CITROEN CX 2000 Operating instructions

HOW TO USE THE MANUAL
PRESENTATION
To facilitate the use of the manual. operations have been qrouped in three volumes
- Volume 1 contains
- the CHARACTERISTICS ADJUSTMENTS CHECKS
This volume is essential for all workshops for repairs or overhauls
Volume 2 contains the operations usually carried out and concerning
- REMOVAL and FITTlNG
- RECONDITIONING
- ELECTRICAL. HEATING and AIR-CONDITIONING SYSTEMS
BODYWORK
- Volume 3 deals with the CX Diesel.
cd
E The above volumes are sold separately. They are presented bound in dark red Fibrex with,a
1~MULTO 1)type mechanism to facilitate the insertion of supplements or the extraction of a
- cl3 particular operation required by the workshop
L
a
COMPOSITION
Every volume comprises
- the list of operations contained in the volume
- these operations filed in numerical sequence
- the list of all the tools mentioned in the operations and the manufacturing drawings for special
tools which are not sold but are intended to be manufactured by the workshop itself (‘(MR)) tools).

OPERATIONS
The sequence of operations has been devised in order to obtain the best standard of work in the
shortest possible time.
The numbering of the operations is made up as follows
a) The code letter for the car (/ MA 3)for all CX vehicles except <fFuel Injection a). /<MA-IE 1)for
CX vehicles with ,cFuel Injection )I.
b ) A number made up of three figures denoting the unit or its component.
c ) A figure code designating the type of repair
- the figures 0 0 0 indicate the characteristics of the car
the figures 0 0 indicate the characteristics of the unit
- the figure 0 indicates checks and adjustments
the figures 1 4. 7 indicate removal or fitting
- the figures 2. 5. 8 indicate dismantling or reassembly and
the figures 3 6 9 indicate reconditioning
The thumb-indexing which corresponds to the list of operations enables the particular operation
to be found without difficulty.
TOOLING
Special tooling is denoted in the text by a number followed by the letter ‘I
The part-numbers inferior to the 6000 series concern tools aiready in use and common to vehicles
previously introduced and to CX vehicles.
The 6000 series refers to tools specially designed for CX vehicles
Additional tools of local manufacture are indicated in the text by a number preceded by the index
MR manufacturing drawings for these tools appear at the end of the particular volume filed in
numerical order.
TIGHTENING TORQUES :
Torques are expressed in the following units
either in metres Newton ( m.N ) the legal unit for measuring torque. with the corresponding
amount in metre-kilogrammes ( m.kg )
or in decanewtonmetres ( da Nm ) 9.8i Nm 1 m.kg ci.981 daNm
The numbers corresponding to the torques are (t rounded off 1)
Examples 2 m.N 0.2 m..kg
60 m.N 6
m.kg
IMPORTANT When a tightening torque figure is followed by the words 11torque wrench 11 the
operution must without fail be carried out with a torque wrench.
IMPORTANT WlTHOUT FAIL after each operation or group of operations there is a chapter
headed (, TIGHTENING TORQUES ,,; the screws nuts or studs which are
underlined indicate
that they are of a special grade ,cSECURITY HARDWARE 1).When refitting it is ESSENTIAL
to use this type of HARDWARE TO THE EXCLUSION OF ANY OTHER.
ADVISORY SERVICE
For a!1 technical information concerning these vehicles please contact
The Service Department,
Citroen Cars Ltd..,
Mill St.,
Slough Berks. GE. Tel. Slough 23808
or DEPARTEMENT TECHNIQUE APRES-VENTE
ASSISTANCE TECHNIQUE -
92000 NANTERRE - FRANCE - Tel. [phone]
:
.-
---

Operation
number
VIA. 000
VIA. 00
VIA. 00-600
vlA. 00-655
VIA. 01
WA. 02
MA. 03
MA. 100-00
MA. 112-O
MA. 120-O
MA. 142-000
MA. 142-00
MA. 142-00 a
MA. 142-00 b
MA. 142-00 SI
MA. 142-O
MA. 142-O SD
MA. 144-00
MA. 144-O
MA. 173-O
MA. 210-00
MA. 210-00 a
MA. 210-O
MA. 210-O a
MA. 220-O
MA. 221-O
MA. 230-00
MA. 230-O
MA. 236-O
MA. 312-00
MA. 314-O
MA. 320-00
MA. 320-O
LIST OF OPERATIONS
IN MANUAL 818-l
ccCX Petrol )) uehicles
DESCRIPTION
GENERAL
General characteristics
Jacking and towing points
Exterior and interior dimensions
Fitting the rubbing rails
Protection of the electrical units
Working on the hydraulic system : fitting precautions
Recommended materials
ENGINE - CA,RBURATlON - IGNITION - COOLING
+O
2
Characteristics and special features of the engine (M 20/616, M 22/ 617,
M 23/623 and M 23/622 )
Checking and adjusting the valve operation :
- Adjusting the rocker clearance
Checking the engine timing
General features of the carburation
Characteristics and special features of the carburettor (M 20/616 engine )
Characteristics and special features of the carburettor ( M 22/617 engine )
Characteristics and special features of the carburettor ( M 23/ 623 engine )
Characteristics and special features of the anti-pollution system
I SWEDISH Jlurket r,c~kicles )
Adjusting the carburettor - adjusting the idling speed
Checking and adjusting the anti-pollution system (SIVI:‘DfSH Mdrkct rvhicles J
Characteristics and special features of the electronic fuel injection system
(L.~etKJnic )
Checking and adjusting the electronic fuel injection system (1..Jetrolzic)
Checking the petrol feed system
- Petrol pump, and petrol filter
Characteristics and special features of the ignition system
Characteristics and special features of the electronic ignition system
Checking and adjusting the ignition
Checkinq and adjusting the electronic ignition
Checking the oil pressure (on the rvhicle )
Filling and adjusting the pneumatic oil gauge
Characteristics and special features of the cooling system
Working on the cooling system
Aligning the pulleys
CLUTCH - TORQUE CONVERTER
*O
3
Characteristics and special features of the pedal-operated clutch
Checking and adjusting the pedal-operated clutch control
- Checking the clutch clearance
Characteristics and special features of the torque converter
- Characteristics
- Operating diagram of the torque converter
Checking and adjusting the gap of the contacts controlling the electro-valve
- Checking the pressure in the converter oil-feed system

