BE1-700C
Digital Overcurrent
Protective Relay
The BE1-700C is a compact multifunction, numeric relay that
provides three phase, ground, and negative sequence overcurrent
protection with breaker failure, breaker monitoring, control, and
metering functions in an integrated system. Four shot reclosing
is available as an option. An onboard Ethernet option can provide
Modbus/TCP connectivity or can provide web and email
capabilities.
Features 2-3
Applications 3
Functional Description 4-7
BESTlogic 8-9
Specifications 10-11
Ordering Information 12
URD-C3
2-06
WINDOWS®SOFTWARE
Interface for setting and communicating
with Basler numeric relays
ADDITIONAL INFORMATION
Instruction Manual
Request publication 9376700990
MODBUS™Instruction Manual
Request publication 9376700991
VOLTAGE VERSION ALSO AVAILABL
E
A voltage version of the BE1-700 is also
available. See Bulletin URD-V.
www.basler.com
ADVANTAGES
• All of the advantages of a fully numeric
product in an economical “current only”
protection package.
• Compact design requires minimal panel
space for overcurrent and reclosing
applications.
• Adds Oscillography, Sequence of Events,
and Metering when single function current
relays are replaced with the BE1-700C.
• BESTlogic provides the user with
complete flexibility in configuring a
protection and control system. User
programmable variable and switch
names make these relays completely
self documenting.
• Programmable LCD display allows
the relay to replace local indication and
control functions, such as panel metering,
alarm annunciation, and control switches.
• Two independent communication ports
with protocol support allows integration
with distributed control systems.
• Available with or without reclosing.
• Optional BESTNet Ethernet package
provides metering and status web pages,
settings and configuration via Ethernet,
and email notification of user-defined
events.
DEVICE FUNCTIONS
50 51 62 BF
79
Option
BESTNet
ETHERNET
Option
Modbus
TCP
Option
Modbus
RTU
Option
DEVICE FUNCTIONS
Features 2-3
Applications 3
Functional Description 4-7
BESTlogic 8-9
Specifications 10-11
Ordering Information 12

PROTECTION
• Phase, Neutral, and Negative Sequence
Instantaneous Overcurrent elements with
settable time delay: 50TP, 150TP, 50TN,
150TN, 50TQ, 150TQ
• Phase, Neutral, and Negative Sequence
Time Overcurrent elements: 51P, 51N,
51Q, 151N
• U.S. and IEC timing curves plus user
programmable curve
• Minimizes transient overreach and
overtravel on overcurrent elements
• Separate ground current input
• Breaker Failure protection function: BF
• Two general purpose logic timers: 62, 162
• Programmable Logic using BESTlogic
• Two protection setting groups with
external or automatic (cold load pickup,
load, unbalance, recloser shot) selection
modes
CONTROL
• Virtual breaker control switch—
controllable from both HMI and com.
ports: 101
• Two virtual selector switches—
controllable from both HMI and com.
ports: 43 and 143
• Optional four shot recloser, including
separate pilot and time delayed reclose
initiates, with zone sequence coordination
and sequence controlled protective
element blocking functions.
INSTRUMENTATION
• Real time A, B, C phase, neutral, and
negative sequence currents
• 1% meter accuracy down to 10% of
nominal current
REPORTS
• Current demands for phase, neutral, and
negative sequence currents—magnitudes
and time stamps are recorded for today's
peak, yesterday's peak, and peak since
reset
• Breaker operations counter and contact
interruption duty
FAULT RECORDING
• Fault summary reports: 16 total. Two
most recent Fault Summary Records
saved to non-volatile memory
• SER: 255 event sequence of events
report with I/O and alarm sub-reports
• Oscillography:
- Up to 16 fault records, 15 cycles long
@ 12 samples/cycle
- 1 or 2 oscillography records per fault
report
- COMTRADE 97 or 99 format
COMMUNICATION PORTS
• Two independent general purpose
communication ports
- Front RS-232 ASCII communications
- Rear RS-485 ASCII or optional
ModbusTM protocols
• IRIG-B time sync (demodulated), TTL
• Optional 10/100 BaseT Ethernet port
with BESTNet Easy Ethernet or with
Modbus/TCP protocol
SELF TEST AND
ALARM FUNCTIONS
• Relay fail, major alarm, and minor alarm
LEDs, and fail-safe alarm output contact
• Extensive internal diagnostics monitor
all internal functions of the relay
• More than 20 additional alarm points—
programmable for major or minor priority
Including:
- Reclose fail and lockout
- Phase demand overload alarm
- Neutral and negative sequence
unbalance demand alarms
- Three breaker alarm points—
programmable for slow trip,
interruption duty threshold, or
operations counter
- Trip circuit voltage and continuity
monitor
- Close circuit monitor via BESTlogic
PROGRAMMABLE I/O
• Four programmable inputs
• Five programmable outputs and one
dedicated programmable alarm output
HARDWARE FEATURES
• Active CT technology for low burden
and increased dynamic range
• Flash Memory for upgrading embedded
programming without changing chips
• Integral HMI with 2x16 character display
• Compact panel mount case with integral
mounting studs for a clean installation.
Less than 3/8" projection in front of
panel.
2
APPLICATIONS ORDERING INFORMATION
BESTlogic SPECIFICATIONS
FUNCTIONAL DESCRIPTION FEATURES

