Cleco 8DL Series Installation and operating instructions

1
Operation & Service Manual
823145 2/01
8DL & 8RDO Series Drills
Gear Train Designation:
3
7928
40 50
14
Offset (Pistol)
Inline
O
Handle:
L(Lever)
8
Rotation:
Reversible
Non Reversible
R
Drill:
8
Series:
XDX X- XX
Concept
Second
B
Generation:
- XX
Drill Chuck:
(3/8-24B) 1/4 Hex Quick Change
3/8 Capacity51
1/4 HD Capacity
1/4 Capacity
3/8 HD Capacity
42
43
38
21 (3/8-24B)
(3/8-24B)
(3/8-24B)
(3/8-24B)
40 No Chuck (3/8-24B)
NORTH AMERICA EUROPE
CooperTools
P.O. Box 1410
Lexington, SC 29071
Cooper PowerTools GmbH & Co.
Postfach 30
D-73461 Westhausen

2
For your safety and the safety of others, read and under-
stand the safety recommendations and operating instruc-
tions before operating a drill.
Always wear protective equipment:
For additional information on eye protection and face
protection, refer to Federal OSHA Regulations, 29 Code
ofFederalRegulations,Section1910.133.,EyeandFace
Protection, and American National Standards Institute,
ANSIZ87.1,OccupationalandEducational Eye andFace
Protection. Z87.1 is available from the American National
Standards Institute, Inc., 11 West 42nd Street, New York,
NY 10036.
Hearing protection is recommended in high noise areas
85 dBA or greater. The operation of other tools and
equipmentinthearea,reflectivesurfaces,processnoises
and resonant structures can substantially contribute to,
and increase the noise level in the area. Excessive air
pressure above 90 PSIG or worn motor components can
also increase sound level emitted by tool. Proper hearing
conservation measures, including annual audiograms
andtrainingintheuseandfitofhearingprotectiondevices
may be necessary. For additional information on hearing
protection,refertoFederal Regulations,Section1910.95,
Occupational Noise Exposure, and American National
Standards Institute, ANSI S12.6, Hearing Protectors.
Drilling operations may produce hazardous fumes and/or
dust. To avoid adverse health effects utilize adequate
Safety Recommendations
WARNING
!
Wear respirator where
necessary.
!
Do not wear loose fitting clothes,
long hair, gloves, ties or jewelry.
WARNING
CAUTION!
Personal hearing protection is
recommended when operating
or working near this tool.
WARNING!
Impact resistant eye protection
must be worn while operating
or working near this tool.
CAUTION !
ventilationand/orweararespirator.Respiratorsshouldbe
selected, fitted, used and maintained in accordance with
Occupational Safety and Health Administration and other
applicable regulations. Read the material safety data
sheet of any cutting fluids or materials involved in the
drilling process.
Follow good ma-
chineshoppractices.
Rotating shafts and
moving components
canentangleanden-
trap, and can result
in serious injuries.
Neverwearlonghair,
loose-fitting clothes,
gloves, ties, or jew-
elry when working
with or near a drill of
any type.
Cleco drills are designed to operate on 90 psig (6.2 bar)
maximum air pressure. If the tool is properly sized and
applied,higherair pressure is unnecessary. Excessive air
pressure increases the loads and stresses on the tool
parts and may result in breakage. Installation of a filter-
regulator-lubricator in the air supply line ahead of the tool
is recommended.
Before the tool is connected to the air supply, check the
throttleforproperoperation(i.e.,throttlemovesfreelyand
returns to closed position). Being careful not to endanger
adjacent personnel, clear the air hose of accumulated
dust and moisture. Before removing a tool from service or
changing a drill bit, tap, reamer, or any accessory make
sure the air line is shut off and drained of air. This will
prevent the tool from operating if the throttle is accidently
engaged.
Suddenandhighreactiontorquemay
be experienced with any drill if:
• drill motor stalls by excessive load being applied to drill
bit or drill bit snags on material being drilled.
• on break-through when the drill bit passes through the
material being drilled. User must be prepared to resist
torque.

