Instruction Manual
POPULAR MASSAGE CHAIR
The Global Health-care and Massage Expert

Important Safety Instructions … … … … … … … … … … … … … … … … … … … … … 1-4
Part Names and Functions… … … … … … … … … … … … … … … … … … … … … … … 5-
Installation of Parts… … … … … … … … … … … … … … … … … … … … … … … … … … 7-8
Remote Controller Instruction… … … … … … … … … … … … … … … … … … … … … 9 -12
Preparation Before Use…………………………………………………………………………………13
Massage Programs… … … … … … … … … … … … … … … … … … … … … … … … … 14-21
Care and Storage… … … … … … … … … … … … … … … … … … … … … … … … … … … … 22
Troubleshooting… … … … … … … … … … … … … … … … … … … … … … … … … … … … 23
6
Thanks for you choose our Popular Massage Chair. B Massager,
p
efore operating the
lease read this User’s M anual thoroughly for the correct methods of usage, especially
the notes on Safety. This manual should be kept available for future reference after you
have read it through.
CONTENTS

DANGER
-To reduce the risk of electric shock: Always unplug this appliance from the Electrical
Outlet immediately after using and before cleaning.
WARNING
-To reduce the risk of burns, fire, electric shock, or injury to persons:
1. This appliance should never be left unattended when plugged in. Unplug from outlet
when not in use, and before putting on or taking off parts.
2. Close supervision is necessary when this appliance is used by, on, or near children,
invalids, or disabled persons.
3. Use this appliance only for its intended use as described in this manual. Do not use
attachments not recommended by the manufacturer.
4. Keep the cord away from heated surfaces.
5. Never operate the appliance with the air openings blocked. Keep the air openings free
of lint, hair, and the like.
6. Never drop or insert any object into any opening.
7. Do not use outdoors.
8. Do not operate where aerosol (spray) products are being used or where oxygen is
being administered.
9. Connect this appliance to a properly grounded outlet only. See Grounding Instruction.
GROUNDING INSTRUCTIONS
This product must be grounded. If it should malfunction or breakdown, grounding
provides a path of least resistance for electric current to reduce the risk of electric shock.
This product is equipped with a cord having an equipment-grounding conductor and a
grounding plug. The plug must be plugged into an appropriate outlet that is properly
installed and grounded in accordance with all local codes and ordinances.
DANGER
Improper connection of the equipment-grounding conductor can result in a risk of
electric shock. Check with a qualified electrician or serviceman if you are in doubt as to
whether the product is properly grounded. Do not modify the plug provided with the
product if it will not fit the outlet, have a proper outlet installed by a qualified electrician.
This product has a grounding plug. Make sure that the product is connected to an outlet
having the same configuration as the plug. No adapter should be used with this product.
IMPORTANT SAFETY INSTRUCTIONS
2. Unsuitable Users
The following users must consult their doctor before use:
●under medical care or feel unwell.
●suffering from malignant tumours.
●Those who are suffering from severe heart diseases.
●pregnant or menstruating.
●spinal disorders, bent or abnormal spinal conditions
●those who have high fever.
3. Safety Precautions During Use
●To ensure safe and correct use of the chair, do not operate the chair without reading
●Do not rest or place heavy objects on the Armrests, Footrest or Backrest. It may
result in machine trouble or injury to the user should these objects topple.
●Do not use the chair with other therapeutic equipment or electric blanket, etc, as it
may result in inefficacy or injury.
1. Usage Environment
●Do not use your chair in an excessively humid or dusty environment, as it may cause
electrical shock or machine trouble.
●Do not put your chair in room temperature higher than 40C.
●Do not expose your chair to heaters, stoves or direct sunlight.
●Do place and use your chair on a flat floor level.
CAUTION
12
CAUTION
You should use the Chair in a cool room, do not increase the room temperature
abruptly. It is recommended that you increase the temperature gradually to a
normal Level. If you want to move the Chair that stored in a cold place to a warm
place, it is advisable to use it one hour later. Machine trouble may be resulted
when a cold machine is being used in a warm room suddenly.
PLEASE SAVE THESE SAFETY
●Do not allow children or pets to play around the chair,
it may result in injury during operation of the chair.
IMPORTANT SAFETY INSTRUCTIONS

