Chevrolet Camaro 2014 Assembly instructions

Review this Quick Reference Guide for an overview of some important features in your Chevrolet Camaro.
More detailed information can be found in your Owner Manual. Some optional equipment described in this
guide may not be included in your vehicle. For easy reference, keep this guide with your Owner Manual in
your glove box.
www.chevrolet.com

2
Turn Signal Lever/Driver
Information Center Controls
Driver
Information Center
Windshield
Wipers Lever
Hood
Release
Lever
Tilt/Telescopic
Steering Wheel
Lever
Audio Steering
Wheel Controls
Cruise
Control
Buttons
Exterior/Interior
Lamps Control
INSTRUMENT PANEL
Safety Belt
Reminder
Check Engine
Low Tire Pressure
Brake System
Warning
Antilock Brake
System Warning
Charging System
Oil Pressure
Airbag Readiness
Security
Fog Lamps
Cruise Control Set
Traction Control Off
StabiliTrak/Traction
Control Off
StabiliTrak/Traction
Control Warning
Lights On
Head-Up
Display
ControlsF

3
* The accessory power outlet does not operate once the key is removed from the ignition and the
driver’s door is opened.
Refer to your Owner Manual to learn about the information being relayed by the lights, gauges and
indicators of the instrument cluster.
See In Brief in your Owner Manual.
Climate Controls/
Heated Seat ButtonsF
Infotainment
Touch ScreenF
Auxiliary
GaugesF
StabiliTrak
Button
Accessory Power
Outlet*
Hazard Warning
Flashers Button
FOptional equipment
ZL1 model shown

4
REMOTE KEYLESS ENTRY TRANSMITTER
FOptional equipment
POWER DOOR LOCKS
Press the power door Lock/ Unlock button, located on each door, to lock or
unlock all doors. An open door will not lock.
To open a locked door from inside the vehicle, pull the inside door handle to unlock the
door and then pull the handle again to open the door.
See Keys, Doors and Windows in your Owner Manual.
Unlock
Press to unlock the driver’s door.
Press again to unlock all doors.
Lock
Press to lock all doors. The driver’s
door will not lock when open if
the Unlocked Door Anti Lock
Out feature is turned on.
Vehicle Locator/Panic Alarm
Press and hold briey to locate
your vehicle. The turn signal lamps
will ash and the horn will sound.
Press and hold for three seconds to
activate the alarm. The turn signal
lamps will ash and the horn will
sound until the button is pressed
again or the ignition is turned on.
Trunk
Press and hold to unlock the trunk.
Note: The remote lock and unlock settings can
be changed in the Vehicle Settings menu by
using the audio system controls.
Remote Vehicle StartF
Press and release the Lock button
and then press and hold the button
until the turn signal lamps ash to start
the engine from outside the vehicle.
After entering the vehicle, turn the
ignition to the ON position.
• During a remote start,
the engine will run for
10 minutes.
• Press and hold the
button until the parking
lamps turn off to cancel a
remote start.
Note: Open Vehicle Settings
in the Conguration menu to
change the remote lock, unlock,
and remote start settings.
If the remote start heated seat option
is selected, the heated seat button indicators do
not illuminate and the temperature performance
of the unoccupied heated seat may be reduced
during the remote start. The heated seat turns
off when the ignition is turned on.
See Keys, Doors and Windows in your Owner Manual.

5
SEAT ADJUSTMENTS
HEAD-UP DISPLAYF
A. Seat Adjustment
Move the horizontal control to move
the seat forward or rearward and to
raise, lower or tilt the seat.
B. Power Seatback Recline Adjustment
Move the vertical control to recline or
raise the seatback.
A. Seat Adjustment
Move the lever up or down repeatedly
to raise or lower the seat.
B. Power Seatback Recline Adjustment
Move the vertical control to recline or
raise the seatback.
Seat Position
Lift the front handle to slide the seat
forward or rearward.
See Seats and Restraints in your Owner Manual.
6-Way Power Seat AdjustmentF
(Driver and Front Passenger)
OFF
Turn the knob fully counterclockwise to turn
off the display.
Brightness
Turn the knob to brighten or dim the
display.
PAGE
Press the PAGE button on the knob to
select one of the display formats.
Up/Down
Press the HUD up or down arrow button to
adjust the up/down position of the display
on the windshield.
The Head-Up Display (HUD) projects a range of vehicle information on the windshield,
reducing the need to look away from the road.
HUD Controls
4-Way Seat Adjustment
(Driver only)
FOptional equipment
See Instruments and Controls in your Owner Manual.
A B
BA