BE1-700C
Digital Overcurrent
Protective Relay
The BE1-700C Overcurrent Protection
System provides three phase, ground,
and negative sequence overcurrent
protection and is intended for use in any
non-directional overcurrent protection
application. Its unique capabilities make
it ideally suited for applications with the
following requirements:
• Applications that require low burden to
extend the linear range of CTs.
• Applications that require the flexibility
provided by wide setting ranges, multiple
setting groups, and multiple coordination
curves in one unit.
BESTCOMS allows you to:
• Enter settings and BESTlogic logic
equations for the BE1-700
• Save settings to a file
• Save BESTlogic logic schemes
(without settings) to a “Logic Library” file
• Print settings
• Upload and download settings
via Serial port
• Upload and download settings via
Ethernet (with BESTNet option)
• View real-time metering and status when
connected to a relay
• View fault records and SER data when
connected to a relay
• View COMTRADE oscillographic records
(with included BESTwave program)
• FREE! with every order
BESTCOMS™ SOFTWARE
Free, easy to use settings program
BESTCOMS Screen, showing at a glance
which relay functions have been enabled
• Applications that require the economy
and space savings provided by a multi
function, multiphase unit. This one unit
can provide all of the protection, as well
as local and remote indication, metering,
and control functions required on a
typical circuit.
• Applications that require communication
capability.
• Applications that require a fundamental
digital signal processing (DSP) algorithm
to provide rejection of harmonics and
low transient overreach.
• Applications where bus protection is
provided by a high speed bus overcurrent
blocking scheme instead of a dedicated
bus differential circuit.
• Applications where the capabilities of
intelligent electronic devices (IEDs) are
used to decrease relay and breaker
maintenance costs.
• Applications using Ethernet communication,
programmable email notifications, and
live metering information via an embedded
web server (with BESTNet option).
• Applications requiring Modbus/TCP
Ethernet communications (with
Modbus/TCP option).
APPLICATIONS
3
APPLICATIONS ORDERING INFORMATION
BESTlogic SPECIFICATIONS
FUNCTIONAL DESCRIPTION
FEATURES