.r.
-/1
LIST OF OPERATIONS
IN MANUAL 818-1
a CX Petrol )) 7,rhifles
--\
-
f-7
i----
_--
-
Operation
number
MA. 330-00
MA ..344-O
MA. 372-00
MA. 390-00
MA. 390-O
MA. 410-00
MA. 410-O
MA. 420-00
MA. 420-O
MA. 430-00
MA. 430-O
MA. 434-O
MA. ,440-00
MA. 440-O
DESCRIPTION
GEARBOX and GEARBOX CQNTROL
*O
4
Characteristics and special features of the gearbox
- Four-speed gearbox with pedal-operated clutch
- Gearbox.with torque converter
- Draining and refilling the gearbox and the torque converter
- Five-speed gearbox with pedal-operated clutch
Adjusting the gearbox control mechanism
DRIVE SttiFTS
Characteristics and special features of the drive-shafts
SOURCE AND RESERVE OF PRESSURE
Characteristics and special features of the source and reserve of pressure -
hydraulic system
Checking the hydraulic components on the vehicle
FRONT AXLE
+O
7
Characteristics and special features of the front axle
Checking and adjusting the front axle :
- Checking the camber
- Checking and adjusting the castor angle
- Checking and adjusting the wheel alignment
- Checking and adjusting the steering geometry
- Checking the steering for straight line deviation ( whirfes cjq77ippcJrl with
REAR AXLE
*O
8
Characteristics and special features of the rear axle
Checking and adjusting the rear axle
SUSPENSION SYSTEM
I,09
Characteristics and special features of the suspension system
Checking and adjusting the suspension and its controls
Adjusting the anti-roll bar
STEERING SYSTEM *@
Characteristics and special features of the steering system
- Manual steering
- Power steering with powered return
Checking and adjusting the steering (see Op. MA. 410-O )
Ob
4
Ob
5
Ok
6
Ok
7
O+
8
O1)
9

LIST OF OPERATIONS
IN MANUAL 818-l
Operation
number
MA. 450-00
MA,. 451-O
MA. 453-O
MA. 454-O
MA. 510-00
MA. 51 O-00 a
MA. 510-00 b
MA. 530-00
MA. 530-O
MA. 540-O
MA. 560-O
MA. 640-00
MA. 640-O
MA. 642-00
MA. 961-O
MA. 700-00
MA. 840-O
MA. 841-O
MA. 844-O
MA. 852-O
MA. 961-O
DESCRIPTION
BRAKES
Characteristics and special features of the braking system
Checking the brake components
Checking and adjusting the hydraulic brake control
- Bleeding the brakes on (( Saloon ))and ((Estate H vehicles (‘)/ lO76- )
- Bleeding the’brakes on (( Estate )) vehicles (
-911976)
- Adjusting the brake pedal free play
Checking and adjusting the handbrake
ELECTRICITY - HEATING
I,0
12
Electrical installation ( 9, 1074
-1,1975)
- All C..X 2000 t’cJllicl0.Y. ( cJ.vc-u[)t those 1.ittcd with optimnl towitzg (,rjriiptueflt )
Electrical installation ( I/ 1975 - 711975)
- All <.X 2000 nrtcl 2200 I c>hiclcs (esrept optiwnl towing ccjrli/mv~~t )
Electrical installation ( c)/ 1!J75 - J
- All Pnllas whirlck (Of 1975 :.I __._._.___............................ (Pfiges j-4)
- Prc,.s tige (I 1976 ----tJ . .. .. .. .. ... . . .. .._.................. (Pngc~s 5-8)
- Estntc SIIpw IIf 1976 -1 . .. .. .. .. ... ... .. .. .... .. .... .. .. ... (Pugc,s 9-12 )
- I~~strriv~cut pajf~,I. nil r~c~hicles (9!’ 1975 - ) . ( Page 13 )
- Tvrqrl~~ COIlI erter. (l/l976 - ) ... .. .. .. ... ... .. .. .... .... .. .. .... . ( I’ogc, 14 )
- Air rotiditioffir~g ( - 7: 1076 ) : . . . (PcIgc- 16)
- Air covditiorli,lg (7! 1976 - J ... .
- ‘l’orytrc~ coilr’f’rter + air contlitiotfirfg ( 12/ 1976 - )
- I?Iect~~r~ic j&l if~iectiov ... .. .. .... .. .. .. .. .. .. .... .. .. .... .. .... .. .... ...
Characteristics of the electrical units
Checking the electrical units
Checking and adjusting the headlamps
Checking and adjusting the windscreen wiper
Pngc 17)
Pogc 15 )
Pup 19)
Characteristics and special features of the air-conditioning system
- Refrigeration
Checking and adjusting the air-conditioning system
- Refrigeration
Characteristics of the (( FROID - 20 )) heating system
Checking and repairing a rear window heating element
(Set, r/JP ccI~OI~~‘WOKK 1) rilnptc~rj
BODYWORK
*0
13
Securing the body-shell to the assembled under-frame
Adjusting the body panels
Adjusting the front and rear doors
Adjusting the boot lid
Adjusting the bonnet
- Adjusting the bonnet
- Unlocking the bonnet ( if the bonnet control is uncoupled )
Checking and repairing a rear window heating element
TOOLING
Special (( T )) Tools
*O
14
Manufacturing diagrams for special tools not sold (ccMR )) tools )
O1)
11
Ol)
12
Ok
13
O1)
14

