Cobra HD 5200 User manual

Please read through this user manual before using the product
and keep the manual for future reference. Product appearance
and/or specifications are subject to change without notice. Before
using this camera, please insert a micro SD card (class 10 card, no
larger than 32GB) into the Adventure HD 5200 camera. Camera
functions will not work without a micro SD card inserted into the
camera. Please note the camera does not include a micro SD card
inside the package, the micro SD card must be purchased
separately.
Adventure Series by Cobra
6500 W. Cortland St., Chicago, IL 60707
1 [phone]

Adventure HD 5200 User Manual
01 August2016 Page 2
Table of Contents
Preface .............................................................................3
Manual Disclaimer ..............................................................3
Safety Precautions ..............................................................3
System Requirements ..........................................................4
Features ............................................................................5
Camera Function Quick Guide Diagram ...................................6
Accessories ........................................................................8
Button Primary Functions .....................................................9
Basic Camera Functions ......................................................10
Installing the Micro SD Card...........................................10
Battery ............................................................................10
Switching Camera On and Off..............................................11
Switching Modes & Changing Settings ...................................11
Camera Modes ................................................................. 11
Video Recording Mode .................................................11
Photo Mode ...............................................................12
Video Playback Mode ...................................................12
Settings Menu.............................................................13
Screen Icons.....................................................................15
Video Mode Screen Icons ..............................................15
Photo Mode Screen Icons ..............................................16
Review Mode Screen Icons ............................................16
Connecting to External Devices ............................................17
Playback on HD TV .......................................................17
View Files on PC / MAC .................................................17
Webcam –PC Only.......................................................17
Technical Specifications ......................................................18
Copyright.........................................................................19

Adventure HD 5200 User Manual
01 August2016 Page 3
Preface
This product is an action-sports camera tailored to meet the demands
of today’s active lifestyles! This action camera is perfect for vehicle
data recording, photography, outdoor sports, home security, and
watersports. It allows you to film anytime, anywhere.
Manual Disclaimer
Every effort has been made to ensure that the contents of this manual
are correct and up to date. However, no guarantee is made regarding
the accuracy ofthe contents. The manufacturer reserves the right to
change the manual contents and product specifications withoutnotice.
Safety Precautions
 Do not store the product in dusty, dirty, or sandy areas, as its
internal components may be damaged.
 Do not store the product in hot areas. High temperatures can
shorten the life of electronic devices, damage batteries and
warp or melt certain plastics.
 Do not store the product in cold areas. When the product
warms up to its normal temperature, moisture can form inside,
which may damage the electronic circuits.
 Do not attempt to open the casing or attempt your own repairs.
High-voltage internal components create the risk ofelectric
shockwhen exposed.
 Do not drop or knock the product. Rough handling may
damage the internal components.
 Do not use harsh chemicals, cleaning solvents or strong
detergents to clean the product. Wipe the product with
a slightly damp softcloth.
 Do not open the battery cover while an image is being
recorded. Doing so will not only make storage of the current
image impossible, it can also corrupt other image data already
stored on the SD card.

Adventure HD 5200 User Manual
01 August2016 Page 4
 If the product or any of its accessories are not working
properly, please contact Cobra Electronics at
[phone]. Our staff will assist you and if necessary,
arrange for the product to be repaired or replaced.
 Test for proper operation before using the camera.
 Cobra Electronics is not responsible for any collisions, damage or
personal injuries resulting from the use of the Adventure HD
Action Camera.
 Cobra Electronics is not responsible for any legal repercussions
from use of the Adventure HD Action Camera or from the sharing
of footage.
Cobra Electronics is not responsible for any property damage or
lost/stolen Adventure HD Action Cameras.
System Requirements
The camera requires a computer with the following minimum
specifications for full HD video playback:
Windows® 7 / MAC OS X 10.8
Intel® Core Duo™ / AMD Dual-Core CPU
2 GB of RAM
DirectX 9 compatible graphics solution
Available hard disk space

Adventure HD 5200 User Manual
01 August2016 Page 5
The camera requires a computer with the following minimum
specifications for WVGA/VGA video playback:
Windows® Vista / MAC OS X 10.5
Intel® / AMD Dual-Core CPU
1 GB of RAM
DirectX 9 compatible graphics solution
Available hard disk space
Minimum requirements for connecting the camera to a PC or Mac:
Standard USB 2.0 port
Features
The camera and its included accessories offer a variety of features and
functions including:
A water-resistant case that allows you to film underwater up to 30
meters
High definition screen that displays and plays back recorded
videos
Removable battery that is easy to replace with a spare to prolong
the recording time of the camera
Video recording while charging
Video recording while battery powered
HD wide-angle lens
HDMI output
Web camera
Supports memory cards up to 32GB maximum storage space, class
10
Multiple video recording formats: 1080P (interpolated) / 720P /
WVGA
Records video in .AVI format
Multiple photo shooting modes: Single shot, Burst, and
Continuous Shooting (Time-lapse)
Compact size

Adventure HD 5200 User Manual
01 August2016 Page 6
Camera Function Quick Guide Diagram

Adventure HD 5200 User Manual
01 August2016 Page 7

Adventure HD 5200 User Manual
01 August2016 Page 8
Accessories
The following items are included in the camera package. If any items are
missing or damaged, contact Cobra immediately.
Waterproof Camera Casing
Adventure HD Camera
Camera Holder
Straight Joint Mounts x3
J-Hook Buckle Mount
Tripod Mount
Basic Buckle Mount
Tripod Mount Adapter
Flat / Curved Adhesive Mounts
Velcro Straps x3
Micro USB Charging Cable
Cleaning Cloth
Adventure HD 5200 Instruction Manual
Zip Ties x4 / 3M Stickers x2

Adventure HD 5200 User Manual
01 August2016 Page 9
Button Primary Functions
Button
Function
Power / Mode Button
Turn the camera on & off.
Change between Video mode,
Photo mode, Playback mode,
and settings menu.
OK Button
OK
Enter and confirm settings in
the settings menu.
Up Button
Scroll up through the settings.
Scroll through videos/photos in
playback mode.
Down Button
Scroll down through the
settings.
Scroll through videos/photos in
playback mode.

Adventure HD 5200 User Manual
01 August2016 Page 10
Basic Camera Functions
Installing the Micro SD Card
To insert the SD card
Find the Micro SD card slot
Insert the card into the slot (make sure the card is facing the
correct way)
Push the card into the slot until it clicks
**Note –Please use a minimum speed Class 10 card, maximum 32GB
storage capacity. Cobra recommends a name brand card such as
Lexar®, SanDisk®, Kingston® or Gigastone.
Follow these steps in reverse order to remove the SD card
**Note - Please ensure that the SD Card is inserted in the correct
direction or you may damage the SD card and/or SD card reader.
Battery
 Use only the type of battery that came with the camera.
Using any other type of
battery may damage the equipment and invalidate the
warranty.
 Do not short the battery terminals. The battery could overheat.
 Do not attempt to split or peel the outer casing.
 Remove the battery if the camera is not going to be used for
a long time. If the battery is left unused for more than 3
months, charge the battery before use.
1. Installing and Removing Batteries
a. Press on battery cap to open it
b. Correctly install the battery into the camera as directed by
the +/- symbols
c. Remove Battery: Open the battery cap to take the battery
out
