Tranquility®console
(Trc) Series
Submittal Data
Models TRC 09 - 018
50Hz - HFC-410A
English Language/S-I Units
Revised: 14 November, 2011
Submittal Data - S-i unitS
Unit Designation:
Job Name:
Architect:
Engineer:
Contractor:
Performance Data
Cooling Capacity: kW
EER:
Heating Capacity: kW
COP:
Ambient Air Temp: °C
Entering Water Temp (Clg): °C
Entering Air Temp (Clg): °C
Entering Water Temp (Htg): °C
Entering Air Temp (Htg): °C
Airflow: l/s
Fan Speed or Motor/RPM/Turns:
Operating Weight: (kg)
electrical Data
Power Supply: Volts Phase Hz
Minimum Circuit Ampacity:
Maximum Overcurrent Protection:

ClimateMaster works continually to improve its products. As a result, the design and specications of each product at the time of order may be changed without notice and may not be as described herein. Please contact ClimateMaster's
Customer Service Department at [phone] for specic information on the current design and specications. Statements and other information contained herein are not express warranties and do not form the basis of any bargain
between the parties, but are merely ClimateMaster's opinion or commendation of its products. The latest version of this document is available at climatemaster.com.
Page ______ of ______Revised: 14 November, 2011EP008 - 2
TRC Series 50Hz - HFC410A Submittal Data Eng/S-I
Table of Contents
*Document page number is shown next to part number (e.g. EP008 - 3 = page 3). Since not all pages are typically
used in the submittals process, the page number in the lower right corner can still be used (page ____of_____).
*Page Number
TRC Series Nomenclature ................................................3
Performance Data - AHRI/ASHRAE/ISO 13256-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Performance Data - Selection Notes ........................................5
Performance Data - TRC09 ...............................................6
Performance Data - TRC12 ...............................................7
Performance Data - TRC15 ...............................................8
Performance Data - TRC18 ...............................................9
Antifreeze Correction Table .............................................10
Performance Data - Correction Tables .....................................10
Blower Performance & Electrical Data .....................................11
Physical Data .......................................................12
Console Cabinet Dimensions - Size 09 - 15 Bottom Return - Left Hand Piping .........13
Console Cabinet Dimensions - Size 09 - 15 Front Return - Left Hand Piping ..........14
Console Cabinet Dimensions - Size 09 - 15 Bottom Return - Right Hand Piping.........15
Console Cabinet Dimensions - Size 09 - 15 Front Return - Right Hand Piping ..........16
Console Chassis Dimensions - Size 09 - 15 ..................................17
Piping Detail - Size 09 - 15 ..............................................18
Console Cabinet Dimensions - Size 18 Bottom Return - Left Hand Piping .............19
Console Cabinet Dimensions - Size 18 Front Return - Left Hand Piping ..............20
Console Cabinet Dimensions - Size 18 Bottom Return - Right Hand Piping ............21
Console Cabinet Dimensions - Size 18 Front Return - Right Hand Piping .............22
Console Chassis Dimensions - Size 18 ......................................23
Piping Detail - Size 18 .................................................24
TRC Series Wiring Diagram Matrix .........................................25
Typical Wiring Diagram Manual & Auto Change Over TRC Units - with CXM Controller ...26
Typical Wiring Diagram Remote Mounted Thermostat TRC Units - with CXM Controller ...27
Typical Wiring Diagram TRC Units with CXM & LON Controller ....................28
Typical Wiring Diagram TRC Units with CXM & MPC Controller ....................29
Typical Wiring Diagram Manual & AutoChange Over TRC Unitsm - with DXM Controller...30
Typical Wiring Diagram Remote Mounted Thermostat TRC Units - with DXM Controller ...31
Typical Wiring Diagram TRC Units with DXM & LON Controller ....................32
Typical Wiring Diagram TRC Units with DXM & MPC Controller ....................33
Tranquility® Console (TRC) Series Engineering Specications .....................34
Revision History .....................................................40

ClimateMaster works continually to improve its products. As a result, the design and specications of each product at the time of order may be changed without notice and may not be as described herein. Please contact ClimateMaster's
Customer Service Department at [phone] for specic information on the current design and specications. Statements and other information contained herein are not express warranties and do not form the basis of any bargain
between the parties, but are merely ClimateMaster's opinion or commendation of its products. The latest version of this document is available at climatemaster.com.
Page ______ of ______Revised: 14 November, 2011EP008 - 3
TRC Series 50Hz - HFC410A Submittal Data Eng/S-I
TRC Series Nomenclature
TRC FB12 EV S S E S R S
94 5 6
7
8 10 11 12 13 14 15
TRC = Tranquility®Console
POWER TERMINATION & OPTIONS
REVISION LEVEL
VOLTAGE
CONTROLS
CABINET
SUBBASE
A = Copper Water Coil w/ -Coated Air Coil
HEAT EXCHANGER OPTIONS
C = Copper Water Coil w/Non-Coated Air Coil
J = Cupro-Nickel Water Coil w/ -Coated Air Coil
N = Cupro-Nickel Water Coil w/Non-Coated Air Coil
R = Right Piping
PIPING CONNECTIONS
L = Left Piping
S = STANDARD
F = Front Return (Standard)
S = Bottom Return (Standard)
S = 5” Subbase (Black)
H = 5” Subbase w/Motorized Damper
N = None
V = Copper Water Coil w/ -Coated Air Coil & Extended Range Insulation
E = Copper Water Coil w/Non-Coated Air Coil & Extended Range Insulation
M = Cupro-Nickel Water Coil w/ -Coated Air Coil & Extended Range Insulation
F = Cupro-Nickel Water Coil w/Non-Coated Air Coil & Extended Range Insulation
1 2 3
Sweat FPT MPT
None S F M
Motorized Water Valve A G N
AutoFlow (2.25 gpm/ton) B H P
AutoFlow (3.0 gpm/ton) C J Q
Motorized Water Valve & AFR (2.25) D K R
Motorized Water Valve & AFR (3.0) E L T
WATER CIRCUIT OPTIONS
G = Front Return w/Locking Control Door (Standard)
N = No Cabinet Chassis Only (Standard)
09
12
15
18
B= CurrentRevision
SERIES
UNIT SIZE
OPTION
A
F
DISCONNECT
SWITCH
-
X
FIELD CONNECTED
(HARD WIRE)
X
-
L = Bottom Return w/Locking Control Door (Standard)
V = 220-240/50/1
E = MCO Unit Mounted Tstat w/CXM
J = MCO Unit Mounted Tstat w/DXM
F = ACO Unit Mounted Tstat w/CXM
K = ACO Unit Mounted Tstat w/DXM
Q = Remote Mounted Tstat w/CXM
G = Remote Mounted Tstat w/DXM
H = Remote Mounted LON w/CXM
V = Remote Mounted LON w/DXM
T = Remote Mounted MPC w/CXM
U = Remote Mounted MPC w/DXM
Rev.: 21 July, 2010
CE Mark

