Chevrolet MONTE CARLO 2005 User manual

Seats and Restraint Systems ........................... 1-1
Front Seats ............................................... 1-2
Rear Seats ............................................... 1-8
Safety Belts .............................................. 1-9
Child Restraints ....................................... 1-27
Airbag System ......................................... 1-46
Restraint System Check ............................ 1-55
Features and Controls ..................................... 2-1
Keys ........................................................ 2-2
Doors and Locks ....................................... 2-8
Windows ................................................. 2-12
Theft-Deterrent Systems ............................ 2-14
Starting and Operating Your Vehicle ........... 2-16
Mirrors .................................................... 2-29
OnStar
®
System ...................................... 2-32
HomeLink
®
Transmitter ............................. 2-33
Storage Areas ......................................... 2-37
Sunroof .................................................. 2-38
Vehicle Personalization ............................. 2-39
Instrument Panel ............................................. 3-1
Instrument Panel Overview .......................... 3-4
Climate Controls ...................................... 3-23
Warning Lights, Gages, and Indicators ........ 3-28
Message Center ....................................... 3-42
Driver Information Center (DIC) .................. 3-51
Trip Computer ......................................... 3-53
Audio System(s) ....................................... 3-54
Driving Your Vehicle ....................................... 4-1
Your Driving, the Road, and Your Vehicle ..... 4-2
Towing ................................................... 4-34
Service and Appearance Care .......................... 5-1
Service ..................................................... 5-3
Fuel ......................................................... 5-5
Checking Things Under the Hood ............... 5-10
Headlamp Aiming ..................................... 5-54
Bulb Replacement .................................... 5-54
Windshield Wiper Blade Replacement ......... 5-58
Tires ...................................................... 5-59
Appearance Care ..................................... 5-86
Vehicle Identification ................................. 5-95
Electrical System ...................................... 5-96
Capacities and Specifications ................... 5-104
Maintenance Schedule ..................................... 6-1
Maintenance Schedule ................................ 6-2
Customer Assistance and Information .............. 7-1
Customer Assistance and Information ........... 7-2
Reporting Safety Defects ........................... 7-10
Index ................................................................ 1
2005 Chevrolet Monte Carlo Owner Manual M

GENERAL MOTORS, GM, the GM Emblem,
CHEVROLET, the CHEVROLET Emblem, and the
name MONTE CARLO are registered trademarks of
General Motors Corporation.
This manual includes the latest information at the time it
was printed. We reserve the right to make changes
after that time without further notice. For vehicles first
sold in Canada, substitute the name “General Motors of
Canada Limited” for Chevrolet Motor Division whenever
it appears in this manual.
Keep this manual in the vehicle, so it will be there if it is
needed while you are on the road. If the vehicle is
sold, leave this manual in the vehicle.
Canadian Owners
A French language copy of this manual can be obtained
from your dealer or from:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207
How to Use This Manual
Many people read the owner manual from beginning to
end when they first receive their new vehicle. If this
is done, it can help you learn about the features
and controls for the vehicle. Pictures and words work
together in the owner manual to explain things.
Index
A good place to quickly locate information about the
vehicle is the Index in the back of the manual. It is an
alphabetical list of what is in the manual and the
page number where it can be found.
Litho in U.S.A.
Part No. 05MONTECARLO A First Edition
©
2004 General Motors Corporation. All Rights Reserved.
ii

Safety Warnings and Symbols
There are a number of safety cautions in this book. We
use a box and the word CAUTION to tell about things
that could hurt you if you were to ignore the warning.
{CAUTION:
These mean there is something that could hurt
you or other people.
In the caution area, we tell you what the hazard is.
Then we tell you what to do to help avoid or reduce the
hazard. Please read these cautions. If you do not,
you or others could be hurt.
You will also find a circle
with a slash through it in
this book. This safety
symbol means “Do Not,”
“Do Not do this” or
“Do Not let this happen.”
iii

Vehicle Damage Warnings
Also, in this manual you will find these notices:
Notice: These mean there is something that could
damage your vehicle.
A notice tells about something that can damage the
vehicle. Many times, this damage would not be covered
by your vehicle’s warranty, and it could be costly. But
the notice will tell what to do to help avoid the damage.
When you read other manuals, you might see
CAUTION and NOTICE warnings in different colors
or in different words.
There are also warning labels on the vehicle. They use
the same words, CAUTION or NOTICE.
Vehicle Symbols
The vehicle has components and labels that use
symbols instead of text. Symbols are shown along with
the text describing the operation or information
relating to a specific component, control, message,
gage, or indicator.
If you need help figuring out a specific name of a
component, gage, or indicator, reference the
following topics:
•Seats and Restraint Systems in Section 1
•Features and Controls in Section 2
•Instrument Panel Overview in Section 3
•Climate Controls in Section 3
•Warning Lights, Gages, and Indicators in Section 3
•Audio System(s) in Section 3
•Engine Compartment Overview in Section 5
iv

