BLAUBERG Ventilatoren KOMFORT EC DB160 R S11 User manual

Heat recovery air Handling unit
KOMFORT EC DB160 R S11
KOMFORT EC DB160 L S11
KOMFORT EC DB250 R S11
KOMFORT EC DB250 L S11
KOMFORT EC DB350 R S11
KOMFORT EC DB350 L S11
KOMFORT EC DB160 R S14
KOMFORT EC DB160 L S14
KOMFORT EC DB250 R S14
KOMFORT EC DB250 L S14
KOMFORT EC DB350 R S14
KOMFORT EC DB350 L S14
USER’S MANUAL
EN

CONTENTS
Safety requirements..................................................................................................................................................................... 2
Purpose................................................................................................................................................................................................ 4
Delivery set........................................................................................................................................................................................ 4
Technical data.................................................................................................................................................................................. 5
Unit design and operating principle................................................................................................................................. 7
Installation and set-up................................................................................................................................................................ 10
Connection to power mains and unit control ............................................................................................................ 13
Technical maintenance.............................................................................................................................................................. 15
Storage and transportation regulations.......................................................................................................................... 16
Manufacturer’s warranty........................................................................................................................................................... 17
Certificate of acceptance.......................................................................................................................................................... 19
Seller information.......................................................................................................................................................................... 19
Installation certificate.................................................................................................................................................................. 19
Warranty card................................................................................................................................................................................... 19
UNIT INSTALLATION AND OPERATION SAFETY PRECAUTIONS
• Disconnect the unit from power mains prior
to any installation operations. • Unpack the unit with care.
• The unit must be grounded!
• While installing the unit, follow the safety
regulations specific to the use of electric
tools.
• Do not change the power cable length
at your own discretion. Do not bend the
power cable. Avoid damaging the power
cable. Do not put any foreign objects on the
power cable.
• Do not lay the power cable of the unit in
close proximity to heating equipment.
www.blaubergventilatoren.de KoMFort ec dB160/250/350 r/l S11/S14
2
This user’s manual is a main operating document intended for technical, maintenance, and operating staff.
The manual contains information about purpose, technical details, operating principle, design, and installation of the
KOMFORT EC DB160/250/350 R/L S11/S14 unit and all its modifications.
Technical and maintenance staff must have theoretical and practical training in the field of ventilation systems and should be able to
work in accordance with workplace safety rules as well as construction norms and standards applicable in the territory of the country.
The information in this user’s manual is correct at the time of the document’s preparation.
The Company reserves the right to modify the technical characteristics, design, or configuration of its products at any time in order to
incorporate the latest technological developments.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means in any information
search system or translated into any language in any form without the prior written permission of the Company.
SAFETY REQUIREMENTS
• Please read the user’s manual carefully prior to installing and operating the unit.
• All user’s manual requirements as well as the provisions of all the applicable local and national construction, electrical, and technical
norms and standards must be observed when installing and operating the unit.
• The warnings contained in the user’s manual must be considered most seriously since they contain vital personal safety
information.
• Failure to follow the rules and safety precautions noted in this user’s manual may result in an injury or unit damage.
• After a careful reading of the manual, keep it for the entire service life of the unit.
• While transferring the unit control, the user’s manual must be turned over to the receiving operator.

• Do not use damaged equipment or cables
when connecting the unit to power mains.
• Do not operate the unit outside the
temperature range stated in the user’s
manual. Do not operate the unit in
aggressive or explosive environments.
• Do not touch the unit controls with wet
hands. Do not carry out the installation and
maintenance operations with wet hands.
• Do not wash the unit with water. Protect
the electric parts of the unit against ingress
of water.
• Do not allow children to operate the unit. • Disconnect the unit from power mains prior
to any technical maintenance.
• Do not store any explosive or highly
flammable substances in close proximity to
the unit.
• When the unit generates unusual sounds,
odour, or emits smoke, disconnect it from
power supply and contact the Seller.
• Do not open the unit during operation. • Do not direct the air flow produced by the
unit towards open flame or ignition sources.
• Do not block the air duct when the unit is
switched on.
• In case of continuous operation of the unit,
periodically check the security of mounting.
• Do not sit on the unit and avoid placing
foreign objects on it. • Use the unit only for its intended purpose.
www.blaubergventilatoren.de
KoMFort ec dB160/250/350 r/l S11/S14
3
THE PRODUCT MUST BE DISPOSED SEPARATELY AT THE END OF ITS SERVICE LIFE.
DO NOT DISPOSE THE UNIT AS UNSORTED DOMESTIC WASTE.

