CITROEN C Crossover 2008 User manual

4
FAMILIARISATION
Sunroof
This roof improves the ventilation and
light in the passenger compartment.
81
80
116
EXTERIOR
Audible rear parking
assistance
This equipment warns you if an ob-
stacle is detected behind the vehicle
when reversing.
Reversing camera
This equipment is activated automati-
cally when reverse gear is engaged
providing a visual return on the colour
display.
Lower tailgate
This lower tailgate provides remark-
able accessibility and makes the load-
ing of bulky objects easier.
117

5
FAMILIARISATION
Fuel tank
A. Opening of the fuel fi ller fl ap.
B. Opening of the fuel tank cap.
83
1. Locking of the vehicle.
2. Unlocking of the vehicle.
Remote control key
A. Unfolding/folding of the key.
B. Unlocking of the vehicle.
C. Locking of the vehicle.
72
Manual centralised control
78
OPENING
When refi tting the cap, insert the up-
per part fi rst turning it to the right.
Capacity of the tank: approximately
60 litres.

6
FAMILIARISATION
Opening
After unlocking the vehicle using the
remote control or the key, press the
handle Aand raise the tailgate.
Tailgate Lower tailgate
Opening
Push the handle C to the right and
tilt the tailgate Dgently.
The maximum authorised
weight on the lower tailgate
when open is 200 kg.
Spare wheel and tools
Access to the spare wheel
Remove the plastic cover Eto gain
access to the spare wheel fi xing
system.
80
OPENING
80 124
Closing
Pull the handle Bdownwards.
Closing
Raise the tailgate D, push it to close
it, then check that it is secured
correctly.
Access to the tools
The tools are stored in the storage com-
partment Fin the boot right-hand trim.

7
FAMILIARISATION
CONFIGURING
Rear seats (row 2)
Forwards-backwards adjustment
Seat back angle adjustment
51
Head restraint height adjustment
Access to the third row (7-seat version)
52
Rear bench seat (row 3)
The rear bench seat can be folded. It
retracts into a location in the fl oor of the
vehicle.
56
50

8
FAMILIARISATION
INTERIOR
Automatic air conditioning
This automatic air conditioning sys-
tem guarantees comfort and a suffi -
cient circulation of air in the passenger
compartment.
Cruise control
This system automatically maintains
the vehicle speed at the value pro-
grammed by the driver, without the ac-
celerator pedal being pressed.
Audio and communication
systems
This equipment benefi ts from the lat-
est technology: MP3 compatible au-
dio equipment, Bluetooth hands-free
telephone, colour display, Rockford
Fosgate audio system, auxiliary sock-
ets.
Four wheel drive system with
electronic control
This system permits the selection of
a transmission mode in relation to the
driving conditions.
44
114
154
112

9
FAMILIARISATION
INSTRUMENTS AND CONTROLS
1. Audio equipment controls.
2. Telephone controls.
3. Steering wheel adjustment control.
4. Front and rear wipers/wash-wipe
control.
5. Instrument panel.
6. Driver’s air bag.
Horn.
7. Cruise control switches.
8. Gear lever.
9. Handbrake.
10. Bonnet release.
11. Enclosed storage compartment.
12. Headlamp height adjustment.
Deactivation of the ASC system.
Deactivation of the audible parking
assistance.
13. Cup holder.
14. Side adjustable and closing vent.
15. Information button.
16. Window de-icing and demisting
vent.
17. Windscreen de-icing vent.

10
FAMILIARISATION
INSTRUMENTS AND CONTROLS
1. Steering lock and ignition.
2. Exterior mirror controls.
Electric window and rear electric
window deactivation controls.
3. Lights and direction indicators
controls. Headlamp wash control.
4. Central adjustable and closing
vents.
5. Sunshine sensor.
6. Upper glove box with air
conditioning.
7. Lower glove box with lock.
Passenger air bag disarming.
Fuse box.
8. Heated seat controls.
9. Armrest with storage
compartments.
12 volt socket (120 W max).
10. Cup holder.
11. Four wheel drive system position
selector.
12. Removable ashtray / Lighter /
12 volt socket (120 W max).
13. Automatic air conditioning controls.
14. Temperature sensor.
15. Hazard warning lights switch.
16. Colour display / Audio equipment.

11
FAMILIARISATION
SITTING COMFORTABLY
49
Front seats
Forwards-backwards Driver’s seat cushion height and angle Seat back angle
Manual adjustments
Electric adjustments (driver’s seat only)
Forwards-backwards Seat cushion height and angle Seat back angle
48

12
FAMILIARISATION
SITTING COMFORTABLY
1. Unlocking of the lever.
2. Locking of the lever.
3. Adjustment of the height of the
steering wheel.
Manual steering wheel height
adjustment Exterior mirror adjustment
A. Selection of the mirror
B. Adjustment of the position of the
mirror.
C. Folding / Unfolding.
60
Interior mirror adjustment
D. Control for selection of the “day /
night” position of the mirror.
59
60
Front seat belt
1. Fastening.
2. Height adjustment.
102