ClimateMaster works continually to improve its products. As a result, the design and specications of each product at the time of order may be changed without notice and may not be as described herein. Please contact ClimateMaster's
Customer Service Department at [phone] for specic information on the current design and specications. Statements and other information contained herein are not express warranties and do not form the basis of any bargain
between the parties, but are merely ClimateMaster's opinion or commendation of its products. The latest version of this document is available at climatemaster.com.
Page ______ of ______Revised: 14 November, 2011EP008 - 4
TRC Series 50Hz - HFC410A Submittal Data Eng/S-I
Performance Data - AHRI/ASHRAE/ISO 13256-1
Model
Water Loop Heat Pump Ground Water Heat Pump Ground Loop Heat Pump
Cooling 30°C Heating 20°C Cooling 15°C Heating 10°C Cooling 25°C Heating 0°C
Capacity
kW
EER
W/W
Capacity
kW COP Capacity kW
EER
W/W
Capacity
kW COP Capacity kW
EER
W/W
Capacity
kW COP
TRC09 2.10 4.3 2.75 5.2 2.53 6.4 2.29 4.3 2.23 4.7 1.70 3.2
TRC12 2.81 3.9 3.49 3.9 3.37 6.5 2.93 3.3 2.99 4.7 2.31 2.5
TRC15 3.33 3.9 4.23 5.0 3.84 6.6 3.53 4.3 3.52 4.7 2.72 3.6
TRC18 3.66 4.8 4.48 4.7 4.18 4.1 3.81 4.2 3.87 4.6 3.05 3.5
Cooling capacities based upon 27°C DB, 19°C WB entering air temperature
Heating capacities based upon 20°C DB, 15°C WB entering air temperature
Ground loop heat pump ratings based on 15% methanol antifreeze solution
All air ow is rated on high speed, Units factory shipped on medium and low motor taps.
All ratings based upon operation at lower voltage of dual voltage rated models

ClimateMaster works continually to improve its products. As a result, the design and specications of each product at the time of order may be changed without notice and may not be as described herein. Please contact ClimateMaster's
Customer Service Department at [phone] for specic information on the current design and specications. Statements and other information contained herein are not express warranties and do not form the basis of any bargain
between the parties, but are merely ClimateMaster's opinion or commendation of its products. The latest version of this document is available at climatemaster.com.
Page ______ of ______Revised: 14 November, 2011EP008 - 5
TRC Series 50Hz - HFC410A Submittal Data Eng/S-I
Performance Data - Selection Notes
For operation in the shaded area when water is used
in lieu of an antifreeze solution, the LWT (Leaving
Water Temperature) must be calculated. Flow must be
maintained to a level such that the LWT is maintained
above 5°C when the JW3 jumper is not clipped (see
example below). This is due to the potential of the
refrigerant temperature being as low as 0°C with 5°C LWT,
which may lead to a nuisance cutout due to the activation
of the Low Temperature Protection. JW3 should never be
clipped for standard range equipment or systems without
antifreeze.
Example:
At 10°C EWT (Entering Water Temperature) and 0.082 l/s
(minimum flow rate), a TRC12 unit has a HE of 2.1 kW. To
calculate LWT, rearrange the formula for HE as follows:
HE = TD x Flow x 4.18
where HE = Heat of Extraction (kW); TD = temperature
difference (EWT - LWT); and
Flow = Water Flow Rate in l/s
TD = HE / (l/s x 4.18)
TD = 2.1 / (0.082 x 4.18)
TD = 6.1°C
LWT = EWT - TD
LWT = 10 – 6.1 = 3.9°C
In this example, operating at minimum flow rate when the EWT is 10°C could cause a nuisance cutout. Therefore, the flow
rate should be increased to maintain a LWT of at least 5°C. This example is typical of open loop systems with EWT at or
below 10°C. The middle flow rate (0.126 l/s) provides a TD of 4.0°C, which maintains a LWT of 6°C, well above the minimum.
184 l/s Nominal Airow Heating, 175 l/s Nominal Airow Cooling
EWT
°C
FLOW
WPD
kPa
COOLING - EAT 27/19 °C HEATING - EAT 20 °C
l/s l/m TC
kW
SC
kW
S/T
Ratio
Power
kW
HR
kW
EER
W/W
HC
kW
Power
kW
HE
kW
LAT
°C
COP
W/W
-5 0.164 9.84 43.4 Operation not Recommended 1.90 0.65 1.3 28.3 1.94
0
0.082 4.92 9.7 3.32 2.44 0.73 0.45 3.8 7.30 2.14 0.66 1.5 29.4 2.24
0.126 7.57 27.6 3.19 2.33 0.73 0.46 3.6 6.96 2.24 0.67 1.6 29.8 2.37
0.164 9.84 39.3 3.11 2.27 0.73 0.47 3.6 6.69 2.29 0.67 1.6 30.0 2.43
5
0.082 4.92 9.0 3.38 2.51 0.74 0.48 3.9 7.10 2.48 0.68 1.8 30.9 2.66
0.126 7.57 24.1 3.35 2.47 0.74 0.46 3.8 7.32 2.60 0.68 1.9 31.4 2.80
0.164 9.84 36.5 3.32 2.43 0.73 0.45 3.8 7.30 2.65 0.69 2.0 31.6 2.86
10
0.082 4.92 9.0 3.34 2.52 0.76 0.52 3.9 6.40 2.81 0.70 2.1 32.3 3.04
0.126 7.57 20.7 3.38 2.52 0.75 0.49 3.9 6.94 2.94 0.70 2.2 32.9 3.18
0.164 9.84 33.1 3.38 2.51 0.74 0.48 3.9 7.12 3.00 0.71 2.3 33.1 3.25
15
0.082 4.92 7.6 3.21 2.48 0.77 0.58 3.8 5.53 3.12 0.71 2.4 33.6 3.38
0.126 7.57 18.6 3.31 2.51 0.76 0.54 3.8 6.17 3.25 0.72 2.5 34.3 3.53
0.164 9.84 30.3 3.34 2.52 0.75 0.52 3.9 6.43 3.32 0.72 2.6 34.5 3.59
20
0.082 4.92 6.9 3.04 2.42 0.79 0.65 3.7 4.67 3.40 0.73 2.7 34.9 3.69
0.126 7.57 17.2 3.17 2.47 0.78 0.60 3.8 5.27 3.54 0.73 2.8 35.5 3.84
0.164 9.84 29.0 3.22 2.48 0.77 0.58 3.8 5.55 3.61 0.74 2.9 35.8 3.90
25
0.082 4.92 6.2 2.84 2.33 0.82 0.73 3.6 3.90 3.67 0.74 2.9 36.1 3.96
0.126 7.57 15.9 2.98 2.39 0.80 0.67 3.7 4.41 3.80 0.74 3.1 36.7 4.11
0.164 9.84 26.9 3.04 2.42 0.79 0.65 3.7 4.66 3.86 0.75 3.1 36.9 4.17
30
0.082 4.92 5.5 2.62 2.24 0.86 0.80 3.4 3.26 3.90 0.75 3.2 37.1 4.22
0.126 7.57 15.2 2.76 2.30 0.83 0.75 3.5 3.67 4.03 0.75 3.3 37.6 4.36
0.164 9.84 25.5 2.83 2.33 0.82 0.73 3.6 3.87 4.08 0.75 3.3 37.9 4.42
35
0.082 4.92 4.8 2.41 2.16 0.90 0.88 3.3 2.74
Operation not Recommended
0.126 7.57 14.5 2.54 2.21 0.87 0.83 3.4 3.05
0.164 9.84 24.8 2.60 2.24 0.86 0.81 3.4 3.21
40
0.082 4.92 4.8 2.22 2.09 0.94 0.95 3.2 2.34
0.126 7.57 13.8 2.33 2.13 0.91 0.91 3.2 2.57
0.164 9.84 24.1 2.39 2.15 0.90 0.89 3.3 2.68
45
0.082 4.92 4.8 2.07 2.07 1.00 1.01 3.1 2.05
0.126 7.57 13.8 2.15 2.08 0.97 0.98 3.1 2.21
0.164 9.84 24.1 2.19 2.09 0.95 0.96 3.2 2.29
Interpolation is permissible, extrapolation is not
All entering air conditions are 27°C DB and 19°C WB in cooling and 20°C DB in heating
All performance data is based upon the lower voltage of dual voltage rated units
See performance correction tables for operating conditions other than those listed above

