Chicago Electric 3670 User manual

Model 03670
ASSEMBLY AND OPERATING INSTRUCTIONS
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at: http://www.harborfreight.com
Copyright 2003 by Harbor Freight Tools®. All rights reserved. No portion of this
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions, please call 1-800-444-3353.
®
3/8” VSR DRILL

PRODUCT SPECIFICATIONS
 
 
 
 
 
 
 
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures, parts list and as-
sembly diagram. Keep your invoice with this manual. Write the invoice number
on the inside of the front cover. Keep this manual and invoice in a safe and dry
place for future reference.
GENERAL SAFETY RULES
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions listed below may result in
electric shock, fire, and/or serious injury.
SAVE THESE INSTRUCTIONS
WORK AREA
1. Keep your work area clean and well lit. Cluttered benches and dark areas
invite accidents.
2. Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases, or dust. Power tools create sparks
which may ignite the dust or fumes.
SKU 03670 PAGE 2
E194601
3. Keep bystanders, children, and visitors away while operating a power tool.
Distractions can cause you to lose control. Protect others in the work area from
debris such as chips and sparks. Provide barriers or shields as needed.

ELECTRICAL SAFETY
4. Grounded tools must be plugged into an outlet properly installed and
grounded in accordance with all codes and ordinances. Never remove the
grounding prong or modify the plug in any way. Do not use any adapter
plugs. Check with a qualified electrician if you are in doubt as to whether
the outlet is properly grounded. If the tools should electrically malfunction or
break down, grounding provides a low resistance path to carry electricity away
from the user.
5. Double insulated tools are equipped with a polarized plug (one blade is
wider than the other). This plug will fit in a polarized outlet only one way. If
the plug does not fit fully in the outlet, reverse the plug. If it still does not
fit, contact a qualified electrician to install a polarized outlet. Do not
change the plug in any way. Double insulation eliminates the need for the
three wire grounded power cord and grounded power supply system.
6. Avoid body contact with grounded surfaces such as pipes, radiators,
ranges, and refrigerators. There is an increased risk of electric shock if your
body is grounded.
7. Do not expose power tools to rain or wet conditions. Water entering a power
tool will increase the risk of electric shock.
8. Do not abuse the Power Cord. Never use the Power Cord to carry the tools
or pull the Plug from an outlet. Keep the Power Cord away from heat, oil,
sharp edges, or moving parts. Replace damaged Power Cords immedi-
ately. Damaged Power Cords increase the risk of electric shock.
9. When operating a power tool outside, use an outdoor extension cord
marked “W-A” or “W”. These extension cords are rated for outdoor use, and
reduce the risk of electric shock.
PERSONAL SAFETY
10. Stay alert. Watch what you are doing, and use common sense when oper-
ating a power tool. Do not use a power tool while tired or under the influ-
ence of drugs, alcohol, or medication. A moment of inattention while operat-
ing power tools may result in serious personal injury.
11. Dress properly. Do not wear loose clothing or jewelry. Contain long hair.
Keep your hair, clothing, and gloves away from moving parts. Loose
clothes, jewelry, or long hair can be caught in moving parts.
SKU 03670 PAGE 3

12. Avoid accidental starting. Be sure the Power Switch is off before plugging
in. Carrying power tools with your finger on the Power Switch, or plugging in
power tools with the Power Switch on, invites accidents.
13. Remove adjusting keys or wrenches before turning the power tool on. A
wrench or a key that is left attached to a rotating part of the power tool may result
in personal injury.
14. Do not overreach. Keep proper footing and balance at all times. Proper
footing and balance enables better control of the power tool in unexpected
situations.
15. Use safety equipment. Always wear eye protection. Dust mask, non-skid
safety shoes, hard hat, or hearing protection must be used for appropriate
conditions.
TOOL USE AND CARE
16. Use clamps (not included) or other practical ways to secure and support
the workpiece to a stable platform. Holding the work by hand or against your
body is unstable and may lead to loss of control.
17. Do not force the tool. Use the correct tool for your application. The correct
tool will do the job better and safer at the rate for which it is designed.
18. Do not use the power tool if the Power Switch does not turn it on or off.
Any tool that cannot be controlled with the Power Switch is dangerous and must
be replaced.
19. Disconnect the Power Cord Plug from the power source before making any
adjustments, changing accessories, or storing the tool. Such preventive
safety measures reduce the risk of starting the tool accidentally.
20. Store idle tools out of reach of children and other untrained persons. Tools
are dangerous in the hands of untrained users.
21. Maintain tools with care. Keep cutting tools sharp and clean. Properly
maintained tools with a sharp cutting edge are less likely to bind and are easier
to control. Do not use a damaged tool. Tag damaged tools “Do not use” until
repaired.
22. Check for misalignment or binding of moving parts, breakage of parts, and
any other condition that may affect the tool’s operation. If damaged, have
the tool serviced before using. Many accidents are caused by poorly main-
tained tools.
SKU 03670 PAGE 4

