side of the seat cushion.
Six-Way Power Seats
• Move the front of the control (A) up
or down to adjust the front of the seat
cushion.
• Move the rear of the control (A) up
or down to adjust the rear of the seat
cushion.
• Slide the control (A) forward or
rearward to move the entire seat.
Power umbar and Side Bolsters
(if equipped)
• Press the vertical lumbar switch (B)
forward to increase support and
rearward to decrease support.
• Pull the horizontal side bolsters
switch (C) up to move the wings of
the seatback in and push the switch
down to move the wings out.
Window Indexing
To provide a tight seal around each
door, the window will automatically lower
slightly when the door is opened and
then automatically rise fully when the
door is closed.
If battery power is disconnected, the
indexing feature must be initialized
after restoring power by performing the
following procedure:
1. Close the door.
2. Raise the window by pulling up the
switch.
3. Hold up the switch for three seconds
after the window is closed and then
release it.
4. Hold up the switch again for three
seconds and then release it.
See Section 2 of your Owner Manual.
AB
C
Interior ight Control
To adjust the brightness of the interior
lights, turn and hold the interior light
control knob located on the left side of
the instrument panel. Push the knob in
to turn the lights on or off.
See Section 3 of your Owner Manual.

17
Coupe Top
Your coupe has a removable roof panel.
Until you are sure you can remove the
panel alone, have someone help you.
To Remove the Top:
There are two latches on the front part
of the panel and one latch in the middle
rear of the panel.
1. Lower the windows.
2. Pull down and turn the front handles
to release the front latches.
3. To unlock the rear of the panel, press
the Latch Release button and pull
down the latch.
4. Lift the front edge of the panel up and
forward out of the vehicle opening.
Once removed, the roof panel should
always be stored properly in the rear
storage compartment. Place it in the
forward position in the stowage
receivers.
To Install the Top:
1. Make sure that the front handles and
the rear latch are in their opened
positions.
2. Place the rear edge of the roof panel
on the back of the roof opening,
aligning the roof panel pins with the
opening in the body weatherstrip.
TOP OPERATION 3. Lower the front edge of the roof
panel.
4. Turn the front handles to the closed
position and push up the rear latch
lever; then check that the roof panel
is securely installed.
See Section 2 of your Owner Manual.
Convertible Power Top
(if equipped)
If your vehicle has a convertible power
top, it can be lowered and stowed under
the tonneau cover behind the seats.
To ower the Convertible Power Top:
1. Start the engine.
2. Shift an automatic transmission into
Park (P) or shift a manual
transmission into Neutral. Set the
parking brake.
3. Make sure that the trunk is closed
and that the trunk partition is in the
fastened, upright position.
4. Unlock the convertible top front latch
by pulling and turning it clockwise.
The driver’s and passenger’s side
windows will lower automatically.
5. Push and hold the bottom of
the power convertible top button
located on the left side of the
instrument panel. A chime will sound
when the convertible top has lowered
completely.
Refer to your Owner
Manual for additional
information.
See Section 2 of your
Owner Manual.

etting to Know Your Corvette
18
OWNER INFORMATION
Opening the Hood
To Open the Hood:
1. Pull the handle below the instrument
panel on the driver’s side.
2. o to the side of the vehicle and pull
up on the rear edge of the hood, near
the windshield.
To close the hood, pull it down and close
it firmly.
See Section 5 of your Owner Manual.
Convertible Manual Top
(if equipped)
If your vehicle has a convertible manual
top, it can be lowered and stowed under
the tonneau cover behind the seats.
To ower the Convertible Manual Top:
1. Shift an automatic transmission into
Park (P) or shift a manual
transmission into Neutral. Set the
parking brake and turn off the
ignition.
2. Make sure the trunk is closed.
3. Unlock the convertible top front
latch by pulling it down and turning it
clockwise.
4. Lift the front edge of the top off the
windshield frame; then lift the rear
edge so it is vertical to the tonneau
cover.
5. Press the release button located
on the underside of the cover behind
the driver’s seat. This will unlatch the
tonneau cover and lower the driver’s
and passenger’s side windows. The
cover will not unlatch if the vehicle
alarm is turned on or the trunk lid is
open.
6. With the tonneau cover open, push
forward on the front edge of the
convertible top to allow the rear edge
of the top to move to its full-down
fully-stored position; then move the
top rearward to its fully stored
position.
7. Make sure the top is fully retracted,
and close the tonneau cover.
Refer to your Convertible Top
supplement for additional information.
See Section 2 of your Owner Manual.

