Ogawa mobile seat NX User manual

User Manual
OZ 0988 使用手册
Ogawa OZ0968.indd 1 3/5/2015 5:57:53 PM

1
All information is correct at the time of print
User Manual
Ogawa OZ0968.indd 1 3/5/2015 5:57:53 PM

2
CONTENTS
Safety Instructions 03
Warranty Claims 05
Main Unit & Accessories 06
Controller Diagram 07
Product Operation Guide 08
Display 12
Product Maintenance 13
Troubleshooting 14
Product Specifications 14
Contact Us 15
S
i.
ii
.
If
c
o
ii
i
i
v
Ogawa OZ0968.indd 2Ogawa OZ0968.indd 2 3/5/2015 5:57:53 PM3/5/2015 5:57:53 PM

3
Safety Instructions
i. Usage environment
●Do not use the appliance in a wet condition or dusty environment as this may
result in malfunction or electric shock.
●Do not use the appliance in the bathroom.
●Do not place or store the appliance where it can fall or be pulled into a tub or
sink.
●Place the appliance in a safe location.
●Do not use or sit on the appliance when driving.
●Do not expose the appliance to a heater or direct sunlight.
ii. Health precautions
If you are experiencing health complications or conditions as stated below, please
consult your doctor before use:
- Suffering from heart disease.
- Pregnancy.
- Any health concerns.
iii. When the product should not be used
●If the use exceeds 15 minutes at one time.
●This unit should not be used by children or invalids without adult supervision.
●Before sleeping.
●If the fabric cover is torn.
●If water is accidentally spilled onto the appliance.
●If the user feels abnormal or severe pain during the massage.
●If the user detects any malfunction or other abnormal conditions during
operation.
●If there is lightning.
iv. Caution and warning
●Unplug the appliance from the outlet when not in use.
●Do not use any attachments that are not recommended by OGAWA.
●Do not operate this appliance if it has a damaged cord or plug. Please return
the unit to OGAWA Service Center for examination and repairs.
●Do not insert your hands or any foreign matters into the massager’s vents and
gaps.
●Handle heated surfaces carefully. The unattended use of the heated surfaces
by children or invalids may be dangerous.
●Do not lift or carry this appliance by the power cord or any cord.
●This product is only intended for personal use only. Commercial use is
prohibited.
Ogawa OZ0968.indd 3Ogawa OZ0968.indd 3 3/5/2015 5:57:53 PM3/5/2015 5:57:53 PM

4
W
1
.
2
.
3
.
4
.
5
.
6
.
7
.
8
.
9
.
Safety Instructions
●Do not cover the appliance during operation. As this may result in malfunction
or fire.
●Do not crush the appliance and avoid any sharp folds.
V. Note
●This appliance can be used by children at the age of 8 or above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge under guidance or if they have been informed of the risks involved
and instructions concerning use of the appliance in a safe way.
●Children shall not play on the appliance.
●Cleaning and maintenance shall not be performed by children without
supervision.
●To ensure safe and proper use of the appliance, do not operate it before reading
this user manual carefully first.
●Extensive usage could lead to excessive heating and a shorter product
lifespan. Should this occur, discontinue the use and allow the unit to cool before
operating again.
●It is normal to hear the noises during use, because they are resulted from
vibration of product.
●For people under medication or with a medical condition, please consult your
doctor before use. Please do not use the product if you are not feeling well.
●If the appliance is used in a cold room, do not increase the room temperature
abruptly. It is advised that the temperature is gradually increased to a normal
level.
●If the appliance is stored in a cold place and being taken into a warm environment,
please wait one hour before use to get the optimum massaging level.
●Do not remove the cover of the appliance. Mishandling the internal components
may result in malfunction or electric shock.
●Do not connect or disconnect the power plug from the electrical outlet with wet
hands.
●Do not use the appliance if the electrical outlet is loose.
●If damaged, the supply cord must be repaired by the manufacturer, after-sales
service provider or qualified persons in similar field so as to avoid a hazard.
●The appliance has a heated surface. Persons insensitive to heat must be
careful when using the appliance.
Ogawa OZ0968.indd 4Ogawa OZ0968.indd 4 3/5/2015 5:57:53 PM3/5/2015 5:57:53 PM