6
INFOTAINMENT SYSTEM
POWER/
VOLUME
PHONE:
Open the
Phone menu
SEEK:
Previous and Next
radio station or le
NAVF:
Map screen
DESTF:
Destination
Entry screen
SOURCE:
Select the
audio source
RPTF:
Repeat voice
guidance
MENU/SELECT:
Tune radio stations/
Open and select
menus
BACK:
Move back
one level in the
menus
See Infotainment System in your Owner Manual.
Note: Once the key is turned off, the audio system will continue to work for 10 minutes or until
the driver’s door is opened. The audio system can be turned on with the vehicle off by pressing the
Power button. Any input will cause the system to operate for 10 minutes or until the Power button
is pressed again.
Touch screen infotainment system
F
shown.
FOptional equipment
Refer to your Owner Manual for important safety information about using the infotainment system
while driving.
Applications:
Touch the
screen icon
to access the
application

7
INFOTAINMENT SYSTEM
Setting the Time
1. Touch the Time Display on the touch screenF.
2. Touch the + (plus) or – (minus) screen button to adjust the hours, minutes or date.
3. Touch the OK screen button to conrm the setting.
Storing Favorite Stations
Radio stations from all bands (AM, FM or XMF) can be stored, in any order, on up to six
pages of favorites.
1. Tune in the desired radio station.
2. Press and hold one of the six preset screen buttons until a beep is heard.
4. Repeat the steps for each desired station.
Portable Audio Devices
A 3.5mm auxiliary input jack and a USB portFare located in the center console.
An iPod®, iPhone®, MP3 Player, a USB ash drive or a USB mass storage device can
be connected to the USB port. Chevrolet MyLinkFwill read the device, build a list of
voice commands, and ll in missing song information and album graphics. Search for
music on-screen or by voice commands.
See Infotainment System in your Owner Manual.
CHEVROLET MYLINKF
MyLink uses a Bluetooth or USB connection to link to a compatible mobile device, such as
a smartphone, cell phone, USB ash drive or portable audio player/iPod®. MyLink enables
streaming audio through a smartphone and hands-free voice control. For assistance with
the MyLink system, contact Customer Assistance at 1-855-4-SUPPORT (1-855-478-7767)
or visit www.chevrolet.com/mylink.
PANDORA®Internet Radio
Listen to personalized radio stations based on favorite artists or genres.
Download the Pandora app to your smartphone. Restart the smartphone and sign in to
Pandora.
Create a station on your phone to listen to a customized song list in the vehicle.
Connect your smartphone/device to the system by Bluetooth or, for Apple devices,
by a USB cable.
Touch the Pandora icon on the touch screen to access Pandora. A slight delay may
occur when loading a song or changing a station.
Stitcher SmartRadio™
Stream favorite podcasts, radio shows and news to your vehicle.
Download the Stitcher app to your smartphone and then restart the smartphone.
Select a category to listen to.
If you like the station, touch the Star screen button to add it to your Favorites list.
See Infotainment System in your Owner Manual.
FOptional equipment

8
AUDIO STEERING WHEEL CONTROLS
Next/Previous
Rotate the thumbwheel up or down
to go to the next or previous favorite
radio station, CD track, or MP3 le.
Push to Talk
Press to answer an incoming call
or interact with the audio, Bluetooth,
or OnStar®system.
End Call/Mute
Press to end or reject a call.
Press and hold to mute the vehicle
speakers.
BLUETOOTH® SYSTEM
See Instruments and Controls in your Owner Manual.
+ –Volume
Press +or –to adjust the volume.
SRC Source
Press to select an audio source.
FOptional equipment
CHEVROLET MYLINKF
Natural Voice Recognition
Control the music source and make phone calls hands-free (after pairing your Bluetooth-
enabled phone) using the natural voice recognition system.
Pair a Phone
1. To use voice recognition, press the
Push to Talk button; after the beep,
say “Pair,” or
To use the touch screen, select Settings
> Bluetooth > Pair Device.
2. Start the pairing process on the phone.
Locate your vehicle name or MyLink on
the phone.
3. Enter the four-digit code that appears
on the touch screen into the phone or,
if a six-digit code appears on the phone,
conrm it on the touch screen.
4. If your phone prompts you to accept the
connection or phone book download,
click “yes” and always allow.
See Infotainment System in your Owner Manual.
• Phone(usingyourpairedphone):
Example command: “Call Amanda” or
“Dial 555-1212”
• MediaMusicDeviceSearch(when
connected to USB only):
Example command: “Play artist [name]”
See Infotainment System in your Owner Manual.
1. Press the Push to Talk button on
the steering wheel.
2. The radio will say “Say a command,”
followed by a beep.
3. Say what you want it to do.
• Radiocontrol:
Example command: “Tune FM 104.3”
Before using a Bluetooth-enabled device in the vehicle, it must be paired with the in-vehicle
Bluetooth system. Not all devices will support all functions. The pairing process is disabled
when the vehicle is moving. For more information, visit www.gmtotalconnect.com.