ClimateMaster works continually to improve its products. As a result, the design and specications of each product at the time of order may be changed without notice and may not be as described herein. Please contact ClimateMaster's
Customer Service Department at [phone] for specic information on the current design and specications. Statements and other information contained herein are not express warranties and do not form the basis of any bargain
between the parties, but are merely ClimateMaster's opinion or commendation of its products. The latest version of this document is available at climatemaster.com.
Page ______ of ______Revised: 14 November, 2011EP008 - 6
TRC Series 50Hz - HFC410A Submittal Data Eng/S-I
Performance Data - TRC09
151 l/s Nominal Airow Heating, 142 l/s Nominal Airow Cooling
EWT
°C
Flow WPD
kPa
Cooling - EAT 27/19 °C Heating - EAT 20 °C
TC
kW
SC
kW
S/T
Ratio
Power
KW
HR
kW
EER
W/W
HC
kW
Power
kW
HE
kW
LAT
°C
COP
W/W
l/s l/m
-5 0.139 8.33 34.52 Operation not Recommended 1.33 0.53 0.8 29.2 2.52
0
0.069 4.16 11.05 2.85 2.05 0.72 0.33 3.2 8.7 1.61 0.54 1.1 29.4 2.98
0.101 6.06 17.95 2.90 2.04 0.70 0.30 3.2 9.6 1.69 0.54 1.1 30.0 3.11
0.139 8.33 31.07 2.93 2.04 0.70 0.29 3.2 10.2 1.75 0.55 1.2 30.3 3.19
5
0.069 4.16 9.67 2.75 2.07 0.75 0.37 3.1 7.5 1.96 0.56 1.4 31.4 3.52
0.101 6.06 15.88 2.81 2.06 0.73 0.34 3.2 8.2 2.06 0.56 1.5 32.0 3.68
0.139 8.33 29.00 2.85 2.05 0.72 0.33 3.2 8.7 2.12 0.56 1.6 32.5 3.77
10
0.069 4.16 8.29 2.65 2.08 0.79 0.41 3.1 6.5 2.27 0.57 1.7 33.3 4.02
0.101 6.06 15.19 2.71 2.07 0.76 0.38 3.1 7.1 2.38 0.57 1.8 33.9 4.18
0.139 8.33 26.24 2.75 2.07 0.75 0.37 3.1 7.5 2.45 0.57 1.9 34.1 4.28
15
0.069 4.16 7.60 2.52 2.07 0.82 0.45 3.0 5.6 2.56 0.57 2.0 35.0 4.46
0.101 6.06 14.50 2.60 2.08 0.80 0.43 3.0 6.1 2.67 0.58 2.1 35.6 4.63
0.139 8.33 25.55 2.64 2.08 0.79 0.41 3.1 6.4 2.74 0.58 2.2 36.0 4.74
20
0.069 4.16 6.90 2.38 2.04 0.86 0.50 2.9 4.8 2.82 0.58 2.2 36.4 4.86
0.101 6.06 13.81 2.46 2.06 0.84 0.47 2.9 5.2 2.93 0.58 2.3 37.1 5.04
0.139 8.33 24.17 2.51 2.07 0.82 0.45 3.0 5.5 3.00 0.58 2.4 37.5 5.15
25
0.069 4.16 6.90 2.22 1.97 0.89 0.55 2.8 4.1 3.05 0.58 2.5 37.8 5.23
0.101 6.06 13.12 2.31 2.01 0.87 0.52 2.8 4.4 3.16 0.58 2.6 38.4 5.40
0.139 8.33 22.10 2.36 2.03 0.86 0.50 2.9 4.7 3.23 0.59 2.6 38.8 5.51
30
0.069 4.16 6.90 2.12 1.91 0.90 0.57 2.7 3.7 3.15 0.59 2.6 38.4 5.40
0.101 6.06 13.12 2.22 1.97 0.89 0.55 2.8 4.1 3.26 0.59 2.7 39.0 5.56
0.139 8.33 21.40 2.28 1.99 0.88 0.51 2.8 4.3 3.33 0.59 2.7 39.4 5.67
35
0.069 4.16 6.21 2.03 1.86 0.91 0.60 2.6 3.4
Operation not Recommended
0.101 6.06 13.12 2.13 1.92 0.90 0.57 2.7 3.7
0.139 8.33 20.71 2.19 1.95 0.89 0.55 2.7 4.0
40
0.069 4.16 6.21 1.82 1.70 0.93 0.66 2.5 2.8
0.101 6.06 12.43 1.93 1.78 0.92 0.63 2.6 3.1
0.139 8.33 20.02 1.99 1.83 0.92 0.61 2.6 3.3
45
0.069 4.16 6.21 1.59 1.50 0.94 0.72 2.3 2.2
0.101 6.06 12.43 1.70 1.60 0.94 0.69 2.4 2.5
0.139 8.33 20.02 1.77 1.66 0.94 0.67 2.4 2.6
Interpolation is permissible; extrapolation is not.
All entering air conditions are 27°C DB and 19°C WB in cooling and 20°C DB in heating.
AHRI/ISO certied conditions are 27°C DB and 19°C WB in cooling and 20°C DB in heating.
Table does not reect fan or pump power corrections for AHRI/ISO conditions.
All performance data is based upon the lower voltage of dual voltage rated units.
Performance stated is at the rated power supply; performance may vary as the power supply varies from the rated.
Operation below 4°C EWT is based upon a 15% methanol antifreeze solution.
Operation below 16°C EWT requires optional insulated water/refrigerant circuit.
See performance correction tables for operating conditions other than those listed above.
Gray shaded area refers to calculations required to determine if heating water ow is sufcient for non-antifreeze systems.

