Chevrolet Silverado Assembly instructions

Review this Quick Reference Guide for an overview of some important features in your Chevrolet Silverado.
More detailed information can be found in your Owner Manual. Some optional equipment
F
described in
this guide may not be included in your vehicle. For easy reference, keep this guide with your Owner Manual
in your glove box.
www.chevrolet.com

2
Memory
Seat
Controls
F
4WD
Control
F
Instrument Panel
Illumination Control/
Exterior Lamp Control
Tow/Haul
Button
Driver
Information
Center
Turn Signal/
Windshield
Wipers Lever
Audio Next/
Previous Favorite
Station Controls
(behind steering
wheel)
Integrated
Trailer Brake
Control
F
Cruise
Control
Buttons
Power Mirror
Control
F
/Door
Lock Switch/
Window Buttons
Instrument Panel
Low Fuel
Traction Control Off
Engine Coolant
Temperature
Brake System
Cruise Control Set
StabiliTrak Active
StabiliTrak Off
Security
Tow/Haul Mode
Lights On Reminder
Airbag Readiness
Check Engine
Antilock Brake System
Low Tire Pressure
Door Ajar
Audio Volume
Controls
(behind
steering
wheel)
Phone
Buttons/Driver
Information
Center
Controls
Tilt
Steering
Wheel
Lever
Telescoping
Steering
Wheel
Lever
F
Instrument Cluster Symbols

3
Refer to your Owner Manual to learn about the information
being relayed by the lights, gauges and indicators on the
instrument cluster.
See In Brief in your Owner Manual.
Driver’s Heated/
Cooled Seat
Buttons
F
Climate
Controls
F
Passenger’s
Heated/Cooled
Seat Buttons
F
Accessory
Power
Outlets
F
Adjustable Pedals
Switch
F
/Traction Control
and StabiliTrak Button/
Cargo Box Lamp Button
Infotainment
System (8-inch*
screen shown
F
)
Front and Rear Parking
Assist Button
F
/Lane
Departure Warning
Button
F
/Hill Descent
Control Button
F
FOptional equipment *screen measured diagonally
Oil Pressure
Charging System
Safety Belt Reminder
110V
Outlet
F
USB
Ports
F

4
Unlock
Press to unlock the driver’s door.
Press again to unlock all doors.
Lock
Press to lock all
doors. The driver’s
door will not lock if
open.
Vehicle Locator/
Panic Alarm
Press and release to
locate your vehicle.
The turn signal lamps
will ash and the horn will sound.
Press and hold to activate the alarm. The
turn signal lamps will ash and the horn will
sound until the button is pressed again or
the ignition is turned on.
DOOr lOCKs
Door Locks
To lock or unlock all doors, press the power door Lock/ Unlock button, located on
the front doors.
Note: To change the lock and unlock settings, go to Power Door Locks in the Vehicle Settings menu.
To open a locked door from inside, pull the inside door handle to unlock the door and
then pull the door handle again to open the door.
Locking Tailgate
To lock or unlock the tailgate, use the door key. The tailgate lock is located next to the
tailgate handle.
See Keys, Doors and Windows in your Owner Manual.
FOptional equipment
Remote Vehicle StartF
Press and release the Lock button and
then press and hold the button until the
turn signal lamps ash to start the engine
from outside the vehicle. After entering the
vehicle, turn the ignition to the ON position.
• During a remote start, the engine will
run for 10 minutes.
• Press and hold the button until
the parking lamps turn off to cancel a
remote start.
Note: To change the remote lock, unlock,
and remote start settings, go to Remote Lock,
Unlock, Start in the Vehicle Settings menu.
If the remote start heated seat option is
selected, the heated seat button indicators do
not illuminate and the temperature performance
of the unoccupied heated seat may be reduced
during the remote start. The heated seat turns
off when the ignition is turned on.
See Keys, Doors and Windows in your Owner Manual.
remOte KeYless entrY transmItter (KeY FOB)F

5
POWer seatsF
HeaD restraInts
Seat Adjustments
To raise the head restraint, pull the head restraint up.
To lower the head restraint, press the button on top of the seatback and push the head
restraint down.
To move the head restraint forwardF, pull the head restraint to the desired position.
To move the head restraint rearwardF, pull the head restraint fully forward until the
locking mechanism releases; then move it rearward to the desired position.
FOptional equipment
A. Seat Cushion Adjustment
Move the front horizontal control to move
the seat forward or rearward, or to tilt, raise
or lower the seat.
B. Seatback Adjustment
Move the vertical control to recline or raise
the seatback.
C. Lumbar Adjustment
Move the rear control to adjust the lumbar
support.
Set Memory Positions
1. With the vehicle in Park, adjust the driver’s
seat, power outside mirrors and adjustable
pedalsFto the desired positions.
2. Press and hold the SET button and button
1 on the driver’s door at the same time
until a beep sounds.
3. Repeat the steps using button 2 for a
second driver.
Set Exit Position
1. Adjust the driver’s seat and adjustable pedalsFto the desired positions.
2. Press and hold the SET button and Exit button on the driver’s door until a beep
sounds.
Recall Positions
With the vehicle in Park and the ignition on, press and release button 1, 2 or to
recall the stored position.
At any time, press and hold button 1 or 2 on the driver’s door until the stored position is
reached. Releasing the button before the stored position is reached cancels the recall.
Note: To change the memory recall and exit settings, go to Comfort and Convenience in the Vehicle
Settings menu.
See Seats and Restraints in your Owner Manual.
See Seats and Restraints in your Owner Manual.
A CB

