Cockpit CKNHND1 User manual

Single On/Off D
ORDERING CODE
FREQUENCY
CKNHND1
868,4 MHz
This module is used for switching on or off the
electrical device (e.g. light or fan). The module can
be controlled either through wireless network or
through the wall switch. The module is designed to
be mounted inside a “flush mounting box”, hidden
behind a traditional wall switch.
Module supports connection of digital temperature
sensor. It is designed to act as repeater in order to
improve range and stability of wireless network.
Supported switches
Module supports mono-stable switches (push
button) and bi-stable switches. The module is
factory set to operate with bi-stable switches.
Installation
•To prevent electrical shock and/or equipment
damage, disconnect electrical power at the
main fuse or circuit breaker before installation
or any servicing.
•Make sure, that no voltage is present in the
installation.
•Prevent the disconnecting device from being
switched on accidentally.
•Connect the module according to electrical
diagram.
•Locate the antenna far from metal elements
(as far as possible).
•Do not shorten the antenna.
Danger of electrocution!
•Module installation requires a great degree of
skill and may be performed only by a qualified
and licensed electrician.
•Even when the module is turned off, voltage
may be present on its terminals.
Note!
Do not connect the module to loads exceeding
recommended values. Connect the module only in
accordance to the below diagrams. Improper
connections may be dangerous.
Electrical installation must be protected by
directly associated over current protection fuse
10A, gG or Time lag T, rated breaking capacity
1500V (ESKA 522.727) must be used according
to wiring diagram to achieve appropriate
overload protection of the module. The fuse
must be installed in fuse holder type: Adels
contact 503 Si / 1DS.
Electrical diagram 230VAC
Option for different load power supply - DPLS:
Notes for the diagrams:
N
Neutral lead
L
Live lead
Q
Input for electrical device power supply
Q
Output for electrical device
I2
Input for switch /push button or sensor
I1
Input for switch /push button
TS
Terminal for digital temperature sensor (only
for On/Off D relay module compatible digital
temperature sensor, which must be ordered
separately).
Wago 221-413 splicing connectors for L and N connection
must be used.
Electrical diagram 24VDC
Option for different load power supply - DPLS:
Notes for the diagrams:
N
+ VDC
L
- VDC
Q
Input for electrical device power supply
Q
Output for electrical device
I2
Input for switch /push button or sensor
I1
Input for switch /push button
TS
Terminal for digital temperature sensor (only
for On/Off D relay module compatible digital
temperature sensor, which must be ordered
separately).
Note!
Output contact is voltage free (dry contact), so also
loads with different power supply can be connected
to the module.
WARNING: Service button S must NOT be used
when module is connected to 110-230V power
supply.
Durability of the module depends on applied load.
For resistive load (light bulbs, etc.) and 10A current
consumption of each individual electrical device,
the durability exceeds 100.000 switches of each
individual electrical device.
Module Inclusion (Adding to Z-wave
network)
•Connect module to power supply (with
temperature sensor connected - if purchased),
•auto-inclusion (works for about 5 seconds after
connected to power supply) or
•press push button I1 three times within 3s (3
times change switch state within 3 seconds) or
•press service button S (only applicable for 24V
SELV supply voltage) for more than 2 second.
NOTE1: For auto-inclusion procedure, first set main
controller into inclusion mode and then connect
module to power supply.
NOTE2: When connecting temperature sensor to
module that has already been included, you have
to exclude module first. Switch off power supply,
connect the sensor and re-include the module.
Module Exclusion/Reset (Removing from
Z-Wave network)
•Connect module to power supply
•bring module within maximum 1 meter (3 feet)
of the main controller,
•enable add/remove mode on main controller
•press push button I1 five times within 3s (5
times change switch state within 3 seconds) in
the first 60 seconds after the module is
connected to the power supply or
•press service button S (only applicable for 24V
SELV supply voltage) for more than 6 second.
By this function all parameters of the module are
set to default values and own ID is deleted
If push button I1 is pressed three times within 3s (or
service button S is pressed more than 2 and less
than 6 seconds) module is excluded, but
configuration parameters are not set to default
values.
NOTE: If the module is included with parameter
100 with values different to default and module
reset is done, wait at least 30s before next inclusion.
Associations
Associations enables On/Off D Module module to
transfer commands inside Z-Wave network directly
(without main controller) to other Z-Wave modules.