-\ I
GENERAL i
OPERATION No MA. 000 : ‘Gcuerul chnrurteristics Op. MA. 000 ‘I1
,r-
IDENTIFICATION OF ALL ((CX n VEHICLES
SALOONS
i
1
Guarantee Official French fiscal 1
Commercial symbol symbol symbol Enqine typ’e ratinq
cx 2000
9-l 971v MB MA series MB M 20/616 11 hp
cx 2200
l-1975 - 7-l 976 MC
MA series MC M 22/617 12 hp
Manual gearbox or torque cotr7~erte1
CX 2200 Diesel
12.1975 _t
CX 0 Prestiqe 1) 2-l 976 -
CX 2400
91976 -
Manual gearbox or torque conilerter
MG
MA series MG M 22/621 9 hp
MK MA series MK M 23/623 13 hp
MJ MA series MJ M 23/623 13 hi
CX 2400 GTI
j-1977 A
ME MA series ME ‘M 23/62i 13 hp
Mal7ual ~-speed gearbox
ESTATES AND AMBULAkES 1
.--
,-
.--.
,/\
Guarantee Official French fiscal
Commercial symbol symbol symbol Engine type ratinq
cx 2000
l-1976 - MD MA series MD M 20/616 llhp
CX 2200 Diesel 2-1976 __t
MH MA series MH M 22/621 9 hp
CX 2400 9-1976 0.
MF MA series MF M 23/623 13 hp
* CX 2000 Ambulance
911976 -
MA series MD M 20/616 11 hp
CX 2200 Ambulance Diesel
9-1976 - MHA MA series MH M 22/621 9 hp
CX 2400 Ambulance
9-1976 - MFA MA series MF M 23/623 13 hp
-\ * This mhicle is for export only.

2 : a m
OPERATION No MA. 000 : GmeraII characteristics. 7 /
/

OPERATION N” MA. 000 : G~~/c~rnl chnracteris/ics Op. MA. 000 3
CX 2000 and CX 2200 SALOON
( Vehicles fitted with M 20/616 1985 cc and M 227617 2175 cc engines )
I. GENERAL CHARACTERISTICS
cx 2000 cx 2200 I
- Official symbol .._... _. .._................. .._. MA series MB MA series MC
- Commercial symbol ., ,. . .._._.._............._........................ cx 2000 cx 2200
Factory symbol ( quarantee ) _._,_..,,.__._..__._..................,.................... ... . MB MC
- Date of int:oduction ....__..._.._....._._..............,.......................,,........,.,...... September 1974 January 1975
- French fiscal ratinq ,.....,...._..._...._,......................,,..,..,........................... 11 cv 12 cv
- Number of seats ._...._...__._..................................,....,...,....................,........ 5 5
NOTE : u CX 2200 1) vi?hicles can be fitted with a gearbox with torque converter as optional equipment.
Wheels and tyres :
_ Rims ___,._.__.__.__.,.._..._..,...,.,,.___..._._.....__.....................,...,...................... .,. _ ..__......_..._ 5 l/2 J X 14 FHA
CX 2000 (rrlith .\fmun/ s/eerir/g 1
- Tyres ( /II/~c~/(~s.s )
Tyre pressures ( in bars, and psi ) ._..__..._._. 2 bars ( 29 psi )
;I 2.1 bars (30 1/2psi) 2.3 ba:s‘( 33 I/ 7psi)
Authoaized alternative ,
- Tyres ( ~r~l~c~less ) 185 SR 14 ZX 185 SR 14 ZX 185 SR 14 ZX
- Tyres with inner tubes 14 F 9 - 13
a) _.., _._. .._,,....___,.__._......................................... 185 SR 14 ZX 18.5 SR 14 ZX 185 SR 14 ZX
b ) . 185 SR 14 ZX 175 SR 14 ZX 175 SR 14 ZX
- Tyres ( special equipment ) _...._._,,.....__._......... 185 R 14 X(M+S) 185R14X(M+S) 185R 14 X(MtS)
From September 1976 onwards, Michelin type ZX tyres, have been replaced by t.ype XZX.
The size and pressure remain the same.
In case of replacement of two TX tyres by two XZX tyres, it is preferable to fit the latter at the rear.
All CX 2200 vehicles and
CX 2000 ( with power steering )
- Tyres (tubeless ) . . ..__._._._.___... ..___.__.._......._.._._ I85 HR 14 XVS 175 HR 14 XVS 175 HR 14 XVS
- Pressures __.,._.__.,__...._.,....~.......,......._ .___......... l.gbars(27 1/2psi) 2.1 bars(30 1/2psi) 2.3 bars (33 ‘/2psi)
Authorized alternative :
-1Tyres (tubeless) _._....._..,___._._....,.,...........,..,.... 185 HR 14 XVS
- Tyres with, inner tubes 14 F 9-13
a) .. .... .. .... . ... ..i,..,..___._..,.._.._.~_..__~.~..~j.,_~.~._.
b) _____.__,,..,..__.__...................................................
- Tyres ( special equipment ) __...._,.___...............;
, .~~~,
NOTE : Tyre pressures are indicated on a label located on the panel at the front of the door on the driver’s side.
II. GENERAL DIMENSIONS
Dimensions :
- Front track ..,..,_.__.................. 1:474 m ( 4 ft. 10 ins ) Front overhang ................._......1~050 m(3ft. 5 l/2 ins)
- Rear track ............._._.............. 1.360 m (4ft. 5 l/2 ins) Overall width ...........................1.730 m ( 5ft. 8 ins )
- Wheelbase ..............____............ 2 845 m (9ft. 4ins ) Height {normal
driving
-- bverall length 1 ( CX 2000 ) __ 4.630 m( 15ft.2 1/2ins) position’) ............................ 1.360 m ( 4ft. 5 1/2ins)
( cx 2200 ) 4.660 m ( 15ft.3 l/2 ins) Ground clearance (normal
driving position ) ...................0.155 m ( 6 1/8th.ins)