KOMFORT EC DB160/250/350 R/L S11 KOMFORT EC DB160/250/350 R/L S14
Name Number Name Number
Air handling unit 1 pc. Air handling unit 1 pc.
User's manual 1 pc. User’s manual 1 pc.
Control panel 1 pc. Control panel 1 pc.
Control panel user's manual 1 pc. Mounting box for wall flush mounting 1 pc.
Packing box 1 pc. Mounting box for wall surface mounting 1 pc.
Fastening kit 1 pc.
Packing box 1 pc.
DESIGNATION KEY
KOMFORT EC D B X L S14
Automation type (control panel type)
Service side
L - left service side
R - right service side
Rated air ow [m3/h]
Additional components
B – bypass
Spigot orientation
D– suspended mounting, horizontal spigot
orientation
Motor type
EC – electronically commutated
Unit type
www.blaubergventilatoren.de KoMFort ec dB160/250/350 r/l S11/S14
4
The unit is designed to ensure continuous mechanical air exchange in houses, offices, hotels, cafés, conference halls, and other utility
and public spaces as well as to recover the heat energy contained in the air extracted from the premises to warm up the filtered stream
of supply air.
The unit is not intended for organizing ventilation in swimming pools, saunas, greenhouses, summer gardens, and other spaces with
high humidity.
Due to the ability to save heating energy by means of energy recovery, the unit is an important element of energy-efficient premises.
The unit is a component part and is not designed for stand-alone operation.
It is rated for continuous operation.
Transported air must not contain any flammable or explosive mixtures, evaporation of chemicals, sticky substances, fibrous materials,
coarse dust, soot and oil particles or environments favourable for the formation of hazardous substances (toxic substances, dust,
pathogenic germs).
Relative humidity of transported air must not exceed 80 % at an ambient temperature of +20 °C.
THE UNIT SHOULD NOT BE OPERATED BY CHILDREN OR PERSONS WITH REDUCED
PHYSICAL, MENTAL, OR SENSORY CAPACITIES, OR THOSE WITHOUT
THE APPROPRIATE TRAINING.
THE UNIT MUST BE INSTALLED AND CONNECTED ONLY BY PROPERLY QUALIFIED
PERSONNEL AFTER THE APPROPRIATE BRIEFING.
THE CHOICE OF UNIT INSTALLATION LOCATION MUST PREVENT UNAUTHORIZED
ACCESS BY UNATTENDED CHILDREN.
PURPOSE
DELIVERY SET

TECHNICAL DATA
MODEL KOMFORT EC DB160 KOMFORT EC DB250 KOMFORT EC DB350
Supply voltage, 50 (60) Hz [V] 1~ 220 – 240
Nominal power consumption [W] 50 101 170
Current [A] 0.4 0.8 1.3
Maximum air flow [m3/h] 190 270 410
RPM, min-1 3770 4480 3200
Sound pressure level at 3 m distance [dBA] 26 28 34
Transported air temperature [°C] from -25 up to +40
Casing material aluzinc steel
Insulation 40 mm mineral wool 40 mm mineral wool 40 mm mineral wool
Extract filter G4
Supply filter F7
Connected air duct diameter [mm] Ø 125 Ø 125 Ø 160
Weight [kg] 48 48 70
Heat recovery efficiency from 82 up to 94 % from 80 up to 98 % from 80 up to 91 %
Heat exchanger type counter-flow
Heat exchanger material aluminium
The unit is designed for indoor application with the ambient temperature ranging from +1 °C up to +40 °C and relative humidity up to 80 %.
In order to prevent condensation on the internal walls of the units, it is necessary that the surface temperature of the casing is 2-3 °C higher
than the dew point temperature of the transported air.
The unit is rated as a Class I electrical appliance.
Hazardous parts access and water ingress protection rating:
• IP22 for the unit connected to the air ducts
• IP44 for the unit motors
The unit design is constantly being improved, thus some models may be slightly different from those described in this manual.
www.blaubergventilatoren.de
KoMFort ec dB160/250/350 r/l S11/S14
5
TECHNICAL DATA