13
FAMILIARISATION
SITTING COMFORTABLY
Ignition switch
1. LOCK position.
2. ACC position.
3. ON position.
4. START position.
74
Electric window controls
1. Driver’s electric window control.
2. Passenger’s electric window control.
3. Rear left electric window control.
4. Rear right electric window control.
Also...
5. Deactivation of the front passenger
and rear electric window controls.
76
Sunroof controls
1. Opening control.
2. Closing control.
3. Partial opening control.
Also...
3. Also permits temporary stopping of
sunroof opening / closing.
81

14
FAMILIARISATION
SEEING CLEARLY
Lighting
Ring A
Ring B
Windscreen wipers
Wipers
Rear wiper
Front fog lamps and rear fog
lamps.
88 89
Lights off.
Automatic switching on of the
lights.
Side lights.
Dipped or main beam head-
lamps.
Single wipe.
Park.
Intermittent (speed which can
be adjusted manually).
Slow.
Fast.
Park.
Intermittent wipe.
Wiping with screen wash.
84

FAMILIARISATION
VENTILATING
Automatic air conditioning
Temperature adjustment.
Exterior air intake.
Interior air recirculation.
Air fl ow adjustment.
Automatic programme (comfort).
Deactivation of the air conditioning.
Air distribution adjustment.
Front visibility control.
Rear screen de-icing.
44

16
FAMILIARISATION
MONITORING
Instrument panel Controls bar
A. Speedometer.
B. Instrument panel display.
C. Rev counter.
D. Fascia lighting rheostat.
When the ignition is on, the orange and
red warning lights come on.
When the engine is running, these
warning lights should switch off.
If warning lights remain on, refer to the
page concerned.
Warning lights
19
A. Passenger air bag disarmed
warning light.
106
B. Hazard warning lights switch.
99
C. Front passenger’s seat belt not
fastened or unfastened warning
light.
103
20
Detection of fastening of the
driver’s seat belt
When the ignition is switched
on, the seat belt warning light
comes on accompanied by an
audible signal if the driver has
not fastened his seat belt.
The warning light switches off when the
seat belt is fastened.
22

17
FAMILIARISATION
KEEPING YOUR PASSENGERS SAFE
Front passenger air bag Child lock
1. Insertion of the key.
2. Selection of the “OFF” position.
3. Removal of the key.
This prevents opening of the door con-
cerned from the inside.
Lower or raise the control Ato lock or
unlock.
106 98
Isofix mounting
Two rings A, located between the seat
back and seat cushion of the vehicle’s
seat, permit the securing of a child
seat.
A ring Bpermits securing of the upper
strap referred to as the TOP TETHER.
95

18
FAMILIARISATION
Cruise control
This maintains a constant vehicle speed
programmed by the driver.
1. “ON/OFF” button: activation /
deactivation of the cruise control
mode.
2. “COAST SET” button: storing of a
driving speed then decreasing of
the cruising speed.
3. “ACC RES” button: increasing of
the cruising speed and recalling of
the stored speed.
4. “CANCEL” button: switching off of
the cruise control.
In order to be programmed or activated,
the vehicle speed must be higher than
25 mph (40 km/h) with at least second
gear engaged.
This detects any obstacle (person, ve-
hicle, tree, gate, etc.) located behind
the vehicle.
The vehicle is fi tted with four sensors:
D. two side sensors.
E. two central sensors.
Audible rear parking assistance
114 116
DRIVING SAFELY
Four wheel drive system
Three transmission modes are avail-
able and can be selected manually by
the driver in accordance with his re-
quirements:
A. Two wheel drive (2WD),
B. Four wheel drive (4WD AUTO),
C. Four wheel drive (4WD LOCK).
112
Also...
You can change transmission mode
when stationary or when driving at a
speed below 60 mph (100 km/h).

I N S T R U M E N T S a n d C O N T R O L S
I
19
1. Speedometer.
2. Left-hand direction indicator and
hazard warning lights indicator
light.
3. Main beam headlamps indicator
light.
4. Diesel pre-heating indicator light.
5. Side lights indicator light.
6. Front fog lamps indicator light.
7. Seat belt not fastened / unfastened
warning light.
DIESEL MANUAL GEARBOX INSTRUMENT PANEL
18. Instrument panel display:
- Warning and status displays.
- Total and trip distance recorders.
- Service indicator.
- Coolant temperature.
- Displaying of the trip computer
information.
- Cruise control reference value.
- Fascia lighting and parameter
settings.
- Fuel level.
- Exterior temperature.
- Transmission mode.
8. Rear fog lamps indicator light.
9. Anti-lock braking system (ABS)
warning light.
10. Battery charge fault warning light.
11. Handbrake applied and brake fl uid
level warning light.
12. Cruise control mode indicator light.
13. Air bags warning light.
14. Engine management warning light.
15. Indicator light for right-hand
direction indicator,
Hazard warning lights indicator
light.
16. Rev counter.
17. Fascia lighting rheostat.
Panel grouping together the dials and
warning/indicator lights. These inform
the driver of the activation of a system
(operation or deactivation indicator
lights) or of the occurrence of a fault
(warning lights).