3
Safety Recommendations
a problem can be addressed before it becomes a debilitat-
ing injury. Any user suffering prolonged symptoms of
tingling, numbness, blanching of fingers, clumsiness or
weakened grip, nocturnal pain in the hand, or any other
disorderoftheshoulders,arms,wrists,orfingersisadvised
toconsult aphysician.If itisdetermined thatthesymptoms
are job related or aggravated by movements and postures
dictated by the job design, it may be necessary for the
employer to take steps to prevent further occurrences.
These steps might include, but are not limited to, reposi-
tioningtheworkpieceor redesigning the workstation, reas-
signing workers to other jobs, rotating jobs, changing work
pace, and/or changing the type of tool used so as to
minimize stress on the operator. Some tasks may require
more than one type of tool to obtain the optimum operator/
tool/task relationship.
Thefollowing suggestionswillhelp reduceormoderate the
effectsofrepetitiveworkmotionsand/orextendedvibration
exposure:
• Use a minimum hand grip force consistent with proper
control and safe operation
• Keep body and hands warm and dry (cold weather is
reported to be a major factor contributing to Raynaud's
Syndrome)
• Avoid anything that inhibits blood circulation
—Smoking Tobacco (another contributing
factor)
—Cold Temperatures
—Certain Drugs
• Tasks should be performed in such a manner that the
wrists are maintained in a neutral position, which is
not flexed, hyperextended, or turned side to side.
• Stressful postures should be avoided — select a tool
appropriate for the job and work location
• Avoid highly repetitive movements of hands and wrists,
and continuous vibration exposure (after each period of
operation, exercise to increase blood circulation)
• Keep tool well maintained and replace worn parts
CAUTION !
Extension Neutral Flexion Radial Deviation Neutral Ulnar Deviation
Avoid Avoid Avoid OK Avoid OK
•Drillbitsare sharp. Handle them carefully to avoidinjury.
•Cuttingtoolmaximumspeedratingmustequalorexceed
rated speed of tool.
•Drillbitsoraccessoriesnotcenteredproperlyinthechuck
can cause excessive wobble or vibration.
•Useappropriatelysizedchuckkeytosecurelytightendrill
bit,tap,orreamerindrillchuck.Alwaysremovechuckkey
before starting tool.
•Use care when drilling because of the possibility of the
cutting tool bending or breaking.
Tools equipped with chuck capacity over 1/4" should have
at least one handle offset at a right angle to drill axis to
counteracttorquedevelopedbytool.Iftoolisequippedwith
a chuck over 3/8" capacity, two handles at right angles to
thedrillaxisshouldbeused.Onehandleshouldcontainthe
tool throttle, such as pistol grip or offset handle models.
Always use a dead handle with low RPM —high torque
tools.
Some individuals may be susceptible to disorders of the
handsandarmswhenperformingtasksconsistingofhighly
repetitive motions and/or exposure to extended vibration.
Cumulative trauma disorders such as carpal tunnel syn-
drome and tendonitis can be caused or aggravated by
repetitious, forceful exertions of the hands and arms.
Vibration may contribute to a condition called Raynaud's
Syndrome. These disorders develop gradually over peri-
ods of weeks, months, and years. It is presently unknown
to what extent exposure to vibrations or repetitive motions
may contribute to the disorders. Hereditary factors,
vasculatory or circulatory problems, exposure to cold and
dampness,diet,smokingandworkpracticesarethoughtto
contribute to the conditions. Any tool operator should be
awareofthefollowing warningsignsandsymptomsso that
CAUTION !
Repetitive work motions and/or vibration
may cause injury to hands and arms.
Use minimum hand grip force consistent
with proper control and safe operation.
Keep body and hands warm and dry.
Avoid anything that inhibits blood circulation.
Avoid continuous vibration exposure.
Keep wrists straight.
WARNING
!
Avoid repeated bending of wrists and hands.