4 OPERATION N” MA. 000 : General characteristics
Weights in kg ( lb )
- Kerb weight ( with full tallk oj fuel ) .... . . ....
- Weight on front axle ...............................................
- Weight on rear axle ................................................
- G.V.W. ( Gross Vehicle Weight, all optional
ecpiip777ei7t i77cluded ) ..............................................
- Maximum authorised weight on front axle ..........
- Maximum authorised weight on rear axle ............
I G.T.W. ( Gross Train Weight ) ..............................
Towing : ( Weights in kg ( lb )
cx 2000
1265 ( 2789 ) 1285 ( 2833 )
845 ( 1863 ) 860 ( 1896)
420 ( 926 1 425 ( 937 1
1740 ( 3836 ) 1760 ( 3880 )
1020 ( 2249 ) 1020 ( 2249 )
750 ( 1653 ) 750 ( 1653)
2370 ( 5225 ) I i77cI77rfi77!: n Ir.oiler
2405 ( 5302 ) ( i/7t/ur/i77g
rc,i/hou/ brnkes cc,eighiug 630 kg o trc7ilcr rt~ithou t brakes
( 1389 Ihs ) rc~ei$iu~ 645 kg ( 1422 Ibs)
n) Vehicles equipped with a single electric cooli,f,c /c[i7 :
”
Maximum trailer weight ( gradient of 1 h 10 ) .__._..,...__,_____............
- Maximum weight for bailer without brakes _..,.__._.,._._..,.,_..,__.._........ . ....... ..
b) Vehicles equipped with tu& electric cooling /ans :
-
Gross Train. Weight ( zc:ith 1300 kg ( 2866 lb ) trailer with brakes ) .....-.’
- Maximum authorised trailer weight (within limits o/ C. 7‘. W’. ) ~..~~...~.....~~~
- Maximum starting gradient ( at G. ‘f. IV, ) _______.._....._...,.................................
cx 2200
cx 2000
900 ( 1984 )
630 ( 1389 )
3040 ( 6702.)
1500 ( 3307)
1 in8 l/3 -
cx 2200
900 ( 1984)
645 (,I422 )
3060 ( 6746 )
1500 ( 3307 )
1 in8 l/3
IMPORTANT NOTE : Referehces to trailers without brakes DO NOT APPLY in U.K.
III.GENERAL INFORMATION
Capacities :
- Fuel tank ...._....__........................................................................................... 68 litres ( 15 galls )
- Cooling system (including beater unit ) 16 dm2 ( 248 sq.in ) radiator 11 litres ( 19.3 pts )
20 dm2 ( 310 sq..in ) radiator 10.6 litres ( 18.6 pts )
- Heater unit alone : i....___.___.._.._.._..........................,..,.,..................................... Cl.6 litres ( 1.05 pt )
- Engine oil :
- After Oil Change _......_._.,_....,..,....,.......,....,................~.,........................., 4.650 litres ( 8.2 pts )
w Difference between Min and Max on dipstick 1.1 litre ( 1.9 pts )
- Hydraulic system ( Approx ) 4 litres ( 7 pts )
- Gearbox
a) ‘11mud ~earlmx :
- Overall capacity ( TOTAL EP 80 ) _.__.__._..._..._._................................... 1.6 litres ( 2.8 pts )
w Difference between Min and Max on dipstick ..................._................... 0.150 litres ( a.26 pts )
b) Ccarbos with /orque: con7jerter :
- Overall capacity ( TOTAL Fluide T ) . ..__.,_.____________....,.,....,....,,..........5.5 litres ( 9.7 pts )
- After Oil Change . . 2 to 3 litres ( 3 l/2 to 5.2 pts )
( according to draining time )
v Difference between Min and Max on dipstick (with oil
cold ) .0..150 litres ( 0.26 pts )
- Usable volume of boot 325 dm3 ( 11.48 cu. ft )..................._................................................................

OPERATION No MA. 000 : General characteristics Op. MA. 000
o CX 2000 u ESTATE
( Vehicle equipped with M 20/616 1985 cc.engine )
I. GE&AL Cl-jARACTERlSTlCS I. :p> ;firJ:s@ -
. .
- Commercial symbol .......................................................................~.................................. I
CX 2000 Estate
- Official symbol ..._._.._._............................................................... .......................__......... MA series MD
- Factory symboI ( warranty symbol ) . . . . ..... . . . . _..__......................_...._..,.,......, MD
- Introduction date _... ..... . .,.,.,.,,..............,.,.,.... January 1976
- French fiscal rating . . ... . . ......~........................................................................... llhp
- Number of seats ............................................................................................................. 5
Wheels and tyres
- Wheel rims . ......._............................................................................................................... 5 l/2 J x 14 FHA
Tyres
MICHELIN Type and pressure in bars (psi)
Front I Rear Spare
Manual 185 SR 14 ZX
Standard steering 2 ( 29 1 2.2
(32 1 2.4 35I .I ( )
fitting
Authorised
f-itting
Power
steering
Manual
steering
Manual or
Power
steering
185 HR 14 XVS-TU
119 ( 27 l/2 ) ,I 2.1 ( 30 l/2 ). 1 2.3 (33 ‘l/2 )
185 HR 14XVS-TU
1 I 1.9 (27 l/2) 2.1 ( 30 l/2 ) 2.3 ( 33 .1/2 )
185 R 14 X (M+S)
1.9 ( 27 l/2 ) 2.1 ( 30 l/2 1
2.3 ( 33 1;2 )
NOTE. : - Vehicles are fitted with (( TUBELESS )) tyres as standard equipment. .
- They can be fitted with tyres with inner tubes of the same type, the pressures remaining the same.
- The tyre pressures are indicated on a label located on the panel at the front of the door (on the
driver’s side ).
From September 1976 onwards, MICHELIN ZX tyres are replaced by XZX tyres.
The sizes and pressures remain the same.
In case of replacement of 2 ZX tyres by 2 XZX tyres, it is preferable to fit the latter at the rear.
.p
il. GENERAL DIMENSIONS a. I
~.
- Front track ..........................................................................................................
- Rear track ........................ .:.................................................................................
-Wheelbase .......................................................... ..i ........ ....................................
- Overall length .....................................................................................................
- Front overhang ............................................. ..i ...................................................
- Overail width ......................................................................................................
- Height of vehicle ( in normal driving position ) ............... ..................................
- Ground clearance ( in normal driving position ) .................................................
1.474 m ( 4 ft. 10 ins )
1.390 m ( 4 ft. 6 3/4 ins )
3.095 m ( 10 ft. 1 3/4 ins )
4.920 m ( 16 ft. 1 3/4 ins )
1.050 m.( 3 ft. 5 l/2 ins )
1.734 m ( 5 ft. 8 l/4 ins )
1.465 m ( 4 ft. 9 3/4 ins )
0.155 m ( 0 ft. 6.1 ins )

