Chip PC Plug PC LXP 2310 User manual

Plug PC LXP 2310
Chip PC Linux
-
based OS
Plug PC LXP 2310
Simple, efficient, scalable - this is not your old PC. The new Plug PC
LXP 2310 from Chip PC ushers in a new era that will take the virtual
desktop and thin client beyond the familiar desktop experience to the
superior!
The Plug PC LXP 2310 supports powerful multimedia with Chip PC
video redirection (ICA/RDP), flexible 3rd party application integration
and Citrix® HDX Plug-n-Play (USB redirection). The HDX Plug-n-
Play
offers simple access to peripherals and other local resources (USB,
multi-monitor, printers, and more) in a virtual application environment
as well as local device resources. The Plug PC LXP 2310
unparalleled in-session performance offers integrated Video-over-ICA
and Video-over-RDP capabilities, where the in-session video is
redirected to be run locally. Such redirection contributes greatly to
highest video performance levels.
The Plug PC LXP 2310 draws as low as 3 watts of power at
maximum load featuring on-board multimedia acceleration; with its
design centered on ease-of-use it provides seamless integration into
cloud, virtualization and server-based computing environments.
Plug PC LXP 2310 is remotely managed by the industry-leading
management and monitoring solution from Chip PC – the Xcalibur
Global, featuring management of Linux-based devices in a Microsoft
Policy-based, Active Directory environment. Xcalibur Global provides
complete, centralized management and monitoring of thousands of
devices from the data center; It offers ultimate manageability,
monitoring and scalability from small, medium install bases to the
richest, largest, most complex cloud, virtual and server-based
environments.
The Plug PC LXP 2310 is a splendid combination of contrasts as a
desktop appliance smaller than a pack of cards yet very powerful;
providing full function multimedia video performance in a 3 watt ultra
green platform of only 6 cubic inch in size.
Highlights at a Glance:
Cross OS upgrade to Windows®CE OS (optional,
requires purchase of Microsoft license/label)
Cross OS Upgrade means that this platform support
s
interchangeable Windows®CE and Linux-
based
Operating Systems, simplifying purchase, reducing
costs and providing
utmost flexibility on the fly for
accessing any server-
based/virtualized/cloud
infrastructure
Strong Performance:
Strong performance devices supporting latest Citrix®
HDX features
Outstanding In-session Performance, including video
and sound
Powerful Multimedia Capabilities:
Powerful multimedia with Chip PC®video
redirection(ICA/RDP)
Highest, demonstrated local video performance
Powerful Linux MPlayer supporting a wide range of
video formats
Flexible, Linux-based OS:
ICA 11 with Citrix®HDX Plug-n-Play (USB redirection)
Cost-effectiveness and security advantages of ultra
thin
devices
Flexible 3rd party application support
Data integrity & security, virus-immune, no security
patches required
Value-Added Management:
Fully managed via Policy-based, value-added Xcalibur
Global management suite
Allows login to Active Directory domain from Linux-
based devices
Manage devices in any environment (LAN, WAN,
Remote site)
Green Devices:
Lowest power consumption, only 3W power
Best power/performance ratio
Smallest form-factor assures minimum carbon footprint
and maximum recycling potential
Power by monitor option with Chip PC USB power
cable
Features at a Glance:
Miniature, Portable Form Factor
RMI 1250 RISC Processor, 528 MHz, including local
multimedia acceleration
256 MB Flash/128 MB RAM DDR2
4 x USB 2.0 ports, DVI-D Video, Audio-In/Out
Resolutions: up to 1600x1200px @ 64K (16 bit) colors