These are some examples of symbols that may be found on the vehicle:
v

✍NOTES
vi

Front Seats ......................................................1-2
Manual Seats ................................................1-2
Six-Way Power Seats .....................................1-3
Manual Lumbar ..............................................1-3
Heated Seats .................................................1-4
Reclining Seatbacks ........................................1-4
Head Restraints .............................................1-6
Seatback Latches ...........................................1-6
Easy Entry Seat .............................................1-7
Rear Seats .......................................................1-8
Split Folding Rear Seat ...................................1-8
Safety Belts .....................................................1-9
Safety Belts: They Are for Everyone .................1-9
Questions and Answers About Safety Belts ......1-13
How to Wear Safety Belts Properly .................1-14
Driver Position ..............................................1-15
Safety Belt Use During Pregnancy ..................1-21
Right Front Passenger Position .......................1-21
Rear Seat Passengers ..................................1-21
Rear Safety Belt Comfort Guides for Children
and Small Adults .......................................1-24
Safety Belt Extender .....................................1-26
Child Restraints .............................................1-27
Older Children ..............................................1-27
Infants and Young Children ............................1-29
Child Restraint Systems .................................1-33
Where to Put the Restraint .............................1-36
Top Strap ....................................................1-37
Top Strap Anchor Location .............................1-38
Lower Anchorages and Top Tethers for
Children (LATCH System) ...........................1-39
Securing a Child Restraint Designed for the
LATCH System .........................................1-41
Securing a Child Restraint in a Rear Seat
Position ...................................................1-41
Securing a Child Restraint in the Right Front
Seat Position ............................................1-44
Airbag System ...............................................1-46
Where Are the Airbags? ................................1-49
When Should an Airbag Inflate? .....................1-51
What Makes an Airbag Inflate? .......................1-52
How Does an Airbag Restrain? .......................1-52
What Will You See After an Airbag Inflates? .....1-53
Servicing Your Airbag-Equipped Vehicle ...........1-55
Restraint System Check ..................................1-55
Checking Your Restraint Systems ...................1-55
Replacing Restraint System Parts
After a Crash ............................................1-56
Section 1 Seats and Restraint Systems
1-1

Front Seats
Manual Seats
{CAUTION:
You can lose control of the vehicle if you try to
adjust a manual driver’s seat while the vehicle
is moving. The sudden movement could startle
and confuse you, or make you push a pedal
when you do not want to. Adjust the driver’s
seat only when the vehicle is not moving. If your vehicle has manual seats, lift the bar located
under the front of the seat to unlock it. Slide the seat to
where you want it and release the bar. Try to move
the seat back and forth to be sure the seat is locked
in place.
1-2

Six-Way Power Seats
If your vehicle has this feature, the control is located on
the outboard side of the front seats. To adjust the
seat do any of the following:
•Move the seat forward or rearward by sliding the
control to the front or the rear.
•Raise or lower the seat by sliding the control
up or down.
•Raise or lower the front portion of the seat cushion
by sliding the front of the control up or down.
•Raise or lower the rear portion of the seat cushion
by sliding the rear of the control up or down.
Manual Lumbar
If your vehicle has this feature, the knob is located on
the outboard side of the driver’s seat. Turn the knob
toward the front of the vehicle to increase lumbar
support. Turn the knob toward the rear of the vehicle to
decrease lumbar support.
1-3

Heated Seats
If your vehicle has this
option, the switches that
control seat temperature
are located on the
center console.
There are two settings, LO and HI.
Press LO to warm the seat to a lower temperature.
Press HI to warm the seat to a higher temperature.
To turn this feature off, move the switch to the center
position.
Reclining Seatbacks
Lift the lever to release the seatback, then move the
seatback to where you want it. Release the lever to lock
the seatback in place. Pull up on the lever without
pushing on the seatback and the seatback will move
forward.
1-4

But don’t have a seatback reclined if your vehicle is
moving.
{CAUTION:
Sitting in a reclined position when your vehicle
is in motion can be dangerous. Even if you
buckle up, your safety belts can not do their
job when you are reclined like this.
The shoulder belt can not do its job. In a
crash, you could go into it, receiving neck or
other injuries.
The lap belt can not do its job either. In a
crash the belt could go up over your abdomen.
The belt forces would be there, not at your
pelvic bones. This could cause serious internal
injuries.
For proper protection when the vehicle is in
motion, have the seatback upright. Then sit
well back in the seat and wear your safety belt
properly.
1-5

Head Restraints
Adjust your head restraint so that the top of the restraint
is closest to the top of your head. This position
reduces the chance of a neck injury in a crash.
Seatback Latches
There is a latch located
on the lower back of the
front seat that enables
the front seatback to
fold forward.
This allows more room for entry and exit of rear seat
passengers.
To fold the locked seatback forward, push the seatback
toward the rear and lift the latch. The seatback will
fold forward. The latch must be down for the seat to
work properly.
1-6