RIGHT-HANDED MODIFICATION
LEFT-HANDED MODIFICATION
H1
H
A2
A
A1
B1 B3 ØD
Ø16
Ø10,2
8 holes
B2
B
AB
L3
L5 L L2
L4
A view (indoor connection)
B view (outdoor connection)
L4
L2 L1 L6
L3
L3
L5 L L2
L4
A view (outdoor connection)
B view (indoor connection)
L4
L2 L1 L6
L3
Model Dimensions [mm]
ØD A A1 A2 B B1 B2 B3 H H1 L L1 L2 L3 L4 L5 L6
KOMFORT EC DB160 125 1008 1105 1073 754 822 480 410 320 361 386 293 245 31 128 123 216
KOMFORT EC DB250 125 1008 1105 1073 754 822 480 410 320 361 386 293 245 31 128 123 216
KOMFORT EC DB350 160 1093 1190 1158 1000 1068 680 610 273 316 555 417 323 29 108 122 260
www.blaubergventilatoren.de KoMFort ec dB160/250/350 r/l S11/S14
6

The unit has the following operating logic: warm stale extract air from the room flows into the unit, where it is filtered by the extract filter,
then air flows through the heat exchanger and is exhausted outside by the extract fan. Cold fresh air from the outside flows into the unit,
where it is cleaned by the supply filter.
Then the air flows through the heat exchanger and is directed to the room with the supply fan. Heat energy of warm extract air is
transferred to clean intake fresh air from the outside and warms it up. The air flows are fully separated while flowing through the heat
exchanger. Heat recovery minimizes heat losses, which reduces the cost of space heating in the cold season.
The difference between the supply and extract air flow temperature leads to condensate generation. Condensate is collected in the drain
pan and is removed outside through the drain pipe.
The KOMFORT EC DB160/250/350 R/L S11 unit assembly
Control panel
Detachable service plates for filter
maintenance operations
Service side
Outdoor temperature sensor
Supply air temperature sensor
Supply fan
Extract fan
Control unit
Bypass damper
Extract filter
Drain pan
Drain pipes
Counter-flow heat exchanger
Supply filter
Temperature sensor for heat
exchanger freeze protection
FS1 humidity sensor*
Electric lead-ins
EVH duct heater
for supply air pre-heating
* Accessories for the unit available on separate order
• FS1 humidity sensor. The unit with the installed humidity sensor maintains a set indoor humidity level. As the humidity level of the
extract air reaches the set point, the unit switches to the maximum speed automatically. As the humidity drops down below the set
point, the unit returns to the previous mode. Installation and connection of the humidity sensor (see page 10) is carried out on site
by the service technician.
• EVH duct heater for supply air pre-heating. The heater maintains the duct air temperature at a point that prevents the heat
exchanger freezing. An automation system regulates heater operation.
www.blaubergventilatoren.de
KoMFort ec dB160/250/350 r/l S11/S14
7
UNIT DESIGN AND OPERATING PRINCIPLE