4. When the Chair Should Not be Used
In the following events, please switch the power OFF immediately and disconnect
the AC power cord from the Electrical Outlet. Contact our centre for servicing:
●If the Chair is spilt accidentally with water or not in operation, continuous to use
under these conditions may result in electrical shock.
●If abnormal or severe pain is felt during massage, stop operation immediately and
consult your doctor.
●If you find any malfunction or any other abnormal condition during operation.
●If there is a power failure, injury may be caused when power is back unexpectedly.
●If there is severe lightning.
Lift the Backrest Pad regularly to check for tears in the upholstery of the Central Cloth.
5. Assembly and Repair of the Chair
●Do not disassemble the back cover from the Chair, touching the inside mechanisms
of the Chair may result in electrical shock.
●The Chair must only be serviced or repaired by our Service Centre,
and user must not disassemble or repair the Chair oneself.
6. Things to Note about Power Plug and Cord
Check that the voltage corresponds with the specifications indicated for the Chair
(only for alternative current).
● Do not disconnect the AC Plug from the Electrical Outlet roughly.
●Do not connect or disconnect the AC Plug from the Electrical Outlet with wet hands.
It may result in electrical shock or machine troubles.
●When disconnecting the AC Plug, pull it out by holding the plug and not by the cord.
●Although the operation will be stopped automatically by the Auto-Timer function,
do not fail to switch off the Main Switch after operation.
●Do not place the AC cord under the Chair as it may damage the cord and result in fire
or electrical shock.
●Do not use the Chair if the power cord/pulg is damaged, use attachments that
recommended by our company only .
●Do not use the Chair if the Electrical Outlet is excessively loose.
7. Caution for the Remote Controller
●Do not sit, step or place heavy objects on the Remote Controller.
●Do not drop the Remote Controller. It is recommended to place it in the Remote
Controller Support when not in use.
●Do not exert excessive force on the Remote Controller.
●Do not operate the Remote Controller with wet hands.
●Do not operate the Remote Controller using sharp-edged or hard objects, this may
result in damage.
●Do not use the Chair when your body is wet.
●Do not operate the Chair with wet hands.
●Continuous long application of the massage at a position of your body may result
in excessive stimulation and may be counter-effective.
●Do not insert your hand or foot along the paths of the Massage Nodes during the
operation of the Chair, as it may cause injury to the user.
→You may place a blanket or towel over the Backrest if you prefer a softer massage.
→Using the Massage Chair as a bed is not encouraged.
→Do not apply Massage Nodes directly on the head, joints of elbows/abdomen, .
→The recommended usage time is 15 minutes, however, you are encouraged not
to use more than 5 minutes on the same spot.
etc
Suggestions
NOTE:
3 4
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS

Headrest
Backrest
Backrest Pad
Armrest
Moving Castor
Chair Base
Seat
( Air bags for Hip)
Footrest
Front Footrest
Remote Controller
●Check the voltage corresponds with the specifications indicated for the
Chair (only for alternative current).
●The plug must be plugged into an appropriate outlet that is properly
installed and grounded in accordance with all local codes and ordinances.
●Advice a minimum distance of 1 metre from AV devices such as television
or radio,to prevent signal interference.
PART NAMES AND FUNCTIONS
Footrest Length Adjustment Level
臀部振动
Line of Connection
to Remote Controller
Port for Remote Controller
Main Power Switch
AC Plug
Power Socket
Fuse
Air bags for
Arm/Waist
※ Note: Specifications are subject to change without notice.
SPECIFICATIONS
Name: Popular Massage Chair
Rated voltage:
AC100-120V AC220-240V
Rated frequency: 50/60Hz
Power consumption: 200W
Working time: 30mins
5 6
PART NAMES AND FUNCTIONS

