Vehicle highlights
The Chevrolet Orlando is a true family vehicle, combining 7-seater practicality and interior flexibility
with striking crossover style design.
Refined and fuel efficient performance thanks to its 2.4 litre direct injected engine and 6-speed
manual or automatic transmissions.
Expected to deliver best seven passenger fuel efficiency for non-hybrid vehicles
MSRP starts at $19,995 in Canada
Model Lineup
Engines
Transmissions
Ecotec 2.4L VVT DI
Six-speed manual
Six-speed automatic
Orlando LS
s
s
-
Orlando LT
s
s
o
Orlando LTZ
s
-
s
Key:
Standard
s
Optional
o
Not available
-
2012 CHEVROLET ORLANDO REDEFINES FAMILY TRANSPORTATION
The all-new 2012 Chevrolet Orlando, like other Chevrolet models recently launched in
various market segments, doesn’t follow convention. Orlando’s design – part MPV, part
crossover –breaks the rules of a historically conservative segment; it makes a statement
and stands out from the crowd. Pricing on the 2012 Chevrolet Orlando begins at an
MSRP of $19,995 for the LS model, $22,295 for the LT and $29,735 for the well
equipped LTZ model.
Orlando demonstrates how innovative design can transform the once ordinary confines
of the family vehicle to create a totally different experience for driver and passengers
alike. That is made clear by a quick look at some of the vital statistics, starting with
overall length. Orlando is remarkably compact for a vehicle that can transport up to
seven people in comfort and it continues the transformation underway at Chevrolet,
reaffirming the commitment to building refined, fuel-efficient vehicles using small-
displacement, four-cylinder engines. It is expected to deliver the best fuel efficiency of
any non-hybrid 7 passenger vehicle –including 10.1 L/100km in the city and 6.7
L/100km on the highway.
"The new Orlando builds on the transformation of Chevrolet's fuel efficient and versatile
product portfolio, offering a family-friendly vehicle in a key segment in the Canadian

market," said Kevin Williams, president and managing director of General Motors of
Canada. "With its expected segment-leading fuel efficiency and standard 7-passenger
seating, Orlando should be a popular choice with Canadian families."
Chevrolet's new compact MPV brings flare to the segment by adopting a bolder look with
its low roofline and crossover inspired silhouette, while retaining the distinctive and
recognizable Chevrolet front grille depicted by the split radiator grille and bow-tie badge.
Based on the show car concept first seen in 2008, the Chevrolet Orlando is nevertheless
a true family car for the times, combining 7-seater practicality, interior flexibility and
generous load space.
Orlando offers a refreshing alternative to many of the family vans and crossovers
currently on the market. The distinctly recognizable Chevrolet front grille is
complemented by a profile characterized by the low swept roofline and the muscular,
protruding wheel-arches, housing 16 or 18 inch wheels. The wheel arches enhance a
'body in, wheel out' appearance while at the same time ensuring Orlando keeps its agile,
sporting stance.
Interior versatility
While the exterior of the new Chevrolet Orlando is sure to attract plenty of attention, the
interior also features many of the latest design cues from Chevrolet such as the
Corvette-inspired dual cockpit and ambient blue backlighting to the centre console. The
interior has three rows of “theatre style” seating and, despite the sweeping roof-line,
designers have succeeded in raising the second and third rows to allow the Orlando's
occupants to get an even better view both forwards and to the side without
compromising headroom. In fact, headroom in the third row of seats in the Orlando is
superior to a number of competitor MPVs.
Numerous seating configurations are possible with either second or third rows folded
independently or together to make a completely flat load area. The second row also has
a tumble-fold feature for both the left and right-hand outer seats to allow easy access for
passengers into and out of the third row. When the time comes to hauling large loads of

cargo, Orlando's cargo area is one of the most voluminous in the segment with 1,594
litres available when both rows of seats are folded behind the first row.
Any hard-working family car needs plenty of storage space for all the bits and pieces that
collect inside. Like the original concept car, the final production version of the Orlando
obliges with a range of compartments of different shapes and sizes and different
locations, including two large cup holders in the center console, map and bottle holders
integrated into the front and rear doors and a number of individual compartments in the
cargo area. However, perhaps the most ingenious is a storage area hidden behind the
front fascia of the audio system, within easy reach of the both the driver and passenger.
Seen originally on the Orlando concept car, designers have been able to integrate a
usefully large area which is revealed by flipping up the face of the audio system, large
enough for such items as an MP3 player, sunglasses and wallets. Within the space
itself, there is a standard auxiliary jack and optional USB port for MP3 or iPod
connectivity, depending on the trim level.
Efficient Ecotec Engine and Six-Speed Transmissions
Just as Orlando is amazingly space efficient, its award-winning 2.4L Ecotec four-cylinder
engine is also impressively fuel efficient –in fact, it has an expected best fuel efficiency
of any non-hybrid seven-seater on the market. A pair of six-speed transmissions –a six-
speed manual and a six-speed automatic –match the standard 2.4L Ecotec direct
injected I-4 engine rated at 174 horsepower. The six-speed manual transmission
delivers 6.7 L/100 km on the highway and 10.1 L/100 km in the city while the 6-speed
automatic delivers 6.9 L/100 km on the highway and 10.6 L/100 km in the city.
Shifts within the automatic transmission are accomplished by applying and disengaging
clutches simultaneously, which provides a more direct feel for the driver, compared to
“freewheeling” gear change mechanisms. On the road, a wide selection of shift patterns
is adapted to the styles and habits of the driver, anticipating when maximum acceleration
or maximum efficiency is required. The electronic control also adapts to the prevailing
road conditions, reducing gear shifting when climbing or descending and using engine
braking assistance during down changes.

