Click CAC-75W User manual

General Safety 4
Remote Control 8
Product Overview 9
How to Use 10
Cleaning and Maintenance 13
Cleaning water tank and top water inlet 13
Changing the honeycomb filter pads 14
Troubleshooting Last page
Specifications Last page
Customer Helpline Last Page
CONTENTS

4
GENERAL SAFETY
Please follow instruction when installing this product in accordance with the instruction
manual. This product must be positioned in a suciently stable location, it can be potentially
hazardous due to falling when mounted and can cause injury, particularly to children if it
positioned incorrectly.
• Before installing this product, make sure your outlet voltage corresponds to the voltage
stated on the power supply rating label.
• Do not use a damaged power cord, plug or loose outlet. Doing so may cause an
electric shock.
• Do not plug several devices into the same outlet. Doing so may cause the outlet to
overheat and start a fire. Make sure the outlet is readily accessible during operation
of the equipment.
• Do not bend, twist or kink the power cord excessively.
• Do not allow anything to rest on or roll over the power cord.
Doing so may cause a fire or an electric shock.
• Do not run the power cord near heat-producing appliances such as radiators, stoves or
irons. The excessive heat could melt the insulation and expose live wires, resulting in
fire or electric shock.
• Do not expose the product to water. The electrical insulation could be damaged
and cause electrocution. Do not touch the unit when barefoot or parts of your body are
wet or damp.
• This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a hazard.
• Do not cover the ventilation openings of the product with items such as newspapers,
tablecloths, curtains etc or insert objects into the slots available on the products.
As this could result in the product temperature rising and could cause a fire.
Read this manual thoroughly before you start using the product.
Store this manual, the completed warranty card, your receipt and the product packaging.
The safety precautions instructions reduces the risk of fire, electric shock and injury when
correctly complied to.
Please follow all instructions and take notice of all warnings.

5
GENERAL SAFETY INSTRUCTIONS (Cont.)
• If you notice any unusual odors or smoke around the unit, immediately disconnect the
unit from the outlet and contact the service center. Failure to do so may result in fire
or electric shock.
• When not using the unit for long periods of time or when you are moving the unit
please ensure to disconnect the power supply from the wall socket.
• Please beware that Dust could accumulate over time on the unit and cause it to generate
heat and or deteriorate insulation, which in turn may result in an electrical fire.
• Batteries from the remote control must be only removed by an adult, the adult must
ensure to keep them out of reach of infants and children. Seek medical attention
immediately if a child has swallowed a battery.
• To maintain the product do not use any chemical or cleaning agent or wet cloth, please
only ensure to utilize a dry cloth to wipe it down from marks or dust and only after
unplugging the product from the power socket.
• Do not direct airflow directly onto plants or animals, as long exposure can aect them.
• Please ensure to contact our call center for any repair or service required for the products
not doing so will make warranty on your product void.
• We assume not liability for any eventual damages to property or injury to persons caused
by misuse of the product or noncompliance with these instructions.
Please make sure upon positioning this product, the place is:
• Not wet or damp and Well ventilated
• Away from direct sunlight or heaters.
• Away from splashes or food.
• Protected from excessive dust or grease.
• Do not place small metallic objects on top of the unit or block the openings as it will
reduce operating eciency of the air con with failures or damages.

6
GENERAL SAFETY INSTRUCTIONS (Cont.)
• This appliance is intended for air conditioning indoor domestic environments. It is not
suitable for commercial, industrial or trade use. Do not use it for any other purpose
(such as drying clothes, cooling food, etc.), and only use it as described in this manual.
• Do not use the unit outdoors. It is for indoor use only.
• Do not insert any objects, or your fingers, into the air outlet, and make sure to warn
children of the dangers. Keep ventilation openings clear of obstructions.
• Supervise children to ensure they do not play with the appliance. Close supervision is
necessary when any appliance is used by or near children. Cleaning and user maintenance
shall not be made by children without supervision.
DO NOT INSTALL/USE THE APPLIANCE IN THE FOLLOWING AREAS:
- outdoors or where water is likely to splash
- near a bath, shower, laundry basin or swimming pool
- in an area where oil is likely to splash
- near a hot gas or electric burner, or sources of fire
- near sources of heat, or exposed to direct sunlight
- in an area where furniture or other objects can obstruct the airflow
- in the presence of flammable substances or vapour such as alcohol, insecticides,
petrol, etc.
- at a dry cleaner’s premises.

7
GENERAL SAFETY INSTRUCTIONS (Cont.)
WARNING:
• Do not expose the appliance to high heat, sparks and open flames.
• Do not pierce or burn the appliance.
• Maintenance must only be carried out by properly qualified, authorised personnel.
If the appliance requires maintenance or service, contact our after sales support
centre [e-mail]

8
REMOTE CONTROL
Using the Remote Control
• Do not mix old and new batteries in the remote
• Do not use dierent types of battery
• If you do not intend to use the unit for a long time, please remove batteries from the
remote to avoid accident.
• Keep batteries away from children and pets.
• Never throw batteries into a fire.
• Do not drop, or impact the remote control as it void warranty immediately.
• The remote control operate at a range of 5 to 6M eectively
• Do not expose the remote control sensor to a bright light.
INSTALLING BATTERIES
1. Open the battery box on the back of remote control, and install
2 x AAA batteries (included).
2. Make sure to match the battery polarities ( + / - ) with the remote
control compartment.
3. Put on the back cover.
SPEEDS
POWER ON/OFF
SWING/
OSCILLATION
ANION ON/OFF
MODE
TIMER
LED DISPLAY ON/OFF
COOL/HUMIDIFY