The KOMFORT EC DB160/250/350 R/L S14 unit assembly
Control panel
Supply fan
Extract fan
Control unit
Bypass damper
Drain pipes
Detachable service plates for filter
maintenance operations
Service side
Outdoor temperature sensor
Extract filter
Drain pan
Counter-flow heat exchanger
Supply filter
Temperature sensor for heat
exchanger freeze protection
FS2 humidity sensor*
Electric lead-ins
The service side of the unit is equipped with detachable plates fixed by screws for filter cleaning and replacement operations. The control
unit is positioned inside the unit casing .
The power cable and grounding cables are connected to the control unit via the electric lead-ins placed at the side of the unit. The
difference between the supply and extract air flow temperature leads to condensate generation. Condensate is collected in the drain pan
and is removed outside through the drain pipes.
*At the request of the customer the unit can be equipped with an FS2 humidity sensor. The humidity sensor is purchased separately as
an accessory.
The unit with the installed humidity sensor maintains a set indoor humidity point. As the extract air humidity rises above the set point, the
system automatically switches to the maximum speed. As the humidity drops down below the set point, the unit returns to the previous
mode. Installation and connection of the humidity sensor is carried out on site by the service technician.
RIGHT-HANDED AND LEFT-HANDED MODIFICATIONS
The figure below shows the arrangement of spigots for left- and right-handed modifications. Choosing the right arrangement can
improve the ease of installation, shorten the length of the ducts and reduce the number of air duct bends.
EXTRACT AIR EXTRACT AIR
LEFTHANDED MODIFICATION RIGHTHANDED MODIFICATION
SUPPLY AIR SUPPLY AIR
INTAKE AIR
CONTROL UNIT
EXHAUST AIREXHAUST AIR INTAKE AIR
HEAT EXCHANGER WITH
A DRAIN PAN
BYPASS DAMPER
EXTRACT FAN
SUPPLY FAN
SUPPLY AIR FILTER
EXTRACT AIR FILTER
EXTRACT AIR EXTRACT AIR
LEFTHANDED MODIFICATION RIGHTHANDED MODIFICATION
SUPPLY AIR SUPPLY AIR
INTAKE AIR
CONTROL UNIT
EXHAUST AIREXHAUST AIR INTAKE AIR
HEAT EXCHANGER WITH
A DRAIN PAN
BYPASS DAMPER
EXTRACT FAN
SUPPLY FAN
SUPPLY AIR FILTER
EXTRACT AIR FILTER
www.blaubergventilatoren.de KoMFort ec dB160/250/350 r/l S11/S14
8

UNIT OPERATION MODES
Heat recovery mode: warm stale extract air from the room flows into the unit, where it is filtered by the extract filter, then air flows
through the heat exchanger and is exhausted outside by the extract fan.
Cold fresh air from the outside flows into the unit, where it is cleaned by the supply filter.
Then the air flows through the heat exchanger and is directed to the room with the supply fan.
Supply air is heated in the heat exchanger by transferring the heat energy of warm and humid extract air to the cold fresh air. The air
flows are fully separated while flowing through the heat exchanger. Heat recovery minimizes heat losses, which reduces the cost of space
heating in the cold season.
EXTRACT AIR
SUPPLY AIR
INTAKE AIR
EXHAUST AIR
EXTRACT AIR
SUPPLY AIR
INTAKE AIR
EXHAUST AIR
Defrosting mode: to prevent the heat exchanger freezing in the cold season the unit has an automatic Defrosting mode. This mode
is activated by the freeze protection temperature sensor located in the exhaust air duct downstream of the heat exchanger. The unit
switches to the Defrosting mode at the extract air temperature +3 ° C. As the temperature rises the unit returns to the previous mode.
Only the extract fan operates in the Defrosting mode, the supply fan is switched off.
EXTRACT AIR
SUPPLY AIR
INTAKE AIR
EXHAUST AIR
EXTRACT AIR
SUPPLY AIR
INTAKE AIR
EXHAUST AIR
Summer Cooling mode: the bypass damper is opened, the intake air that is supplied to the premises bypasses the heat exchanger. The
intake air temperature remains constant.
EXTRACT AIR
SUPPLY AIR
INTAKE AIR
EXHAUST AIR
EXTRACT AIR
SUPPLY AIR
INTAKE AIR
EXHAUST AIR
www.blaubergventilatoren.de
KoMFort ec dB160/250/350 r/l S11/S14
9

INSTALLATION AND SETUP
FS1 HUMIDITY SENSOR INSTALLATION AND CONNECTION IN KOMFORT EC DB160/250/350 R/L S11 UNITS
The SF1 humidity sensor is not included in the delivery set and can be ordered separately.
Remove the service panel and install the humidity sensor into the mount from the side of the extract air duct and connect the humidity
sensor connector to the respective contact socket coming from the control unit.
EVH HEATER MOUNTING IN KOMFORT EC DB160/250/350 R/L S11 UNITS
The EVH heater is not included in the delivery set and can be ordered separately.
The heater is rated for connection to single-phase AC 230 V/50 (60) Hz.
Attach the heater to the air duct connected to the supply air spigot.
The electric heater an the air handling unit must be connected via the cable with the prewired connectors DB-9F.
www.blaubergventilatoren.de KoMFort ec dB160/250/350 r/l S11/S14
10
READ THE USER'S MANUAL BEFORE INSTALLING THE UNIT.

