Cleantecs FFS230 User manual

RADIO
REMOTE CONTROL
FFS230/FFS400
Operating Instructions
BJ 2015 ..
SN 1500 ..
FFS230
BA 0304882 R00 2021-06
Translation of operating instructions for the
Radio Remote Control FFS230/FFS400
enRadio Remote Control FFS230/FFS400

2BA 0304882 R00 2021-06
Basics 7
Safety notices 8
Explanatory information 9
Overview of the components and scope of delivery of the radio remote control
10
How does the radio remote control work? 12
Components and their function 13
Intended use 16
Improper and prohibited use 16
Requirements of the system user 16
Space requirements 16
Specications for power connection 16
Power/technical specications: 230 volts 16
Power/technical specications: 400 volts 17
Where can the radio remote control be used? 17
Radio connection range 17
EC Declaration of Conformity 18
Safety principles 19
For your safety 20
Working safely 22
Working safely 23
Safe operating environment (current protection/FI) 23
Awareness of hazards in the working area 23
Table of contents

3
BA 0304882 R00 2021-06
Radio range (what do I have to consider?) 23
Checking the radio remote control for defects 23
Checking the battery charge level of the handheld transmitter 23
Checking the function of the radio remote control 23
Safety when using the radio remote control 23
Commissioning 25
Preparation for connecting the radio remote control 26
Unpacking and checking new goods 26
Checking before connection 26
Charging the handheld transmitter 28
Working 30
Working with the radio remote control 31
The right place for radio reception 31
The right place for the base unit when working 32
Attaching the strap to the handheld transmitter 33
How do I connect the base unit? 34
How do I wear the strap with the handheld transmitter correctly? 34
Controls on the handheld transmitter 35
What does the GREEN LED indicate? 35
How do I operate the handheld transmitter? 37
How do I change the frequency band? 38
Table of contents

4BA 0304882 R00 2021-06
Table of contents
Taking out of operation 40
Disconnecting the radio remote control 41
How do I disconnect the base unit from the device and the mains? 41
Transport and storage 42
Transporting and storing the radio remote control 43
Preparation for transport 43
Preparation for storage 43
Disposal 44
What happens to the waste? 45
Packaging 45
Base unit and handheld transmitter 45

5
BA 0304882 R00 2021-06
A radio module from ELCA is integrated into our radio remote control. Please
also read the ELCA operating instructions and keep them in a safe place.
Basics

6BA 0304882 R00 2021-06
It is IMPORTANT that you read these operating instructions
CAREFULLY BEFORE USE and KEEP THEM FOR FUTURE
REFERENCE.
Visit our homepage at regular intervals and check for the latest
version of the operating instructions.
The operating instructions are intended for...
the radio remote control manufactured from 2015, serial number
1500. The revision level of the operating instructions is R00.

7
BA 0304882 R00 2021-06
Basics
Components and functions of
the radio remote control
Here you will find information about:
Components of the system, tools for maintenance.

8BA 0304882 R00 2021-06
Explanation of notices
Basics
Note: …
Failure to comply will lead to serious injury or death.
Failure to comply may lead to serious injury or death.
Failure to comply may lead to injuries.
Failure to comply may lead to material damage and
impair the function of the product.
Additional information about product operation.
Safety notices
The notices are for your safety. The notices can be found in the general safety
section and are always accompanied by an action that requires specific attention.
Danger to life due to thunderstorms
A Avoid using the machine during thunderstorms.
This protects you from injury caused by lightning and from
hypothermia.
DANGER
Risk of injury from falling
A Use a fall-arrest system.
This will protect you from injuries from falling off the roof.
WARNUNG
Illness and hypothermia caused by bad weather
A In bad weather, wear suitable protective clothing.
This will protect you from illness caused by hypothermia.
CAUTION
Risk of damage due to frost
A Prevent the machine from freezing up. Otherwise this could
cause damage to the components.
This will protect the machine from frost damage.
NOTICE

9
BA 0304882 R00 2021-06
Basics
The title of the image indicates the
text to which the figure belongs.
The detailed view highlights areas that
are important.
The numbers on the figures refer to
the steps in the explanatory text. They
always start again from [1] on each
double page.
The red arrows always indicate a move-
ment.
Image title
[3]
Explanatory information
This information can be found in the grey shaded area of a figure. It helps you to
find the right figure for the heading in the text, understand the details better, follow
steps, complete movements and identify the position.

10 BA 0304882 R00 2021-06
Overview of the components and scope of delivery of the radio
remote control
Basics

11
BA 0304882 R00 2021-06
Basics
1Radio remote control
2 Handheld transmitter
3Charging unit for
handheld transmitter

12 BA 0304882 R00 2021-06
Basics
How does the radio remote
control work?
The radio remote control consists of
a housing with a radio receiver for re-
ceiving the radio signal and a contactor
switch for switching the current.
A handheld transmitter is used for
contactless operation. With the hand-
held transmitter, the contactor switch
can connect or disconnect the flow
of current without contact and from a
distance (up to 270 metres). When the
START button on the handheld transmit-
ter is pressed, it searches for a frequen-
cy range for the best connection.
Once the best radio connection has
been found, the handheld transmitter
and radio receiver maintain permanent
contact. If this contact is broken for
any reason, a stop signal is automati-
cally activated for safety reasons and
the contactor switch disconnects the
power connection.
An antenna for receiving and transmit-
ting radio signals is installed on the
housing of the radio remote control. To
increase the radio range, this can be
replaced with an optimised antenna,
which provides a range of up to 530
metres.

