We thank you for choosing to drive a new CITROËN
and we congratulate you on your choice.
Please read this handbook carefully before taking to the road.
It contains essential information about driving your vehicle and operating
its equipment, as well as other important advice to be rigorously followed.
The handbook also contains all you need to know about the servicing
and routine maintenance of your vehicle, thus assuring both your safety
and the reliability of your new CITROËN.
A thorough knowledge of your new CITROËN
will enable you to enjoy driving to the full.
Depending on the version of your vehicle and its options, as well as
on the date of manufacture and the country of marketing, some of the
equipment or certain functions described in this handbook may not be
present on your vehicle.
Please note the following point:
The tting of electrical equipment or accessories that are not recommended by CITROËN may result in
a failure of your vehicle’s electronic system. Please note this specic warning. It is advisable to contact a
CITROËN dealer to be shown the recommended equipment and accessories.
c4_dd_sommaire_ed05-2008.indd 1 10/07/2008 13:57:54

2
Display A 31
Display C 34
NaviDrive Display 37
Trip computer 38
II - MULTIFUNCTION
DISPLAYS 31 40
Air distribution 41
Ventilation/Ventilation 43
Automatic air conditioning 45
Scented air freshener 48
Front seats 49
Rear seats 53
Rear view mirrors 55
Steering column adjustment 56
III - COMFORT 41 56
Keys 57
Remote control 58
Alarm 60
Electric windows 62
Child safety 63
Doors 63
Tailgate 64
IV - ACCESS 57 64
Lighting control 65
Headlamp adjustment 66
Direction indicators 67
Hazard warning lamps 67
Directional headlamps 68
Wiper controls 69
Interior lighting 71
V - VISIBILITY 65 72
Interior 73
Boot 77
VI - INTERIOR
COMFORT 73 77
Instrument panel 23
Warning lamps 24
Particle filter (Diesel) 26
Maintenance indicator 27
Engine oil level indicator 29
Display lighting rheostat 29
FAMILIARISATION 4 22
I - OPERATING
CONTROLS 23 30
General 78
Child seats 79
Isofix mountings 81
VII – CHILD SAFETY 78 83
c4_dd_sommaire_ed05-2008.indd 2 10/07/2008 13:57:55

3
Tyre pressure sensors 84
Braking assistance
systems (ABS) 85
Trajectory control
systems (ESP/ASR) 86
Seat belts 87
Airbags 90
Safety advice 94
Lane departure warning system 96
VIII - SAFETY 84 96
Handbrake 97
Manual gearbox 99
Electronic gearbox system
(EGS) - 6 speed 100
Hill start assist 105
Automatic gearbox 106
Cruise control 110
Speed limiter 112
IX - DRIVING 97 115
Bonnet release 116
Petrol engines 117
Diesel engines 118
Levels 119
X - MAINTENANCE 116 123
Refuelling 124
Changing a wheel 125
Replacing bulbs 129
Replacing a fuse 136
Battery 142
Towing 145
Towing a trailer 147
Cold weather shield 148
Accessories 149
XI - PRACTICAL
ADVICE 124 150
Capacities 151
Weights 152
Fuel consumption 157
Dimensions 160
Vehicle identification 162
XII - TECHNICAL
SPECIFCATIONS 151 162
INDEX 180 183
Radio-RDS-CD 163
CD changer 173
Hands-free telephone 174
Frequently asked questions 178
XIII - RADIO 163 179
c4_dd_sommaire_ed05-2008.indd 3 10/07/2008 13:57:55

4
FAMILIARISATION
Directional headlamps
This lighting function automatically im-
proves forward vision when cornering.
68
65
96
EXTERIOR
Lane departure warning system
Above 50 mph, this system is activated
automatically if you inadvertently wander
from your lane.
Visual and audible parking
assistance, front/rear
This system warns you if an obstacle
is detected when manoeuvring the
vehicle.
Guide-me-home lighting
The headlamps stay on for a short
period after switching off the ignition.
114
c4_dd_prise en main_ed05-2008.in4 4 10/07/2008 13:56:21

