CAMERA SYSTEMS
CAMA06-000/01
This is a high quality AHD (Analog High Definition ) Color camera, using the latest CMOS technology, the camera
can produce high definition image with little distortion. Analog High Definition is a high video definition standard,
through the coaxial cable, using the analog modulation technology to transfer progressive-scan HD Video signal.
AHD system is same as traditional analog system, using common 75-3 coaxial cable to carry out as far as 500 meters
HD video without any video signal loss.
Cautions:
• In order to protect the camera, please avoid
placing or using the camera under direct
sunlight.
• Please ensure that the input voltage range is
within the specifications.
• Please do not place the camera in a location
with a temperature exceeding 50ºC.
• Do not attempt to service the camera by
yourself. Please refer all services to qualified
dealers.
3---N/A
4---Video
2---GND (-)
1---DC12V(+)
4
3
2
1
MIRROR Loop
View
Ø66mm
57mm
38mm
Ø73mm
Ø56mm
Ø50mm
Dimensions:
PART NUMBER COLOUR
CAMA06-000 Black
CAMA06-001 Yellow

WARNING LIGHTING │DIRECTIONAL LIGHTING │LIGHTBARS │WHITE LIGHTING │REVERSING SAFETY
[phone] │[email protected]
An ECCO SAFETY GROUP™ Company
CODE3ESG.CO.UK
Fig 1
Fig 2
1. Use the torx-key supplied (1) to loosen the torx-type screw (3) then unscrew
the top cover (2).
2. Attached the mounting base (4) to wall or ceiling, Use the supplied
3. screw (3) to fix camera in position ~ a firm mounting surface is essential for a
stable installation.
4. Connect the 4 ways male din jack to the female jack on the cable.
5. Adjust camera position by loosening the inner knurled ring (6), adjust the
focus sharpness by loosening the focus-lock screw (5).
Fig.1 shows the camera flush-mounted eg. on a ceiling tile, where the surface can
be bored to accommodated the back of the camera housing(4).
Fig.2 shows the method for the panning and tilting the camera. Loosen the locked
ring (6) and position the camera as required.
Model AHD130MP-CM7AR
Pick up Device 1/3” CMOS Sensor AR0130
TV System PAL
Picture Elements 1280(H)*960(V)
Effective pixels 1.3M pixels
Day-night mode External control (default) / Auto /
color / black and white (OSD switching)
Infrared Spectrum 850nm
S/N Ratio More Than 50 dB, (AGC Off)
Auto Gain Control Auto
White Balance Auto
Electronic Shutter AUTO/ 1/50(1/60)-1/100,000sec
Back Light Compensation Auto
Infrared LED 10LEDs
Infrared LED Range 10m
Video output 1 Vp-p, 75ΩComposite, 4 ways Din Jack
Audio Output N/A
Mirror N/A
Lens Standard f2.5mm Fixed Megapixel Lens
Lens Mount M12XP0.5mm Thread
Pan Adjusting +/-180 Degree
Tilt Adjusting 0-62 Degree
Power Supply 12V DC ±10%
Power Consumption 150mA
Dimensions(L x W x H) 73 x 58 mm
Net Weight 168 g
Weatherproof IP67
Operating Temperature -10°C to +50°C
*Specifications are subject to change without prior notice.
