ThinkPad®Regulatory Notice
Read first —regulatory information
Please read this document before you use the ThinkPad computer. ThinkPad
computer complies with the radio frequency and safety standards of any
country or region in which it has been approved for wireless use. You must
install and use your computer in strict accordance with the instructions as
described hereafter.
If your ThinkPad computer contains aWireless WAN adapter, be sure to also
read ThinkPad Regulatory Notice for Wireless WAN adapter,included with your
computer.
Veuillez lire ce document avant d’utiliser l’ordinateur ThinkPad.L’ordinateur
ThinkPad est conforme aux normes de sécurité et de radiofréquence du pays
ou de la région où son utilisation sans fil est agréée. Vous devez installer et
utiliser votre ordinateur en respectant scrupuleusement les instructions
décrites ci-après.
Si votre ordinateur ThinkPad contient une carte de réseau étendu (WAN) sans
fil, veillez àlire également la consigne réglementaire ThinkPad Regulatory
Notice for Wireless WAN adapter,fournie avec votre ordinateur.
USA —Federal Communications Commission (FCC)
I. User installable Wireless LAN module
WLAN Mini PCI Express Cards:
vFCC ID: PPD-AR5BHB63-L (Model: AR5BHB63-L)
vFCC ID: PD9LEN512ANMU (Model: 512AN_MMW)
Wireless LAN Mini PCI Express Cards marketed in the USA and Canada do
not support nor function in the extended channels (12ch, 13ch).
For information concerning the wireless cards announced after the publication
of this notice, visit the Web site at http://www.lenovo.com/support/site.wss/
document.do?sitestyle=lenovo&lndocid=tpad-matrix
i) The FCC RF Exposure compliance: The radiated output power of the
Wireless LAN Mini PCI Express Card authorized to use for the your
©Copyright Lenovo 2008 1

ThinkPad computer is far below the FCC radio frequency exposure limits.
Nevertheless, it shall be used in such amanner that the potential for human
contact during normal operation is minimized as follows:
Caution: To comply with FCC RF exposure compliance requirements, a
separation distance of at least 20 cm (8 inches) must be maintained between
the antennas for the integrated Wireless LAN Mini PCI Express Cards built
into the screen section and all persons. You are not allowed to disable
“sleep (standby) mode” for the power management function, if you cannot
maintain the sufficient antenna separation (at least 20 cm) in any case the
LCD is left opened or closed.
For the location of the antenna, see the ″Location of the UltraConnect wireless
antennas″section in Access Help.
Note: The transmission diversity function is implemented for this product.
For WLAN card (Model: AR5BHB63-L) using Main and Auxiliary antennas for
transmission in the 802.11 b/g transmission mode, radio frequency energy is
not emitted simultaneously from both Main and Auxiliary antennas. One of
the antennas is selected automatically or manually (by users) to have good
quality of radiocommunication (transmission diversity function). For WLAN
card (Model: 512AN_MMW) in the 802.11 a/b/g, or MIMO( Multiple In
Multiple Out )transmission mode, the radio frequency energy is emitted from
Main antenna.
ii) FCC ID of wireless module: There is no FCC ID for Mini PCI Express
Card shown on the enclosure of your ThinkPad computer. Instead you will
find an indicator pointing to the location of the FCC ID on the bottom side of
your ThinkPad computer. For the location of the FCC ID indicator, see the
“Location of the FCC ID and IC Certification number label” section in Access
Help. The FCC ID is affixed on the approved module installed in the Mini
PCI Express Card slot. For the location of the slot, see the “PCI Express Mini
Card slot for wireless LAN/WiMAX” section in Access Help.
iii) Installation of approved wireless module: If no integrated wireless LAN
Mini PCI Express Card has been preinstalled in your ThinkPad computer, you
can install one, provided by Lenovo as an option. Plug the wireless card
option into the Mini PCI Express Card slot. For the installation procedure, see
the ″Installing and replacing the PCI Express Mini Card for wireless
LAN/WiMAX connection″section in Access Help.
Attention: The ThinkPad computers contain an authentication mechanism.
If you install an unauthorized wireless LAN Mini PCI Express Card that is
not approved for use in your computer, the computer will not start, but only
displays an error message and emits audible beeps.
2