4
Warning Labels
The warning labels found on these tools are an essential
part of this product. Labels should not be removed. Labels
shouldbe checked periodically forlegibility.Replacewarn-
ing labels when missing or when the information can no
longerberead.Replacementlabelscanbeorderedasany
spare part.
Thisinformationisacompilationofgeneralsafetypractices
obtained from various sources available at the date of
production. However, our company does not represent
that every acceptable safety practice is offered herein, or
that abnormal or unusual circumstances may not warrant
or require additional procedures. Your work may require
additional specific safety procedures. Follow these proce-
duresas required byyourcompany. Formore information,
see the latest edition of ANSI B186.1, Safety Code for
Portable Air Tools, available from the American National
Standards Institute, Inc., 11 West 42nd Street, New York,
NY 10036.
Safety Recommendations
Work gloves with vibration reducing liners and wrist sup-
ports are available from some manufacturers of industrial
work gloves. Tool wraps and grips are also available from
anumber of different manufacturers.Thesegloves,wraps,
and wrist supports are designed to reduce and moderate
the effects of extended vibration exposure and repetitive
wrist trauma. Since they vary widely in design, material,
thickness, vibration reduction, and wrist support qualities,
itisrecommendedthattheglove,toolwrap,orwristsupport
manufacturer be consulted for items designed for your
specific application. WARNING! Proper fit of gloves is
important. Improperly fitted gloves may restrict blood
flow to the fingers and can substantially reduce grip
strength.
203185-4
READ
OPERATING
INSTRUCTIONS
OVER
CAUTION!
Personal hearing protection is recommended when operating or working near this tool.
WARNING!
Impact resistant eye protection must be worn while operating or working near this tool.
Read Operating Instructions carefully. Follow the Safety Recommendations for your safety and the safety of others. Hearing protection is recommended in high noise areas (above 85 dBA). Close proximity of other tools, reflective surfaces, process noises, and resonant structures can substantially contribute to the sound level experienced by the user.
WARNING
!
Repetitive work motions and/or vibration can cause injury to hands and arms. Use minimum hand grip force consistent with proper control and safe operation. Keep body and hands warm and dry. Avoid anything that inhibits blood circulation. Avoid continuous vibration exposure. Keep wrists straight.
Avoid repeated bending of wrists and hands.
Do not remove this tag until the operator of this tool has read these safety precautions.
203287
203185

5
OPERATION
TheNo.8Seriesdrillsaredesignedtooperateon90psigair
pressure. They should be connected to a 1/4" hose up to 8'
inlength.Ifadditionallengthisrequired,a3/8"orlargerhose
should be connected to the 1/4" hose.
Pistolgripdrillsarestartedbypullingthetriggerandstopped
by releasing the trigger. Lever operated drills start by de-
pressing the lever and stop by releasing it.
LUBRICATION
An automatic in-line filter-lubricator is recommended as it
increasestoollifeandkeepsthetoolinsustainedoperation.
Thein-linelubricatorshouldbe regularly checked and filled
withagoodgradeof10Wmachineoil.Properadjustmentof
thein-linelubricatorisperformedbyplacingasheetofpaper
next to the exhaust ports and holding the throttle open
approximately 30 seconds. The lubricator is properly set
when a light stain of oil collects on the paper. Excessive
amounts of oil should be avoided.
In the event that it becomes necessary to store the tool for
an extended period of time (overnight, weekend, etc.), it
shouldreceivea generousamountof lubricationatthattime
and again when returned to service. The tool should be
stored in a clean and dry environment.
Application of the tool should govern how frequently it is
greased. It is recommended that the idler gears, gear pins
and bearings receive a generous amount of NLGI 2-EP
grease.Greaseisappliedbyunscrewing(lefthandthreads)
thespindle bearingretainer,No. 202031,andremoving the
gear train from the front of the gear case.
FOR YOUR SAFETY AND THE SAFETY OF OTHERS READ AND UNDERSTAND THE SAFETY
RECOMMENDATIONS ON PAGES 2 thru 4 BEFORE OPERATING A DRILL.
OPERATING INSTRUCTIONS

