Chevrolet 2011 Camaro Assembly instructions

Review this Quick Reference Guide for an overview of some important features in your Chevrolet Camaro.
More detailed information can be found in your Owner Manual. Some optional equipment described in this
guide may not be included in your vehicle. For easy reference, keep this guide with your Owner Manual in
your glove box.
✦denotes optional equipment www.chevrolet.com

2
Turn Signal Lever/Driver
Information Center Controls
Driver
Information Center
Windshield
Wipers Lever
Hood
Release
Lever
Tilt/Telescopic
Steering Wheel
Lever
Audio Steering
Wheel Controls✦
Cruise
Control
Buttons
Exterior/Interior
Lamps Control
INSTRUMENT PANEL
Safety Belt
Reminder
Check Engine
Low Tire Pressure
Brake System
Warning
Antilock Brake
System Warning
Charging System
Oil Pressure
Airbag Readiness
Security
Fog Lamps
Cruise Control Set
Traction Control Off
StabiliTrak/Traction
Control Off
StabiliTrak/Traction
Control Warning
Lights On
Head-Up
Display
Controls✦

3
* The accessory power outlet does not operate once the key is removed from the ignition and the
driver’s door is opened.
Note: Refer to your Owner Manual to learn about the information being relayed by the lights, gauges
and indicators of the instrument cluster, as well as what to do to ensure safety and prevent damage.
See Instruments and Controls in your Owner Manual.
Climate Controls/
Heated Seat Buttons✦Audio
System
Auxiliary
Gauges✦
StabiliTrak
Button
Accessory Power
Outlet*
Hazard Warning Flashers Button/
Power Door Locks Button

4
REMOTE KEYLESS ENTRY TRANSMITTER
Unlock
Press to unlock the driver’s door only or all doors. The
unlock setting can be changed in the Vehicle Settings menu
by pressing the CONFIG button on the audio system.
Lock
Press to lock all doors. The driver’s door will not lock
if open.
Trunk
Press and hold to unlatch the trunk.
Vehicle Locator/Panic Alarm
Press and release to locate your vehicle. The turn signal
lamps will flash and the horn will sound.
Press and hold to activate the alarm. The turn signal lamps
will flash and the horn will sound until the button is pressed
again or the ignition is turned on.
Remote Vehicle Start✦
Use to start the engine from outside the vehicle.
REMOTE VEHICLE START✦
During a remote start, the vehicle’s climate control system will operate at the same setting
as when the vehicle was last turned off and, based on outside temperature, the heated
seats will turn on. The heated seats will turn off when the ignition is turned on.
Starting the Vehicle
1. Aim the Remote Keyless Entry transmitter at the vehicle. (Transmitter range depends
on operating conditions.)
2. Press and release the Lock button on the transmitter.
3. Immediately press and hold the Remote Start button for at least two seconds.
When the vehicle starts, the parking lamps will light and remain on while the engine is
running. The engine will continue running for 10 minutes.
4. Repeat these steps for a 10-minute time extension. Remote start can be extended
only once.
After a remote start, the ignition must be turned to the On position before driving.
Canceling a Remote Start
• Press and hold the Remote Start button until the parking lamps turn off.
Note: Several conditions will cause the Remote Vehicle Start feature not to operate, such as if the
key is in the ignition or the hood or doors are not closed.
See Keys, Doors and Windows in your Owner Manual.

5
DRIVER’S SEAT ADJUSTMENTS
HEAD-UP DISPLAY✦
A. Seat Adjustment
Move the horizontal control to move
the seat forward or rearward and to
raise, lower or tilt the seat.
B. Power Seatback Recline
Adjustment
Move the vertical control to recline or
raise the seatback.
A. Seat Adjustment
Move the lever up or down repeatedly
to raise or lower the seat.
B. Power Seatback Recline
Adjustment
Move the vertical control to recline or
raise the seatback.
Seat Position
Lift the front handle to slide the seat
forward or rearward.
4-Way Seat Adjustment
6-Way Power Seat Adjustment✦
OFF
Turn the knob fully counterclockwise to
turn off the display.
Brightness
Turn the knob to brighten or dim the
display.
PAGE
Press the PAGE button on the knob to
select one of three display formats.
Up/Down
Press the HUD up or down arrow button to
adjust the up/down position of the display
on the windshield.
See Instruments and Controls in your Owner Manual.
The Head-Up Display (HUD) projects a range of vehicle information on the windshield,
reducing the need to look away from the road.
HUD Controls
AB
BA