iv) Radio Frequency interference requirements:
vThe devices have been tested and found to comply with the limits for a
Class Bdigital device pursuant to FCC Part 15 Subpart B. The model
AR5BHB63-L was subject to DoC. Refer to “Electronic emission notices” on
page 8. The model 512AN_MMW underwent the certification process with
each respective FCC ID number listed in “I. User installable Wireless LAN
module” on page 1.
vEach device is restricted to indoor use due to its operation in the 5.15 to
5.25 GHz frequency range. FCC requires these products to be used indoors
for the frequency range 5.15 to 5.25 GHz to reduce the potential for harmful
interference to co-channel Mobile Satellite systems.
vHigh power radar are allocated as primary users of the 5.25 to 5.35 GHz
and 5.65 to 5.85 GHz bands. These radar stations can cause interference
with and/or damage this device.
II. Preinstalled integrated Bluetooth module
vFCC ID: QDS-BRCM1033 (Model: BCM92046MD_GEN)
i) FCC ID and installation of the module: If you find the FCC ID
“QDS-BRCM1033” on the label at the bottom side of your computer, your
computer integrates the Bluetooth transmitter module (Model:
BCM92046MD_GEN). The Bluetooth module is preinstalled by Lenovo, and is
not removable by users. If your card requires replacement via the proper steps
shown in ″Getting help and service″of the Service and Troubleshooting Guide,
shipped with your computer, Lenovo will request you to send your computer
with the card to Lenovo so that Lenovo will repair it.
ii) The FCC RF safety requirement: The radiated output power of the
Bluetooth module is far below the FCC radio frequency exposure limits.
Therefore, a20 cm of separation between the Bluetooth antenna and human
body is not required.
For the location of the Bluetooth module “BCM92046MD_GEN” and its built-in
antenna, see the ″About your computer″section in Access Help.
iii) Radio Frequency interference requirements: The device has been tested
and found to comply with the limits for both aClass Bdigital device
regarding FCC Part 15 Subpart Band an intentional radiator regarding FCC
Part 15 Subpart C; then it underwent the certification processes for both rules.
Thus the FCC ID QDS-BRCM1033 of this device includes both certifications of
Part 15 Subpart Band C.
III. Simultaneous use of RF transmitters
Your ThinkPad computer is approved for simultaneous use of the transmitters
listed below:
vWireless LAN adapter (FCC ID: PPD-AR5BHB63-L or PD9LEN512ANMU)
3

vBluetooth module (FCC ID: QDS-BRCM1033)
Please make sure of the following conditions on use of these wireless features:
1. When you use any other RF option device, all other wireless features
including the above integrated devices in your ThinkPad computer are
required to be turned off.
2. Users must follow the RF Safety instructions on wireless option devices
that are included in the RF option device’s user’s manual.
Canada —Industry Canada (IC)
IC Certification number
I) User installable Wireless LAN modules:
vIC: 4104A-ARBHB63L (Model: AR5BHB63-L)
vIC: 1000M-L512ANMU (Model: 512AN_MMW)
Wireless LAN Mini PCI Express Cards marketed in the USA and Canada do
not support nor function in the extended channels (12ch, 13ch).
There is no certification number of Industry Canada for Mini PCI Express
Card shown on the enclosure of your ThinkPad computer. Instead you will
find an indicator pointing to the location of the IC Certification number on the
bottom side of your ThinkPad computer. For the location of the IC
Certification number indicator, see the “Location of the FCC ID and IC
Certification number label” section in Access Help. The IC certification
number is affixed on the approved module installed in the Mini PCI Express
Card slot. For the location of the slot, see the “PCI Express Mini Card slot for
wireless LAN/WiMAX” section in Access Help.
Attention: The ThinkPad computer contains an authentication mechanism.
You can install or remove each wireless feature by yourself. If you install an
unauthorized wireless adapter that is not approved for use in the ThinkPad
computer, the computer will not start, but only displays an error message and
emits audible beeps.
II) Preinstalled integrated Bluetooth module:
vIC: 4324A-BRCM1033 (Model: BCM92046MD_GEN)
If you find an indication “Contains Transmitter Module: Canada IC:
4324A-BRCM1033” on the label at the bottom side of your computer, your
computer integrates the Bluetooth transmitter module. The Bluetooth module is
preinstalled by Lenovo, and is not removable by users. If your card requires
replacement via the proper steps shown in ″Getting help and service″of the
Service and Troubleshooting Guide,Lenovo will request you to send your
computer with the card to Lenovo so that Lenovo will repair it.
4

