Click CPAC1609-H User manual

Model: CPAC-H
PORTABLE
AIR CONDITIONER
INSTRUCTION MANUAL
2.64KW COOLING POWER
2.05KW HEATING POWER

2
IMPORTANT
SAFEGUARDS
When using electrical appliances, in
order to reduce the risk of fire, electric
shock and/or injury, these basic safety
precautions should always be followed:
FOR YOUR SAFETY
Read all instructions carefully, even if you are
familiar with the appliance.
• To prevent fire or shock hazard, do not expose
this appliance to rain or moisture. The appliance
should not be installed in laundry or wet rooms.
• Dangerous high voltages are present inside
this enclosure. To avoid electric shock, do not
open the cabinet. Refer servicing to qualified
personnel only.
• This appliance is intended for indoor use only
and not for commercial, industrial or outdoor
use. Other use not recommended may cause
fire, electric shock or injury.
• To protect against fire, electrical shock and
injury to persons, do not immerse the unit,
plug or cord in water or spray it with liquids.
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory and mental capabilities, or
lack of experience and knowledge, unless they
have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety.
• Children should be supervised to ensure that
they do not play with the appliance.
• Switch o and remove the plug from the power
outlet before cleaning or when not in use. To
unplug, grasp the plug and pull from the power
outlet. Never pull cord.
• Do not operate any appliance with a damaged
power cord or plug, after the appliance
malfunctions, or is dropped or damaged in any
manner.
• Do not use any appliance for anything other
than its intended use. This product is intended
for household use only.
• This appliance is intended to be plugged in or
connected to a -V~ Hz grounded
power outlet only.
• Be sure the air conditioner is properly grounded.
To minimize shock and fire hazards, proper
grounding is important.
• Do not misuse the power cord. Never carry
the appliance by the power cord or pull to
disconnect it from the outlet. Instead, grasp the
plug and pull to disconnect.
• Do not attempt to repair, disassemble or modify
the appliance. There are no user serviceable
parts.
• Arrange the power cord away from trac areas
where it will not be tripped over.
• Do not cover or obstruct the appliance inlet or
outlet when in use.
• Do not insert or allow foreign objects to enter
the air inlet/outlet or openings as this may
cause damage to the appliance and/or injury to
the user.
• Do not plug this appliance into or use with
Extension cords, Double adaptors or Power
Boards. It should only ever be plugged directly
into Domestic Power outlet.
• Be sure the air conditioner has been securely
and correctly installed according to the separate
installation instructions provided with this
manual. Save this manual and the installation
instructions for possible future use in removing
or reinstalling this unit.
• Always install the filter securely and clean it
regularly. Operating the unit without filters will
cause it to fail.
• Do not drink water drained from the air
conditioner, use it to feed animals, nor to water
plants. Empty the water tank and pour the water
down the drain.
• Do not run air conditioner with outside
protective cover in place. This could result in
mechanical damage within the air conditioner.
• Do not modify or use an extension cord. Do
not use a loose or damaged socket. Do not use
an adapter plug. Do not disassemble or modify
the product. The heat generated will cause an
electric shock, fire or product failure.
• Be cautious when unpacking and installing as
sharp edges may cause injury.
• Do not store flammables like gasoline, benzene,
thinner etc. near the air conditioner. If a gas leak
occurs, ventilate the room well before operating
the unit. Doing so may cause an explosion or
fire.

3
• Do not place heavy objects on top of the power
cord, or bend or pinch the cord. Do not place
the power cord near a heater. Do not allow
water to run into the electric parts.
• Do not sit or stand on the unit and do not place
anything on the top of it.
• Unplug the unit if strange sounds, odors, or
smoke came from it. Failure to follow this
warning may results in electric shock and fire.
• Unplug the unit when it will not be used for a
long time to prevent accidental startup and the
possibility of injury.
• The air conditioner must be used, stored and
transported in an upright position, otherwise
the compressor could be damaged.
• Leave the unit in an upright position for at least
 hours before use to allow the compressor
contents to settle.
• This product has not been designed for any uses
other than those specified in this booklet.
WARNING:
• Appliance is filled with flammable gas R.
• Do not pierce or burn.
• Be aware that refrigerants may not contain an
odour.
• The appliance should stay away from gasoline,
flammable gas, stoves and other heat sources.
• Spaces where refrigerant pipes shall be
compliance with national gas regulations.
• Keep any required ventilation openings clear of
obstruction.
• Don’t disassemble, overhaul and modify the
machine arbitrarily, otherwise, it will cause a
machine malfunction or even bring harm to
persons and properties. Do not use insecticide
sprays or other flammable substances near the
air conditioning.
• All working procedure that aects safety means
shall only be carried by competent persons.
Transport of equipment containing flammable
refrigerants Compliance with the transport
regulations.
• Marking of equipment using signs Compliance
with local regulations.
• Disposal of equipment using flammable
refrigerants Compliance with national
regulations.
• Any person who is involved with working
on or breaking into a refrigerant circuit
should hold a current valid certificate from
an industry-accredited assessment authority,
which authorizes their competence to handle
refrigerants safely in accordance with an
industry recognized assessment specification.
• Servicing shall be performed only as
recommended by the manufacturer.
• Do not use means to accelerate the defrosting
process or to clean, other than those
recommended by the manufacturer.
• Maintenance and repair requiring the assistance
of other skilled personnel shall be carried out
under the supervision of the person competent
in the use of flammable refrigerants.
• If the supply power cord is damaged, the power
cord must be replaced by the manufacturer, its
service agent or similarly qualified persons in
order to avoid a hazard.
• The air conditioner should only be plugged in
directly to a domestic power outlet. Do not plug
into power boards, double adapters with other
appliances or extension leads.
Do not use your Air Conditioner under
the following conditions:
• If the power cord is frayed or damaged.
• In areas where children maybe left unattended
or unsupervised.
• On a slope or uneven surface.
• Close to a heat source.
• In areas where there is a risk of water/liquids
falling on/or entering the unit.
• In areas where appliance will be exposed to
outdoor weather conditions.
• In a permanent, very humid environment.
• Always from power outlets where extension
lead is needed to reach the unit.
• Where it may be damaged by chemicals.
• Where there is a risk of interference by foreign
objects.