APPLICATIONS FEATURES
ORDERING INFORMATION
BESTlogic SPECIFICATIONS
The BE1-700C is a multifunction, numeric
relay that provides a comprehensive mix of
protective, control and metering functions
in an integrated system. This system is
suitable for any nondirectional overcurrent
application including feeder applications,
generator/motor applications, cogeneration
applications, and transformer backup.
The unit has one set of three phase and
neutral current sensing inputs to provide
all common protective functions for typical
power distribution overcurrent protection
applications.
Two independent communications ports,
along with built-in support for ModbusTM or
Modbus TCP, provide easy access to
integrating the protection, control, metering,
and status monitoring functions into a
substation automation system. The
standard IRIG-B port provides time
synchronization from a master clock.
Real time metering provides amp and
unbalance loading telemetry for the
protected circuit. Contact sensing inputs
and alarm monitoring functions provide
real time status information. Remote
control is provided by virtual control and
selector switches with select-before-
operate control of programmable outputs.
BESTlogic
BESTlogic programmable logic provides
the user with high flexibility in configuring
a protection and control system.
Each of the protection and control functions
in the BE1-700C is implemented as an
independent function block that is equivalent
to its single function, discrete device
counterpart. Each independent function
block has all the inputs and outputs that
the discrete component counterpart
might have. Figures 5 and 5a show each
of the independent function blocks
available for use in the BE1-700C.
Programming BESTlogic is equivalent to
choosing the devices required by your
protection and control scheme and
drawing schematic diagrams to connect
the inputs and outputs to obtain the
desired operational logic.
The BE1-700C relay can store, as user
settings, one user programmable, custom
logic scheme. To save you time, several
preprogrammed logic schemes have also
been provided. Any of the preprogrammed
schemes may be copied into the logic
settings without making any additional
BESTlogic settings.
BESTlogic provides the protection engineer
with the flexibility to set up this powerful
multifunction system with the same freedom
that was once enjoyed with single function,
discrete devices. It is no longer necessary
to compromise your standard protection
and operating practices to deal with the
limitations in programmability of previous
multifunction devices.
Figures 1A, 1B, 1C, and 2 show typical
external connections, and Figure 4 shows
rear panel connections.
4
FUNCTIONAL DESCRIPTION
BESTNet ETHERNET OPTION
The BESTNet option connects your
BE1-700C relay to the wired world.
BESTNET features include:
• Embedded web server with metering,
status, and fault summary information*
• Email alerts of as many as seven
user-defined conditions**
• Full BESTCOMS support over Ethernet
• Full Basler ASCII protocol for terminal
mode communications (TELNET) or
custom programmed application access
• Support for DHCP or static IP
addressing. IP Discovery function
included in BESTCOMS.
* A web browser with a Java™ Runtime
environment installed is required to view
web pages.
** An external SMTP email server must be
available to use email alerts.
Modbus/TCP ETHERNET OPTION
Instead of the BESTNet option, the
BE1-700 can be ordered with the
Modbus/TCP option. With Modbus/TCP,
your BE1-700 relay offers a true
Modbus/TCP protocol connection via an
internal 10/100 BaseT port. No clumsy
external adaptors are required! Simply
plug in an Ethernet cable and your BE1-
700 is part of your Modbus/TCP network.
NOTE: Modbus/TCP and BESTNet are mutually
exclusive. The Ethernet port can be used for
BESTNet or Modbus/TCP, but not both.
Sample BESTNet Web Page

5
BE1-700C
Digital Overcurrent
Protective Relay
Figure 1A - Typical External Sensing Connections -
Feeder Breaker Application
Figure 1B - Typical External Sensing Connections -
Transformer Backup Application
Figure 1C - Alternate Connections for IN
APPLICATIONS FEATURES
ORDERING INFORMATION
BESTlogic SPECIFICATIONS
FUNCTIONAL DESCRIPTION

APPLICATIONS FEATURES
ORDERING INFORMATION
BESTlogic SPECIFICATIONS
FUNCTIONAL DESCRIPTION
6
TYPICAL APPLICATION FOR THE BE1-700C WITH RECLOSING OPTION
Figure 2 - Typical External Connections
Figure 3 - Typical Application Single Line
Based upon pre-programmed logic 700C-OC79-A-BE.
Not all available protection and control functions are shown.

7
APPLICATIONS FEATURES
ORDERING INFORMATION
BESTlogic SPECIFICATIONS
FUNCTIONAL DESCRIPTION
BE1-700C
Digital Overcurrent
Protective Relay
Figure 4 - BE1-700C Overcurrent Relay Rear Panel Connections

APPLICATIONS FEATURES
ORDERING INFORMATION
FUNCTIONAL DESCRIPTION
SPECIFICATIONS
BESTlogic
8
Figure 5 - BE1-700C Overcurrent Relay Rear Panel Connections

9
APPLICATIONS ORDERING INFORMATION
FUNCTIONAL DESCRIPTION
SPECIFICATIONS
BESTlogic
BE1-700C
Digital Overcurrent
Protective Relay
Figure 5A – BE1-700C BESTlogic Function Blocks
Not included in BESTlogic settings.
Neutral OC elements can be assigned to 3 phase residual or independent ground input.
1
2