Associated Groups:
Root device:
Group 1: Lifeline group (reserved for
communication with the main controller), 1 node
allowed.
Group 2: basic on/off (triggered at change of the
output state and reflecting its state) up to 16 nodes.
Group 3: basic on/off (triggered at change of the
input I2 state and reflecting its state) up to 16 nodes.
Group 4: Binary Sensor Report (triggered at
change of the input I2 state and reflecting its state)
up to 16 nodes.
Group 5: Notification Report (triggered at change of
the input I2 state and reflecting its state) up to 16
nodes.
Group 6: multilevel sensor report (triggered at
change of temperature sensor) up to 16 nodes.
Endpoint 1:
Group 1: Lifeline group, 0 nodes allowed.
Group 2: basic on/off (triggered at change of the
output state and reflecting its state) up to 16 nodes.
Endpoint 2:
Group 1: Lifeline group, 0 nodes allowed.
Group 2: basic on/off (triggered at change of the
input I2 state and reflecting its state) up to 16 nodes.
Group 3: Binary Sensor Report (triggered at
change of the input I2 state and reflecting its state)
up to 16 nodes.
Group 4: Notification Report (triggered at change of
the input I2 state and reflecting its state) up to 16
nodes.
End point 3:
Group 1: Lifeline group, 0 nodes allowed.
Group 2: multilevel sensor report (triggered at
change of temperature sensor) up to 16 nodes.
Configuration parameters
Parameter no. 1 – Input 1 switch type
Available configuration parameters (data type is 1
Byte DEC):
•default value 1
•0 - mono-stable switch type (push button)
•1 - bi-stable switch type
Parameter no. 2 – Input 2 contact type
Available configuration parameters (data type is 1
Byte DEC):
•default value 0
•0 - NO (normally open) input type
•1 - NC (normally close) input type
Parameter no. 10 - Activate / deactivate
functions ALL ON/ALL OFF
Available configuration parameters (data type is 2
Byte DEC):
•default value 255
•255 - ALL ON active, ALL OFF active
•0 - ALL ON is not active ALL OFF is not active
•1 - ALL ON is not active ALL OFF active
•2 - ALL ON active ALL OFF is not active
On/Off D Module module responds to commands
ALL ON / ALL OFF that may be sent by the main
controller or by other controller belonging to the
system.
Parameter no. 11 - Automatic turning off output
after set time
When relay is ON it goes automatically OFF after
time defined by this parameter. Timer is reset to
zero each time the module receive ON command
regardless from where it comes (push button,
associated module, controller,..).
Available configuration parameters (data type is 2
Byte DEC):
•default value 0
•0 - Auto OFF disabled
•1 - 32535 = 1second (0,01s) – 32535 seconds
(325,35s) Auto OFF enabled with define time,
step is 1s or 10ms according to parameter
nr.15
S
Service button (used to
add or remove module
from the Cockpit system
in case of 24 V SELV
power supply).

Parameter no. 12 - Automatic turning on output
after set time
When relay is OFF it goes automatically ON after
time defined by this parameter. Timer is reset to
zero each time the module receive OFF command
regardless from where it comes (push button,
associated module, controller,..). Available
configuration parameters (data type is 2 Byte
DEC):
•default value 0
•0 - Auto ON disabled
•1 - 32535 = 1second (0,01s) - 32536 seconds
(325,35s) Auto ON enabled with define time,
step is 1s or 10ms according to parameter
nr.15
Parameter no. 15 - Automatic turning off / on
seconds or milliseconds selection
Available configuration parameters (data type is 1
Byte DEC):
•default value 0
•0 - seconds selected
•1 - milliseconds selected
NOTE: This parameter is valid for both, turning on
and turning off parameters.
Parameter no. 30 - Saving the state of the relay
after a power failure
Available configuration parameters (data type is 1
Byte DEC):
•default value 0
•0 - On/Off D Module module saves its state
before power failure (it returns to the last
position saved before a power failure)
•1 - On/Off D Module module does not save
the state after a power failure, it returns to
"off" position.
Parameter no. 63 – Output Switch selection
Set value means the type of the device that is
connected to the output. The device type can be
normally open (NO) or normally close (NC).
Available configuration parameters (data type is 1
Byte DEC):
•default value 0
•0 - When system is turned off the output is 0V
(NC).