6 OPERATION No MA. 000 : Gezcral characteristics :
Weights : ( in kg ( Ib ) )
- Kerb weight ( with full tank of fuel ) ................................................................................ 1385 ( 3053 )
- Weight on front axle ............................................................................................................. 880 ( 1940 1
- Weight on rear axle .............................................................................. ,...................... .,...... 505 ( 1113 )
- Gross Vehicle Weight ( including all optional equipment ) ............................................ 2070 ( 4564 )
- Maximum authorised weight on front axle ....................................................................... 1050 ( 2315 )
- Maximum authorised weight on rear axle ........................................................................ 1030 ( 2271 )
- Gross Train Weight with 690 kg ( 1521 Ib ) trailer without brales .................................. 2700 ( 5952 )
Towing :
- Maximum authorised trailer weight ( gradient of 1 in 10 ) :
. a)u Standard Driehicle ......................................................................................................... 900 ( 1984 )
b) Vehicle equipped with twin electric cooling fans ........................................................ 1300 ( 2866 )
- Gross Train Weight with a 1300 kg ( 2866 lb ) trailer with brakes ................................ 3370 ( 7429 )
- Maximum authorised trailer weiqht, within limits of G.T.W. ............................................. 1500 ( 3307 )
- Maximum starting gradient ( at G. T. It’. ). .............................................................. ..~
................ 1 in 9 ( 11 % )
IMPORTANT NOTE : References to trailers without brakes bc) NOT APPLY in U.K.
III. GENERAL INFORMATION
Capacities :
- Fuel tank .._......................................,............................................................... :. .... 68 litres ( 15 galls )
- Cooling system ( Heater unit included) ( 20 dm2 - 310 sq.in ) . . . . .. 10.6 litres ( 18.6 pts )
- Heater unit alone . . . . . . . . . . . . 0.6 litres ( 1.05 pts )
- Engine oil :
- after draining *
. . . . . . . .. . . . . . .. . . . . .. . . . . . . . ...... . . 4.650 litres ( 8..2 pts )
- difference between Min and Max on dipstick . . . . . . . . . . . . . . . . . 1.1 litres ( 1.9 pts )
- Hydraulic system ( approx ) . .. . . . ... .. . ..... ... . . 4 litres ( 7 pts )
- Gearbox :
- after draining ..._._._......................................................... :.................................... 1.6 litres ( 2.8 pts )
- difference between Min and Max on dipstick . . . . . . . . . . . . . :. 0.150 litres ( 6.26 pts )
- Boot volume :
- with rear seat in position ................................................................................. 1100 dm3 ( 38.85 cu.ft )
- with rear seat folded .......................................................................................... 2030 dm3 ( 71.70 cu.ft )

OPERATION No MA. 000 : General characteristics Op. MA. 000 7
CX ,, PRESTIGE ,,‘SALOON
:
( Vehicle equipped with the M 23/623 2350 cc engine )
1. GENERAL CHARACTERISTICS :
- Official symbol MA series MK................................................................................................................................
- Commercial symbol ........................................................................................................................ CX PRESTIGE
- Factory symbol ( Wurrmzty symbol ) ................................................. :.............................................. MK
- Introduction date ........................................................................................................................ February 1976
_ French fiscal rating ............................. ,...........................................................................................
13 hp
- Number of seats . . . ... . . ... . .. .... . . ... . . . . . .. ...... . . . . . . . ... . . . . . . ... . . .
5
NOTE : The following items are standard equipment on CX (( Prestige )) vehicles; VariPower steering ( with
powered return ). Air-conditioning and a (( Froid- 20 1)heater unit. Since December 1976, these vehicles can
be fitted with’a gearbox with torque converter as optional equipment.
Wheels and tyres :
- Wheelrims .,...,._.__._......_...,.................,,....,................................................. ... . ..... . ..... 5 l/2 F x 14 FHA
- Tyres ( tubeless ) . . . . . .
(psi) . ....... ......_.._..........
)
2.2
Authorised alternatives :
-‘Pressure in bars
- Tyres ( .Ppecial equipment) . . . .. . . 185R14 X (M + S ) 185R14X(M+S) 185R14X(M+S)
- Pressure in bars ( psi ) ... .............. .. .
2.2’ ( 32 ) 2.2 ( 32 ) 2.4 ( 35 )
I
II. GENERAL DIMENSIONS
Dimensions :
- Front track ...................................................................................................... 1.474m (4ft. loins)
- Rear track ....................................................................................................... 1.360 m (4 ft. 5 /l/2 ins )
,- Wheelbase ................................... .
................................................................... 3.095m (10 ft. 1 3/4.ins)
- Overall length ............................................................................................. 4.916 m ( 16 ft. 1 /l/2 ins )
- Front overhang ............................................................................................... 1.057 m (3 ft. 5 A/2 ins )
- Overall width ............................................................................................... 1.734m (5 ft. 8 /l/,4 ins)
- Height of vehicle (in normal driving position ) ..:......................................
1.357 m ( 4 ft. 5 /l/2 ins )
- Ground clearance (An normal driving position ) ........................................ 0.155m (9 ft. 6.1 ins)

8 OPERATION No MA. 000 : G~v2~~rnl characteristics
Weights in kg ( Jb ) :
- Kerb weight ( with /hll fmk oipc~trol ) : .............................................................. 1450 (3197 )
- Weight on the front axle ......_
.................................................................................... 970 ( 2138 )
- Weight on the rear axle .................................. ..................................................... 480 ( 1058 )
- Gross Vehicle Weight ( inclr~cli22~ all optimaal eq~ipmm f ) .............................. 1890 ( 4167 )
- Maximum authorised weight on front axle .............................................. .............. lllO( 2447 )
- Maximum authorised weight on rear axle ............................................................... 790 ( 1742
- Gross Train Weight ( with ~2 1300 kg ( 2866 lb 1 frailer u'ith hmkes I ................
3190 ( 7033 )
III. GENERAL INFORMATION :
Capacities :
- Fuel tank ....._._.............., .._.._._. ..._...__................................ ._................,...... 68 litres ( 15 galls )
- Cooling system (i22cludi22g hcc?ter ul2it 1 :
- Manual gearbox ( 20 dm2 - 310 sq.in. radiator ) . ..._..................... 10.6 litres ( 18.6 pts )
mTorque converter gearbox ( 23 dm2 - 356 sq.in. radiator ) . 12.5 litres (22 pts )
- Heater unit alone _, :. I. 0.6 litres ( 1.05 pts )
- Engine oil :
- after draining ...._._._......._._........................................................-.......... 4.650 litres ( 8.2 pts )
.. difference between Min and Max. ,.n dipstick 1.l litres ( 1.9 pts )
- Hydraulic system ( approx. ) .._._..._.__.._._._...,,..,........,.,...................................... 4 litres (
7 pts 1
- Gearbox :
a) ~Z~UI/I~U/gcarho.~ ( TOTAL EP 80 ) _,.,__.___.,.,_._....,,,...................,...........,. 1.600 litres ( 2.8 pts )
- difference between Min. and Max. on dipstick ...........__................... 0.150 litres ( 0.26 pts )
h) Torque corztwrter gcarhox ( TOTAL FLUIDE T ) ._.___._...,,___.._....,...,.....,., 5.5 litres
- after draining _ 2 to 3 litres ( 3.5 to 5.3 pts )
(qccording to draining time)
- difference between Min. and Max. on dipstick (with rhc oil cold) .... .’ 0.150 litres ( 0.26 ‘pts )
w
Usable volume of boot ..___._._.......___................,.............,.............,.......,.,.....,............ 325 dm3 - 11.48 cu.ft.

