MOVEMENT SPECIFICATIONS
CAL. : 6P73/6P75/6P77/6P79
10-1/2 LINGE, MULTI FUNCTION WITH HIGH HAN
D
ANALOGUE QUARTZ, NO JEWEL
BY CITIZEN WATCH CO., LTD. JAPAN
MANUFACTURED IN JAPAN
1.BASIC SPECIFICATION
S
(1) Cal. No. *TO CONFIRM WITH MOV'T DRAWING ATTACHED
CALIBRE 6P73 6P75 6P77 6P79
Ligne
Size*mm
Date 12H 3H 12H 3H
Da
y
×9H9H9H
24Hou
r
6H × 6H 6H
Total heigh
t
Battery life
Batter
y
These calibers above which has anHIGH HAND structure:
each caliber above which has an eye position same as: :
3.45mm
A
pprox. 3 year
s
SILVER OXIDE SR621S
W
or equivalent
10-1/2
22.6×22.6×Φ23.3mm
24H
DateDay
Date
24H
DayDateDay
Date
24H
6P73 6P796P75 6P77
6P23 6P296P25 6P27
Center Hands
Height
Small Hands
Height
6P2＊6P2＊

(2) Time standard
Type of quartz : Tuning fork type quartz crysta
l
Frequency : 32,768H
z
A
ccuracy : +/-20 s/month worn under normal circumstances
(3) Balanceable weight of hand
Minute hand : Max. 0.4 μN.m
Second hand : Max. 0.07 μN.m
Small hands : Max. 0.02 μN.m
(4) Function
24hour, date and retrograde day indicator by small hands.
Powercell Saving Reset Mechanism (PSRM)
Over-loading Compensation Device (OLCD)
Digital Frequency Control (DFC) for time adjustment
2.SEPARATED PART
S
Setting stem x1
Code 065-379
Length from movement center to far end 20.03mm
of setting stem
Thread................................. Ф0.9mm x 12.18mm
3.OTHERS
* Measurement of time rate
The unit (gate) time of measurement must be set at "10 sec." or integer fold
value of 10 sec. owing to the DFC system, and the measurement must be
performed in the form of complete watch.
* Marking on movement
JAPAN
MIYOTA CO.
6P73/75/77/79
NO JEWELS
* Typical clearance
Mov't - Caseback minimum 150 microns
Top of hands - Glass 300 - 400 microns *
* subject to the glass, case structure, and the length of hand

4. INSTRUCTIONS MANUAL
A
) DISPLAYS
B) SETTING THE TIME
For 6P73,6P75,6P77,6P79
1. Pull the crown out to the 2nd Click Position.
2. Turn the crown to set hour and minute hands.
C) SETTING THE DATE
For 6P73,6P75,6P77,6P79
*Please do not set the date between 9:00 PM and 1:00AM
.
1. Pull the crown out to the 1st Click Position.
2. Turn the crown counter-clockwise to set the date.
3.After the date has been set, push the crown back to the noraml position.
D)SETTING THE DAY
For 6P75,6P77,6P79
1. Pull the crown to the 2nd Click Position.
2. Turn the crown clockwise to gain the hour and minute hand.
*The day changes between 0:00 and 5:30AM.
3.After the day has been set, push the crown back to the noraml position.
E)24HOUR
For 6P73, 6P77, 6P79
24Hour hand moves linked with the hour hand.
These specifications might be changed without prior notice.
6P75
Hour Hand Minute Hand
Hour Hand
Day Hand
Date Hand
Normal Position
1st Click Position
2nd Click Position

6P73 6P75 6P77 6P79 6P57
* Other specifications are same as 6P23 / 6P25 / 6P27 / 6P29 .
High Hand version of 6P23 / 6P25 / 6P27 / 6P29
























***** CAL.
6P73/75/77/79
MOV'T PARTS LIST *****
HIGH HAND
ORIGINAL PARTS, MADE IN JAPAN
PART NAME
6P73
6P75
6P77
6P79
HOUR
WHEEL
075-306
075-306
075-306
075-306
CANON PINION WITH DRIVING WHEEL
028-137
028-137
028-137
028-137
FORTH WHEEL AND PINION
023-224
023-224
023-224
023-224
24HOUR
WHEEL
100-430
100-430
100-430
100-430
DAY
WHEEL
-
200-070
200-070
200-070
DATE
WHEEL
187-130
187-150
187-130
187-150
*Ot er parts are same as
・・・
6
P
23
(=
6
P
73
)
6P25 (=6P75)
6
P
27
(=
6
P
77
)
6
P
29
(=
6
P
79
)