•1 - When system is turned off the output is
230V or 24V (NO).
Parameter no. 100 – Disable Endpoint I2 or
select Notification Type and Event
Enabling I2 means that Endpoint (I2) will be present
on UI. Disabling it will result in hiding the endpoint
according to the parameter set value. Additionally,
a Notification Type and Event can be selected for
the endpoint. Available configuration parameters
(data type is 1 Byte DEC):
Endpoint device type selection:
- notification sensor (1 - 6):
GENERIC_TYPE_SENSOR_NOTIFICATION,
SPECIFIC_TYPE_NOTIFICATION_SENSOR
•default value 0
•1 - Home Security; Motion Detection,
unknown location
• 2 - Carbon Monoxide; Carbon Monoxide
detected, unknown location.
•3 - Carbon Dioxide; Carbon Dioxide detected,
unknown location.
•4 - Water Alarm; Water Leak detected,
unknown location.
•5 - Heat Alarm; Overheat detected, unknown
location.
•6 - Smoke Alarm; Smoke detected, unknown
location.
•0 - Endpoint, I2 disabled
- sensor binary (9):
GENERIC_TYPE_SENSOR_BINARY,
SPECIFIC_TYPE_NOT_USED
•9 - Sensor binary
NOTE 1: After parameter change, first exclude
module (without setting parameters to default
value) then wait at least 30s and then re include
the module!
NOTE 2: When the parameter is set to value 9 the
notifications are send for Home Security.
Parameter no. 110 – Temperature sensor offset
settings
Set value is added or subtracted to actual
measured value by sensor. Available config.
parameters (data type is 2 Byte DEC):
•default value 32536
•32536 - offset is 0.0C
•From 1 to 100 - value from 0.1 °C to 10.0 °C is
added to actual measured temperature.
•From 1001 to 1100 - value from -0.1 °C to -10.0
°C is subtracted to actual measured
temperature.
Parameter no. 120 – Temperature sensor
reporting
If digital temperature sensor is connected, module
reports measured temperature on temperature
change defined by this parameter.
Available configuration parameters (data type is 1
Byte DEC):
•default value 5 = 0,5°C
•0 - Reporting disabled
•1- 127 = 0,1°C - 12,7°C, step is 0,1°C
Technical Specifications
Power supply
110 - 230 VAC ±10%
50/60Hz, (24-30VDC)
Rated load current of AC
1 X 10A / 230VAC
output (resistive load)*
Rated load current of
DC output (resistive
load)
1 X 10A / 30VDC
Output circuit power of
AC output (resistive
load)
2300W (230VAC)
Output circuit power of
DC output (resistive
load)
240W (24VDC)
Digital temperature
sensor range (sensor
must be ordered
separately)
-25 ~ +80°C
Operation temperature
-10 ~ +40°C
Distance
up to 30 m indoors
(depending on building
materials)
Dimensions (WxHxD)
(package)
41,8x36,8x15,4mm
(79x52x22mm)
Weight (Brutto with
package)
28g (34g)
Electricity consumption
0,4W
For installation in boxes
Ø ≥ 60mm or 2M,
depth≥ 60mm
Switching
Relay
* In case of load other than resistive, pay attention
to the value of cos φ and if necessary apply load
lower than the rated load. Max current for cos
φ=0,4 is 3A at 250VAC, 3A at 24VDC L/R=7ms.