The six-speed automatic also features ActiveSelect manual control, which allows
sequential driver gear selection via the shift lever. The transmission also has neutral
gear disengagement at idle, which reduces vibration and improves fuel efficiency.
Ride and Handling
Based off Chevrolet's successful and award winning Cruze sedan, already proven to
offer excellent ride and handling, Orlando drivers are assured of a safe, yet involving and
rewarding drive. The Orlando's well proven set up utilizes McPherson struts for the front
suspension and compound crank axle for the rear.
Emulating the successful Chevrolet Cruze, the Orlando's chassis has been tuned to
provide the ideal compromise between ride comfort and agility. McPherson struts used
for the front suspension use hydraulic bushings which are often found in more expensive
vehicles, and provide increased ride isolation for passengers and controlled absorption
of variable road surfaces.
The advanced compound crank (torsion beam) system at the rear is used as it offers the
perfect compromise between suspension control combined with savings in weight and
space. A torsion beam system can also be easily tuned to accommodate the different
vehicle and engine weights.
Safety and Security
Orlando's chassis and body structure have also been engineered with high reserves of
safety as a key consideration. Sixteen-inch ventilated front disc brakes are fitted across
the range, with sixteen-inch solid discs at the rear and with electronic ABS acting on all
wheels. All chassis also benefit from electronic brake force distribution, a system which
governs the amount of braking at each wheel to ensure the shortest stopping distances,
traction control for when road conditions are wet or slippery, electronic stability control
and hydraulic brake assist.
Safety for the vehicle's occupants is always of paramount consideration in this vehicle
segment, and the Orlando provides a comprehensive list of safety and security features,

including: Panic brake assist and cornering brake control, StabiliTrak, traction control, six
standard airbags, head restraints for all seating positions, pedal release system, power
rear child security door locks, child-view mirror, standard OnStar with six months of
Directions and Connections service, and Euro NCAP 5 star rating (one of the top scoring
cars in Europe for 2011).
Most of Orlando's body structure is constructed of high strength steel to form an effective
passenger safety cage providing protection in the event of a collision to the front, rear
and side of the car. Should a collision occur, Orlando's occupants will be protected by six
airbags –twin front, side and curtain.
One of the biggest challenges often faced by emergency services when assisting at the
scene of an incident is helping the occupants of vehicles when the doors are locked.
However, this is not a scenario that Orlando owners will be faced with; Orlando is fitted
with crash sensor technology, where the doors unlock automatically on detection of an
impact.
Finally, like most Chevrolet vehicles, Orlando is available with OnStar that includes
Automatic Crash Response and its latest enhancement, Injury Severity Prediction. This
feature helps OnStar advisors alert first responders when a vehicle crash is likely to
have caused serious injury to the occupants. With Automatic Crash Response, OnStar
uses data from a collection of built-in vehicle sensors that can signal an advisor for help
if the vehicle is involved in a moderate to severe frontal, rear or side-impact crash,
regardless of whether an air bag deploys.
The Chevrolet Orlando is produced at General Motor's South Korea manufacturing
facilities and arrives in Chevrolet dealers across Canada in October 2011.
About Chevrolet in Canada
Founded in 1911, Chevrolet celebrates its centennial as a global automotive brand with
annual sales of about 4.25 million vehicles in more than 140 countries. From today’s
Cruze Eco which consumes just 4.6 L/100 km on the highway to the Volt coming this fall,
which provides up to 80 kilometres of electric, gasoline-free driving and an additional
500 kilometres of extended range, Chevrolet offers gas-friendly to gas-free solutions.

Chevrolet provides customers with fuel-efficient, safe and reliable vehicles that deliver
high quality, expressive design, spirited performance and value. The Chevrolet portfolio
includes award-winning passenger cars and crossovers such as Cruze, Malibu, Equinox
and Traverse and a host of new, smaller, highly efficient models to come including the
all-new Orlando and Sonic (fall 2011) and Spark (2012). Chevrolet also provides iconic
performance cars such as Corvette and Camaro as well as dependable, long-lasting
pickups and SUVs such as Silverado and Suburban. Most new Chevrolet models offer
OnStar safety, security and convenience technologies including OnStar Hands-Free
Calling, Automatic Crash Response and Stolen Vehicle Slowdown. More information
regarding Chevrolet models can be found at www.chevrolet.ca, on Facebook at
http://www.facebook.com/chevroletcanada or by following @ChevroletCanada on
Twitter.
# # #