19
Car Wash Guidelines
Automatic car washes are not
recommended. Some automatic car
washes will cause damage to your
vehicle, wheels, or convertible top, if
equipped.
If you drive your vehicle through an
automatic car wash that does not have
enough clearance for the undercarriage
and/or wide rear tires, you could
damage your vehicle. Verify with the
manager of the car wash that your
vehicle will fit before entering the car
wash. To avoid possible damage, use
touchless automatic car washes.
See Section 5 of your Owner Manual.
Z06 Features
Checking Engine Oil
Z06 models are equipped with a
high performance dry sump engine
lubrication system. This system
operates differently than a standard
engine lubrication system.
You should check your oil level only
after the engine has been thoroughly
warmed up and then shut off for at least
five minutes. This ensures that the oil
level reading obtained will be accurate.
Z06 models also require a special
procedure for changing the engine oil
and filter; refer to your Owner Manual.
Note: Do not read the oil level after
extended periods of vehicle inactivity,
as the level indicated will not be
accurate and may falsely indicate a low
level condition. Any oil added due to this
method of reading may cause the
engine to be over-filled and can lead to
engine damage.
Jump Starting the Battery
The battery of your Z06 is located in the
rear of the vehicle. You do not need
access to the battery for jump starting.
There are remote positive (+) and
negative (–) terminals located under the
hood for this purpose. Refer to your
Owner Manual for the locations of the
terminals.
See Section 5 of your Owner Manual.
Note: Improper jump starting could
result in costly damage to your vehicle
that would not be covered by your
warranty. Be sure to follow all of the
steps in your Owner Manual to safely
and properly jump start your vehicle.

etting to Know Your Corvette
20
15865986A
Roadside Assistance
My GM ink
1-800-CHEV-USA
(1-800-243-8872)
TTY Users: 1-888-889-2438
As the proud owner of a new Chevrolet
vehicle, you are automatically enrolled
in the Chevrolet Roadside Assistance
program. This value-added service is
intended to provide you with peace of
mind as you drive in the city or travel
the open road.
Chevrolet’s Roadside Assistance toll-free
number is staffed by a team of technically
trained advisors who are available
24 hours a day, 365 days a year. The
advisors can provide minor repair
information or make arrangements to
tow your vehicle to the nearest Chevrolet
dealer.
Chevrolet will provide the following
services for 5 years/100,000 miles, at
no expense to you:
• Fuel delivery
• Lockout service (identification
required)
• Tow to nearest dealership for warranty
service
• Flat tire assistance
• Jump start
In many instances, mechanical failures
are covered under Chevrolet’s
comprehensive warranty. However, when
other services are utilized, an advisor will
explain any payment obligations you
might incur.
The Chevrolet Owner Center at My
MLink is a complimentary service for
Chevrolet owners, a one-stop resource to
enhance your Chevrolet ownership
experience. Exclusive member benefits
include online service reminders, vehicle
maintenance tips, online owner manual,
special privileges and more. Sign up
today at www.mygmlink.com.
For prompt and efficient assistance
when calling, please provide the following
information:
• Location of the vehicle
• Telephone number and your location
• Vehicle model, year and color
• Vehicle mileage
• Vehicle Identification Number (VIN)
• Vehicle license plate number
Chevrolet reserves the right to limit
services or reimbursement to an owner or
driver when, in Chevrolet’s judgment, the
claims become excessive in frequency or
type of occurrence.
Roadside Assistance and OnStar®
(if equipped)
Push the OnStar button, the vehicle will
send your PS location to the OnStar
Advisor who will speak to you, assess
your problem, contact Roadside
Assistance and relay your exact location
so you get the help you need.
Certain restrictions, precautions and safety procedures apply to your vehicle. Please read your Owner
Manual for complete instructions. All information contained herein is based on information available at the
time of printing and is subject to change without notice. Copyright 2007 by M Corp. All rights reserved.
*15865986A*