9
DRIVER INFORMATION CENTER
The Driver Information Center (DIC) on
the instrument cluster displays a variety
of vehicle system information and warning
messages.
A. MENU
Press to display the:
– Vehicle Information menu (units,
tire pressure, remaining oil life,
coolant temperature, speed warning).
– Trip/Fuel menu (digital speed-
ometer, trip odometers, fuel range,
average fuel economy, average
vehicle speed, OnStar®Turn-by-Turn
guidanceF).
– Performance menu (lap timer,
coolant temperature, battery voltage,
oil temperature, oil pressure).
B.
Rotate the thumbwheel to scroll through
the items of each menu.
C. SET/CLR
Press the button on the end of the lever
to set a menu item or clear a message.
Press and hold the button to reset a
menu item.
See Instruments and Controls in your Owner Manual.
1. On the touch screen infotainment
systemF, touch the Home screen
button.
2. Touch the Settings screen button.
3. Touch the Vehicle Settings screen
button; or turn the MENU/SELECT knob
(A) to highlight Vehicle Settings, and
then press the knob to select it.
4. Use the screen buttons to select the
desired menu item and setting; or turn
the MENU/SELECT knob to highlight
the desired menu item or setting, and
then press the knob to select it.
5. Press the BACK button (B) to exit
each menu.
See Instruments and Controls in your Owner Manual.
AB
VEHICLE PERSONALIZATION
Some vehicle features can be customized by
using the controls on the audio system.
FOptional equipment
C B A

10
Off/
Fan
control
Defrost
mode
Recirculation
mode
Driver’s
heated seat
controlF
Air conditioning
control
Rear window
defogger
control
Passenger’s
heated seat
controlF
CLIMATE CONTROLS
Recirculation Mode
The recirculation mode can help quickly cool the air inside the vehicle or prevent outside
odors from entering the vehicle. It is not available while the defog or defrost mode is
selected.
When the recirculation mode is used without air conditioning, the air humidity increases
and the windows may fog.
Maximum Cooling
1. Turn the temperature control to the MAX setting.
2. Press the Air Conditioning control button. The indicator will illuminate.
3. Turn the Fan control to the High setting.
See Climate Controls in your Owner Manual.
Temperature
control
Air delivery modes:
Vent
Bi-level
Floor
Defog
FOptional equipment

11
Automatic Headlamp System Off/On
AUTO Automatic Headlamp System
Parking Lamps
Headlamps
Fog LampsF
Press the knob to turn the fog lamps on or off.
Instrument Panel Brightness
Rotate and hold the thumbwheel to adjust the
intensity of the instrument panel lighting.
See Lighting in your Owner Manual.
HI High
LO Low
INT Intermittent
Rotate the band to increase or decrease the
delay between wipes.
OFF
Mist
See Instruments and Controls in your Owner Manual.
EXTERIOR/INTERIOR LIGHTING
WINDSHIELD WIPERS AND WASHER
Interior Lighting
Note: The ambient lightingFon the door
panels does not extend across the instru-
ment panel.
FOptional equipment
ULTRASONIC REAR PARKING ASSIST/REAR VISION CAMERA
F
Ultrasonic Rear Parking Assist
Detected objects are indicated by audible beeps when the vehicle is in Reverse.
The interval between beeps becomes shorter as the vehicle gets closer to an object.
The system operates at speeds less than 5 mph.
To turn the system On/Off, open the Collision Detection Systems menu under the
Vehicle Settings menu by using the audio system controls.
Rear Vision Camera
When the vehicle is in Reverse, a view of the area behind the vehicle appears on the
radio display.
See Driving and Operating in your Owner Manual.
Washer Fluid
Pull the lever toward you to spray
washer uid on the windshield.