ClimateMaster works continually to improve its products. As a result, the design and specications of each product at the time of order may be changed without notice and may not be as described herein. Please contact ClimateMaster's
Customer Service Department at [phone] for specic information on the current design and specications. Statements and other information contained herein are not express warranties and do not form the basis of any bargain
between the parties, but are merely ClimateMaster's opinion or commendation of its products. The latest version of this document is available at climatemaster.com.
Page ______ of ______Revised: 14 November, 2011EP008 - 7
TRC Series 50Hz - HFC410A Submittal Data Eng/S-I
Performance Data - TRC12
184 l/s Nominal Airow Heating, 175 l/s Nominal Airow Cooling
EWT
°C
FLOW WPD
kPa
COOLING - EAT 27/19 °C HEATING - EAT 20 °C
l/s l/m TC
kW
SC
kW
S/T
Ratio
Power
kW
HR
kW
EER
W/W
HC
kW
Power
kW
HE
kW
LAT
°C
COP
W/W
-5 0.164 9.84 43.4 Operation not Recommended 1.90 0.65 1.3 28.3 1.94
0
0.082 4.92 9.7 3.32 2.44 0.73 0.45 3.8 7.30 2.14 0.66 1.5 29.4 2.24
0.126 7.57 27.6 3.19 2.33 0.73 0.46 3.6 6.96 2.24 0.67 1.6 29.8 2.37
0.164 9.84 39.3 3.11 2.27 0.73 0.47 3.6 6.69 2.29 0.67 1.6 30.0 2.43
5
0.082 4.92 9.0 3.38 2.51 0.74 0.48 3.9 7.10 2.48 0.68 1.8 30.9 2.66
0.126 7.57 24.1 3.35 2.47 0.74 0.46 3.8 7.32 2.60 0.68 1.9 31.4 2.80
0.164 9.84 36.5 3.32 2.43 0.73 0.45 3.8 7.30 2.65 0.69 2.0 31.6 2.86
10
0.082 4.92 9.0 3.34 2.52 0.76 0.52 3.9 6.40 2.81 0.70 2.1 32.3 3.04
0.126 7.57 20.7 3.38 2.52 0.75 0.49 3.9 6.94 2.94 0.70 2.2 32.9 3.18
0.164 9.84 33.1 3.38 2.51 0.74 0.48 3.9 7.12 3.00 0.71 2.3 33.1 3.25
15
0.082 4.92 7.6 3.21 2.48 0.77 0.58 3.8 5.53 3.12 0.71 2.4 33.6 3.38
0.126 7.57 18.6 3.31 2.51 0.76 0.54 3.8 6.17 3.25 0.72 2.5 34.3 3.53
0.164 9.84 30.3 3.34 2.52 0.75 0.52 3.9 6.43 3.32 0.72 2.6 34.5 3.59
20
0.082 4.92 6.9 3.04 2.42 0.79 0.65 3.7 4.67 3.40 0.73 2.7 34.9 3.69
0.126 7.57 17.2 3.17 2.47 0.78 0.60 3.8 5.27 3.54 0.73 2.8 35.5 3.84
0.164 9.84 29.0 3.22 2.48 0.77 0.58 3.8 5.55 3.61 0.74 2.9 35.8 3.90
25
0.082 4.92 6.2 2.84 2.33 0.82 0.73 3.6 3.90 3.67 0.74 2.9 36.1 3.96
0.126 7.57 15.9 2.98 2.39 0.80 0.67 3.7 4.41 3.80 0.74 3.1 36.7 4.11
0.164 9.84 26.9 3.04 2.42 0.79 0.65 3.7 4.66 3.86 0.75 3.1 36.9 4.17
30
0.082 4.92 5.5 2.62 2.24 0.86 0.80 3.4 3.26 3.90 0.75 3.2 37.1 4.22
0.126 7.57 15.2 2.76 2.30 0.83 0.75 3.5 3.67 4.03 0.75 3.3 37.6 4.36
0.164 9.84 25.5 2.83 2.33 0.82 0.73 3.6 3.87 4.08 0.75 3.3 37.9 4.42
35
0.082 4.92 4.8 2.41 2.16 0.90 0.88 3.3 2.74
Operation not Recommended
0.126 7.57 14.5 2.54 2.21 0.87 0.83 3.4 3.05
0.164 9.84 24.8 2.60 2.24 0.86 0.81 3.4 3.21
40
0.082 4.92 4.8 2.22 2.09 0.94 0.95 3.2 2.34
0.126 7.57 13.8 2.33 2.13 0.91 0.91 3.2 2.57
0.164 9.84 24.1 2.39 2.15 0.90 0.89 3.3 2.68
45
0.082 4.92 4.8 2.07 2.07 1.00 1.01 3.1 2.05
0.126 7.57 13.8 2.15 2.08 0.97 0.98 3.1 2.21
0.164 9.84 24.1 2.19 2.09 0.95 0.96 3.2 2.29
Interpolation is permissible; extrapolation is not.
All entering air conditions are 27°C DB and 19°C WB in cooling and 20°C DB in heating.
AHRI/ISO certied conditions are 27°C DB and 19°C WB in cooling and 20°C DB in heating.
Table does not reect fan or pump power corrections for AHRI/ISO conditions.
All performance data is based upon the lower voltage of dual voltage rated units.
Performance stated is at the rated power supply; performance may vary as the power supply varies from the rated.
Operation below 4°C EWT is based upon a 15% methanol antifreeze solution.
Operation below 16°C EWT requires optional insulated water/refrigerant circuit.
See performance correction tables for operating conditions other than those listed above.
Gray shaded area refers to calculations required to determine if heating water ow is sufcient for non-antifreeze systems.

ClimateMaster works continually to improve its products. As a result, the design and specications of each product at the time of order may be changed without notice and may not be as described herein. Please contact ClimateMaster's
Customer Service Department at [phone] for specic information on the current design and specications. Statements and other information contained herein are not express warranties and do not form the basis of any bargain
between the parties, but are merely ClimateMaster's opinion or commendation of its products. The latest version of this document is available at climatemaster.com.
Page ______ of ______Revised: 14 November, 2011EP008 - 8
TRC Series 50Hz - HFC410A Submittal Data Eng/S-I
Performance Data - TRC15
189 l/s Nominal Airow Cooling, 198 l/s Nominal Airow Heating
EWT
°C
Flow WPD
kPa
Cooling - EAT 27/19 °C Heating - EAT 20 °C
l/s l/m TC
kW
SC
kW
S/T
Ratio
Power
kW
HR
kW
EER
W/W
HC
kW
Power
kW
HE
kW
LAT
°C
COP
W/W
-5 0.189 11.36 22.8 Operation not Recommended 2.25 0.71 1.5 29.6 3.15
0
0.095 5.68 4.8 4.26 3.20 0.75 0.48 4.74 8.95 2.48 0.73 1.7 30.6 3.39
0.145 8.71 12.4 4.30 3.22 0.75 0.42 4.72 10.14 2.58 0.74 1.8 31.0 3.50
0.189 11.36 20.7 4.29 3.23 0.75 0.40 4.69 10.79 2.64 0.74 1.9 31.3 3.56
5
0.095 5.68 4.1 4.15 3.15 0.76 0.54 4.69 7.63 2.83 0.75 2.1 32.1 3.76
0.145 8.71 11.0 4.24 3.19 0.75 0.49 4.73 8.63 2.96 0.76 2.2 32.6 3.88
0.189 11.36 19.3 4.27 3.21 0.75 0.47 4.74 9.18 3.02 0.77 2.3 32.9 3.95
10
0.095 5.68 3.8 3.98 3.08 0.77 0.61 4.59 6.49 3.18 0.77 2.4 33.6 4.11
0.145 8.71 9.7 4.11 3.14 0.76 0.56 4.67 7.34 3.33 0.78 2.5 34.2 4.24
0.189 11.36 18.6 4.17 3.16 0.76 0.53 4.70 7.81 3.40 0.79 2.6 34.5 4.32
15
0.095 5.68 3.4 3.76 3.00 0.80 0.68 4.45 5.51 3.53 0.80 2.7 35.1 4.44
0.145 8.71 9.0 3.92 3.06 0.78 0.63 4.56 6.22 3.69 0.80 2.9 35.8 4.59
0.189 11.36 17.2 4.00 3.09 0.77 0.60 4.60 6.62 3.78 0.81 3.0 36.1 4.67
20
0.095 5.68 2.8 3.53 2.90 0.82 0.76 4.28 4.65 3.87 0.81 3.1 36.5 4.76
0.145 8.71 8.3 3.70 2.97 0.80 0.70 4.40 5.25 4.05 0.82 3.2 37.3 4.93
0.189 11.36 15.9 3.78 3.00 0.79 0.68 4.46 5.59 4.15 0.83 3.3 37.7 5.02
25
0.095 5.68 2.8 3.27 2.79 0.85 0.84 4.11 3.90 4.22 0.83 3.4 38.0 5.07
0.145 8.71 8.3 3.45 2.87 0.83 0.78 4.23 4.40 4.42 0.84 3.6 38.9 5.26
0.189 11.36 15.2 3.54 2.90 0.82 0.75 4.29 4.69 4.52 0.85 3.7 39.3 5.35
30
0.095 5.68 2.8 3.01 2.68 0.89 0.92 3.93 3.26 4.56 0.85 3.7 39.5 5.38
0.145 8.71 7.6 3.18 2.75 0.87 0.87 4.05 3.67 4.78 0.86 3.9 40.4 5.58
0.189 11.36 14.5 3.27 2.79 0.85 0.84 4.11 3.90 4.90 0.86 4.0 40.9 5.69
35
0.095 5.68 2.8 2.76 2.57 0.93 1.02 3.77 2.71
Operation not Recommended
0.145 8.71 7.6 2.92 2.64 0.91 0.96 3.87 3.04
0.189 11.36 13.8 3.00 2.68 0.89 0.93 3.93 3.23
40
0.095 5.68 2.8 2.52 2.47 0.98 1.12 3.64 2.25
0.145 8.71 7.6 2.66 2.53 0.95 1.06 3.72 2.52
0.189 11.36 13.8 2.74 2.56 0.94 1.03 3.76 2.67
45
0.095 5.68 2.8 2.31 2.39 1.03 1.23 3.55 1.87
0.145 8.71 7.6 2.43 2.43 1.00 1.17 3.59 2.08
0.189 11.36 13.8 2.49 2.46 0.99 1.13 3.63 2.20
Interpolation is permissible; extrapolation is not.
All entering air conditions are 27°C DB and 19°C WB in cooling and 20°C DB in heating.
AHRI/ISO certied conditions are 27°C DB and 19°C WB in cooling and 20°C DB in heating.
Table does not reect fan or pump power corrections for AHRI/ISO conditions.
All performance data is based upon the lower voltage of dual voltage rated units.
Performance stated is at the rated power supply; performance may vary as the power supply varies from the rated.
Operation below 4°C EWT is based upon a 15% methanol antifreeze solution.
Operation below 16°C EWT requires optional insulated water/refrigerant circuit.
See performance correction tables for operating conditions other than those listed above.
Gray shaded area refers to calculations required to determine if heating water ow is sufcient for non-antifreeze systems.

