2. Location of controls
2.1. Front side
1. Speakers (left / right)
2. DBBS LED light
3. Volume knob
4. Function switch
(AUX / RADIO / CD /
OFF)
5. Radio band switch
(AM/FM) & DBBS
OFF/ON switch
6. Radio tuning knob
7. CD “REPEAT” key
8. CD “STOP” key
9. Power LED light
10. IR sensor
11. Display
12. CD “BACK” key
13. CD “PLAY/PAUSE” key
14. CD “NEXT” key
15. CD “PROGRAM” key
2 3 4 5 6 1
1
10
9 15
7 8
11 12 14
13

Location of controls
Version 1 cmx® MSC 7320 Seite 6 von 16
2.2. Rear side
1. Headphone socket
2. Speaker output sockets
(left & right)
3. AUX input socket
4. AC-cord & plug
5. FM-antenna wire
4
1 2 2 3
5

Location of controls
Version 1 cmx® MSC 7320 Seite 7 von 16
2.3. Remote control
1. „PLAY/PAUSE“ key
2. „BACK“ key
3. „REPEAT“ key
4. „STOP“ key
5. „NEXT“ key
6. „RANDOM“ key
7. „PROGRAM“ key
8. Battery compartment
Remove the protective transparent cover which wraps the
outside of the remote control.
Remove (gently pull out) the plastic “TAB” from the battery
compartment at the rear of the remote control.
2 5
1
3
4
6
7
8

Included in delivery
Version 1 cmx® MSC 7320 Seite 8 von 16
3. Included in delivery
User’s manual Warranty card
Remote control

Connections
Version 1 cmx® MSC 7320 Seite 9 von 16
4. Connections
4.1. Power Supply
This set works on normal household AC-power.
Make sure the set voltage of unit matches your local voltage.
Insert the plug of the AC-cord into a wall outlet with AC-
power.
How to switch the unit “on”
To switch on the set, slide the function switch to “AUX”, “CD” or
“RADIO” as desired.
4.2. Speakers
Unwrap the speaker-cords of both speaker-boxes and insert
the left/right plugs into sockets in the rear of main unit
(see point 1 – location of controls).
Place the speaker-boxes as far apart as possible for best
sound effect.
4.3. AUX input
You can connect the audio output of an external device such as a
MP3 player to this unit, to listen to the sound of that device through
the high quality amplifier of this music system.
To connect the external device please use a standard stereo
headphone (3,5 mm to 3,5 mm plugs) cable to connect the
“headphone-out or audio line-out” of the device to the AUX-input
socket of this unit.

Connections
Version 1 cmx® MSC 7320 Seite 10 von 16
Set the function switch to “AUX”.
Make sure that the speakers are connected to the main unit.
Switch on the power of the external device (eg. MP3 player).
Start playback of the external device and adjust the volume
control of the main unit to the desired level.
Remember to switch off the unit when you are finished using
the external device.
4.4. Headphone
To connect the headphones or earphones insert the cable
into socket on the rear of main unit (see point 1 – location of
controls / rear side).
