Chimera 9500 User manual
INSTRUCTIONS FOR SPEED RING 9500
Fits Lowel DP
CAUTION: THE DP SAFETY SCREEN MUST BE USED WITH THIS LIGHT FIXTURE/SPEED
RING COMBINATION.
Mounting the Speed Ring to the Light:
1- Attach the safety screen to the DP light.
2- Loosen all brass thumbscrews and remove all four capture plates.
3- With the Speed Ring oriented so that the plates will be facing into the lightbank, slide the
Speed ring past the flange on the front of the light housing.
4- Replace the capture plates, while squeezing the latch firmly against the Speed ring
between your thumb and forefinger, re-tighten the thumbscrews.
Parts list:
1 95051000 All metal Speed Ring
4 95002000 DP capture plates
8 95005000 8-32 x ½” thumbscrews
CHIMERA 1812 Valtec Lane, Boulder CO 80301 303-444-8000 888-444-1812 fax 303-444-8303 [email protected]
95009700/011901