APPLICATIONS FEATURES
ORDERING INFORMATION
BESTlogic
FUNCTIONAL DESCRIPTIONS
10
SPECIFICATIONS
GENERAL SPECIFICATIONS
5 Amp CURRENT INPUTS
Continuous: 20 Amps
One Sec. rating: 400 Amps
Saturation limit: 150 Amps
Max Burden: <10 milliohms
1 Amp CURRENT INPUTS
Continuous: 4 Amps
One Sec. rating: 250 Amps
Saturation limit: 30 Amps
Max. Burden: <22 milliohms
A/D CONVERTER
Sampling Rate: 12/cycle
POWER SUPPLY
Option 1: 48VDC
Option 2: 120VAC, 125VDC
Option 3: 24VDC
Option 4: 240VAC, 250VDC
Burden: 6 W continuous, 8 W
maximum with all
outputs energized
OUTPUT CONTACTS
Make and carry: 30A (0.2sec)
Continuous: 7A
Break: 0.3A DC (L/R=0.04)
@ 125Vdc or 250Vdc
CONTROL INPUTS
Wetting
Voltage range: Same as control power
supply option.
SERIAL COMMUNICATION
PORTS
Response Time: <100mSec for metering
and control functions
Baud Rate: 300-19200
Protocols: Front RS-232: ASCII
Rear RS-485: ASCII
standard, Modbus
optional
ETHERNET PORT (OPTIONAL)
Type: 10/100 BaseT,
RJ-45 connector
Protocols: BESTNet or
Modbus/TCP, see
Page 4
MECHANICAL ENVIRONMENT
• Operating temperature range: -400C to
700C (-400F to 1580F)*
• Storage temperature range: -400C to
700C (-400F to 1580F)
* Display contrast may be impaired below -200C.
CONFORMS TO STANDARDS:
•IEC 1000-4-2 (EN 61000-4-2)
Electrostatic Discharge Immunity
•IEC 1000-4-3 (EN 61000-4-3)
Radiated RF Immunity
•IEC 1000-4-4 (EN 61000-4-4)
Electrical Fast Transient
•IEC 1000-4-5 (EN 61000-4-5)
Surge-Lightning Strikes
•IEC 1000-4-6 (EN 61000-4-6)
RF Conducted
•IEC 1000-4-8 (EN 61000-4-8)
Power Freq. Magnetic Field
•IEC 1000-4-11 (EN 61000-4-11)
Voltage Dips and Interruptions
•IEC 255-5:
1977 Insulation Tests For Relays
•IEC 255-11:
1979 Interruptions to and AC (Ripple)
in DC
•IEC 255-22-1:
1988 1MHz Burst Disturbance
•IEC 255-22-2:
1996 Electrostatic Discharge
•IEC 255-22-3:
1989 Radiated Disturbance
•IEC 255-22-4:
1992 Fast Transient Disturbance
•IEEE C37.90.1:
2002 Surge Withstand Capability
•IEEE C37.90.1: 2002 Surge Withstand
Capability
•IEEE C37.90.2: 1995 Radiated
Electromagnetic Interference
•IEC 68-2-1: 1990 Test A. Cold
•IEC 68-2-2: 1974 Test B. Dry Heat
•IEC 68-2-3: 1969 Test Ca. Damp Heat
•IEC 68-2-30: 1980 Damp Heat Cyclic
12+12 Hour
•IEC 68-2-56: 1988 Damp Heat Steady
State
•IEC 255-21-1 Vibration Tests
•IEC 255-21-2 Shock and Bump Tests
CERTIFICATIONS
UL recognized per Standard 508 and
Standard CAN/CSA-C22-2 Number
14-M91, UL File Number E97033.
GOST-R certified #POCC
US.ME05.B03391.
CASE SIZE
10.5” wide, 4.46” high, 7.81” behind
panel (.29” front projection)
(266.7 mm wide, 113.23 mm high,
198.49 mm behind panel; 7.38 mm
front projection)
SHIPPING WEIGHT
4.33 pounds (1.96 kg) maximum
WARRANTY
7 years
Control inputs recognize both DC and AC voltages.
Power Supply Option Turn-on Voltage
Range (VDC)
Burden
1) 48 Vdc
2) 120 Vac/125 Vdc
3) 24 Vdc
4) 240 Vac/250 Vdc
26-38 V
69-100 V
5-8 V
138-200 V
13 k ohms
25 k ohms
7 k ohms
54 k ohms