III) Low power license-exempt radiocommunication devices (RSS-210):
Operation is subject to the following two conditions:
1. This device may not cause interference, and
2. this device must accept any interference, including interference that may
cause undesired operation of the device.
The transmitter devices have been designed to operate with the antennas
integrated in ThinkPad computer, and having amaximum gain of within 3
dBi.
The maximum antenna gain permitted for devices in the 5250-5350 MHz,
5470-5725 MHz, and 5725-5825 MHz bands complies with the e.i.r.p. limit in
section A9.2 of RSS-210.
When you use the model 512AN_MMW:
vThe devices for the band 5150–5250 MHz are only for indoor usage to
reduce potential for harmful interference to co-channel Mobile Satellite
systems.
vHigh power radars are allocated as primary users (meaning they have
priority) of 5250–5350 MHz and 5650–5850 MHz and these radars could
cause interference and/or damage to LELAN (Licence-Exempt Local Area
Network) devices.
IV) Exposure of humans to RF fields (RSS-102): ThinkPad computers
employ low gain integral antennas that do not emit RF field in excess of
Health Canada limits for the general population; consult Safety Code 6,
obtainable from Health Canada’s Web site at www.hc-sc.gc.ca/
The radiated energy from the antennas connected to the wireless adapters
conforms to the IC limit of the RF exposure requirement regarding IC
RSS-102, Issue 2clause 4.2.
Numéro d’homologation IC
I) Module sans fil installable par l’utilisateur: Les cartes Express mini-PCI
de réseau local sans fil:
vIC: 4104A-ARBHB63L (Model: AR5BHB63-L)
vIC: 1000M-L512ANMU (Model: 512AN_MMW)
Les cartes de réseau local sans fil Express mini-PCI commercialisées aux
Etats-Unis et au Canada ne prennent pas en charge les canaux étendus (12ch,
13ch) et ne fonctionnent donc pas sur de tels canaux.
Le boîtier de votre ordinateur ThinkPad ne comporte pas de numéro
d’homologation IC (Industry Canada) pour la carte mini-PCI Express ;mais
sous votre Thinkpad, vous trouverez un indicateur pointant vers
5

l’emplacement du numéro d’homologation IC. Pour connaître l’emplacement
du numéro d’homologation IC, consultez la section correspondante dans l’aide
Access. Le numéro d’homologation IC est apposé sur le module installé dans
le logement pour carte mini-PCI Express. Pour savoir où se trouve cet
emplacement, consultez la section ″Logement pour cartes mini-PCI Express
pour réseau local/WiMAX″dans Access Help.
Attention: L’ordinateur ThinkPad contient un mécanisme d’authentification.
Vous pouvez installer ou désinstaller tout dispositif sans fil. Si vous installez
une carte sans fil qui n’est pas homologuée dans votre ordinateur ThinkPad,
l’ordinateur ne démarrera pas mais affichera un message d’erreur et générera
des bips sonores.
II) Module Bluetooth intégré préinstallé:
vIC: 4324A-BRCM1033 (Model: BCM92046MD_GEN)
Si la mention “Contains Transmitter Module: Canada IC: 4324A-BRCM1033”
figure sur l’étiquette située au bas de votre ordinateur, cela signifie que ce
dernier intègre le module de transmission Bluetooth.Le module Bluetooth est
préinstallé par Lenovo et ne peut pas être retiré par les utilisateurs. Si votre
carte doit être remplacée conformément aux étapes du Chapitre relatif àl’aide
et la maintenance dans le manuel Guide de maintenance et d’identification des
incidents,Lenovo vous demandera de lui envoyer votre ordinateur
accompagné de la carte pour réparation.
III) Remarque relative aux appareils de communication radio de faible
puissance sans licence (CNR-210): Le fonctionnement de ce type d’appareil
est soumis aux deux conditions suivantes:
1. Cet appareil ne doit pas perturber les communications radio, et
2. cet appareil doit supporter toute perturbation, ycompris les perturbations
qui pourraient provoquer son dysfonctionnement.
Les périphériques d’émission sont conçus pour fonctionner avec des antennes
intégrées aux ThinkPad et ayant un gain maximal de moins de 3dBi.
Le gain d’antenne maximal pour les périphériques dans les bandes de
fréquence 5250-5350 MHz, 5470-5725 MHz, et 5725-5825 MHz est conforme à
la limite p.i.r.e énoncée dans la section A9.2 de la CNR-210.
Lorsque vous utilisez le modèle 512AN_MMW:
vTout appareil destiné àla bande 5150-5250 MHz devra être exclusivement
utilisé en intérieur afin de réduire les risques de perturbations
électromagnétiques gênantes sur les systèmes de satellite mobile dans un
même canal.
vLes radars àforte puissance sont désignés comme les utilisateurs
principaux (c’est-à-dire qu’ils sont prioritaires) des bandes 5250-5350 MHz
6

et 5650-5850 MHz. Ils peuvent provoquer des perturbations
électromagnétiques sur les appareils de type LELAN (réseau de
communication local sans licence) ou les endommager.
IV) Exposition des êtres humains aux champs radioélectriques (RF)
(CNR-102): L’ordinateur ThinkPad utilise des antennes intégrales àfaible
gain qui n’émettent pas un champ électromagnétique supérieur aux normes
imposées par le Ministére de la santé canadien pour la population. Consultez
le Safety Code 6sur le site Web du Ministére de la santé canadien àl’adresse
www.hc-sc.gc.ca/
L’énergie émise par les antennes reliées aux adaptateurs sans fil respecte la
limite d’exposition aux radiofréquences telle que définie par Industrie Canada
dans la clause 4.2 du document CNR-102.
7