Installation of the Remote Controller Support
2.Removal: hold the top and pull it upward.
●Adjustment of Remote Controller Support: In normal times, adjust it freely and if it
is loose, tighten it by the Manual Fixing Screw securely.
●Installation/Removal of Remote Controller: 1.Installation: insert it from the top.
规格参数
INSTALLATION OF PARTS
Adjusting Freely
Manual Fixing Screw
Headrest
Headrest is stuck to the Backrest Pad with velcro tapes
a. In bonding, stick them together.
b. To separate, take it away directly.
Backrest Pad Installation
●Backrest Pad is attached to the Backrest by zipper, to load or unload Backrest Pad,
only zip the zipper.(B)
● Install Back Heating Function :
a. Insert plug with plug end to end only. b. To separate, pull them out.
Installation
● .(A)
A
Velcro tapes
B Zipper
Insert the plugs for
Back Heating Function
Moving the Massage Chair
●Adjust the backrest to its fully upright position and there should be two more persons:
one catching hold of the one side of armrest upward and the other press the backrest
downward, causes the moving castors to be well-grounded then together. push it to move
●
●The Chair is rather heavy. Take sufficient care when lifting it.
Please pull out AC Plug from Electric Outlet before moving Chair.
7 8
INSTALLATION OF PARTS
Block
Airbags for Arm Air Massage(Waist
velcro tapes
2.Fig 2: stick the airbags on both sides of backrest only .
Air Massage)
Note: It is 2 usage of method for this airbag see below:
1.Fig 1: fold the airbags and encircles the arms, then stick them by .
Backrest
Fig1 Fig2
stuck by velcro tapes
For Arm Air Massage For Waist Air Massage
stuck
Folded it as show

REMOTE CONTROLLER INSTRUCTION
1.
2.
3.Vibration Speed -
4.Kneading Massage
5.Tapping Massage
Hip Vibration Massage
Vibration Speed +
6.Kneading & Tapping Massage
7.Pressing Massage
8.Width Adjustment
9.Back Heating Function
10.Foot Heating Function
1
2
3
8
9
10
4
5
6
7
6.Automatic Massage Programs
Relaxation Mode
B: Activation Mode
C: Vitality Mode
D: Morning Mode
E: Night Mode
7.LCD Display
8. Back massage part
9.Timer
10. Up/down
11. Air Massage
A:
1.
2.Start
3.Footrest & Backrest Reset
（Footrest down/Backrest up）
4.Backrest Adjustment
(Adjust the recline angle of the
Backrest and Footrest simultaneously.)
5.Footrest Adjustment
(Adjust the recline angle of the Footrest.）
Stop
1
2
3
4
5
7
8
9
10
11
6
910
REMOTE CONTROLLER INSTRUCTION

1. Air Massage Function
a.Arm Air Massage
b.Waist Air Massage
c.Hip Air Massage
d.Calf Air Massage
e.Calf Traction Air Massage
2.Hip Vibration Massage
3.Air Massage Level Adjustment
4.Vibration Speed Adjustment
1
2
3
4
5
6
7
8
9
10
11
5.Kneading Speed Adjustment
6.Manual Massage Modes
7.Select Back Parts Area
8.
9.Back Heating Function
10.Foot Heating Function
11.Up/Down Adjustment
Tapping Speed Adjustment
Width Adjustment
12.
5. a.Kneading Speed
b.Tapping Speed
c. Air Massage Level
6.Up/Down the Back Massage Part
7.Arm Air Massage
8.Back Heating Function
9.Show the Massage Nod Position
10.Hip Air Massage
1. Automatic
2.Timer
3.Foot Heating Function
4.1.Calf Air Massage
2.Calf Traction Air Massage
5 Massage Programs
LCD Display
To show the operating massage functions, massage parts and timer.
Kneading
Tapping
Pressing
Hip Air Massage
Hip Vibration Massage
Calf Air Massage
Calf Traction Air Massage
Kneading & Tapping
1
Backrest Adjustment
Footrest Adjustment
5
6
7
8
10
2
3
4
11 12
REMOTE CONTROLLER INSTRUCTION REMOTE CONTROLLER INSTRUCTION
9
12