ClimateMaster works continually to improve its products. As a result, the design and specications of each product at the time of order may be changed without notice and may not be as described herein. Please contact ClimateMaster's
Customer Service Department at [phone] for specic information on the current design and specications. Statements and other information contained herein are not express warranties and do not form the basis of any bargain
between the parties, but are merely ClimateMaster's opinion or commendation of its products. The latest version of this document is available at climatemaster.com.
Page ______ of ______Revised: 14 November, 2011EP008 - 9
TRC Series 50Hz - HFC410A Submittal Data Eng/S-I
Performance Data - TRC18
269 l/s Nominal Airow Heating, 250 l/s Nominal Airow Cooling
EWT
°C
Flow
WPD
kPa
Cooling - EAT 27/19 °C Heating - EAT 20 °C
l/s l/m TC
kW
SC
kW
S/T
Ratio
Power
kW
HR
kW
EER
W/W
HC
kW
Power
kW
HE
kW
LAT
°C
COP
W/W
-5 0.215 12.87 32.4 Operation not Recommended 2.49 0.79 1.7 28.4 3.14
0
0.120 7.19 9.0 4.31 3.33 0.77 0.80 5.1 5.36 2.71 0.80 1.9 29.1 3.36
0.145 8.71 15.2 4.32 3.34 0.77 0.77 5.1 5.59 2.77 0.81 2.0 29.3 3.42
0.215 12.87 30.3 4.32 3.37 0.78 0.73 5.1 5.94 2.87 0.82 2.1 29.7 3.51
5
0.120 7.19 8.3 4.24 3.28 0.77 0.89 5.1 4.76 3.09 0.84 2.3 30.4 3.69
0.145 8.71 13.8 4.27 3.30 0.77 0.86 5.1 4.99 3.16 0.84 2.3 30.7 3.76
0.215 12.87 28.3 4.31 3.32 0.77 0.81 5.1 5.35 3.29 0.85 2.4 31.1 3.86
10
0.120 7.19 6.9 4.13 3.22 0.78 0.99 5.1 4.18 3.50 0.87 2.6 31.8 4.00
0.145 8.71 12.4 4.18 3.24 0.78 0.95 5.1 4.40 3.59 0.88 2.7 32.1 4.07
0.215 12.87 26.2 4.24 3.28 0.77 0.89 5.1 4.75 3.75 0.90 2.9 32.6 4.17
15
0.120 7.19 6.2 3.98 3.16 0.79 1.09 5.1 3.64 3.92 0.91 3.0 33.2 4.28
0.145 8.71 11.0 4.04 3.18 0.79 1.05 5.1 3.84 4.03 0.93 3.1 33.6 4.35
0.215 12.87 24.8 4.13 3.22 0.78 0.99 5.1 4.17 4.21 0.94 3.3 34.2 4.47
20
0.120 7.19 5.5 3.80 3.09 0.81 1.21 5.0 3.15 4.34 0.95 3.4 34.6 4.54
0.145 8.71 10.3 3.87 3.11 0.80 1.16 5.0 3.33 4.46 0.97 3.5 35.0 4.62
0.215 12.87 23.4 3.98 3.16 0.79 1.10 5.1 3.62 4.66 0.98 3.7 35.7 4.74
25
0.120 7.19 4.8 3.60 3.00 0.83 1.33 4.9 2.70 4.75 0.99 3.8 36.0 4.79
0.145 8.71 9.7 3.67 3.03 0.83 1.28 5.0 2.86 4.87 1.00 3.9 36.4 4.87
0.215 12.87 22.1 3.79 3.08 0.81 1.21 5.0 3.12 5.07 1.01 4.1 37.1 5.00
30
0.120 7.19 4.1 3.37 2.89 0.86 1.46 4.8 2.30 5.12 1.02 4.1 37.3 5.04
0.145 8.71 9.0 3.45 2.93 0.85 1.41 4.9 2.44 5.25 1.02 4.2 37.7 5.13
0.215 12.87 20.7 3.58 2.99 0.84 1.34 4.9 2.67 5.44 1.03 4.4 38.3 5.28
35
0.120 7.19 4.1 3.12 2.77 0.89 1.60 4.7 1.94
Operation not Recommended
0.145 8.71 9.0 3.21 2.82 0.88 1.55 4.8 2.06
0.215 12.87 20.0 3.34 2.88 0.86 1.48 4.8 2.26
40
0.120 7.19 3.4 2.86 2.63 0.92 1.76 4.6 1.63
0.145 8.71 8.3 2.95 2.68 0.91 1.70 4.7 1.73
0.215 12.87 19.3 3.08 2.76 0.89 1.63 4.7 1.90
45
0.120 7.19 3.4 2.59 2.47 0.95 1.92 4.5 1.35
0.145 8.71 8.3 2.68 2.52 0.94 1.86 4.5 1.44
0.215 12.87 19.3 2.82 2.61 0.93 1.78 4.6 1.58
Interpolation is permissible; extrapolation is not.
All entering air conditions are 27°C DB and 19°C WB in cooling and 20°C DB in heating.
AHRI/ISO certied conditions are 27°C DB and 19°C WB in cooling and 20°C DB in heating.
Table does not reect fan or pump power corrections for AHRI/ISO conditions.
All performance data is based upon the lower voltage of dual voltage rated units.
Performance stated is at the rated power supply; performance may vary as the power supply varies from the rated.
Operation below 4°C EWT is based upon a 15% methanol antifreeze solution.
Operation below 16°C EWT requires optional insulated water/refrigerant circuit.
See performance correction tables for operating conditions other than those listed above.
Gray shaded area refers to calculations required to determine if heating water ow is sufcient for non-antifreeze systems.