HUMIDITY SENSOR INSTALLATION AND CONNECTION IN KOMFORT EC DB160/250/350 R/L S11/S14 UNITS
The humidity sensor is not included in the delivery set and can be ordered separately.
Mounting sequence:
• Remove the mounting screws of the service side panel and take it off. Install the humidity sensor into the mount on the inner side
of the casing near the extract air duct and connect the connector to the respective contact socket coming from the control unit,
refer to the External wiring diagram.
• Install the service panel back to the unit.
UNIT INSTALLATION
To attain the best performance of the unit and to minimise turbulence-induced air pressure losses connect the straight air duct section
to the spigots on both sides of the unit while mounting.
Minimum straight air duct length:
• equal to 1 air duct diameter on the intake side
• equal to 3 air duct diameters on the outlet side
If the air ducts are too short or not connected, protect the unit parts from ingress of foreign objects. To prevent uncontrollable access to
the fans, the spigots may be covered with a protecting grille or other protecting device with mesh width not more than 12.5 mm.
While installing the unit, ensure convenient access for subsequent maintenance and repair.
Fasteners for ceiling mounting are not included in the delivery set and should be ordered separately. While choosing fasteners consider
the material of the mounting surface as well as the weigh of the unit, refer to the Technical data section. Fasteners for unit installation
should be selected by a qualified technician.
Wall and ceiling mounting examples
Nut
Washer
Vibration absorbing rubber
www.blaubergventilatoren.de
KoMFort ec dB160/250/350 r/l S11/S14
11

WALLMOUNTED CONTROL PANEL INSTALLATION
Control panel wall surface or flush mounting are available.
Examples of wall flush mounting using a mounting box are shown in the control panel user’s manual.
The mounting box and the fastening kit for the units with an S11 automation are purchased separately.
CONDENSATE DRAINAGE
Connect the drain pipe to the sewage system using the SFK 20x32 U-trap kit (available upon separate order). The pipe slope downwards
must be at least 3°.
min 3°
min 3°
Drain hose
U-trap
Sewage system
Drain pipe
Drain hose
U-trap
Sewage system Drain pipe
Drain hose Drain hose
min 3°
min 3°
The condensate drainage system is designed for normal operation in premises with air temperatures above 0 °C!
If the expected ambient air temperatures are below 0 °C, the condensate drainage system must be equipped with heat insulation and
pre-heating facilities.
www.blaubergventilatoren.de KoMFort ec dB160/250/350 r/l S11/S14
12

