Clean Logix ALX-ABB User manual

USER
MANUAL
English (Original Instrucons)
Updated: 03/24/21
MODEL:
ALX-ABB
Chemical Allocaon Manual Air Buon Box

USER MANUAL (MODEL: ALX-ABB) Page 2 of 5 Updated: 03/24/21
USER MANUAL: ALX-ABB
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
1. Determine mounng locaon, with consideraon
of the following:
• User accessibility
• Distance to ALX controller/tower
• Distance to Devices and pumps
• Connecons for air
2. Using appropriate mounng hardware (not
included) to install.
Installaon
NOTE: For more informaon on Controller
installaon requirements and conguraon please
consult the User Manual for the included ALX
Controller for model-specic requirements.

USER MANUAL (MODEL: ALX-ABB) Page 3 of 5 Updated: 03/24/21
USER MANUAL: ALX-ABB
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
1. Connect regulated compressed air supply to main airline inlet.
• If ALX Tower or addional ALX-ABB is to be used with the system, remove plug from tee ng and
connect addional airlines as necessary.
2. Connect air lines from solenoid devices to the air inlet check valves.
3. Connect air lines to the chemical pumps for each corresponding solenoid output.
Consult the diagram below for more informaon:
Installaon (cont.)
FROM
AIR REGULATOR
TO ALX TOWER OR
ADDITIONAL ABB
(IF APPLICABLE)
CAN-SO-4
(SOLENOID OUTPUT)
ALX-ABB-4
AODD PUMP
FROM
AIR REGULATOR
TO ALX TOWER OR
ADDITIONAL ABB
(IF APPLICABLE)
CAN-SO-4
(SOLENOID OUTPUT)
ALX-ABB-4
AODD PUMP
NOTE: Example connecon shows ALX-ABB-4, installaon set-up may vary.

USER MANUAL (MODEL: ALX-ABB) Page 4 of 5 Updated: 03/24/21
USER MANUAL: ALX-ABB
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
Operaon
Please contact Clean Logix at:
(616)-438-9200 or [email protected]
iMore Informaon
1. In the event a manual dispense needs to be
iniated, idenfy the pump/chemical to be
dispensed and it’s override control buon.
2. Press and hold the buon to dispense.
3. When dispense volume has been obtained,
release the buon to stop the dispense.
Maintenance
1. Check hose/tubing for secure connecons
2. Ensure there are no air line leaks
3. Verify air regulator sengs (consult ALX controller
manual for recommended regulator sengs)
NOTE: Check valves connect to push buons
front to back / boom to top (i.e. the front check
connects to the boom buon and so on).

USER MANUAL (MODEL: ALX-ABB) Page 5 of 5 Updated: 03/24/21
USER MANUAL: ALX-ABB
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
Appendix - Parts Callout
PART NUMBER DESCRIPTION
F1012 SCREW MACHINE 10-32 x 5/8 SS PHILLIPS
F1014 SCREW MACHINE 10-32 x 1 1/2 SS PHILLIPS
F1096 SCREW MACHINE 10-32 X 3/8 SS PHILLIPS TRUSS HD
F1181 WASHER LOCK EXT TOOTH #10 SS
M1630 ABB FRONT PLATE
M1631 ABB REAR PLATE
P1181 ENCLOSURE FIBOX AR1086CHSSL
P1202 QUICK FIT ELBOW 3/8" NPT X 3/8" TUBE
P1214 QUICK FIT TEE 3/8"
P1215 QUICK FIT REDUCER 3/8" X 1/4"
P1219 QUICK FIT ADAPTER 3/8" NPT x 3/8" TUBE
P1271 3/8" OD POLYETHYLENE TUBING - NATURAL
P1316 QUICK FIT PLUG 3/8"
P1535 VALVE STEM 1/4 NPT X 3/8 QUICK FIT QTY. BREAKS AT 50, 100
P1536 VALVE PUSHBUTTON ACTUATOR GREEN/ENP, QTY. BREAKS AT 50, 100
P1537 MANIFOLD 1/4" 4-PORT 3/8" INLETS
P1538 STANDOFF 10-32 X 1 F-F HEX AL
P1771 CHECK VALVE, 3/8 QUICK FIT X 3/8 QUICK FIT