Expand/Folding the Chair
1.To expand, please raise the Backrest to an upright position until a “click”sound is heard.
2.To fold it for storage:
1. Remove the Headrest and Backrest Pad.
2. Pull the Backrest Folding Lever up.
3. Push the Backrest forward.
●Take care not to fold abruptly.
●Be careful not to get hand or fingers caught
between the Armrest and Backrest.
Raise Backrest to an upright position. Push the Backrest forward to fold.
Pull Backrest Folding Lever up
Put a carpet under the Chair to prevent
scratching of the flooring.
Make sure that there is no obstruction
behind the Chair for a safe recline during
operation.
→
→
●Secure sufficient space around the Chair for reclining purpose.
●Make sure that there is an allowance of more than 45cm in the front of and 75cm
behind the Chair.
Placing of the Chair
45cm
at leas t
75cm
at leas t
CAUTION
Suggestions
How to Use the Reclining System
Backrest
●To recline: Press the“Backrest Down”button until the Backrest is down and Footrest
is up to your desired angle.
●To incline: Press the“Backrest Up”button until the Backrest is up to your desired angle.
Power On
1.Connect the AC Plug to the Electrical Outlet.
2.Turn on the Main Power Switch located on the Electric Control Box.
3.Press the“START”button, it is ready to work .
Make sure that the AC cord is not placed under the Chair Base.
Make sure that all switches are at the OFF position (including the Main
Power Switch)before the AC Plug is connected to an Electrical Outlet.
●
●
CAUTION
1314
PREPARATION BEFORE USE MASSAGE PROGRAMS

Footrest
1.To lift: Press the“Footrest Up”button until the Footrest
is upward to your desired height.
2.To lower: Press the“Footrest Down”button until the
Footrest is downward to your desired height.
Rest:
●To rest: Press the“Reset”button, the Backrest and Footrest
is to the initial position.
Massage Programs
Do not exert excessive force on ●Footrest Length Adjustment Lever.
About 8cm
(Shorten) (Lengthen)
How to Adjust the Length of the Footrest
The length of the Footrest can be adjusted to the comfort of the user by lifting the
Footrest Length Adjustment Lever.
1.To lengthen: Lift the lever and push out the Footrest with your feet to get the
proper position and loosen the lever to lock the Footrest.
2.To shorten: Just lift the lever and the Footrest is to the initial position automatically.
Footrest Length Adjustment Lever
Timer
1.The default massage time is 30 minutes and the massage procedure will be closed
automatically after 30 minutes.
2.How to set the time: a. Press button to be increased by 5 minutes
b. Press button to be decreased by 5 minutes
After setting of the time, the machine will begin to count
down till the remaining time is zero and then the procedure
will be closed automatically.
3.In changing of Automatic Massage Programs and Manual
Programs, the remaining time won't be changed.
Choosing Back Massage Parts
Press following buttons to choose one of 3 massage parts. When it is chosen, the
correspond icon is lighting on the LCD.
The Whole Course: It will give massage up and down from neck to waist.
Back Part: It will give massage up and down from upper back to lower back.
Waist Part: It will give massage up and down from lower back to waist part.
●
Up/down Massage
●This function is for Kneading Massage, Tapping Massage and Kneading & Tapping
Massage only. It is 2 method to use this function During Back Massage:
1.Press“Up”or“Down”button continuously, the Massage Nods will move up or
down. Release it, the nods will stop on your desired part.
2.While the nods massage on you desired part, just press“Up”or“Down”button
once and the nods will stop there for a spot massage.
back part waist part
the whole course
15 16
MASSAGE PROGRAMSMASSAGE PROGRAMS