11
APPLICATIONS FEATURES
ORDERING INFORMATION
BESTlogic
FUNCTIONAL DESCRIPTIONS
SPECIFICATIONS
BE1-700C
Digital Overcurrent
Protective Relay
PERFORMANCE SPECIFICATIONS
Pickup: 5A CT: 0.50-16.0A
1A CT: 0.10-3.20A
Time Dial: TD=K=0 - 99 for 46 curve
TD=0.0 - 9.9 for all other curves
Time-Current Characteristics:
The following expression describes the inverse time current
characteristic for each curve:
TT= AD + BD + K = Time to trip
MN-C
TR= RD = Time for decaying reset
M2-1
where D = Time dial, M = Multiple of PU and A, B, C, N, K
and R are constants that govern the shape of each curve. The
protection engineer can set the constants for the P (programmable)
curve to achieve virtually any characteristic.
BREAKER FAILURE
(BF)
Time: 50-999 mSec
Dropout: 5A CT: 0.5A
1A CT: 0.1A
Time Accuracy: ±0.5% or +11/4cyc/ -1/2cyc
GENERAL PURPOSE LOGIC TIMERS
(62, 162)
Mode: PU.DO
1 Shot, Non-Retrig.
1 Shot, Retrig.
Integrating
Latch
T1 and T2 Delay Time: 0.000 - 9999 sec.
Time Accuracy: ±0.5% or ±3/4cyc
RECLOSER
(79) (Optional)
Mode: Power up to close, Power up to lockout
Reclose Shots: 0 – 4
Reclose, Reset,
Fail, Max.
Cycle Timers: 0.100 – 600 Sec.
Time Accuracy: +0.5% or + 13/4cyc/-0 cyc
CURRENT PICKUP ACCURACY
Phase and Neutral: 5A: 2% or 50mA
1A: 2% or 10mA
Negative Sequence: 5A: 3% or 75mA
1A: 3% or 75mA
SETTING GROUPS
Setting Groups: 2
Control Modes: Automatic: CLP; Dynamic load or
unbalance
External: Discrete Input Logic;
Binary Input Logic
METERING
Current Range: 5A: 0.5 to 15.0; 1A: 0.1 to 3.0
Current Accuracy: ±1%
DEMANDS
(IA, IB, IC, IN, IQ)
Demand Interval: 1 - 60 min.
Demand Mode: Thermal
BREAKER MONITORING
Duty Mode: I or I2
Duty Alarm Range: 0-100%
Op Counter Alarm Range: 0-99999
Trip Time Alarm Range: 20-1000 mSec
Pickup:
PU time with TD=0.000 Sec
Delay Time:
Time Accuracy:
5A CT: 0.5-150.0A
1A CT: 0.1-30.0A
2 cyc for P&N @ 5 x PU
3 cyc for Q @ 5 x PU
0.000 - 60 sec
±0.5% or ±1/2cyc for P&N
±0.5% or ±1 cyc for Q
INSTANTANEOUS OVERCURRENT WITH
SETTABLE DELAY
(50TP, 150TP, 50TN, 150TN, 50TQ, 150TQ)
TIME OVERCURRENT
(51P, 51N, 51Q, 151N)
Available on e-catalog CD,
online at www.basler.com,
or from your representative
GUIDEFORM SPECS
Curve
Type A B C N K R
S1 0.2663 0.03393 1.000 1.2969 0.028 0.5000
S2 0.0286 0.02080 1.000 0.9844 0.028 0.0940
L1 5.6143 2.18592 1.000 1.000 0.028 15.750
L2 2.3955 0.00000 1.000 0.3125 0.028 7.8001
D0.4797 0.21359 1.000 1.5625 0.028 0.8750
M0.3022 0.12840 1.000 0.5000 0.028 1.7500
I1 8.9341 0.17966 1.000 2.0938 0.028 9.0000
I2 0.2747 0.1042 1.000 0.4375 0.028 0.8868
V1 5.4678 0.10814 1.000 2.0469 0.028 5.5000
V2 4.4309 0.0991 1.000 1.9531 0.028 5.8231
E1 7.7624 0.02758 1.000 2.0938 0.028 7.7500
E2 4.9883 0.0129 1.000 2.0469 0.028 4.7742
A0.01414 0.00000 1.000 0.0200 0.028 2.0000
B1.4636 0.00000 1.000 1.0469 0.028 3.2500
C8.2506 0.00000 1.000 2.0469 0.028 8.0000
G12.1212 0.00000 1.000 1.000 0.028 29.000
F0.0000 1.00000 0.000 0.0000 0.028 1.0000
46
*0 0 2 0.028 100
P0 to 600 0 to25 0 to1 .5 to 2.5 0.028 0 to 30
Constants
S1, S2 = CO Short Inv, IAC Short Inv A = IEC Standard Inverse
L1, L2 = CO Long Inv, IAC Long Inv B= IEC Very Inverse
D= CO Definite Time C= IEC Extremely Inverse
M= CO Moderately Inverse G= IEC Long Time Inverse
I1, I2 = CO Inverse, IAC Inverse F= Fixed Time
V1, V2 = CO Very Inv, IAC Very Inv 46 =
Neg. Sequence Overcurrent
E1, E2 = CO Ext Inverse, IAC Ext. Inverse P = Programmable