6
SERVICE INSTRUCTIONS — DISASSEMBLY
MOTOR DISASSEMBLY
Slip the front bearing plate and bearing off the front of the
rotor and remove the cylinder and four (4) rotor blades. Set
therearbearingplateonthevisejawswiththerotorhanging
down.Usea7/32"punchtodrivetherotoroutoftherearrotor
bearing.
DL BLACKHEAD DISASSEMBLY
Forinspection or replacementof the throttle valveseal, No.
847426, unscrew and remove the throttle valve cap, No.
832207.
Unscrew the air inlet bushing, No. 867882, for inspection
and cleaning of the air inlet screen, No. 833300, and the
muffler,No.869510.Ifeitherthescreenormufflerisclogged
or torn, it should be replaced.
RDO HANDLE DISASSEMBLY
Forinspectionorreplacementofthethrottlevalve,unscrew
the air inlet bushing, No. 867916. The air inlet screen, No.
412775, should also be inspected at this time. Replace the
screen if clogged or torn.
Themuffler, No. 869200,may be removed forcleaning and
inspection by removing the muffler screen retainer, No.
847033.
DISASSEMBLY - GENERAL - ALL MODELS
Non-Reversible Models
Insertahexwrenchintothedrillchuckandtightenthechuck
securely. Use a suitable hammer to strike the hex wrench
sharply in a counterclockwise direction when facing the
chuck. Remove the drill chuck from the spindle. Unscrew
and remove the gear case. The motor unit may now be
removed from the front of the handle. See the following
paragraphs for complete disassembly instructions on the
various subassemblies.
Reversible Models
Presstheadjustmentsleeveoffthechuck and drive the roll
pinoutofthechuckandspindle.Unscrew(lefthandthreads)
thespindlebearingretainerandremovethespindleassem-
blyfromthefrontofthegearcase.Clampthespindleinavise
and unscrew the chuck. The spindle may now be pressed
out of the spindle bearings.
Unscrewandremovethegearcase.Themotorunitmaynow
be removed from the front of the backhead. See the follow-
ingparagraphsforcompletedisassemblyinstructionsonthe
various subassemblies.
GEAR TRAIN DISASSEMBLY
Unscrew (left hand threads) the spindle bearing retainer
202031.Thespindlemaynowbepressedoutofthespindle
bearings.
Ifreplacementoftheidlergearpinsisnecessary,theoldpins
should be pressed out the rear and the replacement pins
pressed in as shown in the following diagrams.
SINGLE REDUCTION MODEL
DOUBLE REDUCTION MODEL
.240
(6.10mm)
.255
(6.48mm)
Front Rear
.360
(9.14mm)
.375
(9.53mm)
Front Rear
.240
(6.10mm)
.255
(6.48mm)
Front Rear

7
SERVICE INSTRUCTIONS — REASSEMBLY
REASSEMBLY—GENERAL
All parts should be washed in a solvent and inspected for
damage or wear. Particular attention should be given to all
bearings, gears, gear pins, and rotor blades as failure of
these parts could cause damage to more expensive parts.
Particular attention should be paid to the governor assem-
bly, replacing any of its' parts that show wear or damage. It
is recommended that new rotor blades be installed at each
repaircycle. Ifnot replaced,the usedones mustmeasurea
minimum of 3/16" (4.7mm) at both ends. Failure of these
partscouldcausedamagetomoreexpensivecomponents.
All gears, gear pins, and open bearings should receive a
generousamountofNLGI2-EPgreaseduringreassembly.
Reassembly of all of the various subassemblies is in the
reverse order of disassembly; however, the following para-
graphs list some of the more important reassembly proce-
dures.
GEAR CASE REASSEMBLY
Thefrontspindlebearing,No.202032, mustbe installedon
the spindle with its sealed side out (visible after assembly).
MOTOR REASSEMBLY
Install the rear rotor bearing, No. 847609, into the rear
bearing plate. Press the bearing plate assembly (press on
thebearing's inner race) onto the rear rotor shaft untilthere
is approximately .0015" (.038mm) clearance between the
rear bearing plate and rotor. Install the cylinder with the
slotted end toward the front bearing plate.
REASSEMBLY—COMPLETE TOOL
Installthe motorblock, No.867857,into thehandle withthe
smaller notch lined up with the cylinder pin hole.
Lineuptherearcylinderpinwiththenotchinthemotorblock
and install the motor unit and spacer. Screw the gear case
into the handle at this time.
NOTE:Thegeartrainmayhavetoberotatedtoengagethe
rotor pinion.
Puta few dropsof 10W machine oilinto the tool's airinlet to
insureimmediatelubricationofallmotorpartswhenthetool
is tested.
.0015" (.038mm)
Clearance
Must be replaced if less than
3/16" (4.7mm) on either end.