23. Use only accessories that are recommended by the manufacturer for your
model. Accessories that may be suitable for one tool may become hazardous
when used on another tool.
SERVICE
24. Tool service must be performed only by qualified repair personnel. Service
or maintenance performed by unqualified personnel could result in a risk of injury.
25. When servicing a tool, use only identical replacement parts. Follow
instructions in the “Inspection, Maintenance, And Cleaning” section of this
manual. Use of unauthorized parts or failure to follow maintenance instructions
may create a risk of electric shock or injury.
SPECIFIC SAFETY RULES
1. Hold tool by insulated gripping surfaces when performing an operation
where the cutting tools may contact hidden wiring or its own cord. Contact
with a ‘live’ wire will make exposed metal parts of the tool ‘live’ and shock the
operator.
2. Maintain labels and nameplates on the Drill. These carry important information.
If unreadable or missing, contact Harbor Freight Tools for a replacement.
3. Always wear safety impact eye goggles and heavy work gloves when using
the Drill. Using personal safety devices reduce the risk for injury. Safety impact
eye goggles and heavy work gloves are available from Harbor Freight Tools.
4. Maintain a safe working environment. Keep the work area well lit. Make sure
there is adequate surrounding workspace. Always keep the work area free of
obstructions, grease, oil, trash, and other debris. Do not use a power tool in
areas near flammable chemicals, dusts, and vapors. Do not use this product in a
damp or wet location.
5. Make sure to read and understand all instructions and safety precautions as
outlined in the manufacturer’s manual for the Drill.
6. When using a hand-held power tool, always maintain a firm grip on the tool
with both hands to resist starting torque.
7. Always keep the extension cord away from moving parts on the tool.
8. Avoid unintensional starting. Make sure you are prepared to begin work
before turning on the Drill.
SKU 3670 PAGE 5

10. Make sure the Drill bit being used is free from burrs and any other foreign
matter which could damage the tool.
11. Never leave the Drill unattended when it is plugged into an electrical outlet.
Turn off the tool, and unplug it from its electrical outlet.
12. Always unplug the Drill from its electrical outlet before performing and
inspection, maintenance, or cleaning procedures.
13. WARNING! Some dust created by power sanding, sawing, grinding, drilling,
and other construction activities, contain chemicals known (to the State of Cali-
fornia) to cause cancer, birth defects or other reproductive harm. Some ex-
amples of these chemicals are: lead from lead-based paints, crystalline silica
from bricks and cement or other masonry products, arsenic and chromium from
chemically treated lumber. Your risk from these exposures varies, depending on
how often you do this type of work. To reduce your exposure to these chemicals:
work in a well ventilated area, and work with approved safety equipment, such as
those dust masks that are specially designed to filter out microscopic particles.
(California Health & Safety Code 25249.5, et seq.)
14. WARNING! People with pacemakers should consult their physician(s)
before using this product. Operation of electrical equipment in close proximity to
a heart pacemaker could cause interference or failure of the pacemaker.
SKU 03670 PAGE 6
GROUNDING
WARNING!
Improperly connecting the grounding wire can result in the risk of electric
shock. Check with a qualfified electrician if you are in doubt as to whether the
outlet is properly grounded. Do not modify the power cord plug provided with
the tool. Never remove the grounding prong from the plug. Do not use the
tool if the power cord or plug is damaged. If damaged, have it repaired by
a service facility before use. If the plug will not fit the outlet, have a proper
outlet installed by a qualified electrician.
GROUNDED TOOLS: TOOLS WITH THREE PRONG PLUGS
1. Tools marked with “Grounding Required” have a three wire cord and three prong
grounding plug. The plug must be connected to a properly grounded outlet. If
the tool should electrically malfunction or break down, grounding provides a low
resistance path to carry electricity away from the user, reducing the risk of elec-
tric shock. (See Figure A.)

