Christie M Series User manual

Portrait Adapter Instruction Sheet 1 of 5
020-100304-02 Rev. 1 (10-2010)
Portrait Adapter
Instruction Sheet
INTRODUCTION
This document describes user instructions for the M Series Portrait Adapter (#118-116109-XX).
Do not use the Portrait Adapter if the mirror is cracked or broken.
Do not look directly into the light from the mirror while projector is switched
on.
Figure 1 Portrait Adapter

2 of 5 Portrait Adapter Instruction Sheet
020-100304-02 Rev. 1 (10-2010)
The Portrait Adapter, which uses a front-surface mirror mounted at 45° to the optical axis, allows the
displayed image to be changed from landscape to portrait (see Figure 2). The adapter mounts directly
to the projection lens.
Figure 2 Image Displayed as Portrait
The applicable projection lenses and specifications in portrait mode are given below.
NOTE: *Some distortion of the image may occur with this lens.
Mirage S+/HD/WU
Matrix S+HD/WU
Christie HD/DS+/WU, DLV
Lens Part Number
M Series Models
Lens Part Number Lens Throw Ratio Horizontal Offset
Vertical
Offset
104-113101-01 118-100113-01 2.0-2.8:1 SXGA+
1.8-2.6:1 HD
±65%
±85%
±50%
±35%
104-114101-01 118-100114-01 2.8-4.5:1 SXGA+
2.6-4.1:1 HD
±100%
±119%
±50%
±42%
104-115101-01 118-100115-01 4.5-7.5:1 SXGA+
4.1-6.9:1 HD
±100%
±119%
±50%
±42%
104-130101-01 118-100116-01* 7.5-11.2:1 SXGA+
6.9-10.4:1 HD
±100%
±119%
±50%
±42%

Portrait Adapter Instruction Sheet 3 of 5
020-100304-02 Rev. 1 (10-2010)
INSTRUCTIONS
To prepare for Portrait Adapter installation:
- Always attach the Portrait Adapter Safety Cable for all installations.
1. Remove the protective film from the surface of the mirror.
To attach the Portrait Adapter:
2. Loosen the locking latch, see Figure 4.
Figure 3 Secure Safety Cable with Carabiner Clip
Figure 4 - Latched Unlocked

4 of 5 Portrait Adapter Instruction Sheet
020-100304-02 Rev. 1 (10-2010)
3. Move the Portrait Adapter onto the end of the projection lens (see Figure 5).
Make sure the collar touches the end of the projection lens, see Figure 6 for correct installation, and
Figure 7 for incorrect installation. NOTE: If necessary, cut a 1/2 inch strip of foam (supplied) and
apply to the colar of the portrait adapter to obtain a tight fit when the latch is closed.
Figure 6 - CORRECT Installation Figure 7 - INCORRECT Installation
Figure 5 - Mounting the Portrait Adapter

Portrait Adapter Instruction Sheet 5 of 5
020-100304-02 Rev. 1 (10-2010)
4. Lock the latch, refer to Figure 8. NOTE: Make sure the the Portrait Adapter is fixed to the
projection lens when the latch is closed.
5. Focus the image, and if necessary unlock and rotate the Portrait Adapter to make sure the mirror
edge is aligned properly with the screen. NOTES:1) Make sure the latch is fully locked when
complete. 2) For lens 118-100113-XX, it is necessary to unlock the Portrait Adapter to focus the
lens without rotating the Adapter.
6. Focus, zoom and offset the lens as necessary. NOTE: For some applications, it may be necessary
to boresight the lens mount with the Portrait Adapter installed, refer to the M Series User Manual
for details.
7. Using the on-screen menu, set the correct image orientation based on projector installation.
• To set the image orientation, select the MAIN MENU > CONFIGURATION > OUTPUT OPTIONS
> SCREEN IMAGE ORIENTATION.
Figure 8 - Latch Locked