BE1-700C
Digital Overcurrent
Protective Relay
OPTION 1
N) No reclosing
R) Reclosing
CASE
X) Panel mount
non-drawout case
OPTION 2
N) No Option
BE1-700 XN
POWER SUPPLY
And
CONTACT RANGE
1) 48 VDC
2) 120 VAC/125 VDC
3) 24 VDC
4) 240 VAC/250 VDC
COMMUNICATIONS
PROTOCOLS
0) RS-485 ASCII Protocol,
No Ethernet Protocol
1) RS-485
Modbus
™
Protocol,
No Ethernet Protocol
4) RS-485 ASCII
Protocol, BESTNet
Ethernet Protocol
5) RS-485 Modbus
Protocol, BESTNet
Ethernet Protocol
7) RS-485 ASCII Protocol,
Modbus/TCP Ethernet
Protocol
SELECTING COMMUNICATIONS PROTOCOL
All units include two independent communications ports
standard: Com0 (front RS-232) and Com2 (rear RS-485).
ASCII Communications is standard on Com0 and Com2.
Com0 is always ASCII.
• If BESTNet is ordered (option 4 or 5), an Ethernet Port
(Com1) is added with ASCII and Web Protocols only. Com2
is ASCII or Modbus, depending on ordering option.
• If Modbus/TCP is ordered (option 7), Ethernet Port Com1
is added with Modbus/TCP only. No web or email features
are added, and BESTCOMS™ cannot be used over Com1.
Com2 can be used for ASCII and BESTCOMS™. ASCII
Communications is standard on Com0 and Com2.
APPLICATIONS FEATURES
FUNCTIONAL DESCRIPTION BESTlogic SPECIFICATIONS ORDERING INFORMATION
SAMPLE STYLE NUMBER
The style number identification chart below defines the electrical characteristics and
operation features included in the BE1-700C relay. For example, if the style number
were BE1-700 F0R4X5N, the device would have the following:
BE1-700 Digital Overcurrent Protective Relay
(F0) - 5 Amp Nominal Phase Current with 1 Amp Nominal Ground Input
(R) - Reclosing
(4) - 240 VAC/250 VDC Power Supply, 240 VAC/250 VDC Contact Inputs
(X) - Panel mount, non-drawout case
(5) - Modbus on RS-485 port, BESTNet Ethernet protocol
(N) - Not applicable
INPUT SENSING
B0) 1 Amp Nominal
Phase Current,
1 Amp Nominal
Ground
E0) 5 Amp Nominal
Phase Current,
5 Amp Nominal
Ground
F0) 5 Amp Nominal
Phase Current,
1 Amp Nominal
Ground
Route 143, Box 269, Highland, Illinois U.S.A. 62249
Tel [phone] Fax [phone]
e-mail: [e-mail]
P.A.E. Les Pins, 67319 Wasselonne Cedex FRANCE
Tel [phone] Fax [phone]
e-mail: [e-mail]
1300 North Zhongshan Road, Wujiang Economic Development Zone
Suzhou, Jiangsu Province, PRC 215200
Tel [phone] Fax [phone]
e-mail: [e-mail]