8
PART NO.
202031
202032
202033
202034
202035
202037
202038
202261
202263
202312
832128
842728
843635
846177
865576
865862
867866
867871
867902
867903
NAME OF PART
Bearing Retainer
Spindle Bearing (Front)
-28 Spindle - Incl. 867922
-40 Spindle - Incl. 867922
-50 Spindle - Incl. 867922
-3 & -7 Spindle
-9 & -14 Spindle - Incl. 832128
-3 Spider (15T) - Incl. 884125
-3 Gear Case (45T)
Bearing Spacer
Gear Pin
Gear Pin
Spindle Bearing (Rear)
Gear Bushing
Thrust Washer
-50 Pinion (12T)
-28 Idler Gear (18T) - Incl. 867921
-28, -40, & -50 Gear Case (42T)
-3 & -14 Pinion (15T)
-3 Idler Gear (15T) - Incl. 867925
(-14 Require 3 Only)
PART NO.
867904
867905
867907
867921
867922
867925
869181
869254
869255
869256
869258
869259
869552
869554
869584
869640
884125
NAME OF PART
-9 & -14 Idler Gear (15T)
-3 & -14 1st Red. Spider (15T) - Incl. 884125
-7, -9, & -14 Gear Case (45T)
Gear Bearing
Gear Pin
-3 Gear Bushing (-14 Require 3 Only)
-40 Idler Gear (16T) - Incl. 867921
-7 Idler Gear (19T) - Incl. 867921
-3 & -7 Idler Gear (15T)
-7 1st Red. Spider (15T) - Incl 867922
-9 Idler Gear (17T) - Incl. 867921
-9 Spider (15T) - Incl. 867922
Chuck Spacer
-50 Idler Gear (15T)
-3, -14 & -50 Pinion Spacer
Gear Pin
-3 Gear Pin (-14 Require 3 Only)
QTY.
1
1
1
1
1
1
1
1
1
1
3
3
1
3
1
1
3
1
1
6
QTY.
3
1
1
3
3
6
3
3
3
1
3
1
1
3
1
3
6
8DL GEAR TRAINS
PARTS LIST
The complete gear train can be purchased as a sub-assembly using the part numbers below:
-3* —201020
-7 —861954
-9 —861955
*Does not include pinion spacer
-14* —861956
-28 —861957
-40 —861958
-50* —861959
O
F
F
869552
202031
202032
202312
843635
869584
(-50 Only)
O
F
F
869552
202031
202032
202312
843635
202033 -28
202034 -40
202035 -50
867907
867902
(-14 Only)
869584
(-14 Only)
867922 -28
867922 -40
867922 -50
867921 -28
867921 -40
846177 -50
867866 -28
869181 -40
869554 -50
867871 -28
867871 -40
867871 -50
None -28
None -40
865862 -50
O
F
F
869552
202031
202032
202312
843635
869255
202263
202261
884125
867925
867903
867902
869584
202037
842728
884125
867925
867903
865576 867905
869255 -7
867904 -9
867904 -14
202037 -7
202038 -9
202038 -14
842728 -7
832128 -9
832128 -14
867921 -7
867921 -9
867925 -14
869254 -7
869258 -9
867903 -14
869256 -7
869259 -9
867905 -14
867922 -7
867922 -9
884125 -14
-3 Gear Train - CAUTION: High Torque Tool - Always Use Dead Handle
-28, -40, & -50, Gear Trains
-7,-9, & -14 Gear Trains