Plug PC LXP 2310
Chip PC Linux
-
based OS
Product Specifications Plug PC LXP 2310
CPU •RMI Au 1250, 528 MHz RISC, equivalent to x86 1.8 GHz
Memory •128 MB DDR2
Mass Storage •256 MB Disk-On-Chip with FFS
•10 years data retention
Display Support
•Digital video DVI-D connector
Resolutions •Up to 1600x1200 Pixels @ 64k (16 bit)
Video Player •DivX HD CODEC (hardware accelerated)
•MPEG4 (hardware accelerated)
Audio Support •Stereo Audio Output - 3 mm (1/8 inch) Audio-Out Jack; 16-bit Stereo
•Microphone Input - 3 mm (1/8 inch) Audio-In Jack
•Software volume / mute control
Input/Output •4 x USB 2.0 ports
Operating System •Linux-based kernel
Firmware •ICA 11 with Citrix® HDX Plug-n-Play (USB redirection)
•RDP (RDesktop 1.6)
•MPlayer
•X-Windows 7.2 server
Network
•10/100 Fast Ethernet, twisted pair (RJ-45) with Auto-negotiate TCP/IP with
DNS and
DHCP
•Wake On LAN support
Warranty
•
1 year automatic Warranty, additional 2 years pending on product registration
http://www.chippc.com
•Extended Warranty for
years 4 & 5, optional, to be obtained during first year after
purchase

Plug PC LXP 2310
Chip PC Linux
-
based OS
Product Specifications Plug PC LXP 2310
Power •Device input: 5V DC 2A max.
•Normal power consumption:3W
•Power consumption (sleep mode): 0.35W
•Wall-mount power supply input: Universal 90 – 240V AC 50-60 Hz input (included)
•Optional USB power (no AC/DC is required)
Physical Characteristics
•Dimensions: 5 (W) x7.7 (D) x 2.4 (H) cm / 2 (W) x 3 (D) x 0.9 (H) inch
•Device weight: 62 gr [2 oz]
•Shipping weight: 0.3 Kg [0.7 lbs]
Environmental
•Temperature range: Operating - 32ºF to 104ºF (0ºC to 40ºC)
•Storage: -46ºF to 163ºF (-20ºC to 70ºC)
•Humidity: Operating - 20 to 80% non condensing; Storage - 0 to 90% non condensing
•Altitude: 0 to 42,000 ft
Regulatory Compliance •Safety: UL 1950, cUL, EN/IEC60950-1
•EMI/EMC: FCC Class B, CE Mark, EN61000-6-3, EN61000-6-1, VCCI
•EPA ENERGY STAR
Optional Software Plug-
Ins (for an additional
cost)
•Visit www.chippc.com to download /purchase
Optional Accessories
(for an additional cost)
•Visit www.chippc.com for an updated list
Enclosure Color Black Metalized
Monitor, keyboard and mouse - to be purchased separately
Xcalibur Global & Plugin licenses - to be purchased separately
Above features are supported in latest firmware image version released
Actual display support is dependent on display hardware and cable quality; some of the resolutions and display modes described
above may not be supported by certain displays or cables
Specifications are subjected to change without prior notice

Plug PC LXP 2310
Chip PC Linux
-
based OS
The Company
Since its inception, Chip PC has been a world leader in server-
centric-computing. A public company with branches in Europe
and the U.S., Chip PC develops and manufactures, top notch,
thin client technology and management systems to integrate
seamlessly with any cloud, server-based or virtualization
environment.
Chip PC’s team of dedicated researchers and developers have
combined their years of experience to yield novel ideas and
deliver an outstandingly innovative family of thin client
products.
With the award winning Xcalibur Global management system
and innovative thin client units, Chip PC maintains a leading
market position with its end-to-end solution.
The End-to-End Solution
Chip PC is aimed at solving the thorny problem of
combining intelligent thin client networking with
sophisticated management and control. Chip PC’s
unique solution constructs a ground-up thin client
network from the revolutionary Jack PC that fits into
a standard wall jack, through the Xtreme PC Series,
state-of-the art, powerful, desktop units, the
miniature Plug PCs and powerful EX PCs.
These revolutionarily designed, units are
comprehensively managed by Chip PC’s Xcalibur
Global. The Xcalibur Global Management System
simulates an Active Directory environment with
intelligent usage of its management principles of
policies and tools and offers flexible management
that applies down to the specific needs of every particular client unit or user.
