clare Value Series User manual

ClareVision Video
Surveillance
Value Series Wi-Fi Fixed
Lens Turret Camera
Installation Guide
1 | ClareVision Value Series Wi-Fi Turret Cameras

Box Contents
For Setting up cameras and complete user
manuals, please scan these QR codes:
https://bit.ly/3ndBOKO
Quick Start Guide
https://bit.ly/3gEEj7s
User Manual
• Camera and antenna
• 12VDC Power Supply
• Mounting template
• Mounting kit
• Accessory kit
Required Equipment
• Phillips head screwdriver
• Power source: Ethernet cable
• Drill with ¼” drill bit
2 | ClareVision Value Series Wi-Fi Turret Cameras

Inspection
Ensure that the device is in good condition and
all the assembly parts are included.
• Make sure that all equipment is powered o
during installation.
• Ensure the mounting surface is strong enough
to withstand three times the weight of the camera
and the mount.
• If the product does not function properly, please
contact technical support. Do not disassemble
the camera for repair or maintenance.
WARNING: This product can expose you
to chemicals including cadmium, which
which is known to the State of California to cause
cancer. For more information, go to
www.p65warnings.ca.gov.
3 | ClareVision Value Series Wi-Fi Turret Cameras

Overview
Before installing, familiarize yourself with
the parts of the camera. Please note, the
Wi-Fi Turret camera does not support
POE.
4 | ClareVision Value Series Wi-Fi Turret Cameras
NOTE: Screw in the
antenna into the
antenna jack before
installation.

Installation
Before You Get Started: You will need to
physically connect the camera to the local
area network using an Ethernet cable to
configure the Wi-Fi.
A Wi-Fi signal strength of -60dBm or
greater is required at the installation
location to establish a reliable connection to
the network.
5 | ClareVision Value Series Wi-Fi Turret Cameras
1. Using an Ethernet cable, connect the
camera to the home network via router,
modem, or switch.
Power up the camera using the included
12VDC power supply.

Installation
2. Access the camera web console using the
IP Address. You can use the IP Search Tool to
discover the camera IP address. Download
the tool here: https://bit.ly/3En7jJ7
3. Input the default username (Admin) and
password (first six characters of the UUID).
Change the password when prompted.
4. Connect the camera to the desired
2.4GHz network using the Web Console,
You can add the network by navigating to:
Configuration > Network > Wi-Fi.
Select the desired Wi-Fi SSID and input the
password. Tap Save once completed.
5. Check and update the firmware:
Configuration > System Configuration >
Maintenance > Check Current Version.
6 | ClareVision Value Series Wi-Fi Turret Cameras

Installation
6. Check to make sure you are able to
discover and add the Wi-Fi camera using the
ClareVision App (iOS or Android) when on
the local area network.
7. At the desired installation location, check
the Wi-Fi signal strength to ensure it is
-60dBm or greater with the perimeter
doors closed. If the signal is too low, you may
need to boost the signal with a Wi-Fi range
extender or wireless access point.
You can check the Wi-Fi signal strength using
a Wi-Fi analyzer app such as:
• Wi Analyzer app for Android
• AirPort Utility Tool for iOS
7 | ClareVision Value Series Wi-Fi Turret Cameras

Installation
8. Press the locking button on the side of the
mounting bracket to disconnect it from the
body of the camera.
8 | ClareVision Value Series Wi-Fi Turret Cameras
9. Mount the base to the desired location
using the four mounting screws and anchors.

Installation
10. Snap the camera into place by lining up
the ridges on inner part of the mounting
bracket with the outer ridges of the camera.
Press the button to lock it back into place.
11. Adjust the camera by panning, tilting,
and rotating the camera body to the desired
viewing angle.
9 | ClareVision Value Series Wi-Fi Turret Cameras

10 | ClareVision Value Series Wi-Fi Turret Cameras
Support
For additional help:
Integrator/Dealer Support:
Phone: [phone]
Email: [email protected]
For more information, instructional videos, or
support documentation, visit our Help Center
and view your item’s product page:
https://www.clarecontrols.com/helpcenter
Camera Setup & Default Password
IMPORTANT NOTE: The default camera
setup password is the FIRST 6 Characters
of the UUID/SN.
You will be prompted to change the
password when setting up the camera.
Please refer to the Quick Start Guide for
complete setup instructions or by visiting:
https://bit.ly/3ndBOKO

Contact Information
Clare Controls, LLC.
7519 Pennsylvania Ave, Suite 104
Sarasota, FL 34243
General: 941.328.3991
Fax: [phone]
www.clarecontrols.com
Warranty Information
Clare Controls offers a two (2) year limited
warranty on original Clare Controls
components, from the date of shipment
from Clare Controls. To view complete
limited warranty details, including limitations
and exclusions, please visit:
www.clarecontrols.com/warranty
11 | ClareVision Value Series Wi-Fi Turret Cameras

Camera Information
Please provide this guide to the customer
and notate the camera installation location
and new camera password. This guide
includes important camera details.
Camera Password:_____________________
Installation Location:___________________
Camera Details:
Product
Label
12 | ClareVision Value Series Wi-Fi Turret Cameras
Doc ID: 2021-12-2131-03