OPERATION No MA. 000 : Gwc~rnl characteristics Op. MA. 000 9
CX 2400 SALOON
( Vehicles equipped with thk M 23/623 - 2350 cc engine )
I. GENERAL CHARACT.ERlSTlCS :
- Official symbol .._.. .._..._......................,.............._....._._....__._..__._........... MA series MJ
- Commercial symbol .._..._._..._.........,._........._...... .._ .._..._..._..._..._._... .._..._..._._..._._ CX 2400
- Factory symbol ( Warrar~ty symbol ) MJ
. ...o........................,,.....................................
- Introduction date .._.... _...._.. _._... ,.. .._...,_,.,. ,._... .,._.... September 1976
- French fiscal rating .._............._..........._..__._..,...._....._.._........_.,.,.,..,.,......, .,_.. ,........ 13 hp
- Number of seats ..I.... ,.................................................,..... 5
NOTE CX 2400 saloon vehicles can be fitted with a torque converter gearbox and an air-conditioning unit as
optional.equipment. From December 1976 onwards, these two items can be fitted together.
Wheels and tyres :
- Wheelrims .._.._......_.,._..._.,....._..._..............,........................ ~. . . . . . . 5 l/2 Jx14FHA
TYPE AND PRESSURE IN BARS ( PSI )
MICHELIN I
TYRES
r~-~
FRONT
185 HR 14 XVS-TU
STANDARD
FITTING 1.9 (27.5)
REAR SPARE
175 HR 14 XVS-TU
2.1 (30.5) 2.3 (33.5)
185 HR 14 XVS - TU
AUTHORISED 1.9 (27.5) 1.9 (27.5) 2.1 (30.5) \
ALTERNATIVE 185-14 X
(M + S )
1.9 (27.5 ) 1.9 (27.5) 2.1 ( 30.5 )
NOTE Vehicles are fitted with TUBELESS tyres as standard equipment. They can be fitted with tyres with
inner tubes of the same type, the pressures remaining the same.
The tyre pressures are indicated on a label located on the panel at the front of the door (011 the drilw’s side).
II. GENERAL QIMENSIONS
Dimensions :
- Front track ........................................................ ................................................... 1.474 m ( 4ft. 10 ins)
- Rear track ...................................................................... :. ....................................... 1.360 m ( 4 ft. 5 1/2ins)
- Wheelbase ............................................................................................................... 2.845 m ( 9 ft. 4 ins )
- Overall length ............................................................................................................ 4.660 m ( 15ft. 3 1/2ins)
- Front overhang ........................................................................................................... 1.050 m ( 3 ft. 5 l/2 ins)
- Overall width .......................................................................................................... ; 1.730 m ( 5 ft. 8 ins )
- Height of vehicle (in the normal driving position ) ...............................................
1.360 m ( 4 ft. 5 1/2ins)
_ Ground clearance ( in the uormal drilhzg position ) ..................................................
; 0.155 m ( 0 ft.6.1 ins )

10 OPERATION No MA. 000 : (;vt/c~ra/ chorac/vris/ics
Weights in kg ( lb )
- Kerb weight I wit/~ iLlI /m/k. oi !IIVI ) .......................................................................
- Weight on the front axle ....................... ........................ ........... .......................
- Weight on the rear axle ......................... ....................................................................
- Gross Vehicle Weight ....... ........................................................................... ...........
1300 ( 2866 )
870 ( 1918 )
430 ( 948 )
1790 ( 3946 )
- Maximum authorised weight on the fr-ont axle ............................_..._..._._......._._._....._..._.. 1050 ( 2315 )
- Maximum authorised weight on the rear axle . . . . . . . .. ..~.. .. . . . . . .. . . . . . . 750 ( 1653 )
- Gross Train Weight (with a 1300 kg ( 2866 lb ) trailer ) . . . . . .. . . 3090 ( 6812 )
- Gross Train Weight ( with a 650 kg ( 1433 lb ) trailer without brakes ) . . . . 2440 ( 5379 )
Towing :
- Maximum weight of trailer without brakes ..... __......................................................... 650 ( 1433 )
- Maximum weight of trailer ( within G.T.W. limit of 3090 kg ( 6812 lb ) ..................... 1500 ( 3307 )
- Maximum starting gradient ( at G.T.W. ) ..................................................... .............. 12% (1 in8 l/2)
NOTE For towing a trailer heavier than 900 kg ( 1984 lb ). ‘t .1 1s necessary to fit a second lo-blade electric
cooling fan.
IMPORTANT NOTE : References to trailers without brakes DO NOT APPLY in U.K.
III. GENERAL INFORMATION
Capacities :
- Fuel tank .__._.___..._....__..__...,.._.,.....__________.___.___.___.__.__.__._...................,.....:._.___.____._. 68 litres ( 15 galls )
- Cooling system f itfcltrrlivg hcatcr rirlil ) :
- Manual or torque converter gearbox .._..._..__._._,.._..._._.. _..._._._......._......._._._...... 10.6 litres ( 18.6 pts )
- Optional torque converter t air-conditioning unit .._............................... 12.5 litres ( 22 pts )
- Heater unit alone _._..._._._..,__..._.........,....._._._....__.___......... ._. _._._._._....._., .,,._......._. 0.6 litres ( 1.05 pts )
- Engine oil :
- after draining _..,.._._._....___..._.__....................._._._..._..._....._..._._._................... 4.650 litres (8.2 pts )
- difference between Min. and Max. on dipstick 1.1 litres ( 1.9 pts )
- Hydraulic system ( approx ) _....,_._.__.._._.........,..._..._._.___._......._._._._._._._..................... 4 litres ( 7 pts )
- Gearbox :
_ Overall cspacity ( TOTAL EP 80 ) . . . .. .._.... .._._._..._._._....._._._..._..._... 1.600 litres ( 2.8 pts )
- Difference between Min. and Max. on dipstick ..... . ... ....... ..... ... .... . . 0.150 litres ( 0.26 pts )
h) Torque con7~c~rter grarbos :
- Overall capacity ( TOTAL FLUIDE T ) _._._._._.,_...._........_.._.................... 5.5 litres ( 9.7 pts )
- After draining _._,_,_,_.,._.._......_._._._._._._..._..._._._._..._._..__._..._._..................... 2 to 3 litres ( 3.5 to 5.3 pts )
according to draining time
- Difference between Min. and Max. on dipstick (r!,ith the oil cold) _._,......
0.150 litres ( 0.26 pts )
-Usable volume of boot .~...............,.........,,............................................. .. 325 dm3 ( 11.48 cu.ft )