CONNECTION TO POWER MAINS AND UNIT CONTROL
The air-handling unit is rated for connection to single-phase AC 230 V/50 (60) Hz mains. The unit has a power cord with a plug to connect
to a standard grounded outlet. The power cord is pre-wired to the terminal block.
The external power input must be equipped with an automatic circuit breaker built into the stationary wiring to open the circuit in the
event of overload or short-circuit. The circuit breaker trip current is selected based on data of the “Technical data” section.
The position of the circuit breaker must ensure free access for quick unit power-off.
CONNECTION OF ADDITIONAL EXTERNAL CONTROLS TO THE KOMFORT EC DB160/250/350 R/L S11 UNITS
The unit has an option of connection of additional external controls
• DX cooler
• Electric actuator of outer supply and exhaust air dampers
• Fire alarm panel
The unit controls must be connected to the X1 terminal block, which is located in the control unit. The cables are connected to the
control unit via the electric lead-ins.
If intake air cooling is needed, the DX cooler operating signal closes the contacts 8 and 9 to allow operating of the cooler and opens them
to block the operation. The permissible current via the power contacts must not exceed 2 A, 230 V.
When connecting the supply and/or exhaust air dampers to the contacts 4 and 5 of the external connection terminals, electric voltage
230 V/50 (60) Hz is supplied to the above terminals when the air dampers must be opened and is cut off when the air dampers must be
closed. The automatic fire extinguishing system contact is connected to the contacts 6 and 7 (X1 terminal). The contact must be normally
open. If the fire alarm signal turns on, the contact closes that results in equipment shutdown.
External control units wiring diagram
ССU
(no-contact)
Power input 230 VAC
Х1
Electric shock hazard!
1
L
2
N
3
PE
4
L
5
N
6
c
7
no
8
c
9
no
10
+12V
11
GND
12
B
13
A
14
+5V
15
GND
16
Vo
SM1*
12
NL
SM2*
12
NL
PK1*
21
P1
Gnd AB
+12V
t °C
TE1
Gnd Vo+5V
White
Green Brown Yellow
Designation Name Model Wire**
CCU* DX cooler N0 2x0.75 mm2
S1* Supply air damper actuator LF 230 2x0.75 mm2
S2* Extract air damper actuator LF 230 2x0.75 mm2
1* Contact from a fire alarm panel N0 2x0.75 mm2
1 Control panel
1 Outdoor temperature sensor The sensor is installed by the manufacturer in the intake air duct.
*Is not included in the delivery set ** Maximum connecting cable length is 20 m!
www.blaubergventilatoren.de
KoMFort ec dB160/250/350 r/l S11/S14
13
ANY TAMPERING WITH THE INTERNAL CONNECTIONS IS PROHIBITED
AND WILL VOID THE WARRANTY.
POWER OFF THE POWER SUPPLY PRIOR TO ANY OPERATIONS WITH THE UNIT.
THE UNIT MUST BE CONNECTED TO POWER SUPPLY BY A QUALIFIED ELECTRICIAN.
THE RATED ELECTRICAL PARAMETERS OF THE UNIT ARE GIVEN ON THE
MANUFACTURER’S LABEL.

CONNECTION OF ADDITIONAL EXTERNAL CONTROLS TO THE KOMFORT EC DB160/250/350 R/L S14 UNITS
The unit has an option of additional external controls connection to the X2 terminal block, which is located on the hinged electrical
mounting plate of the control unit. Extra connections to the unit are shown in dotted lines in the External wiring diagram.
Connection of the automatic re ghting system contact (PK).
Upon connecting the automatic fire extinguishing system contact remove the jumper between the terminals 1 and 2. In case of fire
the normally closed dry contact breaks the control circuit from the central fire-fighting board and cuts off power supply to the unit.
Connection of the external control unit contact, such as CO2sensor (NO, C terminals).
Connect the CO2sensor to the terminals 6 and 7 by using a normally closed dry contact. If the dry contact is closed, the unit turns to the
maximum speed.
FS2 (+U, 0-10V, GND) humidity sensor connection.
Connect the FS2 humidity sensor (not included in the delivery set, can be ordered separately) to the contact socket located on the side
panel of the control unit from the side of the extract pipe in accordance with the External wiring diagram.
Connection of outer air dampers (SM1 supply air damper, SM2 exhaust air damper).
The air dampers and the actuator are not included in the delivery set and can be purchased separately.
For controlling the air dampers use the LF 230 BELIMO electric actuator with a voltage of 230 V and an open-close controlling. Connect
the electric actuators to the 12 and 13 terminals (refer to the External wiring diagram).
External control units wiring diagram:
Power input 230 VAC
Electric shock hazard!
11
L
22
N
33
PE PK PK +U +U0-10V
44 5 6 7 8910 11 12 13
White
Green
Brown
Yellow
External device
NO (CO2sensor))
Control panel
-Tx Rx +
Tx Rx
3
2
1
GND
+U
0 -10V
GND GNDNО C
X1 X2
SM-L SM-N
Humidity sensor
Electric actuators
of the external air dampers
SM1
supply
L1 N
SM2
exhaust
L1 N
PK fire alarm panel
(remove the jumper while connecting the contact)
The unit is operated with the control panel. For detailed information, read the control panel user’s manual.
To work with the pre-installed software connect the KOMFORT EC DB160/250/350 R/L S14 unit to a laptop or to a PC via a USB cable with
the Type A and Type В contact sockets.
The USB cable is not included in the delivery set.
USB Type A
USB Type B
www.blaubergventilatoren.de KoMFort ec dB160/250/350 r/l S11/S14
14