9
PRODUCT OVERVIEW

10
HOW TO USE
POWER ON/OFF - After connecting the power cord the air cooler is in standby
mode and the display will indicate the current room temperature and will
gradually change as the room temperature changes. Press the ON/OFF button to
turn the air cooler on or o.
SPEED - Press the SPEED button to cycle through the fan speeds. The current
selected fan speed will be illuminated on the display: Low, Medium or High.
The set speed will flash several times and then the display will return to indicate
the current room temperature and will gradually change as the room
temperature changes.
MODE - Press the MODE button change between the three airflow styles:
Standard Wind The fan will blow at maximum speed.
Natural Wind The fan speed will fluctuate to imitate natural wind.
Sleep Wind The fan speed will decrease by 1 level per half hour and
then continue to run at low speed.
LIGHT - Press to turn OFF the LED Display
TIMER - Press the TIMER button to activate timer, the time can be set from 1 to 12
hours. LED screen will display the corresponding set time. The air cooler will stop
automatically after the set time has expired.
SWING/OSCILLATION - Press the SWING button to turn to oscillaiton function of
the air outetlet ON/OFF.
The SWING indicator will be displayed on the screen when activated.
The vertical direction of the air flow can be manually adjusted.
Please open the horizontal loubers manually before operating the
unit in order to avoid damaging the unit motor.

11
HOW TO USE (Cont.)
ANION
Press this button to activate the ionizer. Press the button again to turn o.
When activated the Anion button will illuminate on the display.
This function is used to purify the room air while also
blowing air.
Creating negative ions using electricity and then
discharges them into the air. These negative ions attach
to positively charged partcles in the room, such as dust,
bacteria, pollen, smoke and other allergens.
This then bonds the ions together to create dense dirt
particles that cannot float in the air.
COOL
Press the COOL button to turn on your humidifying function and cool the air.
3. Press Again to Turn OFF.
4. When the COOL function is turned OFF, the Air Cooler will operate as a
fan and the water will not be used to cool the air.
1. Before you activate this mode, MAKE SURE the water level is at the “MIN”
level or above. NO WATER in the tank may damage the unit.
REFER TO PAGE 9 - WATER TANK (7).
2. The 2x Ice Packs should be placed in freezer and frozen before placing
into top of the Air Cooler.
You can do this by raising the top lid and placing the 2x ice packs as to below.

12
HOW TO USE (Cont.)
LOW WATER ALARM - The unit is equipped with a Low Water Alarm sensor. In
Cooling Mode, when water in the tank is below the minimum level, you will hear
a beeping sound and the indicator light will flash continuously. The unit will auto-
matically pause evaporative cooling.
Refill the water tank to deactivate the alarm in cool mode. First switch OFF the
unit and unplug from the power outlet. Fill the water tank with water above the
minimum water level mark. Plug in and switch ON again.
To deactivate the alarm and continue using the unit as a fan (without evaporative
cooling), switch the unit OFF and then ON again. The Low Water Alarm will not
act ivate in Fan only mode. The Low Water Alarm will sound again if the COOL
function is activated while the water tank is still empty.

13
b. Pull the water tank out from the cooler and put the unloaded water
pump in a small dish to avoid water dropping on the ground.
c. Clean the water tank with a soft brush or cloth.
Note: Do not use gasoline, thinners, solvents, ammonias or other
chemicals for cleaning and maintenance.
4. Clean the water filter under running water and soft brush if needed.(fig.4)
5. Drain all water in the water tank after cleaning.
6. Put the water pump inside the water tank. Install the water pump to
the pump platform.
7. Hold the water tank lock tab and push the water tank back to the cooler
until the lock tab clicks into the cooler properly.
CLEANING & MAINTENANCE
Cleaning Water Tank and Top water Inlet
1. Before undergoing maintenance, please disconnect the power cord
plug out the power source.
2. Add water into the water tank via top water inlet.
3. When all the water in the top water inlet drain into the water tank,
remove the water tank as per the procedures below:
a. Detach the water pump sit inside the water tank by pressing the
2 bracket hook inwards (fig. 1) to release it from the pump
platform (fig.2).

14
CLEANING & MAINTENANCE (Cont.)
Changing the Honeycomb Filter Pads
The appliance is supplied with Honeycomb cooling / filters pads.
The cleaning frequency for the Honeycomb filter depends on local air and
water conditions. In areas where the mineral content of water is high
(hard water), mineral deposits may build up on the honeycomb cooling
filter and restrict air flow. If mineral deposits remain on the Honeycomb
pads, the filter should be removed and washed under fresh water. For a
deeper clean a mild detergent should be used with a soft brush. Once
cleaned the filter should be rinsed in clean water before leaving to dry.
We recommend cleaning the honeycomb filter at least every two months,
depending on your needs. For best resul ts, allow the honeycomb filter to
dry after each use by turning o the COOL function and running the unit as
a fan for 15 minutes before turning the unit o.

15

16
TROUBLSHOOTING
If you experience problems with your product, or it appears
not to be operating correctly, check the information below for solutions
to common problems. If none of the solutions oered help you solve
your problem, please contact our support centre for advice on
[e-mail] Do not attempt to repair the appliance yourself!
SPECIFICATIONS
Rating 220-240V ~ 50-60Hz
Power POWER 75W
Weights
NET 6.4 kg
GROSS 7.7 kg
Dimensions 260 (W) × 300 (D) × 700 (H) mm