{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
press rearward on the seatback to be sure it is
locked.
Easy Entry Seat
The right front passenger seat is designed to make it
easy to get into and out of the rear seat.
1. Lift the latch on the back of the right front seat and
tilt the seatback forward. The seat can be pushed
and slid forward to allow someone to get into or out
of the rear seat area.
2. Return the seatback upright to lock it. Slide the seat
fully rearward to lock it into its original position.
3. The front passenger must try to slide the entire
seat back and forth to make sure the seat is
locked into place.
{CAUTION:
If the easy entry right front seat is not locked,
it can move. In a sudden stop or crash, the
person sitting there could be injured. After you
have used it, be sure to push rearward on an
easy entry seat to be sure it is locked.
1-7

Rear Seats
Split Folding Rear Seat
If your vehicle has this feature, you can fold either side
of the seatback down for more cargo space. Make
sure the front seat is not reclined. If it is, the rear
seatback will not fold down all the way.
To lower the rear seatback, pull forward on the seat tab
located on the outboard side of the seatback cushion
and fold the seatback down. This will allow you
direct access to the trunk.
To raise the rear seatback, follow these steps:
1. Raise the seatback up and make sure it latches.
2. Push and pull on the seatback to be sure it is locked
in position.
3. Ensure that the safety belts are properly stowed
over the seatback in all three positions.
{CAUTION:
A safety belt that is improperly routed, not
properly attached, or twisted will not provide
the protection needed in a crash. The person
wearing the belt could be seriously injured.
After raising the rear seatback, always check
to be sure that the safety belts are properly
routed and attached, and are not twisted.
{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
press rearward on the seatback to be sure it is
locked.
When the seat is not in use, it should be kept in the
upright locked position.
1-8

Safety Belts
Safety Belts: They Are for Everyone
This part of the manual tells you how to use safety
belts properly. It also tells you some things you should
not do with safety belts.
{CAUTION:
Do not let anyone ride where he or she can not
wear a safety belt properly. If you are in a
crash and you are not wearing a safety belt,
your injuries can be much worse. You can hit
things inside the vehicle or be ejected from it.
You can be seriously injured or killed. In the
same crash, you might not be, if you are
buckled up. Always fasten your safety belt,
and check that your passengers’ belts are
fastened properly too.
{CAUTION:
It is extremely dangerous to ride in a cargo
area, inside or outside of a vehicle. In a
collision, people riding in these areas are more
likely to be seriously injured or killed. Do not
allow people to ride in any area of your vehicle
that is not equipped with seats and safety
belts. Be sure everyone in your vehicle is in a
seat and using a safety belt properly.
Your vehicle has a light
that comes on as a
reminder to buckle up. See
Safety Belt Reminder
Light on page 3-32.
1-9

In most states and in all Canadian provinces, the law
says to wear safety belts. Here is why: They work.
You never know if you will be in a crash. If you do have
a crash, you do not know if it will be a bad one.
A few crashes are mild, and some crashes can be so
serious that even buckled up, a person would not
survive. But most crashes are in between. In many of
them, people who buckle up can survive and sometimes
walk away. Without belts they could have been badly
hurt or killed.
After more than 30 years of safety belts in vehicles, the
facts are clear. In most crashes buckling up does
matter...a lot!
Why Safety Belts Work
When you ride in or on anything, you go as fast as
it goes.
Take the simplest vehicle. Suppose it is just a seat
on wheels.
1-10

Put someone on it. Get it up to speed. Then stop the vehicle. The rider
does not stop.
1-11

The person keeps going until stopped by something. In
a real vehicle, it could be the windshield... or the instrument panel...
1-12

or the safety belts!
With safety belts, you slow down as the vehicle does.
You get more time to stop. You stop over more distance,
and your strongest bones take the forces. That is why
safety belts make such good sense.
Questions and Answers About
Safety Belts
Q: Will I be trapped in the vehicle after an accident
if I am wearing a safety belt?
A: You could be — whether you are wearing a safety
belt or not. But you can unbuckle a safety belt,
even if you are upside down. And your chance of
being conscious during and after an accident,
so you can unbuckle and get out, is much greater if
you are belted.
Q: If my vehicle has airbags, why should I have to
wear safety belts?
A: Airbags are in many vehicles today and will be in
most of them in the future. But they are
supplemental systems only; so they work with
safety belts — not instead of them. Every airbag
system ever offered for sale has required the use of
safety belts. Even if you are in a vehicle that has
airbags, you still have to buckle up to get the most
protection. That is true not only in frontal collisions,
but especially in side and other collisions.
1-13

Q: If I am a good driver, and I never drive far from
home, why should I wear safety belts?
A: You may be an excellent driver, but if you are in an
accident — even one that is not your fault — you
and your passengers can be hurt. Being a good
driver does not protect you from things beyond your
control, such as bad drivers.
Most accidents occur within 25 miles (40 km) of
home. And the greatest number of serious injuries
and deaths occur at speeds of less than 40 mph
(65 km/h).
Safety belts are for everyone.
How to Wear Safety Belts Properly
This part is only for people of adult size.
Be aware that there are special things to know about
safety belts and children. And there are different
rules for smaller children and babies. If a child will be
riding in your vehicle, see Older Children on page 1-27
or Infants and Young Children on page 1-29. Follow
those rules for everyone’s protection.
First, you will want to know which restraint systems your
vehicle has.
We will start with the driver position.
1-14