2. The grounding prong in the plug is connected through the green wire inside the
cord to the grounding system in the tool. The green wire in the cord must be the
only wire connected to the tool’s grounding system and must never be attached
to an electrically “live” terminal. (See Figure A.)
3. Your tool must be plugged into an appropriate outlet, properly installed and
grounded in accordance with all codes and ordinances. The plug and outlet
should look like those in the following illustration. (See Figure A.)
FIGURE A
SKU 03670 PAGE 7
FIGURE B
DOUBLE INSULATED TOOLS: TOOLS WITH TWO PRONG PLUGS
4. Tools marked “Double Insulated” do not require grounding. They have a special
double insulation system which satisfies OSHA requirements and complies with
the applicable standards of Underwriters Laboratories, Inc., the Canadian
Standard Association, and the National Electrical Code. (See Figure B.)
5. Double insulated tools may be used in either of the 120 volt outlets shown in the
following illustration. (See Figure B.)

SKU 03670 PAGE 8
1. Grounded tools require a three wire extension cord. Double Insulated tools
can use either a two or three wire extension cord.
2. As the distance from the supply outlet increases, you must use a heavier gauge
extension cord. Using extension cords with inadequately sized wire causes a
serious drop in voltage, resulting in loss of power and possible tool damage.
(See Figure C, next page.)
3. The smaller the gauge number of the wire, the greater the capacity of the cord.
For example, a 14 gauge cord can carry a higher current than a 16 gauge cord.
(See Figure C.)
4. When using more than one extension cord to make up the total length, make
sure each cord contains at least the minimum wire size required.
(See Figure C.)
5. If you are using one extension cord for more than one tool, add the nameplate
amperes and use the sum to determine the required minimum cord size.
(See Figure C.)
EXTENSION CORDS
6. If you are using an extension cord outdoors, make sure it is marked with the suffix
“W-A” (“W” in Canada) to indicate it is acceptable for outdoor use.
7. Make sure your extension cord is properly wired and in good electrical condition.
Always replace a damaged extension cord or have it repaired by a qualified
electrician before using it.
8. Protect your extension cords from sharp objects, excessive heat, and damp or
wet areas.


















     
     
     
     
     
     
     

 FIGURE C

SKU 03670 PAGE 9
SYMBOLOGY
Double Insulated
Volts Alternating Current
Amperes
UNPACKING
When unpacking, check to make sure all the parts shown on the Parts List on page 13
are included. If any parts are missing or broken, please call Harbor Freight Tools at the
number shown on the cover of this manual as soon as possible.
Canadian Standards
Association
Underwriters
Laboratories, Inc.
No Load Revolutions
per Minute (RPM)
noxxxx/min.
A
V ~

ASSEMBLY AND OPERATING INSTRUCTIONS
NOTE: For additional information regarding the parts listed in the following pages, refer
to the Assembly Diagram on page 14.
SKU 03670 PAGE 10
Chuck
Belt Hanger
Trigger
Tool Hanger Loop
Lock Button
Torque Adjustment
Power Cord
FIGURE 1
Directional Switch
Level
Refer to FIGURE 1 and 2.
Warning! Always unplug the unit when changing bits.
Warning! After drilling or driving screws, the bit will be extremely hot. Do not touch it
until it has had ample time to cool down.
1. To load a bit, hold the back end of the Chuck (#5)
with one hand, while turning the front end counter-
clockwise to open the jaws.
2. Insert the bit.
3. Hold the back end of the Chuck (#5) with one hand,
while turning the front end clockwise to close and
tighten the jaws around the bit shank.
4. With heavy leather gloves on, tug on the bit and
make sure it is securely attached. Check that it is
straight.
Note: Always use sharp bits. Dull or damaged bits may cause undue stress on the drill and
possibly break causing injury. Bits are available at Harbor Freight Tools.
Loading Bits
FIGURE 2
Back End
Front End