12
Adjusting Cruise Control
Use the following switches to adjust or
cancel cruise control:
RES+ Resume/Accelerate
Rotate the switch up to resume a set
speed.
If the system is active, rotate the switch
up to increase speed.
SET– Set/Coast
If the system is active, rotate the switch
down to decrease speed.
Cancel
Press to cancel the cruise control
but retain the set speed in memory.
The cruise control set speed is erased
when cruise control or the vehicle ignition
is turned off.
See Driving and Operating in your Owner Manual.
Using Tap Shift
1. Move the shift lever to the
M (Manual) position. S (Sport
Mode) will be shown in the Driver
Information Center (DIC).
2. Press the paddles on the back of
the steering wheel toward you to
shift gears. Press the left (–) paddle
to downshift and the right (+) paddle
to upshift. The current gear selection
will be shown in the DIC and HUDF.
If current vehicle speed is too high or
too low for the requested gear, the shift
will not occur.
When coming to a stop, the transmis-
sion will automatically shift to 1st gear
(V6) or to 2nd gear (V8).
See Driving and Operating in your Owner Manual.
CRUISE CONTROL
AUTOMATIC TRANSMISSION TAP SHIFTF
Setting Cruise Control
1. Press the On/Off button. The
Cruise Control symbol will illuminate in
white in the instrument cluster.
2. When traveling at the desired speed,
rotate the SET– switch down to set the
speed. The Cruise Control symbol
will illuminate in green in the instrument
cluster.
The 6-speed automatic transmission
has a Tap Shift mode that allows you to
shift gears similar to a manual transmis-
sion. When using this feature, the vehicle
will have rmer shifting and sportier
performance.
FOptional equipment

13
MANUAL TRANSMISSION OPERATION
Turning Off Traction Control
Traction control should be turned off if the vehicle is
stuck and rocking the vehicle is required.
To turn off traction control, press the
StabiliTrak/Traction Control button.
The Traction Control Off light will illuminate.
Press the button again to turn on traction control.
See Driving and Operating in your Owner Manual.
STABILITRAK®/TRACTION CONTROL SYSTEMS
The 6-speed manual transmission (V8) includes a 1-to-4 shift feature that helps achieve
the best possible fuel economy.
The 1-to-4 shift light will turn on when, from a standstill, acceleration and vehicle speed
qualications are met. When the shift light is on, the transmission can be shifted only from
1st to 4th gear. Forcing the shift lever into any other gear may damage the transmission.
Note: When selecting Reverse, a swift motion to the left side (V6) or right side (V8) of the gear
pattern is required. When 1st (V6) or 5th (V8) is the desired selection, a slower motion toward the
gear is the proper method. When in Reverse (V6), an R illuminates in the DIC and a chime sounds.
See Driving and Operating in your Owner Manual.
COMPETITIVE MODE AND LAUNCH CONTROL (V8)
Note: Competitive Mode and Launch Control are recommended only for use during closed track
events and competitive driving venues. See your Owner Manual.
Competitive Mode
Competitive Mode is an optional handling mode.
To turn on the Competitive Mode, press the StabiliTrak/Traction Control button
twice quickly. Competitive Mode will be displayed in the Driver Information Center.
Press the button again to return to normal StabiliTrak/traction control operation.
Launch Control (V8 with Manual Transmission)
Launch Control is a form of traction control that optimizes wheelspin while launching the
vehicle. It is activated when the vehicle is at a standstill while in Competitive Mode.
When the accelerator pedal is pressed to the oor with the clutch engaged, the RPM
is limited to a predetermined level. Releasing the clutch while keeping the accelerator
pressed to the oor provides controlled wheelspin and acceleration.
See Driving and Operating in your Owner Manual.
The traction control system limits wheelspin, and the StabiliTrak stability control system
assists with directional control of the vehicle in difcult driving conditions. Both systems
turn on automatically every time the vehicle is started.

14
SUNROOFF
Vent/Open
Press the rear of the switch to the rst
detent to vent the sunroof.
Press the rear of the switch to the second
detent to express-open the sunroof.
Close
Press and hold the front of the switch to
close the sunroof.
CONVERTIBLE TOP OPERATIONF
Before operating the convertible top, park the vehicle, remove the tonneau cover from
the vehicle (if installed), make sure that the cargo shade (A) is in the extended, fastened
position with no objects above the shade, and that the trunk is closed.
Operate the Power Top
1. Start the engine, shift to Park or Neutral, and set the parking brake.
2. Pull and turn the front latch clockwise to unlock the top; pull and turn it counterclockwise
to lock the top.
3. Press and hold the Open switch (rear part of the switch) on the left side of the
overhead console to lower the top; press and hold the Close switch (front part of
the switch) to raise the top. The windows will automatically lower. A chime will sound
when the top is lowered completely.
Tonneau Cover Installation
1. Unfold and place the cover on the vehicle.
2. Attach the cords on each side of the cover to the
posts on the back seat rear panel.
3. Insert the forward tabs (B) under the trim on both
sides and push the outer rim and center of the
cover under the trim.
Loss of Vehicle Power
If the vehicle has lost power, the convertible top can
be raised manually by releasing pressure on the
hydraulic pump. Refer to your Owner Manual.
Note: Top will not operate in cold weather below 32°F (0°C).
See Keys, Doors and Windows in your Owner Manual.
B
A
See Keys, Doors and Windows in your Owner Manual.
FOptional equipment