5
FAMILIARISATION
Press once to lock the vehicle.
Press again to unlock the vehicle.
Remote control
A. Unfolding/folding the key.
B. Unlocking the vehicle.
C. Locking the vehicle.
 57
Manual central locking
63
OPENING
In addition...
A long press on button Clocks the
vehicle and closes the windows.
Two successive presses on button C
deadlocks the vehicle.
D. Activating/deactivating
guide-me-home lighting.
 59
c4_dd_prise en main_ed05-2008.in5 5 10/07/2008 13:56:22

6
FAMILIARISATION
Unlock the vehicle with the remote control
or the key.
Press up on the lever and lift the tailgate.
Tailgate Spare wheel and tools
Access to the spare wheel
Lift the carpet, then remove the tool
holder to gain access to the wheel.
OPENING
 125
Access to the tools
The tools are located in a protective
holder in the spare wheel.
Fuel tank
A. Opening the fuel fi ller fl ap.
 124
B. Removing the fi ller cap.
If your spare wheel is of different
dimensions to the wheels on the
vehicle, it is essential to use it only
on a temporary basis, and to not
drive above 80 km/h (50 mph).
 64
To open the fuel fi ller fl ap, pull at its
notched edge. There is a fuel label on
the inside of the fl ap.
Locking filler cap
Turn the key a quarter turn to lock and
unlock the fi ller cap.
When refuelling, place the cap on the
carrier on the inside face of the fi ller
fl ap.
Fuel tank capacity: 60 litres approxi-
mately.
c4_dd_prise en main_ed05-2008.in6 6 10/07/2008 13:56:23

7
FAMILIARISATION
INTERIOR
Translucent instrument panel
This system gives optimum contrast,
whatever the external light level.
Cruise control/Speed limiter
These two systems allow the vehicle’s
speed to be maintained at a programmed
level.
Scented air freshener
The air freshener distributes scented
air throughout the cabin. It is located
in the centre air vent
Audio and communication
systems
These systems make use of the latest
technologies: MP3-compatible audio,
Bluetooth®hands-free kit, GPS mobile
phone.
 23
 110, 112
48
 163
c4_dd_prise en main_ed05-2008.in7 7 10/07/2008 13:56:24

8
FAMILIARISATION
DASHBOARD
1. Controls:
• Mirrors.
• Windows.
• Child safety
2. Headlamp adjustment.
3. Controls:
• ESP.
• Parking assistance.
• Lane departure warning system.
• Anti-intrusion alarm.
4. Steering lock and ignition switch.
5. Controls:
• Windscreen wiper.
• Screen wash.
• Rear screen wiper.
• Trip computer.
6. Fixed centred controls.
7. Direction indicator warning lamps.
8. Speed indicator.
9. Controls:
• Trip mileage recorder reset
button.
• Display lighting rheostat.
• Display of alerts and status of
functions.
10. Centre air vents.
11. Driver’s airbag.
12. Horn.
13. Gear lever.
14. Handbrake.
c4_dd_prise en main_ed05-2008.in8 8 10/07/2008 13:56:25

9
FAMILIARISATION
DASHBOARD
1. Bonnet release.
2. Fusebox cover.
3. Storage drawer (left and right).
4. Lateral air vent (left and right).
5. Side window demister vent
(left and right).
6. Loudspeaker (Tweeter) (left and right).
7. Passenger’s airbag.
8. Control for central locking of doors
and boot.
9. Multifunction display.
10. Hazard lamps control.
11. Scented air freshener.
12. Controls:
• Lighting.
• Direction indicators.
• Front fog lamps
• Rear fog lamps.
13. Steering column adjustment lever.
14. Radio-CD or NaviDrive radio navigation .
15. Air conditioning or heating/ventilation .
16. Cigar lighter.
17. 12-volt accessory socket (150 W max).
or
USB socket.
18. Ashtray.
19. Carrier bag hook.
20. Key-operated switch:
• Passenger’s airbag activation/
deactivation.
21. Lower glovebox.
• Handbook pack storage.
c4_dd_prise en main_ed05-2008.in9 9 10/07/2008 13:56:26

10
FAMILIARISATION
FIXED CENTRED CONTROLS STEERING WHEEL
Controls for speed limiter
and cruise control Audio system
controls
Warning lamps:
lighting and direction
indicators
Function
controls:
Multifunction display controls
Horn
- Display lighting rheostat
- Voice recognition
- Air recirculation
- Telephone
- Personal button
c4_dd_prise en main_ed05-2008.in10 10 10/07/2008 13:56:27