CRUISE
I N S T R U M E N T S a n d C O N T R O L S
I
20
INSTRUMENT PANEL INDICATOR LIGHTS
Indicator lights is on Cause Observations
Left-hand
direction
indicator
Flashing
with
buzzer
This fl ashes when you
press the lights stalk
down.
If this indicator light fl ashes abnormally quickly,
this could indicate that the electric bulb of one
of the direction indicators has blown. Change
the bulb or contact a CITROËN dealer.
Right-hand
direction
indicator
Flashing
with
buzzer
This fl ashes when you
push the lights stalk up.
If this indicator light fl ashes abnormally quickly,
this could indicate that the electric bulb of one
of the direction indicators has blown. Change
the bulb or contact a CITROËN dealer.
Main beam
headlamps Fixed
This comes on when
you pull the lights stalk
towards you. Pull the stalk to return to dipped headlamps.
Side lights Fixed
This comes on when
the lights stalk is in the
“Side lights” or “Dipped
headlamps” position.
Turn the stalk to the position required.
Front fog
lamps Fixed This comes on when you use the front fog lamps. Turn the ring on the stalk forwards to switch on the fog lamps.
Rear fog lamps Fixed This comes on when you
use the rear fog lamps. Turn the ring on the stalk forwards to switch on the fog lamps.
Cruise control Fixed This comes on when the
mode is active. Press the “ON/OFF” button to activate/ deactivate the mode.

I N S T R U M E N T S a n d C O N T R O L S
I
21
Indicator lights is on Cause Observations
Diesel
pre-heating Fixed This comes on when the
ignition switch is at ON.
Wait until this light has switched off before
starting.
The duration for which this is displayed is
determined by the exterior climatic conditions.
Warning lights is on Cause Observations
Handbrake /
Brake fl uid
level Fixed
This comes on for a
few seconds when the
ignition is turned to “ON”
then switches off.
It is accompanied by a message on the
instrument panel display.
The handbrake is
applied or has not been
released fully.
It is accompanied by a message on the
instrument panel display. Release the handbrake
to switch off the warning light.
The brake fl uid level is
too low.
It is accompanied by a message on the
instrument panel display. Top up with brake fl uid
and contact a CITROËN dealer.
Emission
control system Fixed or fl ashing
This comes on or
fl ashes if the system
fails.
Consult a CITROËN dealer.
It should switch off a few seconds after starting
the engine.
Battery charge Fixed
This comes on if a
charging circuit fault
occurs.
It should switch off when the engine is started.
It is accompanied by a message on the
instrument panel display. Check the battery
terminals (refer to the “Battery” section).

I N S T R U M E N T S a n d C O N T R O L S
I
22
Warning lights is on Cause Solution - action
Driver’s
seat belt not
fastened Fixed
The driver has not
fastened or has
unfastened his seat belt.
This is accompanied by a message on the
instrument panel display.
Fasten the driver’s seat belt.
ABS Fixed
This comes on if an
anti-lock braking system
failure occurs.
It is accompanied by a message on the
instrument panel display. The vehicle retains
conventional braking without assistance but
you are advised to stop. Have it checked by a
CITROËN dealer.
Air bags and
pretensioners Fixed
This comes on for a
few seconds when the
ignition is turned to “ON”
then switches off.
It should switch off when the engine is started. If
it does not switch off, contact a CITROËN dealer.
This comes on if an air
bag or pretensioner
failure occurs.
It is accompanied by a message on the
instrument panel display. Have the system
checked by a CITROËN dealer without delay.

I N S T R U M E N T S a n d C O N T R O L S
I
23
Each time the engine is started: a series of warning lights and/or messages come on applying a checking self test. They
switch off after a few seconds. Engine running: the warning light or the message becomes a warning if it remains on
continuously or fl ashes. This initial warning may be accompanied by an audible signal and a message on the display. Do not
ignore these warnings.
When the cause of the appearance of the warning light or warning message has been rectifi ed, the warning disappears from
the display automatically. If the cause of the warning is not rectifi ed, you can return to the previous screen at any time by
pressing the INFO button on the fascia.
The symbol “!” is displayed.
To return to the previous screen (with the “!” symbol), you must press the INFO button several times.
INSTRUMENT PANEL DISPLAYS
Warning messages (ignition at “OFF”)
You can shut down the warning messages which show these symbols in order to move on to the next screen.
To do this, press the INFO button according to the symbol displayed.
Press briefl y . Press and hold.
Symbols which appear in the top right corner of the display.
Message is on Associated
warning
light Cause Solution - action Observations
Key in
ignition Fixed -
The driver’s door
is open and you
have forgotten to
remove the key
from the ignition.
Turn the ignition
switch to the LOCK
position and remove
the key.
Only if the engine has
been started.
An intermittent audible
signal is heard.
Lights left
on Fixed -
You have
forgotten to
switch off your
lights.
Switch off your lights
by placing the stalk at
OFF.
An intermittent audible
signal is heard.