Supported loads:
Electric motor
Convent. incandescent and halogen lights
LED and CFL bulb, low voltage halogen
bulbs with electronic transformer
Low voltage halogen bulbs with
conventional transformer
Z-Wave Device Class:
ZWAVEPLUS_INFO_REPORT_ROLE_TYPE_SLAVE_AL
WAYS_ON
GENERIC_TYPE_SWITCH_BINARY
SPECIFIC_TYPE_POWER_SWITCH_BINARY
Z-Wave Supported Command Classes:
COMMAND_CLASS_ZWAVEPLUS_INFO
COMMAND_CLASS_VERSION_V2
COMMAND_CLASS_MANUFACTURER_SPECIFIC
COMMAND_CLASS_DEVICE_RESET_LOCALLY
COMMAND_CLASS_POWERLEVEL
COMMAND_CLASS_BASIC
COMMAND_CLASS_SENSOR_BINARY
COMMAND_CLASS_NOTIFICATION_V5
COMMAND_CLASS_SWITCH_ALL
COMMAND_CLASS_SWITCH_BINARY
COMMAND_CLASS_SENSOR_MULTILEVEL_V7
COMMAND_CLASS_MULTI_CHANNEL_V4
COMMAND_CLASS_ASSOCIATION_V2
COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_
V3
COMMAND_CLASS_ASSOCIATION_GRP_INFO_V2
COMMAND_CLASS_CONFIGURATION
COMMAND_CLASS_MARK
COMMAND_CLASS_BASIC
Endpoint 1
COMMAND_CLASS_ZWAVEPLUS_INFO
COMMAND_CLASS_VERSION_V2
COMMAND_CLASS_BASIC
COMMAND_CLASS_SWITCH_ALL
COMMAND_CLASS_SWITCH_BINARY
COMMAND_CLASS_ASSOCIATION_V2
COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_
V3
COMMAND_CLASS_ASSOCIATION_GRP_INFO_V2
COMMAND_CLASS_MARK
COMMAND_CLASS_BASIC
Endpoint 2 (I2):
Device Class:
ZWAVEPLUS_INFO_REPORT_ROLE_TYPE_SLAVE_AL
WAYS_ON
GENERIC_TYPE_SENSOR_NOTIFICATION
SPECIFIC_TYPE_NOTIFICATION_SENSOR
Command Classes:
COMMAND_CLASS_ZWAVEPLUS_INFO
COMMAND_CLASS_VERSION_V2
COMMAND_CLASS_SENSOR_BINARY
COMMAND_CLASS_BASIC
COMMAND_CLASS_NOTIFICATION_V5
COMMAND_CLASS_ASSOCIATION_V2
COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_
V3
COMMAND_CLASS_ASSOCIATION_GRP_INFO_V2
COMMAND_CLASS_MARK
COMMAND_CLASS_BASIC
Endpoint 3:
Device Class:
ZWAVEPLUS_INFO_REPORT_ROLE_TYPE_SLAVE_AL
WAYS_0N
GENERIC_TYPE_SENSOR_MULTILEVEL
SPECIFIC_TYPE_ROUTING_SENSOR_MULTILEVEL
Command Classes:
COMMAND_CLASS_ZWAVEPLUS_INFO_V2
COMMAND_CLASS_VERSION_V2
COMMAND_CLASS_ASSOCIATION_V2
COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_
V3
COMMAND_CLASS_ASSOCIATION_GRP_INFO_V2
COMMAND_CLASS_SENSOR_MULTILEVEL_V7
NOTE: The above list is valid for the product with
a temperature sensor connected to TS terminal. In
case the sensor isn’t connected then following
command class isn’t supported:
COMMAND_CLASS_SENSOR_MULTILEVEL_V7
This product can be included and operated in any
Z-Wave network with other Z-Wave certified
devices from any other manufacturers. All
constantly powered nodes in the same network
will act as repeaters regardless of the vendor in
order to increase reliability of the network.
Important disclaimer
Z-Wave wireless communication is inherently not
always 100% reliable, and as such, this product
should not be used in situations in which life and/or
valuables are solely dependent on its function.
Warning!
Do not dispose of electrical appliances as
unsorted municipal waste, use separate collection
facilities. Contact your local government for
information regarding the collection systems
available. If electrical appliances are disposed of
in landfills or dumps, hazardous substances can
leak into the groundwater and get into the food
chain, damaging your health and well-being.
When replacing old appliances with new once, the
retailer is legally obligated to take back your old
appliance for disposal at least for free of charge.
Products are not authorized for use as critical
devices in life support systems or applications.
Life support systems or applications are systems
or applications which support or sustain life, and
whose failure to perform, when properly used in
accordance with instructions for use provided in
the labelling, can be reasonably expected to result
in a significant injury to the user.
This user manual is subject to change and
improvement without notice. NOTE: User manual
is valid for module with SW version S5 (SW
version is part of P/N)!
Cockpit Smart Home d.o.o.
Ulica Klementa Juga 007
5250 Solkan, Slovenia
Web: www.yourcockpit.biz
Tel: [phone]
Date: 04.03.2018
Document: Cockpit SL_Single On Off D user
manual_V1.5B_eng