ClimateMaster works continually to improve its products. As a result, the design and specications of each product at the time of order may be changed without notice and may not be as described herein. Please contact ClimateMaster's
Customer Service Department at [phone] for specic information on the current design and specications. Statements and other information contained herein are not express warranties and do not form the basis of any bargain
between the parties, but are merely ClimateMaster's opinion or commendation of its products. The latest version of this document is available at climatemaster.com.
Page ______ of ______Revised: 14 November, 2011EP008 - 10
TRC Series 50Hz - HFC410A Submittal Data Eng/S-I
Air Flow Correction Table
Entering Air Correction Table
Performance Data - Correction Tables
Airow Heating Cooling
% of Nominal Heating
Capacity
Power
kW
Heat of
Extraction
Total
Capacity
Sensible
Capacity
Power
kW
Heat of
Rejection
75 0.970 1.070 0.950 0.950 0.910 0.970 0.950
83 0.983 1.042 0.968 0.964 0.953 0.981 0.967
89 0.990 1.026 0.981 0.974 0.974 0.987 0.977
94 0.995 1.012 0.991 0.987 0.990 0.993 0.988
100 1.000 1.000 1.000 1.000 1.000 1.000 1.000
106 1.004 0.991 1.007 1.015 1.002 1.008 1.014
111 1.006 0.985 1.011 1.031 0.996 1.016 1.028
Heating
Entering
Air DB °C
Heating
Capacity
Power
kW
Heat of
Extraction
15 1.030 0.910 1.060
17 1.019 0.949 1.037
20 1.000 1.000 1.000
22 0.987 1.032 0.975
24 0.973 1.065 0.950
26 0.960 1.109 0.931
Cooling
Entering
Air WB °C
Total
Capacity
kW
Sens Clg Cap Multiplier-EAT db °C Power
kW
Heat of
Rejection
21 23 25 27 29.5 32 35
15 0.900 0.7 0.9 1.0 * * * * 1.0000 0.9000
17 0.961 0.6801 0.8495 0.9996 * * * * 1.0014 0.9631
19 1.000 0.5261 0.7376 0.9140 1.0000 1.1602 * * 1.0000 1.0000
21 1.050 0.5663 0.7679 0.8461 1.0202 1.1870 *0.9999 1.0408
23 1.100 0.5000 0.5000 0.7000 0.9000 1.1000 1.0000 1.1000
25 1.176 0.5250 0.5910 0.7980 1.0040 1.1780 1.0470 1.1490
* = Sensible capacity equals total capacity
AHRI/ISO/ASHRAE 13256-1 uses entering air conditions of Cooling - 27.0°C DB/19.0°C WB, 1
and Heating - 20.0°C DB/15.0°C WB entering air temperature
Antifreeze Type Antifreeze %
Cooling Heating WPD
Corr. Fct.
EWT -1°C
EWT 32°C EWT -1°C
Total Cap Sens Cap Power Htg Cap Power
Water 0 1.000 1.000 1.000 1.000 1.000 1.000
Propylene Glycol
50.995 0.995 1.003 0.989 0.997 1.070
15 0.986 0.986 1.009 0.968 0.990 1.210
25 0.978 0.978 1.014 0.947 0.983 1.360
Methanol
50.997 0.997 1.002 0.989 0.997 1.070
15 0.990 0.990 1.007 0.968 0.990 1.160
25 0.982 0.982 1.012 0.949 0.984 1.220
Ethanol
50.998 0.998 1.002 0.981 0.994 1.140
15 0.994 0.994 1.005 0.944 0.983 1.300
25 0.986 0.986 1.009 0.917 0.974 1.360
Ethylene Glycol
50.998 0.998 1.002 0.993 0.998 1.040
15 0.994 0.994 1.004 0.980 0.994 1.120
25 0.988 0.988 1.008 0.966 0.990 1.200
Antifreeze Correction Table

ClimateMaster works continually to improve its products. As a result, the design and specications of each product at the time of order may be changed without notice and may not be as described herein. Please contact ClimateMaster's
Customer Service Department at [phone] for specic information on the current design and specications. Statements and other information contained herein are not express warranties and do not form the basis of any bargain
between the parties, but are merely ClimateMaster's opinion or commendation of its products. The latest version of this document is available at climatemaster.com.
Page ______ of ______Revised: 14 November, 2011EP008 - 11
TRC Series 50Hz - HFC410A Submittal Data Eng/S-I
Model Voltage
Code Voltage Min/Max Voltage
Compressor Fan
Motor
FLA
Total
Unit
FLA
Min
Circ
Amp
Max
Fuse/
QTY RLA LRA
TRC09 T220-240/50/1 198-264 1 3.2 17 0.4 3.6 4.4 15.0
TRC12 T220-240/50/1 198-264 1 4.0 19 0.4 4.4 5.4 15.0
TRC15 T220-240/50/1 198-264 1 4.7 23 0.6 5.3 6.5 15.0
TRC18 T220-240/50/1 198-264 1 5.6 25 0.6 6.2 7.6 15.0
Blower Performance & Electrical Data
Blower Performance
Electrical Data
Model
Rated
Airow
HTG l/s
Rated
Airow
CLG l/s
Airow l/s
High Medium Low
Speed Speed Speed
TRC09 151 142 146 127 113
TRC12 184 175 175 142 118
TRC15 189 198 189 170 149
TRC18 269 250 250 212 179
Notes:
All airow is rated at the lowest voltage if unit is dual voltage rated. I.e. 220 volts for 220/240 volt rated units.
All units AHRI/ISO/ASHRAE 13256-1 rated on High fan speed.
Units shipped on Medium and Low taps.
All units are designed and rated for zero external static pressure (non ducted) application.

ClimateMaster works continually to improve its products. As a result, the design and specications of each product at the time of order may be changed without notice and may not be as described herein. Please contact ClimateMaster's
Customer Service Department at [phone] for specic information on the current design and specications. Statements and other information contained herein are not express warranties and do not form the basis of any bargain
between the parties, but are merely ClimateMaster's opinion or commendation of its products. The latest version of this document is available at climatemaster.com.
Page ______ of ______Revised: 14 November, 2011EP008 - 12
TRC Series 50Hz - HFC410A Submittal Data Eng/S-I
Physical Data
Model 09 12 15 18
Compressor (1 Each) Rotary
Factory Charge HFC-410A [kg] 0.737 0.822 0.936 0.850
PSC Fan Motor & Blower (3 Speeds)
Fan Motor W 37 62 93 93
Blower Wheel Size (dia x w) -
[mm] - Qty 2 133 x 159
Water Connection Size
O.D. Sweat [mm] 12.7 19.1
Optional FPT Fittings (in) 1/2 3/4
Optional MPT Fittings (in) 1/2 3/4
Condensate Connection Size
I.D. Vinyl Hose [mm] 15.9
Air Coil Size
Dimensions (h x w) - [cm] 20.3 x 66.0 25.4 x 66.0 25.4 x 81.2
Filter Size
Bottom Return [cm] 25.4 x 76.2 x 2.5 25.4 x 91.4 x 2.5
Front Return [cm] 17.8 x 74.9 x 0.32 17.8 x 80.0 x .32
Cabinet Size
Bottom Return (Std. 5" Base)
(W x H x D) - [cm] 121.9 x 66.0 x 30.5 137.2 x 66.0 x 30.5
Front Return (No Subbase)
(W x H x D) - [cm] 121.9 x 53.3 x 30.5 137.2 x 53.3 x 30.5
Cabinet Size
Weight - Operating [kg] 79 82 86.2 99.8
Weight - Packaged [kg] 83.9 86 90.8 105.2
All units have rubber grommet compressor mountings and TXV expansion devices.
Unit Maximum Water Working Pressure
Options Max Pressure kPa
Base Unit 2,068
Internal Secondary Pump (ISP)
999
Internal Motorized Water Valve (MWV)
2,068
Internal Auto Flow Valve
2,068
Use the lowest maximum pressure rating when multiple options are combined.