OPERATION No MA. 000 : ~(~tlc,rol tllNrar/vristics Op. MA. 000 11
CX 2400 ESTATE
( Vehicles fitted with the M 23/623 i 2350 cc engine)
I, GENERAL CHARACTERISTICS
- Commercial symbol _............................................................................................................. CX 2400 Estate
- Official symbol ................................................................................................................... MA series MF
- Factory symbol ( Wnrrmty syrh~l i ...................................................................................... MF
- Introduction date ................................................................................................................ September 1976
- French fiscal rating ............................................................................................................ 13 hp
- Number of seats ................................................................................................................... 5
Wheels and tyres :
- Wheelrims .......................................................................................................................... 5 i/2J x14FHA
Tyres
MICHELIN TYRES Type and pressure in bars ( psi )
I _-- --. --ZX - TU
STANDARD
I
AUTHORISED
] ALTERNATIVE
Manual
steering
Power
steering -_
Manual
steering
Manual or
Power steering
185 SH 14 xi
2.1 ( 30.5) 2.2 ( 32 ) I 2.4 ( 35 )
185 HR 14 XVS TU-
2 ( 29 1 2.1 ( 30.5 ) 2,3 (33.5 )
185 HR14 XVS TU-
2 ( 29 1 2.1 ( 30.5) 2.3 ( 33.5 )
185 R 14 X ( M + S )
2 ( 29 ) 2.1 (30.5 1 2.3 ( 33.5 )
NOTE : Vehicles are fitted with TUBELESS tyres as standard equipment. They can be fitted with tyres with
inner tubes of the same type, the pressures remaining the same.
Tyre pressures are indicated on a label on the panel at the front of the door ( on the driver’s side ).
II. GENERAL DIMENSIONS
- Front track .................................................................................................................... 1.474 m ( 4 ft. 10 ins )
- Rear track ................................................................... _................................................ . 1.390 m ( 4 ft. 6 314 ins)
- Wheelbase .................................................................................................................. 3.095 m ( loft. 1 3/4 ins )
- Overall length ......................................................................................................... 4.920 m ( 16ft. 1 3/ 4 ins )
- Front overhang ........................................................................................................... 1.050 m ( 3 ft. 5 l/2 ins )
- Overall width .............................................................................................................. 1..73 4 m ( 5 ft. 8 l/4 ins )
- Height of vehicle (ie the ~zormal drilhzg positim) ..................................................... 1.465 m (4ft.9 3/4 ins)
- Ground clearance (in the ?zormal driuiug positiaN ) .................................................... 0.155 m (0 ftl6.1 ins)

12 OPERATION No MA. 000: Gcvc,d chnmcteristics
_.
Weights in kg ( lb )
- Kerb weight ( with full tar/k of ihd ) _
................_..............__._._......._._..__.___....._._..._....... 1405 ( 3097 )
- Weight on front axle ................................................................................................ 900 ( 1984 )
- Weight on rear axle .._. .._._.... .._. .._................. 505 ( 1113 )
- Gross Vehicle Weiqht (i~~rl~lrlir~g ctll optinnnl c,quipv/<,t/t ) . . . . . ..._................................. 2095 ( 4619 )
- Maximum authorised weight on front axle ......_..._._............._..__......._......._._._._.,.,.,..._....... 1075 ( 2370 )
- Maximum authorised weight on rear axle ..................................................... ...__._........ 1030 ( 2271 )
- Gross Train Weight ( with a 700 kg ( 1543 lb ) trailer without brakes ) .” ~~.....~....~.~~...~ 2795 (6162 )
Towing :
- Maximum trailer weight ( gradient of 1 in 10 )
cl) K Stmclurd )) twhic-le ._..... . . .._..._..._._......,.._...._.._.,.,............,...._....._._....,,...................,.... 900 ( 1984 )
b ) Vchiclc jittcil with n second IO-hladc clcctric cooli7lg /atI ................. ................ 1300 ( 2866)
- Gross Train Weight with a 1300 kg ( 2866 lb ) trailer with brakes ............................. 3395 ( 7485 )
- Maximum trailer weight within limit of G.T.W. ( 3395 kg - 7485 lb ) ............................. 1500 ( 3307 )
- Maximum starting gradient .Cat.G. T. W. J ........................................................................ llS(lin9)
IMPORTANT NOTE : References to trailer without brakes DO NOT APPLY in U.K.
III. GENERAL lNFORMATlOt!4
Capacities :
- Fuel tank __.,.,........._._______...__.____._.,.,..._,_._..,._..._._.._._..._.........................................
- Cooling system ( itzcludivg heater fluit ) .................... ..................
- Heater unit alone _.,.,,., ,.,,....__. ._._.._.._.__..._. __...........................
- Engine oil :
- after draining . _._.,.......___.._.____..__..._._._....._...................................................
- difference between Min. and Max. on dipstick . ... . . .. . . . . . . .. . . .
- Hydraulic system ( approx ) _....,.,,......._.___..._.._.._.............................................
- Gearbox :
- after draining ...._..._......,,_,....._...._...._._._................................ _.....,.,.........
- difference between Min. and Max. on dipstick _.._,.............,....._._._._._......._.,
- Volume of boot :
- with rear seat in position ............................................................................
- with rear seat folded back .........................................................................
68 litres ( 15 galls )
16.6 litres ( 18.6 pts )
0,6 litres ( 1.05 pts )
4.650 litres ( 8.2 pts )
1.1 litres ( 1.9 pts )
4 litres ( 7 pts )
1.6 litres ( 2.8 pts )
0.150 litres (0.26 pts )
1100 dm3 ( 38.85cu.ft )
2030 dm3 ( 71.70cu.ft )