Width Adjustment
1.It is suitable for Tapping Massage and Pressing Massage only.
2.Press“Width”button to adjust the massage width according to your desire.
After Use
●Press the“Stop”button to stop massage.
●To avoid malfunction and accidents with children, do
remember to switch off the Main Power Switch and
disconnect the AC Plug from the Electrical Outlet after use.
There are 2 series of massage: 1.Automatic Massage Programs
2.Manual Massage Programs
1.How to Use the Automatic Massage Programs
This menu of 5 specialised massage programs which is designed to meet specific
well goals with a simple touch of the Remote Controller.
Choose from a range of 5 different kinds of pre-programed massages.
The Automatic Massage Programs buttons
The correspond icons on the LCD
●To start massage, press any one of the 5 buttons, you can enjoy a continuous
massage on the whole body. Press the buttons again to stop massage.
A-- Relaxation mode B-- Activation mode C-- Vitality mode
D– Morning mode E– Night mode
2.Manual Massage Programs
It allows you to mix and match from a choice of massage actions, you can adjust
,
massage action s speed, level or position to suit yourself.
●A.4 Back Massage Programs:
- Kneading Massage
- Tapping Massage
- Kneading & Tapping Massage
- Pressing Massage
●B.4 Air Massage Programs:
- Arm Air Massage
- Waist Air Massage
- Hip Air Massage
- Calf Air Massage
- Calf Traction Air Massage
●C.1 Vibration Massage Program:
- Hip Vibration Massage
●D.2 Heating Functions:
- Back Heating Function
- Foot Heating Function
Choosing of Manual Programs, please see the following form for detail.
MASSAGE PROGRAMS
Hip Vi br at ion Mas sage
Hip Ai r Massage
Pressing
Knea di ng & Tapping
LCD SPEED ADJUSTMENT
WIDTH PARTS
UP/DOWN
LEVEL
MASSAGE PROGRAMS
Back Hea ting Function
Foot Hea ting Function
Calf Ai r Massage
Calf Traction Massage
Tappi ng
Knea di ng
Arm Ai r Massage
1718
MASSAGE PROGRAMS

1.Kneading Massage
●Press the“KNEADING ”button, it begins to Kneading Massage and the correspond
icon is lighting on the LCD.
●Press button to select one of 3 massage parts.
●For a spot massage just press or button to adjust the Massage Nods position.
●To adjust the speed, press the button and the correspond iconwill show
on LCD Screen: .
●Press the“KNEADING ”button again to stop massaging.
2.Tapping Massage
●Press the“TAPPING ”button, it begins to Tapping Massage and the correspond
icon is lighting on the LCD.
●Press button to select one of 3 massage parts and adjust the Tapping
Massage width by press button according to your desire.
●For a spot massage just press or button to adjust the Massage Nods position.
●To adjust the speed, press the button and the correspond icon will show
on LCD Screen: .
●Press the“TAPPING ”button again to stop massaging.
3.Kneading & Tapping Massage
●Press the“KNEADING & TAPPING ”button, it begins to Kneading & Tapping Massage
and the correspond icon is lighting on the LCD.
●Press button to select one of 3 massage parts.
●For a spot massage just press or button to adjust the Massage Nods position.
●Press the button to adjust speed and the correspond icons will
show on LCD Screen: .
●Press th“KNEADING & TAPPING ”button again to stop massaging.
A. BACK MASSAGE PROGRAMS
B. AIR MASSAGE PROGRAMS
1.Hip Air Massage
●Press the button, it begins to Air Massage on Hip and the corresponding icon
is lighting on the LCD.
●Press the button to adjust the level and the corresponding icon
is lighting on the LCD. 4 levels can be selected.
●Press the button again to stop massaging.
2.Calf Air Massage
●Press the button, it begins to Air Massage on Calf and the corresponding icon
is lighting on the LCD.
●Press the button to adjust the level and the corresponding icon
is lighting on the LCD. 4 levels can be selected.
●Press the button again to stop massaging.
3.Calf Traction Air Massage
●Press the button, it begins to Air Traction Massage on Calf and the correspond
icon is lighting on the LCD.
●Press the button to adjust the level and the corresponding icon
is lighting on the LCD. 4 levels can be selected.
●Press the button again to stop massaging.
4.Arm Air Massage
●Press the button, it begins to Air Massage on Arm and the corresponding
icon is lighting on the LCD.
●Press the button to adjust the level and the corresponding icon
is lighting on the LCD. 4 levels can be selected.
●Press the button again to stop massaging.
3.Pressing Massage
●Press the“PRESSING ”button, it begins to Pressing Massage and the correspond
icon is lighting on the LCD.
●Press button to select one of 3 massage parts and adjust the Pressing
Massage width by press button according to your desire.
●Press the“PRESSING ”button again to stop.
1920
MASSAGE PROGRAMSMASSAGE PROGRAMS

