iReliev Relaxable Series User manual

Available in these colors:
Shiatsu Pillow Massager
iReliev®®
Model # MA-9000
Relaxable™Series

Thank you for purchasing the Relaxable™ Shiatsu Pillow Massager. Please
read this manual carefully before use to ensure proper operation. This manual
should be kept in a safe place for future reference.
TABLE OF CONTENTS
Warnings.....................................................................................................3
Indications for Use.....................................................................................4
What’s Included..........................................................................................4
Product Description ...................................................................................5
Operation Guide .........................................................................................6
Specifications.............................................................................................7
Troubleshooting Guide ..............................................................................8
Other Products You May Like....................................................................9-14
iReliev®®
Model Numbers
MA-9000-BK
MA-9000-GR
MA-9000-PK
MA-9000-BL

WARNINGS
To reduce the risk of malfunction, electric shock, injury, fire, death, and
equipment damage, please read all instructions and warnings carefully
before using this product.
1. If the massage intensity feels too strong, you can place a towel or
blanket between your body and the massage pillow to reduce intensity.
2. To extend the life of the massager, allow the device to cool down for 15
minutes between 30-minute sessions.
3. Do not pull on the wire when unplugging the charger from the device.
4. Please use the factory adapter for charging to avoid fire or
damage to the product.
5. Do not operate the device in dusty or damp environments.
6. Do not place the device near steam, heat, or fire.
7. Do not place the device in direct sunlight.
8. Do not use this product without your physician’s consent if you have a
serious health condition that could be contraindicated.
9. Consult your doctor before using if you have an injury or had recent
surgery.
10. Do not disassemble the product or adapter in any way.
11. Contact iReliev®Customer Service for assistance if the adapter or wire
is damaged.
12. This device is NOT intended for use by children under 18.
13. Do not leave children unattended with this device.
3

4
WHAT’S INCLUDED:
•Shiatsu Pillow Massager
• Wall Charger
INDICATIONS FOR USE
The iReliev®Relaxable™ Shiatsu Pillow Massager is not intended for medical use.
Consult your doctor prior to using this product if you are pregnant, have a
pacemaker or if you have any concerns regarding your health.
Read this instruction manual before operation. Be sure to comply with all
CAUTIONS and WARNINGS in this manual. Failure to follow use and operating
instructions can cause harm to the user or device.

5
PRODUCT DESCRIPTIONPRODUCT DESCRIPTION
The Shiatsu Pillow Massager combines the relief of therapeutic massage with
the beauty of a stylish throw pillow.
This easy-to-operate device offers one massage speed with optional heat. It
features four 3D massage heads that provide a deep tissue kneading
massage. Pressing the Direction button allows you to reverse the movement of
the massage heads. The massager shuts off automatically after 10 minutes of
use.
The Shiatsu Pillow Massager features a rechargeable battery for wireless
operation. It is available in four color options: Black, Pink, Gray, and Blue.
Charging port
Power button
Direction button

6
OPERATION GUIDE
1. Insert charger cable into the DC output of the massage pillow.
2. Insert the charger into your power outlet.
3. The charger light will display as RED to indicate it is charging. The full
charging cycle is 3 hours.
4. The charger light will display as GREEN when the device is fully charged.
The massager will operate ~2 hours per full charge.
5. Hold the Power button for 3 seconds to start your massage therapy with heat.
6. Press the Power button for 1 second to shut off the heat feature (red lights
will turn off). Press the Power button again to resume the heat feature
(red lights will turn on).
7. Massager will shut off automatically after 10 minutes of use. Press the
Power button for 3 seconds to resume treatment.
8. Hold the Power button for 3 seconds to stop the massager.

7
SPECIFICATIONS
Product Name: iReliev®Relaxable™
Shiatsu Pillow Massager Rated Voltage: 110-220v
Rated Power: 38W
Battery Specs: 2200Ma, 19v Lithium Battery
Charging Time: ~ 3 hours
Intended for use by adults 18 and over
Size: 16” x 8“ x 19”
Color Choice: Black/Pink/Gray/Blue
NW: 3.1 lbs
IMPORTANT
If the charger becomes damaged, it must be replaced with a DC 12.6V charger.
This will ensure your safety and prevent device damage.

8
TROUBLESHOOTING GUIDE
NOTE: Do not disassemble this device for any reason. iReliev®is not responsible
for damage to product, property or persons caused by improper use or
disassembly. Thank you for your cooperation.
For any issues not described above, please contact iReliev®Customer Service by
calling [phone] or emailing [e-mail].
Problem
Device is making a
humming or tapping noise
Possible Issue
None
Troubleshoot Method
Device is working normally
Device suddenly stops
operating
Automatic timer has expired Press the Power button
for 3 seconds to restart
Device feels hot Overheating due to prolonged
use
Discontinue use and allow
the device to cool
completely before restarting
Device will not turn on No charge Charge the device fully
before restarting

9