Using the Lock Button.
When you are drilling for
extended times and want to
take your finger off of the
Trigger, use the Lock Button.
Squeeze the Trigger to start the
drill, then push the Lock Button.
The drill will stay on. When you
are finished, just squeeze the
Trigger to stop the drill.
SKU 03670 PAGE 11
Torque Adjustment
Trigger
Directional
Lock Button
FIGURE 3
Operation (continued)
Refer to FIGURE 1,2, and 3.
Note: When holding the drill in your hand, the Directional Switch points toward the right,
the unit will drill forward. When it is pointed to the left, the unit will drill in reverse.
Drilling
1. Securely clamp your workpiece.
2. When drilling wood, place the bit at the point to be drilled. If you are drilling a hard,
smooth surface, use a punch to mark the drill location. Set the Directional Switch to
forward (right). Grasp the handle firmly and slowly squeeze the Trigger. Never force the
tool. Only apply light pressure when drilling. If you need more or less torque, use the
Torque Adjustment on the Trigger. Turning the Torque Adjustment screw toward the +
sign will add more torque. See FIGURE 3.
Note: When drilling plastics or plastic coated chip board, follow the same directions as
stated in number 2 for wood.
Note: If a bit becomes wedged into the workpiece, change the Directional Switch to the
reverse position.
3. When drilling metal, always use a punch to mark the drilling position. Use a lubricant to
prolong the life of the bit and increase the drilling action with most metals. With steel, tin,
and sheet metal use a light machine oil, with aluminum, use paraffin. Do not use lubricants
with brass, copper, and cast iron. Grasp the handle firmly and slowly squeeze the Trigger.
Never force the tool. Only apply light pressure when drilling.
4. When driving screws, use bits suitable for the type and size of screw you are using. Drill
a pilot hole for the screw head to bite into. Use the lowest torque setting. Grasp the handle
firmly with both hands and slowly squeeze the Trigger. Never force the tool. To back out a
screw, change the Directional Switch to the reverse position (left).

SKU 03670 PAGE 12
INSPECTION, MAINTENANCE, AND CLEANING
Refer to the Assembly Drawing on page 14.
1. WARNING! Make sure the Power Switch of the Drill is in its “OFF” position
and that the tool is unplugged from its electrical outlet before performing any
inspection, maintenance, or cleaning procedures.
2. BEFORE EACH USE, inspect the general condition of the Drill. Check for loose
screws, misalignment or binding of moving parts, cracked or broken parts, dam-
aged electrical wiring, and any other condition that may affect its safe operation. If
abnormal noise or vibration occurs, have the problem corrected before further
use. Do not use damaged equipment.
3. Periodically check the mounting screws and tighten if necessary.
4. Clean the unit with a damp cloth. Never use solvents to clean the unit.
5. Inspect the chuck and remove any dirt or debris.
6. Inspect the Carbon Brushes (#14) periodically. See the Assembly Drawing on page
9. Remove the Carbon Brush Holder (#15) on the side of the drill. Take the
Carbon Brush (#14) out of the Carbon Brush Holder (#15). If it is dirty, use a
pencil eraser to clean it. If it is worn, replace it and replace the Carbon Brush (#14).
If you replace one Carbon Brush, you must replace them both. Repeat the process
with the Carbon Brush Holder (#15) on the other side of the drill.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT
HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTUER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE
UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER
ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL
PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION
OF REPLACEMENT PARTS THERETO.

SKU 03670 PAGE 13
Parts List
Part No. Description Qty.
2 Left Motor Housing 1
3 Screw M5 x 22 1
4 Spring Washer (5) 1
5 Chuck 1
6 Spindle 1
7 Half Circle Key 1
8 Bearing 201 1
9 Gear 1
10 Fender Ring 10 1
11 Brass Bushing 1
12 Bearing 1
13 Armature 1
14 Carbon Brush 2
15 Carbon Brush Holder 2
16 Bearing 1
17 Stator 1
18 Clip 1
19 Self Tapping Screw 4 x 12 2
20 Cable Sheath 1
21 Power Cord and Plug 1
22 Switch Module 1
23 Limb 2
24 Outgoing Line 2
25 Limb 2
26 Right Motor Housing 1
27 Screw 4 x 16 2
28 Screw 4 x 20 6
NOTE: Some parts are listed and shown for illustration purposes only, and are not avail-
able individually as replacement parts.

SKU 03670 PAGE 14
ASSEMBLY DIAGRAM