5
Warranty Claims
1. Warranty is not transferable.
2. This warranty is effective only if the product is purchased from OGAWA.
3. Proof of purchase (original receipt) is required for all warranty repairs.
4. All implied warranties, including but not limited to these implied warranties of fitness
and merchantability, are limited to the duration stated in the warranty policy.
5. Damage due to misuse, improper treatment and unauthorized modification and
repair are not covered by this warranty.
6. Warranty does not cover accessories and attachments which do not belong to the
massage unit.
7. Warranty is not effective to rental, business, commercial, institutional or other non-
residential users.
8. All services covered by this warranty must be approved by OGAWA and repaired by
authorized technicians only.
9. If replacement parts for defective materials are not available, OGAWA reserves the
right to make substitution in lieu of repair or replacement.
o
n
n
s
n
d
e
d
u
t
n
g
ct
r
e
m
u
r
r
e
al
n
t,
ts
e
t
e
s
b
e
Ogawa OZ0968.indd 5Ogawa OZ0968.indd 5 3/5/2015 5:57:53 PM3/5/2015 5:57:53 PM

6
Main Unit & Accessories
A) Back Cushion
B) Detachable Backrest Flap
C) Seat Cushion
D) Cable plug
E) Controller
C
Ogawa OZ0968.indd 6 3/5/2015 5:57:53 PM

1
67
89
10 11
12
3
2
4 5

8
Product Operation Guide
i. Preparation before use
●A screw is applied on the back of the product to protect the massager
apparatus during shipment. Remove the screw before use.
●Use the equipped wrench to remove the screw and insert the power cord
provided into the opening.
ii. Placing the massager
●The massager is equipped with back strap that allow user to faster onto
most chairs.
●Place the massager on a chair, wrap the two end of the strap at the back of
the chair then secure with Velcro.
iii. Backrest flap
●A detachable backrest flap is provided for a gentler massage.
●Remove the backrest flap if you prefer more intense massage.
P
1
.
2
.
3
.
4
.
5
.
6
.
Ogawa OZ0968.indd 8Ogawa OZ0968.indd 8 3/5/2015 5:57:53 PM3/5/2015 5:57:53 PM

f
Product Operation Guide
Ogawa OZ0968.indd 9 3/5/2015 5:57:53 PM
1. Power
Insert the power plug into the electric outlet. Turn on the power.
If the roller are not at the bottom position, the light of the Power button will
2. Upper Relief
This key is valid when Power is on.
Press this button to activate the Upper Relief function, the indicator light turn on.
Press this button again to close the Upper Relief function, the indicator light turn off.
3. Lower Relief
This key is valid when Power is on.
Press this button to activate the Lower Relief function, the indicator light turn on.
Press this button again to close the Lower Relief Function, the indicator light turn off.
4. Remedy
This key is valid when Power is on.
Press this button to activate the Remedy function, the indicator light turn on.
Press this button again to close the Remedy function, the indicator light turn off.
5. Refresh
This key is valid when Power is on.
Press this button to activate the Refresh function, the indicator light turn on.
Press this button again to close the Refresh function, the indicator light turn off.
6. Spot upward
This key is valid in the spot / upper relief / lower relief / remedy / refresh. Long
press this button,the roller move upward, the indicator light flashes; if the roller
touch the limit sensor, roller will stop , the indicator light turn on; release the
button, the roller will stop moving, indicator light turn off. At this point roller will
change to kneading.
7. Spot downward
This key is valid in the spot / upper relief / lower relief / remedy / refresh . Long press
this button, the roller move upward, the indicator light flashes; if the roller touch the
limit sensor, roller will stop , the indicator light turn on; release the button, the roller
will stop moving, indicator light turn off. At this point roller will change to kneading.
8. Shiatsu
This key is valid when Power is on.
Press this button, turn on (shiatsu + rolling) slow mode.,the indicator light turn on.
Press this button second time, turn on (shiatsu + rolling) fast mode, the indicator ligh
turn on.
Press this button again, turn off (shiatsu + rolling) function, the indicator light turn off.
9

Product Operation Guide
P
1
4
1
5
1
6
1
7
1
8
1
9
Ogawa OZ0968.indd 10 3/5/2015 5:57:54 PM
9. Rolling
This key is valid when Power is on.
Press this button, turn on rolling in slow mode.,the indicator light turn on.
Press this button second time, turn on rolling in fast mode, the indicator ligh turn on.
Press this button again, turn off rolling) function, the indicator light turn off.
10. Vibration
This key is valid when Power is on.
Press this button to activate the vibration, the indicator light turn on.
Press this button again to close the vibration, the indicator light turn off
11. Width adjustment
This key is valid when rolling function is on.
Press this button to adjust the massage roller width.
12. Heat
This key is valid in the spot / Upper Relief / Lower Relief / Remedy / Refresh
Press this button to activate the heating, the indicator light turn on.
Press this button again to close the heating, the indicator light turn off
10