4
Storage of equipment/appliances:
• The storage of equipment should be in
accordance with the manufacturer’s instructions.
• Appliance shall be installed, operated and stored
in a room with a floor area larger than m.
• The appliance shall be stored so as to prevent
mechanical damage from occurring.
• The appliance shall be stored in an area where
the room size corresponds to the room area as
specified for operation.
• The appliance shall be stored in a room without
continuously operating ignition sources (for
example: open flames, an operating gas appliance
or an operating electric heater.)
• Storage of packed (unsold) equipment Storage
package protection should be constructed
such that mechanical damage to the equipment
inside the package will not cause a leak of the
refrigerant charge.
• The maximum number of pieces of equipment
permitted to be stored together will be
determined by local regulations.
Caution, risk of re
The RCM Mark (Regulatory Compliance
Mark) indicates that the product
complies with the relevant guidelines
of the ACMA as well as corresponding
government requirements for the
safety of electrical devices.
SAVE THESE
INSTRUCTIONS
GETTING TO
KNOW YOUR AIR
CONDITIONER
Congratulations on the purchase of your new
Portable Air Conditioner.
Before the first use of your new appliance, it is most
important that you read and follow the instructions
in this Use & Care booklet, even if you feel you
are quite familiar with this type of appliance. Find
a place and keep this booklet handy for future
reference. Attention is particularly drawn to the
section dealing with “IMPORTANT SAFEGUARDS”.
This appliance has been designed to operate from
a standard outlet. It is not intended for industrial or
commercial use.
Carefully unpack the appliance and remove all
packing materials.
WARNING: The air conditioner is heavy! Use two or
more people to lift and install the unit. Failure to do
so could result in injuries.
Hints for Economical Operation
• Do not cover or block the inlet or outlet of air
flow inside with blinds, curtains or furniture.
• The size of the room must fit the capacity of
the Air Conditioner for ecient and satisfactory
operation.
• Position and vent the Air Conditioner near
windows and walls that receive the most shade
during the heat of the day.
• Close the fireplace damper, floor and wall
registers so cool air does not escape up the
chimney and into the duct work.
• Keep blinds and drapes in other windows closed
during the sunniest part of the day.
• Proper insulation in your home will help keep
warm air out and cool air in.
• External house shading with trees, plants or
awnings will help reduce the air conditioner’s
workload.
• Keep the air filter clean. A clogged air filter
reduces cooling eciency and should be
cleaned once every two weeks, depending on
usage.
• Avoid opening doors and windows more often
than necessary.

5
• When cooling, close the curtains. This will
prevent counteracting cooling eect in
summers.
• Use the timer eectively. Set the timer for the
desired operating time.
• To protect the unit, we recommend not
using the cooling function when the ambient
temperature is higher than 35°C.
• Try to create a uniform circulation of room air.
Adjust air flow direction for even circulation of
room air.
• To ensure optimal eciency of the product,
keep doors and windows closed when it is
used as an air conditioner or dehumidifier. If
the product is being used with the fan function
only, an open window could improve air
circulation.
NOTE: For optimum performance, operate
the unit under the usable operating
temperature and humidity conditions
indicated in this owner’s manual. If the
unit operates beyond these conditions,
it may cause malfunctions of the unit or
condensation to drip from the unit.
PERFORMANCE
PARAMETERS
Model CPAC1609-H
Power AC 220-240V
~ 50Hz
Rated cooling capacity(W) 9000BTU
(2.64KW)
Rated heating capacity (W) 7000BTU
(2.05KW)
Rated input power(W) Cool 1010W
Heat 810W
Refrigerant/Charge R290/195g
Air flow volume(m³/h) 350
Max. Dehumidifying capacity
(L/h)
1.75
Waterproof class IP20
Protection class Class I
Climate type T
Working temperature 7-35°C
Note: As a result of continual
improvements, the design and
specifications of the product within may
dier slightly to the unit illustrated on the
packaging.
NOTICE:
1. The indicated noise parameter is measured in
laboratories before leaving factory.
2. The rated cooling capacity is tested under the
following conditions:
Cooling
operation 35°C(DB) 24°C(WB)
The rated heating capacity is tested under the
following conditions:
Heating
operation 20°C(DB) 12°C(WB)
3. We will not make formal notice for any
change in parameters. Please take the name
plate attached to the air conditioner as major
reference.
4. Operating temperature range:
Maximum
cooling
Minimum
cooling
DB/WB (°C) 35/24 21/15
5. Wiring diagram of the air conditioner is attached
on the unit.
6. If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a
hazard.
7. The air conditioner must be operated within the
temperature range indicated below:
Mode Room temperature
Cool 17-35°C
Dehumidifying 7-35°C