15
Tire Pressure Monitor
The Low Tire Pressure warning light on the instrument cluster illuminates when one
or more of the vehicle’s tires is signicantly underinated. Fill the tires to the proper tire
pressures. The proper tire pressures for the vehicle are listed on the Tire and Loading
Information label, located below the driver’s door latch. Current tire pressures can be
viewed in the Driver Information Center.
Tire pressure is affected by cold weather and distance driven. If the low tire pressure
warning light illuminates when the vehicle is rst started in cooler temperatures and then
turns off as the vehicle is driven, check for the proper tire pressures.
Refer to your Owner Manual for additional information about normal monthly tire maintenance.
Tire Sealant and Compressor Kit
The tire sealant and compressor kit can be used to temporarily seal small punctures in
the tread area of the tire. The kit is located under the trunk oor. Refer to the tire inator kit
instructions for complete operating information.
Snow Tires
Your vehicle features rear-wheel drive and may be equipped with “summer” performance
tires that offer excellent handling on dry roads. However, during winter months, it is
recommended to switch to snow tires that will provide additional traction in poor weather
conditions. See your Chevrolet dealer for information about recommended snow tires.
See Vehicle Care in your Owner Manual.
TIRES
The vehicle battery is located below the trunk oor. Jump-start positive and negative posts
are located under the hood on the driver’s side of the vehicle.
See Vehicle Care in your Owner Manual.
ENGINE OIL LIFE SYSTEM
The Oil Life System calculates engine oil life based on vehicle use and displays Change
Engine Oil Soon on the Driver Information Center when it’s necessary to change the
engine oil and lter. The system should be reset to 100% only following an oil change.
See Vehicle Care in your Owner Manual.
BATTERY
WINDOW INDEXING
To provide a tight seal, the window will automatically open slightly when the door is opened
and then automatically close when the door is closed. If battery power is disconnected,
follow the Owner Manual procedure for initializing the indexing feature.
See Keys, Doors and Windows in your Owner Manual.

16
ROADSIDE ASSISTANCE
1-800-CHEV-USA TTY Users: 1-888-889-2438
(1-800-243-8872)
As the owner of a new Chevrolet, your vehicle is automatically enrolled in the Chevrolet
Roadside Assistance program for 5 years/100,000 miles, whichever occurs rst, at no
expense to you. This value-added service is intended to provide you with peace of mind as
you drive in the city or travel the open road.
Chevrolet’s Roadside Assistance toll-free number is staffed by a team of technically trained
advisors who are available 24 hours a day, 365 days a year, to provide minor repair informa-
tion or make arrangements to tow your vehicle to the nearest Chevrolet dealer.
Roadside Assistance and OnStar
If you have a current OnStar subscription, press the OnStar button and the vehicle will
send your current GPS location to an OnStar Advisor who will speak to you, assess your
problem, contact Roadside Assistance and relay your exact location so you will get the help
you need.
CHEVROLET OWNER CENTER
MYCHEVROLET AND ONSTAR® MOBILE APPS
The Chevrolet Owner Center, a complimentary service for Chevrolet owners, is a one-stop
resource designed to enhance your Chevrolet ownership experience. Exclusive member ben-
ets include online service reminders, vehicle maintenance tips, online owner manual and
special privileges. Sign up today at my.chevrolet.com.
22897946 A
!22897946!
Certain restrictions, precautions and safety procedures apply to your vehicle. Please read your Owner Manual
for complete instructions. All information contained herein is based on the latest information available at the
time of printing and is subject to change without notice. Copyright 2013 by General Motors. All rights reserved.
We recommend to always use ACDelco or genuine GM service parts.
The myChevrolet and OnStar RemoteLink mobile apps connect owners to
a variety of vehicle information and services, such as a searchable Owner
Manual, real-time fuel information and Roadside Assistance, as well as
enabling users to perform Remote Keyless Entry transmitter commands,
including locking and unlocking the doors and starting the vehicle.
An active OnStar account is required to use the OnStar mobile app. Visit OnStar.com
for more information. Download the mobile apps from your iPhone®or Android™ device’s
app store.