11
FAMILIARISATION
Controls for speed limiter and
cruise control Audio system controls See "Audio" or your Navidrive instructions
Selection of speed
limiter or cruise
control
Activation of speed
limiter and
Deactivation/
Reactivation
of cruise control and
speed limiter
Search for
higher radio
frequencies
Scrolling of
memorised
stations
Decrease speed/
Activate cruise
control
Increase speed/
Activate cruise
control
Increase sound
volume Reduce sound
volume
Mute
FIXED CENTRED CONTROLS STEERING WHEEL
c4_dd_prise en main_ed05-2008.in11 11 10/07/2008 13:56:27

12
FAMILIARISATION
Display
lighting
rheostat
Starting voice
recognition
(See "Audio" or
your Navidrive
instructions) Access to "Main
menu"* Scrolling in the
multifunction
display
Telephone pick-
up/hang-up
(See "Audio" or
your Navidrive
instructions)
Personal button:
- Black panel (default function), or
- Interior lamp on/off, or
- Log of alerts, or
- Status of functions
Give a long press on this button to
display the personalisation menu.
Selection of the type of in-
formation displayed on the
right of the screen (radio,
trip computer, navigation/
guidance…) and for screen
A, choice of activation/deac-
tivation of your functions and
choice of your adjustments
Cancel the current
operation or return to the
previous screen
Air recirculation
Validation of the function selected or the
value modied
Pick up/hang up
(See "Audio" or your Navigation instructions)
* In compliance with national
legislation, in some coun-
tries the "menu" control is
deactivated when driving.
Display the
"Directory" menu
(See "Audio" or
your Navidrive
instructions)
FIXED CENTRED CONTROLS STEERING WHEEL
c4_dd_prise en main_ed05-2008.in12 12 10/07/2008 13:56:28

13
FAMILIARISATION
SITTING COMFORTABLY
 51
Front seats
Forwards-backwards Driver’s seat cushion height and angle
adjustment Seat back angle and lumbar adjustment
Manual adjustments
Electrically operated adjustments
(driver’s seat only)
Forwards-backwards Seat cushion height and angle adjustment Seat back angle and lumbar
adjustment
 50
c4_dd_prise en main_ed05-2008.in13 13 10/07/2008 13:56:30

14
FAMILIARISATION
SITTING COMFORTABLY
1. Unlock the steering column using
the lever.
2. Adjust the position of the steering
wheel for height and reach.
3. Lock the steering column with the
lever.
Manual adjustment of steering
wheel height and reach
 56
Front seat belt
1.Locking.
 87
Adjustment of front head
restraints
Adjustment of rear head restraints
 53
Height and angle.
A. Low position.
B. High position.
A. Height adjustment (5-door)
B. Holding the seat belt (3-door)
 50
c4_dd_prise en main_ed05-2008.in14 14 10/07/2008 13:56:31

15
FAMILIARISATION
Adjustment of exterior rear view
mirrors
A. Select the mirror.
B. Adjust the mirror.
C. Fold-back/Unfolding.
Adjustment of interior rear view mirror
 55
SITTING COMFORTABLY
Electric windows
 62
Child safety
5. Inhibition of the opening of the
passenger and rear doors and
electric windows.
1. Driver’s window control.
2. Passenger’s window control.
3. Left hand rear window control.
4. Right hand rear window control.
1. Mirror direction.
2. Selection of the mirror’s "day"
position.
 56
c4_dd_prise en main_ed05-2008.in15 15 10/07/2008 13:56:32

16
FAMILIARISATION
VISIBILITY
Lighting
Ring A
Ring B
Windscreen wipe
Screen wipe
Rear screen wipe
Front foglamps and rear
foglamps.
65  69  70
Lighting off.
Automatic lighting.
Sidelamps.
Dipped or main beam.
2Fast speed.
1Normal speed.
IIntermittent.
0Off.
AUTO Automatic wipe or single wipe.
Off.
Intermittent.
Timed wipe and wash.
Deactivation of automatic wipe
Go to position Ithen return to position 0.
c4_dd_prise en main_ed05-2008.in16 16 10/07/2008 13:56:35