Electronic emission notices
Federal Communications Commission (FCC) Statement
vModel: AR5BHB63-L
Note: The models 512AN_MMW and BCM92046MD_GEN underwent
certification process for the FCC Part 15 Subpart Bcompliance under each
respective FCC ID number.
This equipment has been tested and found to comply with the limits for a
Class Bdigital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in aparticular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
vReorient or relocate the receiving antenna.
vIncrease the separation between the equipment and receiver.
vConnect the equipment into an outlet on acircuit different from that to
which the receiver is connected.
vConsult an authorized dealer or service representative for help.
Lenovo is not responsible for any radio or television interference caused by
unauthorized changes or modifications to this equipment. Unauthorized
changes or modifications could void the user’s authority to operate the
equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Responsible Party:
Lenovo (United States) Incorporated
1009 Think Place-Building One
Morrisville, NC 27560
Telephone: [phone]
8

Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
Industry Canada Class BEmission Compliance Statement
This Class Bdigital apparatus complies with Canadian ICES-003.
Avis de conformité àla réglementation d’Industrie Canada
Cet appareil numérique de la classe Best conforme àla norme NMB-003 du
Canada.
Telecommunication notices
Federal Communications Commission (FCC) and Telephone Company
Requirements (Part 68 of the FCC Rules)
1. The Telephone Consumer Protection Act of 1991 makes it unlawful for
any person to use acomputer or other electronic device to send any
message via atelephone fax machine unless such message clearly
contains in amargin at the top or bottom of each transmitted page or on
the first page of the transmission, the date and time it is sent, and an
identification of the business or other entity, or other individual sending
the message and the telephone number of the sending machine or such
business, other entity, or individual.
In order to program this information into your computer, you should be
sure to follow the installation instructions for your fax software package.
2. This equipment complies with Part 68 of the FCC rules and the
requirements adopted by the ACTA. On this equipment is alabel that
contains, among other information, aproduct identifier in the format
US:AAAEQ##TXXXX. If requested, this number must be provided to the
telephone company.
3. The REN is used to determine the number of devices that may be
connected to atelephone line. Excessive RENs on atelephone line may
result in the devices not ringing in response to an incoming call. In most
but not all areas, the sum of RENs should not exceed five (5.0). To be
certain of the number of devices that may be connected to aline, as
determined by the total RENs, contact the local telephone company. The
REN for this product is part of the product identifier that has the format
US:AAAEQ##TXXXX. The digits represented by ## are the REN without
adecimal point (e.g., 03 is aREN of 0.3).
4. If the built-in modem causes harm to the telephone network, the
telephone company may discontinue your service temporarily. If possible,
they will notify you in advance. But, if advance notice isn’t practical, you
will be notified as soon as possible. You will be advised of your right to
file acomplaint with the FCC.
9

5. Your telephone company may make changes in its facilities, equipment,
operations, or procedures that could affect the proper operation of your
equipment. If they do, you will be given advance notice so as to give you
an opportunity to maintain uninterrupted service.
6. No customer repairs are possible to the modem. If you experience trouble
with this built-in modem, contact your Lenovo Authorized Seller, or the
Customer Support Center. For the most current phone numbers, go to
http://www.lenovo.com/think/support and click Support phone list.
The telephone company may ask you to disconnect this equipment from
the network until the problem has been corrected, or until you are sure
the equipment is not malfunctioning.
7. The modem may not be used on coin service provided by the telephone
company. Connection to party lines is subject to state tariffs. Contact your
state public utility commission or corporation commission for
information.
8. When ordering network interface (NI) service from the Local Exchange
Carrier, specify service arrangement USOC RJ11C.
9. Aplug and jack used to connect this equipment to the premises wiring
and telephone network must comply with the applicable FCC Part 68
rules and requirements adopted by the ACTA. Acompliant telephone
cord and modular plug is provided with this product. It is designed to be
connected to acompatible modular jack that is also compliant. See
installation instructions for details.
10. If your home has specially wired alarm equipment connected to the
telephone line, ensure the installation of this Data/Fax Modem does not
disable your alarm equipment. If you have questions about what will
disable alarm equipment, consult your telephone company or aqualified
installer.
Industry Canada requirements
Notice:This equipment meets the applicable Industry Canada Terminal
Equipment Technical Specifications. This is confirmed by the registration
number. The abbreviation, IC, before the registration number signifies that
registration was performed based on aDeclaration of Conformity indicating
that Industry Canada technical specifications were met. It does not imply that
Industry Canada approved the equipment.
Before installing this equipment, users should ensure that it is permissible to
be connected to the facilities of the local telecommunications company. The
equipment must also be installed using an acceptable method of
communication. In some cases, the company’s inside wiring associated with a
single line individual service may be extended by means of acertified
connector assembly (telephone extension cord). The customer should be aware
that compliance with the above conditions may not prevent degradation of
service in some situations.
10