Maintenance operations of the unit are required 3-4 times per year. Maintenance includes general cleaning of the unit and the following
operations:
1. Filter maintenance (3-4 times per year).
Dirty filters increase air resistance in the system and reduce supply
air volume. The filters require cleaning not less than 3-4 times per
year. Vacuum cleaning is allowed. After two consecutive cleanings
filters must be replaced. For new filters, contact the Seller.
To clean or replace the filters, detach the removable plates located
on the service side of the unit. After cleaning install the filters and
the detachable plates in the reverse order.
2. Heat exchanger maintenance (once per year).
Some dust may accumulate on the heat exchanger even in case
of regular maintenance of the filters. To maintain the high heat
recovery efficiency, regular cleaning is required.
The heat exchanger is connected with the drain pan by the fixing
bands that should be removed only in case of heat exchanger
replacement.
The drain pan is fixed to the unit casing using three screws.
To clean the heat exchanger pull it and the drain pan out, drain the
water through the pipes, then flush the heat exchanger with warm
detergent solution. After cleaning install the dry heat exchanger
with the drain pan back to the unit.
www.blaubergventilatoren.de
KoMFort ec dB160/250/350 r/l S11/S14
15
DISCONNECT THE UNIT FROM POWER SUPPLY BEFORE
ANY MAINTENANCE OPERATIONS!
TECHNICAL MAINTENANCE

3. Fan maintenance (once per year).
Even in case of regular maintenance of the filters, some dust may accumulate inside the fans and reduce the fan performance and supply
air flow. Clean the fans with a soft brush or cloth. Do not use water, aggressive solvents, or sharp objects as they may damage the impeller.
4. Technical maintenance of condensate drainage system (once a year).
The condensate drainage (drain line) may get clogged by dirt and dust particles contained in the exhaust air. Pour some water inside the
drain pan to check the pipe for clogging. Clean the U-trap and the drain pipe if required.
5. Ductwork system maintenance (once in 5 years).
Even regular fulfilling of all the maintenance operations prescribed above may not completely prevent dirt accumulation in the air ducts,
which leads to air pollution and reduces the unit capacity. Duct maintenance means regular cleaning or replacement.
6. Control unit maintenance (if necessary).
The control unit is positioned inside the unit casing. For accessing the control unit remove the fixing screws on the service panel and
remove it.
CAUTION! The control unit maintenance must be performed by an expert qualied for unassisted operations with electrical
installations with the voltage up to 1000 V after careful reading of the user’s manual.
TROUBLESHOOTING
Problem Possible reasons Troubleshooting
The fan(s) do(es) not get
started. No power supply.
Make sure the power supply line is connected
correctly, otherwise troubleshoot a connection
error.
Low air flow. Filters, fans or the heat exchanger are soiled. Clean or replace the filters, clean the fans, and the
heat exchanger.
The ventilation system is soiled or damaged. Make sure the air ducts are clean and intact.
Noise, vibration.
The fan impeller is soiled. Clean the impellers.
Fan screw connection is loose. Check tightening torques.
Water leakage. The drainage system is soiled, damaged, or
installed incorrectly.
Clean the drain line if necessary. Check the drain
line slope angle. Make sure that the U-trap is filled
with water and the drain pipes are frost protected.
www.blaubergventilatoren.de KoMFort ec dB160/250/350 r/l S11/S14
16
• Store the unit in the manufacturer’s original packaging box in a dry closed ventilated premise with temperature range
from +5 ˚С to +40 ˚С and relative humidity up to 70 %.
• Storage environment must not contain aggressive vapors and chemical mixtures provoking corrosion, insulation, and sealing
deformation.
• Use suitable hoist machinery for handling and storage operations to prevent possible damage to the unit.
• Follow the handling requirements applicable for the particular type of cargo.
• The unit can be carried in the original packaging by any mode of transport provided proper protection against precipitation and
mechanical damage. The unit must be transported only in the working position.
• Avoid sharp blows, scratches, or rough handling during loading and unloading.
• Prior to the initial power-up after transportation at low temperatures allow the unit to warm up at operation temperature for at least
3-4 hours.
STORAGE AND TRANSPORTATION REGULATIONS