6
DRIVER INFORMATION CENTER
The Driver Information Center (DIC) on the instrument cluster displays a variety of vehicle
system information and warning messages.
DIC Controls A. MENU
Press to display the:
–Vehicle Information menu
(units, tire pressure, remaining oil
life, coolant temperature, speed
warning).
–Trip/Fuel menu (digital speed-
ometer, trip odometers, fuel range,
average fuel economy, average
vehicle speed, OnStar®Turn-by-Turn
guidance✦).
B.
Rotate the switch to scroll through the
items of each menu.
C. SET/CLR
Press to set or clear the displayed
menu item or warning message. Some
urgent messages cannot be cleared
from the DIC display.
Vehicle Personalization Some vehicle features can be customized
by using the controls on the audio system.
1. Press the CONFIG button (A) to enter
the Settings menu.
2. Turn the MENU/SELECT knob (B) to
highlight the Vehicle Settings menu;
press the knob to select it.
3. Turn the MENU/SELECT knob to high-
light desired menu item; press the knob
to select it.
4. Turn the MENU/SELECT knob to high-
light the desired selection; press the
knob to select it and move back to the
last menu.
5. Press the BACK button (C) to exit
each menu.
See Instruments and Controls in your Owner Manual.
B
CA
CB A

7
AUDIO SYSTEM
RADIO/
BAND
(FM, AM,
XM)
POWER/
VOLUME
INFO:
Display available
song information
FAV:
Display pages of
favorite radio stations
MENU/SELECT:
Tune radio stations and
open/select menus
CD/AUX:
Play a
CD or
portable
audio
device
PHONE:
Open the
Phone
menu
SEEK:
Previous
and Next
radio
station
CONFIG:
Open the
Settings
menu
BACK:
Move back
one level
in the
menus
TONE:
Open the
Tone menu
See Infotainment System in your Owner Manual.
Note: Once the key is turned off, the audio system will continue to work for 10 minutes or until the
driver’s door is opened. The audio system can be turned on with the vehicle off by pressing the
Power button. Any input will cause the system to operate for 10 minutes or until the Power button is
pressed again.

8
AUDIO SYSTEM
Note: Avoid extended searching for specific items or configuring system settings while driving.
Favorite Stations
Radio stations from all bands (AM, FM or XM) can be stored in any order on up to six
pages of favorites.
Setting Number of Favorite Pages
1. Press the CONFIG button.
2. Turn the MENU/SELECT knob to highlight the Radio Settings menu; press the knob to
select it.
3. Turn the MENU/SELECT knob to highlight Radio Favorites; press the knob to select it.
4. Turn the MENU/SELECT knob to select the desired number of favorite pages; press
the knob to select it.
Storing Favorite Stations
1. Tune in the desired radio station.
2. Press the FAV button to display the page where the station is to be stored.
3. Press and hold one of the six numeric pushbuttons until the station is heard, indicating
it is stored.
4. Repeat the steps for each pushbutton on each page.
Setting the Time
1. Turn on the radio.
2. Press the CONFIG button.
3. Turn the MENU/SELECT knob to highlight Time and Date Settings; press the knob
to select it.
4. Turn the MENU/SELECT knob to highlight the desired time or date item; press the
knob to select it.
5. Turn the MENU/SELECT knob to change the value; press the knob to confirm the
set value.
6. Press the BACK button to exit each menu.
Portable Audio Devices
A 3.5mm auxiliary input jack and, in select models, a USB port are located in the
center console.
A portable audio device connected to the auxiliary input jack can be controlled only by
using the portable device controls. To optimize speaker volume, fully increase the volume
level of the portable device.
Compatible devices connected to the USB port can be controlled by the audio system.
Not all devices may be supported. Use the MENU/SELECT knob and the audio steering
wheel controls to access various functions.
See Infotainment System in your Owner Manual.

9
AUDIO STEERING WHEEL CONTROLS✦
+ –Volume
Press + or – to increase or decrease
the volume.
Next/Previous
Rotate up or down to go to the next
or previous favorite radio station, CD
track, or MP3 file.
SRC Source
Press to select an audio source.
Push to Talk
Press to interact with the OnStar
or Bluetooth system.
End Call/Mute
Press to end or reject an OnStar
or Bluetooth call.
Press and hold to mute the vehicle
speakers.
BLUETOOTH®SYSTEM✦
The in-vehicle Bluetooth system allows users with a Bluetooth-enabled cell phone to make
and receive hands-free calls using the vehicle’s audio system, microphone and controls.
The Bluetooth-enabled cell phone must be paired with the in-vehicle Bluetooth system
before it can be used in the vehicle. Not all phones will support all functions.
Bluetooth audio streaming is also available with devices that support the following
Bluetooth profiles: A2DP version 1.2 and AVRCP version 1.0.
Visit www.gm.com/bluetooth for more information.
See Infotainment System in your Owner Manual.

10
Off/
Fan
control
Defrost
mode
Recirculation
mode
Driver’s heated
seat control✦Air conditioning
control Rear window
defogger
control
Passenger’s
heated seat
control✦
CLIMATE CONTROLS
Recirculation Mode
The recirculation mode can help to quickly cool the air inside the vehicle or prevent
outside odors from entering the vehicle. It is not available while the defog or defrost
mode is selected.
When the recirculation mode is used without air conditioning, the air humidity increases
and the windows may fog.
Maximum Cooling
1. Turn the temperature control to the MAX setting.
2. Press the Air Conditioning control button. The indicator will illuminate.
3. Turn the Fan control to the High setting.
See Climate Controls in your Owner Manual.
Temperature
control
Air delivery modes:
Vent
Bi-level
Floor
Defog