11
P
T
O
●
●
●
●
T
O
●
●
●
●
●
C
A
●
●
●
●
●
Display
1. Shiatsu and rolling massaging programs can relax your back.
2. Fixed-position massaging function provides Shiatsu of specific position.
3. Seat cushion vibration relieves the lower body tension.
4. Heat function can increase the Shiatsu and Rolling effect and improve blood
circulation.
5. Light and portable design.
6. Easy to use remote controller.
7. Auto shut-off after 15 minutes.
8. LED light indicators.
Effects by using the appliance
1. Relieves the muscle ache and pain.
2. Relieves the tension and reduce the stress.
3. Improves blood circulation.
When you do not use the product, press the [Power] button, and please don’t cut off
the power immediately until the rollers have resumed to the bottom and the indicator
light is off.
Press the [Power] button after use and the massager will stop operating. Massage
roller will resume to their original position. Unplug the appliance from power outlet.
Ogawa OZ0968.indd 12 3/5/2015 5:57:54 PM

12
Product Maintenance
TO STORE
●Keep massager in the box or a safe, dry and cool place.
●Keep away the massager from sharp edges or pointy objects that might cut or
puncture the product’s fabric surface.
●Do not wrap the power cord around the unit.
●Do not hang the unit with the controller cord.
TO CLEAN
●Avoid immersing the unit in any liquid during cleaning.
●Unplug the unit and allow it to cool before cleaning.
●Clean only with a soft, slightly damp sponge.
●Keep the appliance away from water or any liquid.
●Avoid using abrasive cleaners, brushes, gasoline, kerosene, glass/furniture polish or
paint thinner to clean the product.
CAUTION
●Do not lean on the dual massage mechanism in the cushion when adjusting your
body position to avoid tears on the products cushion surface.
●Do not jam or force any part of your body against the moving massage mechanism.
●Not recommended for use on wooden surfaces as the zipper may damage the wood.
●Only gentle force should be exerted against the unit in order to eliminate any risk of
injury.
●Do not attempt to repair the product, please contact ‘OGAWA Service Center’ for any
servicing required.
o
d
Ogawa OZ0968.indd 13 3/5/2015 5:57:54 PM
Beware when put on light color PU / fabric seat, some material may have color dyeing
Beware when put printing document on product, some material may have color dyeing
●
●

13
Troubleshooting
Symptoms Solutions
Not operating. ●Use the product when electricity is restored.
●Reconnect the power cord.
●Turn on the power switch.
No light & heating after pressing
the heat switch.
●Press the ‘Shiatsu’ switch before turning the
‘Heat’ switch.
●Press the ‘Rolling’ switch before turning on the
‘Heat’ switch.
During operation, the controller
is working but the massager is
not working.
●The massager could be overheated after
prolonged use. It will automatically cool down
to resume its normal condition. Please turn off
the power and stop using the massager for 30
to 50 minutes to facilitate heat dissipation of the
engine.
Back massage function does
not work.
●Turn on the power switch.
●Reconnect the power cord.
Seat vibration does not work. ●Turn on the ‘Vibration’ button.
●Reconnect the power cord.
Sudden stop. ●Use the product when electricity is restored.
●Reconnect the power cord.
Product Specifications
Product Name Mobile Seat NX
Model number of the product OZ 0988
Power source 220-240V~
zH06~05ycneuqerF
Output Voltage 24V 2.5A
Power consumption 60W
Dimension (Length/width/height) L810 x W480 x H210 (mm)
gk87.7thgieW
C
Ogawa OZ0968.indd 14 3/5/2015 5:57:54 PM

District
OGAWA Vietnam Co Ltd
2nd floor,Petroland Tower,
12 Tan Trao,Tan Phu ward
Ho Chi Minh
4

15
目录
71明说全安
91限权修保
02件附及件部要主
12明说器控手
22明说作操品产
62示指能性
72养保品产
82答解难疑
82格规品产
92们我络联
安
i.
ii
.
以
ii
i
i
v
Ogawa OZ0968.indd 16 3/5/2015 5:57:54 PM