www.blaubergventilatoren.de
KoMFort ec dB160/250/350 r/l S11/S14
17
FOLLOWING THE REGULATIONS STIPULATED HEREIN WILL ENSURE A LONG AND
TROUBLEFREE OPERATION OF THE UNIT.
USER’S WARRANTY CLAIMS SHALL BE SUBJECT TO REVIEW ONLY UPON
PRESENTATION OF THE UNIT, THE PAYMENT DOCUMENT AND THE USER’S MANUAL
WITH THE PURCHASE DATE STAMP.
The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby
declare that the product complies with the provisions of Electromagnetic Council Directive 2014/30/EU, Low Voltage Directive 2014/35/
EU and CE-marking Directive 93/68/EEC. This certificate is issued following test carried out on samples of the product referred to above.
The manufacturer hereby warrants normal operation of the unit for 24 month after the retail sale date provided the user's observance
of the transportation, storage, installation, and operation regulations. Should any malfunctions occur in the course of the unit operation
through the Manufacturer's fault during the guaranteed period of operation, the user is entitled to get all the faults eliminated by the
manufacturer by means of warranty repair at the factory free of charge. The warranty repair includes work specific to elimination of faults
in the unit operation to ensure its intended use by the user within the guaranteed period of operation. The faults are eliminated by means
of replacement or repair of the unit components or a specific part of such unit component.
The warranty repair does not include:
• routine technical maintenance
• unit installation/dismantling
• unit setup
To benefit from warranty repair, the user must provide the unit, the user's manual with the purchase date stamp, and the payment
paperwork certifying the purchase. The unit model must comply with the one stated in the user’s manual. Contact the Seller for warranty
service.
The manufacturer’s warranty does not apply to the following cases:
• User’s failure to submit the unit with the entire delivery package as stated in the user’s manual including submission with missing
component parts previously dismounted by the user.
• Mismatch of the unit model and the brand name with the information stated on the unit packaging and in the user's manual.
• User’s failure to ensure timely technical maintenance of the unit.
• External damage to the unit casing (excluding external modifications as required for installation) and internal components caused
by the user.
• Redesign or engineering changes to the unit.
• Replacement and use of any assemblies, parts and components not approved by the manufacturer.
• Unit misuse.
• Violation of the unit installation regulations by the user.
• Violation of the unit control regulations by the user.
• Unit connection to power mains with a voltage different from the one stated in the user's manual.
• Unit breakdown due to voltage surges in power mains.
• Discretionary repair of the unit by the user.
• Unit repair by any persons without the manufacturer’s authorization.
• Expiration of the unit warranty period.
• Violation of the unit transportation regulations by the user.
• Violation of the unit storage regulations by the user.
• Wrongful actions against the unit committed by third parties.
• Unit breakdown due to circumstances of insuperable force (fire, flood, earthquake, war, hostilities of any kind, blockades).
• Missing seals if provided by the user’s manual.
• Failure to submit the user’s manual with the unit purchase date stamp.
• Missing payment paperwork certifying the unit purchase.
MANUFACTURER’S WARRANTY

www.blaubergventilatoren.de KoMFort ec dB160/250/350 r/l S11/S14
18

www.blaubergventilatoren.de
KoMFort ec dB160/250/350 r/l S11/S14
19
Unit Type Heat recovery air handling unit
Seller’s Stamp
Model KOMFORT EC DB_______S___
Serial Number
Manufacture Date
Purchase Date
Warranty Period
Seller
Unit Type Heat recovery air handling unit
Model KOMFORT EC DB_______S___
Serial Number
Manufacture Date
Quality Inspector’s
Stamp
Seller
Seller’s Stamp
Address
Phone Number
E-mail
Purchase Date
This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are
acknowledged and accepted.
Customer’s Signature
The KOMFORT EC DB_______S___ unit has been connected to power mains pursuant to the
requirements stated in the present user’s manual.
Installation Stamp
Seller
Address
Phone Number
Installation
Technician’s Full Name
Installation Date: Signature:
The unit has been installed in accordance with the provisions of all the applicable local and national construction,
electrical and technical codes and standards. The unit operates normally as intended by the manufacturer.
Signature:
CERTIFICATE OF ACCEPTANCE
SELLER INFORMATION
INSTALLATION CERTIFICATE
WARRANTY CARD

www.blaubergventilatoren.de
B108EN-03