ClimateMaster works continually to improve its products. As a result, the design and specications of each product at the time of order may be changed without notice and may not be as described herein. Please contact ClimateMaster's
Customer Service Department at [phone] for specic information on the current design and specications. Statements and other information contained herein are not express warranties and do not form the basis of any bargain
between the parties, but are merely ClimateMaster's opinion or commendation of its products. The latest version of this document is available at climatemaster.com.
Page ______ of ______Revised: 14 November, 2011EP008 - 13
TRC Series 50Hz - HFC410A Submittal Data Eng/S-I
Console Cabinet Dimensions - Size 09 - 15
Bottom Return - Left Hand Piping
30°
2923
125
89
658
DAMPER OPENING
1219
1041
41
298 251
15
533
125
REAR VIEW
Ai
Sub-base
r
Inlet
Discharge
Air
305
Rev.: 10/03/08B
BOTTOM VIEW
279
FRONT VIEW
Control Access Door
AIR INLET AREA
1219
851
44.5
127
Left Hand Bottom Return
Notes:
38
90
44
76
19
Bottom Access for
Piping and Electric
(Note 2)
L.H.
Rear Access
For Piping
and Electric
(NOTE 2)
254
174
25
25
114
508
SIDE
VIEW
Filter located inside and at
Discharge Air Grille
top of air inlet area. Rotate
filter latch forward, filter rack
can be pulled forward 75 to 100
mm for filter access.
1. All Dimensions are in mm.
2. Access is reduced if optional disconnect box is selected.
3. Optional autoflow regulator, motorized water valve, and disconnect box are not shown.
4. Filter is 25 mm thick fiberglass throwaway.
54
Fixed
Back
Wrapper
Removable
Cabinet

ClimateMaster works continually to improve its products. As a result, the design and specications of each product at the time of order may be changed without notice and may not be as described herein. Please contact ClimateMaster's
Customer Service Department at [phone] for specic information on the current design and specications. Statements and other information contained herein are not express warranties and do not form the basis of any bargain
between the parties, but are merely ClimateMaster's opinion or commendation of its products. The latest version of this document is available at climatemaster.com.
Page ______ of ______Revised: 14 November, 2011EP008 - 14
TRC Series 50Hz - HFC410A Submittal Data Eng/S-I
Console Cabinet Dimensions - Size 09 - 15
Front Return - Left Hand Piping
°
L.H. Rear
Access for
Piping and
Electric (NOTE 2)
Notes:
1. All Dimensions are in mm.
2. Access is reduced if optional disconnect box is selected.
3. Optional autoflow regulator, motorized water valve, and disconnect box are not shown.
4. Filter is a cleanable polypropylene mesh.
89
533
305
1041
13
19
105
25
25
533
Bottom Access for
Piping and Electric
(Note 2)
Fixed Back
Wrapper
Removable
Cabinet
292
114
Left Hand Front Return
1110
1219
201
279
38
127 Discharge Air Grille
1219

ClimateMaster works continually to improve its products. As a result, the design and specications of each product at the time of order may be changed without notice and may not be as described herein. Please contact ClimateMaster's
Customer Service Department at [phone] for specic information on the current design and specications. Statements and other information contained herein are not express warranties and do not form the basis of any bargain
between the parties, but are merely ClimateMaster's opinion or commendation of its products. The latest version of this document is available at climatemaster.com.
Page ______ of ______Revised: 14 November, 2011EP008 - 15
TRC Series 50Hz - HFC410A Submittal Data Eng/S-I
Console Cabinet Dimensions - Size 09 - 15
Bottom Return - Right Hand Piping
30
292
125
89
658
DAMPER OPENING
1219
41
1041
298 251
15
533
125
REAR VIEW
Air
Inlet
Discharge
Sub-base
Removable
Cabinet
Fixed Back
Wrapper
Air
44
76
54
Bottom Access for
Piping and Electric
(Note 2)
25
25
114
305
254
BOTTOM VIEW
FRONT VIEW
Control
Discharge Air
Grille
Access Door
AIR INLET AREA
1219
851
127
48
Right Hand Bottom Return
3
90
SIDE
VIEW
Rev.: 10/03/08B
˚
Notes:
R.H.
Rear Access
for Piping
and Electric
(Note 2)
1. All Dimensions are in mm.
2. Access is reduced if optional disconnect box is selected.
3. Optional autoflow regulator, motorized water valve, and disconnect box are not shown.
4. Filter is 25 mm thick fiberglass throwaway.
174
19
38
279
Filter located inside and at
top of air inlet area. Rotate
filter latch forward, filter rack
can be pulled forward 75 to 100
mm for filter access.

ClimateMaster works continually to improve its products. As a result, the design and specications of each product at the time of order may be changed without notice and may not be as described herein. Please contact ClimateMaster's
Customer Service Department at [phone] for specic information on the current design and specications. Statements and other information contained herein are not express warranties and do not form the basis of any bargain
between the parties, but are merely ClimateMaster's opinion or commendation of its products. The latest version of this document is available at climatemaster.com.
Page ______ of ______Revised: 14 November, 2011EP008 - 16
TRC Series 50Hz - HFC410A Submittal Data Eng/S-I
Console Cabinet Dimensions - Size 09 - 15
Front Return - Right Hand Piping
30
89
533
533
REAR VIEW
Discharge
Air
25
25
114
305
279
FRONT VIEW
Control Access Door
Discharge
Air Grille
1219
127
1110
Right Hand Front Return
201
Bottom Access
for Piping
and Electric
305 BOTTOM VIEW
1219
SIDE
VIEW
Air
Inlet
Filter located behind return
air grille and requires removal of
cabinet front for access.
˚
Notes:
1. All dimensions are in mm.
2. Access is reduced if optional disconnect box is selected
3. Optional autoflow regulator, motorized water valve, and disconnect box are not shown.
4. Filter is a cleanable polypropylene mesh.
13
292
19
105
1041
38
R.H.
Rear Access
for Piping
and Electric
(Note 2)
Removable
Cabinet
Fixed Back
Wrapper

ClimateMaster works continually to improve its products. As a result, the design and specications of each product at the time of order may be changed without notice and may not be as described herein. Please contact ClimateMaster's
Customer Service Department at [phone] for specic information on the current design and specications. Statements and other information contained herein are not express warranties and do not form the basis of any bargain
between the parties, but are merely ClimateMaster's opinion or commendation of its products. The latest version of this document is available at climatemaster.com.
Page ______ of ______Revised: 14 November, 2011EP008 - 17
TRC Series 50Hz - HFC410A Submittal Data Eng/S-I
Console Chassis Dimensions - Size 09 - 15
Left Hand Configuration
(Bottom Return)
Power Supply
Blower Deck
Blower Access Panel
Compressor
Access
Panel
Control Box
Notes: All Dimensions are in millimeters. * If subbase option is selected for installed dimension, add to dimension shown 124mm for 5" subbase, or dimension unit is raised above floor (124 minimum) Optional autoflow valve, motorized water valve and disconnect box are shown.
1041
113
19 19
*521
293
*423
30°
22
Right Hand Configuration
(Bottom Return)
Hard Wire
Power Supply
Blower Deck
Blower Access Panel
Compressor
Access
Panel
Control Box
116
22
293
87
*423
30°
76
136
19 19
113
*521
1040
76
136
Optional Motorized Water Valve
Optional Autoflow Valve
*90
87
*90
Optional Disconnect Box (mounted to cabinet
not chassis) Power supply enters Bottom of Box
116
Optional Disconnect Box
(mounted to cabinet
not chassis)
Optional
Motorized
Water Valve
Optional
Autoflow
Valve
Power supply enters
Bottom of Box