9
PART NO.
202031
202032
202261
202263
202312
203735
203736
203737
203738
617166
832128
842728
843635
846177
865576
867866
867871
867902
867903
NAME OF PART
Bearing Retainer
Spindle Bearing (Front)
-3 Spider (15T) - Incl. 884125
-3 Gear Case (45T)
Bearing Spacer .003"
-3 & -7 Spindle (Incl. 617166)
-9 & -14 Spindle - Incl. 832128 (Incl. 617166)
-28 Spindle - Incl. 867922 (Incl. 617166)
-40 Spindle - Incl. 867922 (Incl. 617166)
Chuck Retainer Screw (Not Shown)
-9 & -14 Gear Pin
-3 & -7 Gear Pin
Spindle Bearing (Rear)
-50 Gear Bushing
-3 Thrust Washer
-28 Idler Gear (18T) - Incl. 867921
-28 & -40 Gear Case (42T)
-3 & -14 Pinion (15T)
-3 Idler Gear (15T) - Incl. 867925
(-14 Require 3 Only)
PART NO.
867904
867905
867907
867921
867922
867925
869181
869254
869255
869256
869258
869259
869552
869584
884125
NAME OF PART
-9 & -14 Idler Gear (15T)
-3 & -14 1st Red. Spider (15T) - Incl. 884125
-7, -9, & -14 Gear Case (45T)
-7, -9, -28 & -40 Gear Bearing
-7, -9, -28, -40 & -50 Gear Pin
-3 Gear Bushing (-14 Require 3 Only)
-40 Idler Gear (16T) - Incl. 867921
-7 Idler Gear (19T) - Incl. 867921
-3 & -7 Idler Gear (15T)
-7 1st Red. Spider (15T) - Incl 867922
-9 Idler Gear (17T) - Incl. 867921
-9 Spider (15T) - Incl. 867922
Chuck Spacer
-3 & -14 Pinion Spacer
-3 Gear Pin (-14 Require 3 Only)
QTY.
1
1
1
1
1
1
1
1
1
1
3
3
1
3
1
3
1
1
6
QTY.
3
1
1
3
3
6
3
3
3
1
3
1
1
1
6
8RDO GEAR TRAINS
PARTS LIST
The complete gear train can be purchased as a sub-assembly using the part numbers below:
-3* —201494
-7 —201495
-9 —201496
*Does not include pinion spacer
-14* —201497
-28 —201498
-40 —201499
-28 & -40 Gear Trains
O
F
F
869552
202031
202032
202312
843635
O
F
F
869552
202031
202032
202312
843635
202033 -28
202034 -40
867907
867902
(-14 Only)
869584
(-14 Only)
867922 -28
867922 -40
867921 -28
867921 -40
867866 -28
869181 -40
867871 -28
867871 -40
O
F
F
869552
202031
202032
202312
843635
869255
202263
202261
884125
867925
867903
867902
869584
202037
842728
884125
867925
867903
865576 867905
869255 -7
867904 -9
867904 -14
202037 -7
202038 -9
202038 -14
842728 -7
832128 -9
832128 -14
867921 -7
867921 -9
867925 -14
869254 -7
869258 -9
867903 -14
869256 -7
869259 -9
867905 -14
867922 -7
867922 -9
884125 -14
-3 Gear Train - CAUTION: High Torque Tool - Always Use Dead Handle
-7,-9, & -14 Gear Trains
Chuck Retainer Screw
617166 included in
Spindle on Reversible
Models

10
NAME OF PART
Spacer
Rotor (6T)
Cylinder
Rear Bearing Plate
Bearing Plate
Spacer
Rotor (9T)
Spacer
PART NO.
812167
833718
844234
847095
847609
863738
867853
867854
867855
NAME OF PART
Rear Cylinder Pin
Rear Cyiinder Pin
Front Cylinder Pin
Rotor Bearing
Rotor Bearing (-9 & -40 require one (1 ) only)
Rotor Blade
Cylinder
Rear Bearing Plate
Front Bearing Plate
QTY.
1
1
1
1
2
4
1
1
1
PART NO.
867873
867880
867936
867937
869179
869180
869183
869584
QTY.
1
1
1
1
1
1
1
1
REAR BEARING PLATE
Non-Rev. 867854
Rev. 867937
847609
CYLINDER
Type Part No.
Non-Rev. 867853
Rev. 867936
863738
844234
847603
Pistol Models
Only
SPACER
Model Part No.
-9 869180
-40
-3 867873
-7
-14
-28
-50
FRONT
BEARING PLATE
Model Part No.
-9 869179
-40
-3 869179
-7
-14
-28
-50
FRONT BEARING
Model Part No.
-9 847095
-40
-3 847609
-7
-14
-28
-50
ROTOR
Model Part No.
-9 869183
-40
-3 867880
-7
-14
-28
-50
REAR CYLINDER PIN
Non-Rev. Lever 833718
Rev. Offset 812167