Repairs to certified equipment should be made by an authorized Canadian
maintenance facility designated by the supplier. Any repairs of alterations
made by the user to this equipment, or equipment malfunctions, may give the
telecommunications company cause to request the user to disconnect the
equipment.
Users should ensure for their own protection that the electrical ground
connections of the power utility, telephone lines and internal metallic water
pipe system, if present, are connected together. This precaution may be
particularly important in rural areas.
Caution:Users should not attempt to make such connections themselves, but
should contact the appropriate electric inspection authority, or electrician, as
appropriate.
The Ringer Equivalence Number (REN) for the terminal equipment
RD02-D450 is 0.1. The REN assigned to each terminal equipment provides an
indication of the maximum number of terminals allowed to be connected to a
telephone interface. The termination on an interface may consist of any
combination of devices subject only to the requirement that the sum of the
Ringer Equivalence Numbers of all the devices does not exceed five.
Avis:Le présent matériel est conforme aux spécifications techniques
d’Industrie Canada applicables au matériel terminal. Cette conformité est
confirmée par le numéro d’enregistrement. Le sigle IC, placé devant le
numéro d’enregistrement, signifie que l’enregistrement s’est effectué
conformément àune déclaration de conformité et indique que les
spécifications techniques d’Industrie Canada ont été respectées. Il n’implique
pas qu’Industrie Canada aapprouvé le matériel.
Avant d’installer ce matériel, l’utilisateur doit s’assurer qu’il est permis de le
raccorder aux installations de l’entreprise locale de télécommunication. Le
matériel doit également être installé en suivant une méthode acceptée de
raccordement. Dans certains cas, les fils intérieurs de l’entreprise utilisés pour
un service individuel àligne unique peuvent être prolongés au moyen d’un
dispositif homologué de raccordement (cordon prolongateur téléphonique
interne). L’abonné ne doit pas oublier qu’il est possible que la conformité aux
conditions énoncées ci-dessus n’empechent pas la dégradation du service dans
certaines situations. Actuellement, les entreprises de télécommunication ne
permettent pas que l’on raccorde leur matériel àdes jacks d’abonné, sauf dans
les cas précis prévus par les tarifs paticuliers de ces entreprises.
Les réparations de matériel homologué doivent être effectuées par un centre
d’entretien canadien autorisé désigné par le fournisseur. La compagnie de
11

télécommunications peut demander àl’utilisateur de débrancher un appareil à
la suite de réparations ou de modifications effectuées par l’utilisateur ou à
cause de mauvais fonctionnement.
Pour sa propre protection, l’utilisateur doit s’assurer que tous les fils de mise
àla terre de la source d’énergie électrique, des lignes téléphoniques et des
canalisations d’eau métalliques, s’il yen a, sont raccordés ensemble. Cette
précaution est particulièrement importante dans les régions rurales.
Avertissement:L’utilisateur ne doit pas tenter de faire ces raccordements
lui-même; il doit avoir recours àun service d’inspection des installations
électriques, ou àélectricien, selon le cas.
L’indice d’équivalence de la sonnerie (IES) du présent matériel RD02-D450
este de 0.1. L’IES assigné àchaque dispositif terminal indique le nombre
maximal de terminaux qui peuvent être raccordés àune interface
téléphonique. La terminaison d’une interface peut consister en une
combinaison quelconque de dispositifs, àla seule condition que la somme
d’indices d’équivalence de la sonnerie de tous les dispositifs n’excède pas 5.
Trademarks
The following terms are trademarks of Lenovo in the United States, other
countries, or both:
Lenovo®
ThinkPad®
Other company, product, and service names may be trademarks or service
marks of others.
Printed in China
12