ClimateMaster works continually to improve its products. As a result, the design and specications of each product at the time of order may be changed without notice and may not be as described herein. Please contact ClimateMaster's
Customer Service Department at [phone] for specic information on the current design and specications. Statements and other information contained herein are not express warranties and do not form the basis of any bargain
between the parties, but are merely ClimateMaster's opinion or commendation of its products. The latest version of this document is available at climatemaster.com.
Page ______ of ______Revised: 14 November, 2011EP008 - 18
TRC Series 50Hz - HFC410A Submittal Data Eng/S-I
Left Hand Configuration
Water In
Water Out
Notes:* Dimension reduced by fitting if selected
96
Right Hand Configuration
Water In
Water Out
Blower Deck
Blower Access Panel
Compressor
Access
Panel
Control Box
47
19
521
1040
Condensate
Condensate
15.9 ID
Vinyl Hose
Optional
Motorized
Water Valve
Optional
Autoflow
Valve
Water Connections
15.9
OD Copper,
1/2" FPT or
1/2" MPT
Optional
Disconnect Box
(mounted to cabinet
not chassis)
Optional
Motorized
Water Valve
Optional
Autoflow
Valve
Water Connections
15.9AA
OD Copper,
1/2" FPT or
1/2" MPT
Optional Fused
Disconnect Box
(mounted to cabinet
not chassis)
Also Available in Non-Fused
Optional Disconnect
Only Box (All Configurations)
Optional Flow
Regulator
Optional
Motorized
Water Valve
44
Out
In
Water Connections
15.9 OD
Copper, 1/2” FPT, or
1/2” MPT
57
In
Out
*286
51
1.50
Min
203
57
15.9 ID
Vinyl Hose
Min
203
Water Connections
15.9 OD
Copper, 1/2” FPT,
or 1/2” MPT
*286
41
51
57
CAUTION!Corrosivesystemwaterrequirescorrosion
treatment.
� CAUTION! �
CAUTION!Pipingmustcomplywithallapplicablecodes.
� CAUTION! �
Piping Detail - Size 09 - 15
Left Hand Configuration
Water In
Water Out
Notes:* Dimension reduced by fitting if selected
96
Right Hand Configuration
Water In
Water Out
Blower Deck
Blower Access Panel
Compressor
Access
Panel
Control Box
47
19
521
1040
Condensate
Condensate
15.9 ID
Vinyl Hose
Optional
Motorized
W
ater Valve
Optional
Autoflow
V
alve
W
ater Connections
15.9
OD Copper,
1/2" FPT or
1/2" MPT
Optional
Disconnect Box
(mounted to cabinet
not chassis)
Optional
Motorized
Water Valve
Optional
Autoflow
Valve
Water Connections
15.9AA
OD Copper,
1/2" FPT or
1/2" MPT
Optional Fused
Disconnect Box
(mounted to cabinet
not chassis)
Also Available in Non-Fused
Optional Disconnect
Only Box (All Configurations)
Optional Flow
Regulator
Optional
Motorized
Water Valve
44
Out
In
Water Connections
15.9 OD
Copper, 1/2” FPT, or
1/2” MPT
57
In
Out
*286
51
1.50
Min
203
57
15.9 ID
Vinyl Hose
Min
203
Water Connections
15.9 OD
Copper, 1/2” FPT,
or 1/2” MPT
*286
41
51
57
CAUTION!Corrosivesystemwaterrequirescorrosion
treatment.
� CAUTION! �
CAUTION!Pipingmustcomplywithallapplicablecodes.
� CAUTION! �
Notes:* Dimension reduced by tting if selected.
Dimensions are in mm.
Optional autoow valve and motorized water valve are shown.

ClimateMaster works continually to improve its products. As a result, the design and specications of each product at the time of order may be changed without notice and may not be as described herein. Please contact ClimateMaster's
Customer Service Department at [phone] for specic information on the current design and specications. Statements and other information contained herein are not express warranties and do not form the basis of any bargain
between the parties, but are merely ClimateMaster's opinion or commendation of its products. The latest version of this document is available at climatemaster.com.
Page ______ of ______Revised: 14 November, 2011EP008 - 19
TRC Series 50Hz - HFC410A Submittal Data Eng/S-I
Console Cabinet Dimensions - Size 18
Bottom Return - Left Hand Piping
30˚
292 125
89
658
DAMPER OPENING
1193
41
298 403
15
533
125
REAR VIEW
Air
Inlet
Discharge
Air
Rev.: 10/06/08B
BOTTOM VIEW
FRONT VIEW
Control Access Door
AIR INLET AREA
1010
1372
1372
44.5
127
Left Hand Bottom Return
Notes:
279
38
90
44
76
19
254
25
25
114
SIDE
VIEW
305
1. All Dimensions are in mm.
2. Access is reduced if optional disconnect box is selected.
3. Optional autoflow regulator, motorized water valve, and disconnect box are not shown.
4. Filter is 25 mm thick fiberglass throwaway.
174
54
L.H.
Rear Access
for Piping
and Electric
(Note 2)
Discharge Air
Grille
Bottom Access for
Piping and Electric
(Note 2)
Sub-base
Removable
Cabinet
3
Fixed
Back
Wrapper
Filter located inside and at
top of air inlet area. Rotate
filter latch forward, filter rack
can be pulled forward 75 to 100
mm for filter access.

ClimateMaster works continually to improve its products. As a result, the design and specications of each product at the time of order may be changed without notice and may not be as described herein. Please contact ClimateMaster's
Customer Service Department at [phone] for specic information on the current design and specications. Statements and other information contained herein are not express warranties and do not form the basis of any bargain
between the parties, but are merely ClimateMaster's opinion or commendation of its products. The latest version of this document is available at climatemaster.com.
Page ______ of ______Revised: 14 November, 2011EP008 - 20
TRC Series 50Hz - HFC410A Submittal Data Eng/S-I
Console Cabinet Dimensions - Size 18
Front Return - Left Hand Piping
30˚
89
533
533
REAR VIEW
Discharge
Air
305
279
38
FRONT VIEW
Control Access Door
127
Left Hand Front Return
1219
201
533
292 BOTTOM VIEW
105
114
25
SIDE
VIEW
Air
Inlet
Rev.: 10/06/08B
Filter located behind return
air grille and requires removal of
cabinet front for access.
19
25
Notes:
1. All Dimensions are in mm.
2. Access is reduced if optional disconnect box is selected.
3. Optional autoflow regulator, motorized water valve, and disconnect box are not shown.
4. Filter is a cleanable polypropylene mesh.
13
1372
1372
Fixed
Back
Wrapper
Bottom Access for
Piping and Electric
(Note 2)
1193
L.H.
Rear Access
for Piping
and Electric
(Note 2)
Discharge Air
Grille
Removable
Cabinet