11
Valve Block
Exhaust Deflector
Throttle Lever
Inlet Bushing (incl. 833300)
Throttle Valve
Backhead
Muffler
PART NO.
202410
412603
832207
832636
833300
844060
847426
863454
865728
NAME OF PART
Throttle Lever Pin
Bail
Throttle Valve Cap
Throttle Valve Cap Gasket
Inlet Screen
Throttle Valve Spring (incl. 847426)
Throttle Valve Seal
"O"-Ring 9/16" x 11/16"
Inlet Screen Spring
QTY.
1
1
1
1
1
1
1
1
1
QTY.
1
1
1
1
1
1
1
PART NO. NAME OF PART
867857*
867874
867877
867882
869036
869044
869510
The complete handles can be purchased as a subassembly using Part No. - 861628.
*Parts not included in subassembly.
863454
833300
865728 867882
867857 869044
412603
869510
867874
202410
867877
844060
832636
832207
869036
847426

12
201905
202020
202339
202674
412775
833303
847033
847411
847767
844787
865770
867878
867911
867915
867916
869200
869253
869350
Trigger Assembly
Drive Screw
-3 Caution Label
Non-Locking Reversing Valve
Air Inlet Screen
Muffler Screen
Muffler Screen Retainer
O-Ring 11/16" X 13/16"
Throttle Valve Spring
Trigger Pin
Reversing Valve Spring
Reversing Valve Retainer Screw
Throttle Link Pin
Reversible Handle
Air Inlet Bushing
Muffler
Locking Reversing Valve
Throttle Valve
1
4
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Part No. Name of Part Qty. Part No. Name of Part Qty.
The complete Offset handle can be purchased as a subassembly using part no. 861581.
The handle includes non-locking reversing valve 202674.
844787
867911
847033
833303869200 869350 412775
847767
847272
847411 867916
867915
202339 202020
869253 Locking
202674 Non-locking
865770
867878
201905

13
MODELS
8RDO-3
8RDO-7
8RDO-9
8RDO-14
8RDO-28
8RDO-40
8DL-7B
8DL-9B
8DL-14B
8DL-28B
8DL-40B
8DL-50B
STANDARD EQUIPMENT
43 - 3/8" CHUCK 849103
CHUCK KEY 849123
51 - 3/8" CHUCK (Small Diameter) 849108
CHUCK KEY 849120
38 - 1/4" CHUCK 849102
CHUCK KEY 849116
OPTIONAL EQUIPMENT
ANY CHUCK AND RESPECTIVE KEY LISTED
21 - 1/4" HEX QUICK-CHANGE CHUCK 849414
SUPPORT HANDLE 861006
42 - 1/4" CHUCK (Heavy Duty) 849106
CHUCK KEY 849118
51 - 3/8" CHUCK (Small Diameter)* 849108
CHUCK KEY 849120
43 - 3/8" CHUCK* 849103
CHUCK KEY 849123
SUPPORT HANDLE 861006
21 - 1/4" HEX QUICK CHANGE CHUCK 849414
*STRAIGHTHANDLE DRILLSMUST BEEQUIPPED
WITHDEADHANDLE(861006),IFCHUCKSLARGER
THAN 1/4" ARE SPECIFIED.
DO NOT USE CHUCKS LARGER THAN 3/8" ON
THESE DRILLS.

14
NOTES

15
NOTES

16
CooperTools
670 Industrial Drive
Lexington, SC 29072
Phone: [phone]
Fax: [phone]
www.cooperindustries.com