16
安全说明
i. 使用环境
●请勿在潮湿或灰尘密集的环境下使用本产品，以免导致触电或机器故障
●请勿在浴室中使用本产品。
●请勿将此产品放在浴缸或水槽旁，以免脱落。
●请将本产品存放在安全的地方。
●请勿在驾驶时，使用或坐在此产品上。
●请勿将此产品暴露于热源或阳光直射下。
ii. 健康注意事项
以下人士，请在使用前先咨询医生的意见：
- 心脏病患者
- 怀孕
- 身体不适者
iii. 以下情况请勿使用本产品
●当一次使用本产品超过15分钟时。
●小孩或残病人士在无人监督的情况下。
●睡前。
●产品外层破损。
●液体泼溅到产品上。
●使用过程中感到不寻常或剧烈疼痛。
●使用中过程中发觉任何机件故障或不寻常状况。
●打雷时
iv. 警告
●没有使用时，请拔下电源插头。
●请勿使用非OGAWA提供的配件。
●当电源线或插头损坏时，请勿使用并及时联系OGAWA服务中心进行维修检
查。
Ogawa OZ0968.indd 17 3/5/2015 5:57:54 PM

17
安全说明
●请勿将手或任何异物塞入按摩器间隙中。
●请务必谨慎使用按摩器的导热功能，勿用于对热能反应较为迟钝的皮肤上及血
液循环不良的部位。请问让儿童或身心功能障碍者自行使用导热功能。
●请勿扯动电源线来移动本产品。
●本产品仅为个人使用，禁止用于商业用途。
●请勿在使用中覆盖本产品，以免引起故障或火灾。
●请勿挤压或用尖锐物刮破本产品
v. 注意
●8岁及大于该年龄的儿童，肢体不健全、感官或者精神上有障碍或缺乏相关知
识经验的人必须在被告知相关风险以及正确使用方法，并在有人指导并监督的
情况下使用该产品。
●儿童不能在产品上玩耍。
●儿童必须在有监管的条件下才能对该产品进行清洁及维护。
●为确保安全及正确使用，使用前请务必详细参阅本说明书。
●过度使用可能会导致产品过热或缩短产品寿命，重复使用时，须让产品冷却一
段时间后再使用。
●使用时发出的声响属正常，这是由产品振动而产生的。
●正在接受药物或医疗治疗者，请在使用前咨询医师。若您感觉不适，请勿使用
本产品。
●如果在低温室中使用，请勿骤然升高温度。建议将温度逐渐升高调整到正常温
度后。
●若将产品存放于低温或高温的环境中，建议您在一小时后才进行使用本产品以
达到最佳的按摩体验
●请勿拆卸本产品。触碰内部机件可能导致故障或触电意外。
●请勿用潮湿的手安插或拔出电源插头。
●当电源插座有松动时，请勿使用。
●如果电源线破损，必须由该产品的制造商、售后服务提供商或者由类似有资质
的个人维修，以避免不良后果的产生。
●该产品有加热表面，对于热不敏感的人必须小心使用。
保
1
.
2
.
3
.
4
.
5
.
6
.
7
.
8
.
9
.
Ogawa OZ0968.indd 18 3/5/2015 5:57:54 PM

18
血
知
的
一
用
温
以
质
保修权限
1. 本保修权限不可转让。
2. 本保修服务仅对在OGAWA购买的产品有效。
3. 当要求保修服务时，请出示购买证明（正本收据）。
4. 所有保修项目，包括但不限于这些健身及适销性的保修项目有效期限需视保修政策
而定。
5. 因错误使用、处理不当以及未经授权私自改装和维修产品而导致的损坏，不属于保
修范围。
6. 此保修范围不包括不属于产品本身的附件。
7. 此保修范围不适用于租凭、交易、商业、机构或其他非住宅用户。
8. 此保修范围内所涉及的维修服务需经过OGAWA授权，且必须由授权的技术人员维
修。
9. 若需更换的维修附件缺货，OGAWA有权采用替代配件进行维修。
Ogawa OZ0968.indd 19 3/5/2015 5:57:54 PM

19
主要部件及附件
A) 背垫
B) 可拆式披风
C) 坐垫
D) 适配器接头
E) 手控器
手
Ogawa OZ0968.indd 20 3/5/2015 5:57:54 PM