13
BA 0304882 R00 2021-06
Components and their function
The radio receiver and the contac-
tor switch are accommodated in the
housing. The housing has protection
classes IP66/IP67/IP69.
The handheld transmitter provides
contactless control of the contactor
switch via the receiver. The connection
to the circuit is closed with the START
button and broken with the STOP but-
ton. The arrow keys have no function.
The antenna provides a good radio
connection up to 150 metres with ob-
stacles and up to 270 metres without
obstacles.
The protective plate protects the hous-
ing from mechanical stress and is used
for transport and mounting options.
Housing
Protective plate
Antenna
Handheld transmitter with strap
Basics

14 BA 0304882 R00 2021-06
The carrying handle, which is integrat-
ed into the protective plate, helps to
carry the radio remote control safely.
The suspension eyes offer the option
of mounting the radio remote control on
a surface.
The hook can be used to hang the ra-
dio remote control on our DI filter trolley
or in another suitable location.
The rubber feet protect against dirt
and provide slip resistance.
The connections connect to the
mains and the device to be started and
stopped.
The charging unit for the handheld
transmitter is needed to charge the
battery in the handheld transmitter.
Power connection
Charging unit for handheld transmitter
Hook for hanging
Rubber foot
Carrying handle
Suspension eye
Basics

15
BA 0304882 R00 2021-06
Basics
Intended use
Here you will find the following information:
For what purposes may the FFS be used,
where may the FFS be used, who may use
the FFS?

16 BA 0304882 R00 2021-06
Intended use
The FFS radio remote control is for
STARTING and STOPPING devices in
the commercial sector by means of a
radio signal.
Improper and prohibited use
The FFS radio remote control must not
be tampered with. No devices may be
connected for which the required power
consumption exceeds the possible
power consumption of the radio remote
control.
Requirements of the system user
The user of the radio remote control is
in the commercial sector.
Operator: The operator must be in-
structed by the plant operator in the
assigned tasks and possible dangers in
case of improper conduct. The operator
may only carry out tasks that go beyond
normal operation if this is indicated in
this manual and the plant operator has
expressly instructed them to do so.
Qualified personnel: Due to their techni-
cal training, knowledge, experience and
familiarity with the relevant standards
and regulations, qualified personnel are
able to carry out the work assigned to
them, recognise possible dangers and
avoid risks independently.
The following groups of people are not
allowed to operate the radio remote
control:
�People with limited physical, sensory
or mental capacities
�Children and young people under
18 years of age
�Persons who have not been trained
Space requirements
�Space requirements for storage:
W 230 mm x L 140 mm x H 370 mm
�The following working area is
required: W 230 mm x L 140 mm x
H 370 mm
Specifications for power
connection
The power connection must have a fuse
rating of 230/400 volts and 16 amps.
In addition, the power connection must
have a residual current circuit breaker
(FI or RCD).
Power/technical
specifications: 230 volts
�Voltage 230 volts
�Current 16 amps
�Frequency 50/60 hertz
�Radio type ELCA AR MITO-MINI
�Operating frequency
868.0125 - 869.9875 MHz
Basics

17
BA 0304882 R00 2021-06
Power/technical
specifications: 400 volts
�Voltage 400 volts
�Current 16 amps
�Frequency 50/60 hertz
�Radio type ELCA AR MITO-MINI
�Operating frequency
868.0125 - 869.9875 MHz
Where can the radio remote
control be used?
The housing of the radio remote control
is approved according to protection
class IP66/IP67/IP69. The housing is
therefore dust-proof, can be submerged
in water for short periods and can also
withstand a high-pressure water jet.
This allows the radio remote control to
be used both indoors and outdoors.
Radio connection range
The radio connection range depends on
the obstacles present in the radio path.
Range without obstacles:
�270 metres
Range with obstacles:
�150 metres
An antenna can be fitted to increase the
range as an option.
Range without obstacles:
�530 metres
Range with obstacles:
�300 metres
Basics

18 BA 0304882 R00 2021-06
Basics
EC Declaration of Conformity

19
BA 0304882 R00 2021-06
Safety principles
General safety instructions
Important instructions for safe use of the
system and for ensuring safe cleaning.

20 BA 0304882 R00 2021-06
Safety principles
For your safety
Important instructions for safe use of the system. These instructions enable you to
protect yourself and others from dangerous situations and injuries.
Danger to life due to inadequate fuse protection
A Operate the radio remote control only with a power supply
system that has adequate fuse protection.
This will prevent injury/death from electrocution.
DANGER
Danger to life due to missing residual current circuit breaker (FI)
A Operate the radio remote control only with a power supply
system that has a residual current circuit breaker (FI).
This will prevent injury/death from electrocution.
DANGER
Danger to life due to defect
A In the event of a defect, rst disconnect the radio remote
control from the mains.
This will prevent injury/death from electrocution.
DANGER
Danger to life due to defective components
A Before putting into operation, check the housing, cables,
connections and strap for damage. Damage must be repaired
or replaced with original parts.
This will prevent injury/death from electrocution.
DANGER
WARNING
Report malfunction
A Report malfunctions to your supervisor immediately.
This will prevent injuries or damage.