OPERATION No MA. 000 : General characteristics
CX 2400 GTI SALOON
Op. MA. 000
( Vehicles fitted with the M 23/622 - 2350 cc fuel injection engine )
13
I
I. GENERAL CHARACTERISTICS
- Commercial symbol .................................................................................................................. CX 2400 GTI
- Official symbol .......................................................................................................................... MA series ME
- Factory symbol ( Wdrranty symbol J .........................................................................................
ME
_ Introduction date ....................................................................................................................... May i977
- French fiscal rating ................................................................................................................ 13 hp
- Number of seats ..................................................................................................................... 5
Wheels and tyres :
- Wheelrims ..,.__......_..._............................._.........._.._.,_____...................... MICHELIN 5 l/2 J x 14 FHA 5.49 D
Tyres :
- Tyres ( tubeless
- Pressure in bars
Front Rear
1 . 185 HR 14 XVS
( psi ) .. . . . . . ... .. 2.1 ( 30.5 )
*
Authorised Alternative :
Spare
,
- Tyres ( special, equipment ) . . ... . ... . ...... 185 R 14 X(M+S) 185 R 14 X (M+S ) 185 HR14 X (M+S)
- Pressure in bars ( psi ) ......__................. 2.1 ( 30.5 ) 2.2 ( 32 1
2.4 ( 35 1 ,
NOTE : - Vehicles are fitted with TUBELESS tyres as standard equipment. They can be fitted with tyres with
inner tubes of the same type, the pressures remaining the same.
- Tyre pressures are indicated on a label located on the panel at the front of the door (on the driver’s
s id,e ).
II. GENERAL DIMENSIONS :
- Front track ............................................................................................................. ...
- Rear track ..............................................................................................................
- Wheelbase ..............................................................................................................
- Overall length .............................................. ................................................................
- Front overhang ........................................................................................................
- Rear overhang ................................................................. ........................................
- Overall width ......................................................................................................
-Height of vehicle I in normal dtiuing position ) ......................................................
- Ground clearance ( in normal dtiuing position ) .......................................................
1.474 m ( 4 ft. 10 ins )
1.360m(4ft.S 1/2ins)
2.845 m ( 9 ft. 4 ins )
4.670 m ( 15ft. 3 3/4 ins)
1.057 m ( 3 ft. 5 l/2 ins )
0.764 m ( 2 ft. 6 ins )
1.734 m ( 5 ft. 8 l/4 ins )
1.366 in ( 4.ff. 5 .1/2 ins )
Q.155m ( O.ft. 6.1 ins )
.
.8
1

14
OPERATION No MA. 000 : G<,ncraZ charactc,ristics
Weights in kg ( lb ) :
- Kerb weight ( with jull Iauk of fill ) ....................... ............................................................................. 1345 ( 2965 )
- Weight on front axle ........... .................................................................................................................... 910 ( 2006 )
Weight on rear axle ........................................................................................................................ 435 ( 959 )
- Gross Vehicle Weight ( ir~cludiug all mp/inual ~~quipmwt ) ....................................................... 1810 ( 3990 )
- Maximum authorised weight on front axle ................................................................................... . 1075 (2370 )
- Maximum authorised weight on rear axle .................................................. ..~...............~ .............. 750 ( 1653 )
- Gross Train Weight with a 670 kg ( 1477 lb ) trailer without brakes ) .......................................... 2480 ( 5467 )
Towing :
- Maximum weight of trailer ( on gradient of 1 in 10 ) :
a) s StaiJdard )) r,ehiclc ................................................................................................................ 900 ( 1984 )
h) Vchicfe equipped with a second IO-blade cooling jar? ....................................................... 1300 ( 2866 )
- Gross Train Weight with a 1300 kg ( 2866 lb ) trailer with brakes ............................................ 3110 ( 6856 )
- ‘Max. trailer weight within limit of G.T.W. ( 3110 kg - 6856 lb ) .................... .............................. 1500 ( 3307 )
- Max. starting gradient ( at G. 7‘. W. I) .......................................................................................... 12 % ( 1 in 8 l/2)
I1.l..GENERAL INFORMATION
Copoci;ies :
- Fuel tank .._.___._._._._.’__.._._._..._....._._._,_..,._.,_..._..,_,._...._,___....___._______.............,.,.... 68 litres ( 15 galls )
- Cooling system ( ilzcluding heater unit,) __...._.___,_.__.....,....._._.___..___._._____..._._._. 12.3 litres ( 21.6 pts )
- Heater
unit alone . ....... . ........... . . ... . . ........... . .. ... ... .._......... .
0.6 litres ( 1.05 pts )
- Engine oil :
- after draining ..... . . ...... . . . ...... . ... ............... ... . . . . . . . . ... . ..... . ... 4.650 litres ( 8.2 pts )
- difference between Min. and Max. on dipstick .._._........._.___.,._.____.__.__._.. 1.l litres ( 1.9 pts )
- Hydraulic system ( approx ) : .._.__.,_,...,._...,.....,..........,..............................,...... 4 litres ( 7 pts )
- Gearbox :
- after draining .....__._....__._......._......................_......._.__________._._____.............. 1.6 litres ( 2.8 pts )
- difference between Min. and Max. on dipstick ... .... . . ..._..._..._..____......... 0.150 litres ( 0.26 pts )
- Usable volume of rear boot .__..____.___._____..__._____._.________.._....,...,,.._._.,......__..__........325 dm3 ( 11..48 cu.ft )