***** CAL.
6PXX
MOV'T PARTS LIST *****
ORIGINAL PARTS, MADE IN JAPAN
PART NAME
6P23
6P25
6P27
6P29
24 HOUR WHEEL
100-350
100-340
100-350
100-350
24 HOUR WHEEL GUARD
117-270
117-260
117-270
117-270
BATTERY
280-340
280-340
280-340
280-340
BATTERY CONNECTOR SPRING
231-163
231-163
231-163
231-163
CALENDAR CORRECTING PILLAR WHEEL
255-340
255-340
255-340
255-340
CANNON PINION WITH DRIVING WHEEL
028-196
028-196
028-196
028-196
CENTER WHEEL COCK
711-183
711-183
711-183
711-183
CLUTCH WHEEL
064-790
064-790
064-790
064-790
COIL UNIT
246-121
246-121
246-121
246-121
DATE CORRECTOR WHEEL
213-330
213-330
213-330
213-330
DATE DIAL DRIVING WHEEL
103-970
103-970
103-970
103-970
DATE FINGER
106-740
106-740
106-740
106-740
DATE JUMPER
109-520
109-520
109-520
109-520
DATE WHEEL
187-060
187-080
187-060
187-080
DAY WHEEL
-
200-030
200-030
200-030
DIAL GUARD
293-870
293-870
293-870
293-870
DIAL GUARD GIB
027-102
027-102
027-102
027-102
ELECTRINIC CIRCUIT UNIT
279-735
279-735
279-735
279-735
FIFTH WHEEL & PINION
084-460
084-460
084-460
084-460
FOURTH WHEEL & PINION
023-205
023-205
023-205
023-205
HOUR WHEEL
075-328
075-328
075-328
075-328
INTERMEDIATE 24 HOUR DRIVING WHEEL(1)
087-990
087-990
087-990
087-990
INTERMEDIATE 24 HOUR DRIVING WHEEL(2)
087-101
087-101
087-101
087-101
INTERMEDIATE DATE CORRECTING WHEEL
087-620
087-620
087-620
087-620
INTERMEDIATE DATE WHEEL(1)
100-330
100-330
100-330
100-330
INTERMEDIATE DATE WHEEL(2)
103-950
100-340
-
100-340
MINUTE WHEEL AND PINION
072-890
072-890
072-890
072-890
MONTH CORRECTOR LEVER GUARD
-
117-260
-
117-260
ROTOR
285-800
285-800
285-800
285-800
SCREW FOR CALENDAR GUARD(X3)
929-520
929-520
929-520
929-520
SCREW FOR TRAIN FOR BRIDGE(X4)
-
923-810
923-810
923-810
SCREW FOR TRAIN FOR BRIDGE(X3)
923-810
-
-
-
SETTING LEVER
067-173
067-173
067-173
067-173
MINIMUM UNIT ORDER : 100PCS PER EACH EXCEPT * MARK(=1,000PCS)
SETTING LEVER SPRING
077-109
077-109
077-109
077-109
SETTING STEM
065-379
065-379
065-379
065-379
SETTING WHEEL
076-640
076-640
076-640
076-640
SPACER FOR SETTING STEM
212-146
212-146
212-146
212-146
SPACER FOR TRAIN WHEEL BRIDGE(2)
027-101
027-101
027-101
027-101
STATOR
190-790
190-790
190-790
190-790
THIRD WHEEL AND PINION
017-119
017-119
017-119
017-119
TRAIN WHEEL BRIDGE
701-F58
701-B84
701-B86
701-B87
YOKE
071-970
071-970
071-970
071-970
LONGER SETTING STEM(20.985MM)
065-407
065-407
065-407
065-407
LONGER SETTING STEM(23.985MM) *standard
065-426
065-426
065-426
065-426

UNIVERSAL MASTERPIECE BORN IN JAPAN
MADE IN JAPAN
METAL MOVEMENT
INSTRUCTION MANUAL FOR MIYOTA WATCH MOVEMENT
CALIBER NO. 6P27/6P77
BATTERY: SR621SW
FEATURES : ANALOG MULTI-FUNCTION QUAR TZ WATCH WITH DAY, DATE AND 24HOUR
INSTRUCTION MANUAL
A) DISPLAY
B) OPERATION PROCEDURE
C) SETTING THE DAY AND TIME (HOUR, 24 HOUR, MINUTE, SECOND)
D) SETTING THE DATE (BY QUICK OPERATION)
A) DISPLAY
NORMAL CROWN POSITION
1ST POSITION QUICK OPERATION - DATE (COUNTERCLOCKWISE)
2ND POSITION TIME/DAY SETTING (CLOCKWISE)
B) OPERATION PROCEDURE
1 SETTING THE DAY
SETTING THE TIME (HOUR, 24HOUR, MINUTE and SECOND)
2 SETTING THE DATE
24HOUR HAND
DATE
DAY (OF THE WEEK)
HOUR HAND
SECOND HAND
MINUTE HAND 1ST POSITION
2ND
POSITION
NORMAL CROWN POSITION