6
tIlt/telesCOPInGF steerInG WHeel
With the vehicle in Park, pull the lever
(A) on the left side of the steering col-
umn to adjust the tilt position of the
steering wheel. The steering wheel can
then be moved up or down. Release the
lever to lock the steering wheel in place.
With the vehicle in Park, push down the
leverF(B) closer to the instrument panel
on the left side of the steering column to
move the steering wheel in or out. Pull
up the lever to lock the steering wheel
in place.
See Instruments and Controls in your Owner Manual.
Automatic Headlamp System
Rotate the knob to activate the exterior
lights.
lIGHtInG
FOptional equipment
Off/On
AUTO Automatic Headlamp System
Automatically activates the Daytime
Running Lamps (DRLs) or the headlamps
and other exterior lamps depending on out-
side light conditions.
Parking Lamps
Headlamps
Fog LampsF
Press to turn the fog lamps on or off.
Instrument Panel Brightness
Rotate the thumbwheel located on the left
side of the instrument panel to adjust the
instrument panel lighting.
See Lighting in your Owner Manual.
Instrument Panel Lighting
Cargo Lamp
Cargo Box Lamp
With the vehicle in Park, press to turn
the cargo lamp and under-rail pickup box
lightsFon or off. The button indicator will
illuminate when the lights are on.
See Instruments and Controls in your Owner Manual.
B A

7
FOptional equipment *screen measured diagonally
DrIVer InFOrmatIOn Center
The Driver Information Center (DIC) on the instrument cluster displays a variety of vehicle
system information and warning messages.
Work Truck 3.5-inch* Driver Information Center
Menu Items
Turn the reset stem on the instrument
cluster to scroll through the following
menu items: Digital Speedometer, Trip
Odometer, Fuel Range, Average Fuel
Economy, Tire Pressure, Remaining Oil
Life, Transmission Fluid Temperature,
Trailer Brake, Hour Meter, and Units.
Reset an Item
Press the reset stem to set a menu item
or clear a message. Press and hold the
stem to reset a menu item.
Uplevel 4.2-inch* Color Driver Information CenterF
Use the control padFon the right side of the steering wheel to view the Info (includes the
trip odometers and fuel information), Audio, Phone, Navigation, and Settings menus.
Menu Items
Press the or button to move
between the display zones.
Press the or button to move
through the menus.
Press to open a menu or select/
deselect a setting.
Reset an Item
1. Use the control pad to display the item.
2. Press and hold to reset or clear
the item.
See Instruments and Controls in your Owner Manual.

8
ClImate COntrOls
Recirculation Mode
Press Recirculation Mode to quickly cool the air inside the vehicle or prevent
outside odors from entering the vehicle. It is not available while the Defog or Defrost
Mode is selected.
Note: When the Recirculation Mode is used without air conditioning, the air humidity increases and
the windows may fog.
See Climate Controls in your Owner Manual.
Defog Mode
Defrost
Mode
Recirculation
Mode
Floor Mode
TEMP
Temperature
Control
Bi-level Mode
REAR
Rear Window
Defogger
F
Fan Speed
Control/Off
Vent Mode
A/C
Air
Conditioning
Control
FOptional equipment

9
autOmatIC ClImate COntrOlsF
FOptional equipment
Automatic Operation
1. Press AUTO.
2. Set the temperature for the driver and front passenger. The system automatically
controls the fan speed, air delivery, air conditioning and recirculation to reach the set
temperature. Allow time for the system to reach the desired temperature.
If the air delivery mode or fan speed is manually adjusted, automatic operation is
turned off.
Recirculation
Press Recirculation Mode to quickly cool the air inside the vehicle or prevent
outside odors from entering the vehicle. It is not available while the Defog or Defrost
Mode is selected.
Note: When the Recirculation Mode is used without air conditioning, the air humidity increases and
the windows may fog.
Sync Temperature Settings
Press SYNC to link the passenger’s temperature setting to the driver’s temperature set-
ting. When the passenger’s setting is adjusted, the different passenger’s temperature
setting is displayed.
See Climate Controls in your Owner Manual.
Driver’s
Temperature
Control
Defog Mode
Defrost
Mode
Passenger’s
Temperature
Control
AUTO
Automatic
Operation
Recirculation
Mode
Floor Mode
SYNC
Link passenger’s
temperature
setting to driver’s
temperature
setting
Bi-level Mode
REAR
Rear Window/
Outside Mirror
Defogger
F
Fan Speed
Control/On/Off
Vent Mode
A/C
Air
Conditioning
Control

10
WInDsHIelD WIPers
FOptional equipment
Rotate the band on the lever to activate the
wipers.
Fast Wipes
Slow Wipes
INT Intermittent
Adjust the delay between wipes. The
wipers activate more often as the band is
rotated upward.
OFF
Mist
Single wipe
Washer Fluid
Push the paddle forward to spray washer
uid on the windshield.
See Instruments and Controls in your Owner Manual.
auDIO steerInG WHeel COntrOlsF
Push to Talk
Press to answer an incoming call or to use
natural voice recognitionFwith the audio,
BluetoothF, navigationFor OnStar®F
system.
End Call/Mute
Press to end or reject a call.
Press to mute the vehicle speakers.
Next/Previous
With the Audio screen displayed on the
DIC, press or to seek the previous or
next radio station or track.
Volume
(behind right side of steering wheel)
Press the top or bottom button to adjust the
volume.
Next/Previous Favorite Station
(behind left side of steering wheel)
Press the top or bottom button to go to the
next or previous favorite radio station or
track.
See Instruments and Controls in your Owner Manual.
Next/Previous Favorite Station button shown. Volume button is
located behind the right side of the steering wheel.