C. Hip Vibration Massage
●Press the or button, it begins to vibration massage on Hip and the
correspond icon is lighting on the LCD.
●To adjust the speed, press the or button.
●Press the“HIP VIB”button again to stop massaging.
D. Heating Massage Function
1.Back Heating Function
●Press the or button, it begins to Back Heating Function and the
correspondicon of Hip Part is lighting on the LCD.
●Press the “HIP HEAT” button again to stop massaging.
2.Foot Heating Function
●Press the or button, it begins to Foot Heating Function and the correspond
icon of Feet Parts is lighting on the LCD.
●Press the “FOOT HEAT”button again to stop massaging.
1.Storing the Chair
● Wipe off dust and dirt from the chair. Keep it clean and away from places of high
humidity. Damp and dust will shorten the machine's life and may become the causes
of mouldy or dirty marks.
●If the chair is not in use for a long period of time, cover the chair with a dustproof
cover to protect it from dust.
● Make sure the power is turned off and pull the plug out from the outlet when it is kept.
2.Cleaning Of Remote Controller
●Remove fouling on the Remote Controller with a piece of dry cloth. As a wet cloth
may cause damage.
3.Cleaning Of Leather
●To clean the leather sections, wipe with a piece of cloth impregnated with neutral
detergent at first. Then remove the detergent with a soft cloth wetted with water
and air dry.
●Use a piece of dry cloth to wipe over the painted areas.
CARE AND STORING
Please keep away from direct sunlight or heating appliances
like heat stove It could cause discolouration or deterioration.
→
Suggestions
CAUTION
■
■
Don't use diluents, volatile oil or bleaching powder will cause
discolouration or cracks.
Do not use the iron.
5.Waist Air Massage
●Press the button, it begins to Air Massage on Waist.
(Note: No icon for this Function)
●Press the button to adjust the level and the corresponding icon
is lighting on the LCD. 4 levels can be selected.
●Press the button again to stop massaging.
2122
MASSAGE PROGRAMS

TROUBLESHOOTING
If you encounter any problems with the operation of your massage chair,please check
the following troubleshooting guide for some common issues to see if they can be
resolved. If the massage chair still does not work or malfunctions, please switch off the
Main Power and remove the AC Plug from the Electrical Outlet and contact us.
Do not disassemble or attempt to repair the Chair by yourself.
CONDITIONS POSSIBLE CAUSE OR ACTION
Loud sound during Tapping,
Kneading or Pressing
Knocking sound at the change of function
Sound of the vibration
These sounds are results of
mechanical structure and are
not indicators of machine trouble.
Check the AC Plug is firmly connected
to the Electrical Outlet.
Confirm that the Main Power is
switched on.
The chair does not operate using the
Remote Controller
Do not lean too hard against the
Backrest.
Working is time out or power off.
It may work too long, turn it off and
let it cool.
Stop working during the massage
Massage rollers stop moving
23
